Oversize Revolving Head Assembly Gravity Lube Channel

1
Nowak Products, Inc. NP

• High ROI Products
• Quality and Innovation

2
Wedge Style Threading Clutch Attachment Retrofit
NP-MB-226-160-SA-R
3
Generation II Wedge Chuck Assembly for Work and
Burring Spindle NP-100-R

• Simple design improvements to the Patented Wedge
  Chuck Assembly
• smoother closing
• greatest holding power

4
Wedge Chuck Assembly for Work Spindles Burring
Spindle NP-100-A
Original design
5
Wedge Chuck Assembly for Hand Clutch NP-200
For consistent machine operation
6
Wedge Chuck Assembly for High Speed Clutch NP-300
For consistent machine operation
7
Flat Barrel Roll Chuck Mechanism For Work
Spindles Burring Spindle NP-100-40-SA
Flat on central segment of the Barrel Roll
Improves performance PAT NO. 5,762,345
UNMATCHED LONGEVITY AMONG BARREL CHUCKS
8
Revolving Head Assembly NP-8-SA
Standard Size Same day shipping
9
Oversize Revolving Head Assembly NP-8-SA
Custom Manufactured to your specified size
carriage bores up to 8.8500 Same day shipping
10
Oversize Revolving Head Assembly Gravity Lube
Channel NP-8-SA-GL
A better method of conventional lubrication Same
day shipping
11
Revolving Head Gear NP-5132
AGMA Quality
12
Revolving Head Gear Wear Size NP-5133-2
Eliminates the need to band your Frame AGMA
QUALITY
13
Locating Lever Block NP-729
Proper geometry for excellent wear
14
Revolving Head Locating Block NP-724-1
Matched Set of 5
15
Locating Lever NP-5080-34
Tough Fatigue Resistant Ductile Iron
16
Eccentric Bushing - Locating Lever NP-5080-196
Part of the Head Locating Solution
17
Locating Cam Lever NP-5080-35-1
Tough Fatigue Resistant Ductile Iron
18
Tool Post Stop NP-2186-SA
Most accurately preset stop available
19
Spindle Internal Gear NP-936
Precision
20
Stationary Head NP-9-27
Location, Location, Location Same day shipping
21
Oversize Stationary Head NP-9-27-OS
Location, Location, Location Same day shipping
Custom Manufactured to your specified size
carriage bores up to 8.8500
22
Strainer Cleaning Assembly NP-207-S-SA
Assures Coolant Flow
23
Front Cross Slide Assembly w/ Wear
Plate NP-5080-62-P-SA
High Strength Ductile Iron
24
Rear Cross Slide Assembly w/ Wear
Plate NP-5080-63-P-SA
High Strength Ductile Iron
25
Front Cross Slide Assembly NP-5080-91-1-SA
High Strength Ductile Iron
26
Rear Cross Slide Assembly NP-5080-94-1-SA
High Strength Ductile Iron
27
Front Cross Slide Gib NP-5080-92-1

• SUPERIOR SOLUTION
• Straightened
• Precision ground
• Stable Ductile Iron

28
Rear Cross Slide Gib NP-5080-95-1

• SUPERIOR SOLUTION
• Straightened
• Precision ground
• Stable Ductile Iron

29
Front Wear Plate NP-5080-62-1-P

• ADVANTAGE SOLUTION
• Straightened
• Precision ground
• Tool Steel

30
Rear Wear Plate NP-5080-63-1-P

• ADVANTAGE SOLUTION
• Straightened
• Precision ground
• Tool Steel

31
Slide Base - Front NP-5080-62-1

• SUPERIOR SOLUTION
• CNC Precision manufactured
• Scraped
• High Strength Stable Ductile Iron
• Optional wear plate mounting holes included -
  exclusive trim to fit width

32
Slide Base - Rear NP-5080-63

• SUPERIOR SOLUTION
• CNC Precision manufactured
• Scraped
• High Strength Stable Ductile Iron
• Optional wear plate mounting holes included -
  exclusive trim to fit width

33
Front Cross Slide NP-5080-91-1

• ADVANTAGE SOLUTION
• CNC Precision manufactured
• Scraped
• High Strength Stable Ductile Iron

34
Rear Cross Slide NP-5080-94-1

• ADVANTAGE SOLUTION
• CNC Precision manufactured
• Scraped
• High Strength Stable Ductile Iron

35
Geneva Motion Star Wheel NP-5134-1
ACCURATE TO 5 ARC SECONDS
36
Geneva Disc Gear NP-5132
AGMA Rated Quality
37
Chuck/Feed Cam Assembly Repair Kit NP-5080-83-1-RK

Precision Custom Reamer
38
Rear Worm Wheel NP-5080-20-10
AGMA QUALITY
39
Chuck and Feed Cam Assembly Repair
Service NP-5088-83-1 Ask

• The Best Choice
• Replace Front Worm Wheel NP-5080-82
• Ream and Install Chuck and Feed Cam Roll
• less than 48 hour turnaround guaranteed

40
Davenport Cam Carrier Bracket
Repair NP-5080-43 ASK

• INSTALL
• Cam Carrier Bracket Bushing (NP-5080-33-1)
• Cam Carrier Bracket Fixed Bushing (NP-5080-43-FB)
• Precision Line Reaming
• Fast turnaround

41
Left Slide Bracket NP-5080-400-3-1-S Support
Ring NP-MB-380-2 REPAIR INQUIRE
Renew with NOWAK Precision Replacement Parts
Fast turnaround time and low cost alternative
to replacement
42
Pump Top Plate Upgrade or Repair NP-849-BSP-S
UNREPAIRED
REPAIRED
Renewed Ball Valve Function
43
Main Drive Shaft Replacement Parts
Improved components NP-MB-43-A NP-MB-7Y-1-1/8-A An
d Others
44
Clutch Body - Long NP-5080-8
Concentricity and Perpendicularity
45
Driving Clutch Gear Hub NP-5080-227-4
Concentricity and Perpendicularity
46
Driving Clutch Gear Ring NP-5080-227-5
Concentricity and Perpendicularity AGMA QUALITY
47
Driving Clutch Body NP-5512-1
Concentricity and Perpendicularity
48
Clutch Body - Short NP-5080-9-1
Concentricity and Perpendicularity
49
Cam/Mechanical Bronze Brake assembly NP-600-B
For Light duty
50
Cam/Mechanical Iron Brake Assembly NP-600-B
Heavy Duty
51
Split Brake Drum Assembly NP-5080-187-SH-SA-1
Take Full Control Of Your Index
52
Support Ring NP-MB-5080-380-2
Concentricity Concentricity Concentricity
53
Left Slide Bracket Assembly NP-5080-400-3-1-SA
Ductile Iron New Style Rails (NP-5080-400-3-5) Sup
port Ring (NP-MB-5080-380-2)
54
Thrust Bearing NP--13-79-S

• Steel Cage
• Price
• Quality
• Delivery

55
Air Lubrication System for the Davenport Model
B NP-2250-ALS-SA First one free with a
complete rebuild

• Constant purge of oil entrained air to all
  spindles and the head bosses
• Improved component life

56
Coolant Pump For Davenport Automatics NP-849-60-S
A-1
The BEST Replacement Solution
57
Size Tool Rolls NP2 NP3 NP4 NP5 NP6 NP7 NP8

• View of a few
• CHECK OUT OUR WEB SITE FOR MORE DETAILS
• WE HAVE A SIZES FOR ANY OCCASION

58
5th Position Cam Lever (Burring
Spindle) NP-1263-1-1
High Strength and Impact Ductile Iron
59
1st 2nd Position Cam Levers NP-5080-54-SA
High Impact and Strength Ductile Iron
60
Rapid Start Bearings Market Priced
Superior Quality Bearings Produced By State of
the Art Production Equipment
61
Center Wire Case Carrier NP-5080-381-8
Lightweight Impact Resistant Aluminum
62
Outer Carrier 1-3/8 NP-5080-381-9
Wear Resistant Ductile Iron
63
Inner Carrier Head 1-3/8 NP-5080-382-8
Ductile Iron
64
Complete Hush Tube Assembly NP-HT 87-137

• 10 standard
• Available in any Length

65
Stock Reel Retaining Ring Assembly NP-5072-9-SA
Best Wire Carrier Mounting Available
66
Standard Magnetics Cabinet NP-E43-SA ASK
The Practical Solution
67
Davenport Model B Remanufacturing

• Inquire about rebuilding by the only source with
• Extensive Manufacturing Capability
• Modern 26000 Sq. ft Factory
• State of the Art Production and Assembly
• Innovative Machine Enhancements
• SERVO DRIVE NOW AVAILABLE

68
Davenport Model B Partial Remanufacturing

• Leverage existing maintenance and repair skills
• Nowak will do the core rebuilding
• Frame preparation
• Boring
• Replacement of the Heads
• Alignment verification
• Replacement of the Locating Lever
• Taylor Made Remanufacturing
• Ask for details

69
Nowak Acme Wedge Chuck A Direct Upgrade for the
Acme-Gridley Finger Holder Assembly

• Patented wedge design for full circle contact to
  improve concentricity
• Wedge design allows it to rock free no stick
• Centrifugal force engages the holding pins thus
  eliminating spool guard damage
• Pressure collar design allows for fine adjustment
  of collet tension
• Ease of installation and periodic lubrication
• Adequate stock for immediate delivery
• Our installed customer base history indicates the
  chucks are virtually maintenance free

70
Wedge Chuck for 7/16 RA-6 NP-716
Also Available for BSA Machines
71
Wedge Chuck Assembly for 9/16 RA RAN 6 NP-916
Proven to improve your Machine
72
Wedge Chuck Assembly for 3/4 RA 8 NP-750
Proven to improve your Machine
73
Wedge Chuck Assembly For 1 RA RAN-6 NP-1000
Proven to improve your Machine
74
Wedge Chuck Assembly For 1-1/4 RA-6
RB-8 NP-1250
Proven to improve your Machine
75
Wedge Chuck Assembly For 1-5/8 RA RB-6 NP-1625
Proven to improve your Machine
76
Wedge Chuck Assembly for 1-5/8 RB-8 NP-1625-RB-8
Proven to improve your Machine
77
Wedge Chuck For 1-5/8 RBN-8 NP-1625-RBN
Proven to improve your Machine
78
Wedge Chuck Assembly for 2 RA RB-6 NP-2000
Proven to improve your Machine
79
Wedge Chuck Assembly for 2 RB-8 NP-2000-RB-8
Proven to improve your Machine
80
Wedge Chuck Assembly for 2-5/8 RA RB - 6
8 NP-2625
Proven to improve your Machine
81
Nowak Products, Inc.NP

• Steven FarrellDirector Marketing and Sales
• 1-800-423-0970
• sfarrell_at_nowakproducts.comwww.nowakproducts.com
