Security In Condor Condor Week EU in Barcelona

1
Security In CondorCondor Week EU in Barcelona
2
Overview

• General Authorization Mechanisms
• Host-based Authorization (Default)
• Problems With Default Installation
• Security Policy Configuration
• Configuring Security Methods
• Conclusion and Questions

3
Authorization

• Condor uses ALLOW / DENY lists to control
  authorization
• There are different levels of access in Condor,
  and each can have a separate authorization list
  and security policy.

4
Authorization

• Possible values for authorization levels
• CLIENT
• READ
• WRITE
• CONFIG
• ADMINISTRATOR
• OWNER
• DAEMON
• NEGOTIATOR

5
Authorization

• There is also a hierarchy of authorization levels

NEGOTIATOR
DAEMON
ADMINISTRATOR
WRITE
CONFIG
OWNER CLIENT
READ
6
Authorization

• There is a separate ALLOW / DENY list for each
  authorization level.
• DENY takes preference over ALLOW
• HOSTALLOW_READ
• HOSTALLOW_WRITE .cs.wisc.edu
• HOSTALLOW_ADMINISTRATOR condor-cm.cs.wisc.edu
• HOSTDENY_WRITE zeroday.cs.wisc.edu

7
Host-based Authorization

• This is the default setup, which has some
  shortcomings but is easy to configure.
• Allows you to specify capabilities by hostname,
  IP address, and/or subnet.

8
Host-based Authorization

• Examples
• HOSTALLOW_WRITE
• HOSTALLOW_WRITE goose.cs.wisc.edu
• HOSTALLOW_WRITE .cs.wisc.edu
• HOSTALLOW_WRITE 128.105.
• HOSTALLOW_WRITE 128.105.0.0/16

9
Host-based Authorization

• Each entry is a comma-separated list.
• Wildcards are allowed only at the beginning of
  hostnames or at the end of IP addresses.
• Subnets are supported using a / and number of
  significant bits.
• HOSTALLOW_WRITE .cs.wisc.edu, .engr.wisc.edu
• HOSTALLOW_WRITE 128.105., .engr.wisc.edu,
  128.105.64.0/18

10
Problems With Default Installation

• Host-based granularity is too big
• Any user who can login to central manager has
  Administrator privileges
• HOSTALLOW_ADMINISTRATOR (CONDOR_HOST)
• Any user on an execute machine can evict the job
  on that machine via condor_vacate
• HOSTALLOW_OWNER (FULL_HOSTNAME)

11
Problems With Default Installation

• Most connections are NOT authenticated
• Queue management commands (condor_submit,
  condor_hold, etc.) are because Condor explicitly
  forces authentication.
• Daemon-to-daemon commands are not.
• It is possible to send false information to the
  collector and other denials of service

12
Problems With Default Installation

• Traffic is not encrypted or checked for
  integrity.
• Possibility of someone eavesdropping on your
  traffic, including files transferred to or from
  execute machine
• Possibility of someone modifying your traffic
  without detection

13
Security Policy Configuration

• Condor provides many mechanisms to address the
  previous shortcomings
• Many authentication methods
• Strong encryption
• Signed checksums for integrity

14
Security Policy Configuration

• Condor will negotiate security requirements and
  supported methods

server
client
I want to submit a job
You must authenticate w/ kerberos
KERBEROS
normal submit protocol
15
Security Policy Configuration

• Default Policy

SEC_DEFAULT_ENCRYPTION OPTIONAL SEC_DEFAULT_INTE
GRITY OPTIONAL SEC_DEFAULT_AUTHENTICATION
OPTIONAL SEC_DEFAULT_AUTHENTICATION_METHODS FS,
GSI, KERBEROS, SSL, PASSWORD UNIX SEC_DEFAULT_AUT
HENTICATION_METHODS NTSSPI, KERBEROS, SSL,
PASSWORD WIN32
16
Security Policy Configuration
Default Policy Possible Policy Values NEVER do
not allow this to happen OPTIONAL do not request
it, but allow it PREFFERED request it, but do
not require it REQUIRED this is mandatory
SEC_DEFAULT_ENCRYPTION OPTIONAL SEC_DEFAULT_INTE
GRITY OPTIONAL SEC_DEFAULT_AUTHENTICATION
OPTIONAL SEC_DEFAULT_AUTHENTICATION_METHODS FS,
GSI, KERBEROS, SSL, PASSWORD UNIX SEC_DEFAULT_AUT
HENTICATION_METHODS NTSSPI, KERBEROS, SSL,
PASSWORD WIN32
17
Security Policy Configuration
Policy Reconciliation
Server Policy
R P O N
Required
Preferred
Client Policy
Optional
Never
18
Security Policy Configuration
Very Secure Policy
SEC_DEFAULT_ENCRYPTION REQUIRED SEC_DEFAULT_INTE
GRITY REQUIRED SEC_DEFAULT_AUTHENTICATION
REQUIRED SEC_DEFAULT_AUTHENTICATION_METHODS
SSL SSL CONFIGURATION LATER IN THIS TUTORIAL
19
Security Policy Configuration
Policy Reconciliation Example 1
CLIENT POLICY SEC_DEFAULT_ENCRYPTION OPTIONAL
SEC_DEFAULT_INTEGRITY OPTIONAL SEC_DEFAULT_AUTH
ENTICATION OPTIONAL SEC_DEFAULT_AUTHENTICATION_M
ETHODS FS, GSI, KERBEROS, SSL,
PASSWORD SERVER POLICY SEC_DEFAULT_ENCRY
PTION REQUIRED SEC_DEFAULT_INTEGRITY
REQUIRED SEC_DEFAULT_AUTHENTICATION
REQUIRED SEC_DEFAULT_AUTHENTICATION_METHODS
SSL RECONCILED POLICY ENCRYPTION
YES INTEGRITY YES AUTHENTICATION
YES METHODS SSL
20
Security Policy Configuration
Policy Reconciliation Example 2
CLIENT POLICY SEC_DEFAULT_ENCRYPTION
PREFERRED SEC_DEFAULT_INTEGRITY
OPTIONAL SEC_DEFAULT_AUTHENTICATION
REQUIRED SEC_DEFAULT_AUTHENTICATION_METHODS
SSL, GSI, KERBEROS, PASSWORD SERVER
POLICY SEC_DEFAULT_ENCRYPTION
NEVER SEC_DEFAULT_INTEGRITY
PREFERRED SEC_DEFAULT_AUTHENTICATION
OPTIONAL SEC_DEFAULT_AUTHENTICATION_METHODS
FS,GSI,SSL RECONCILED POLICY ENCRYPTION
NO INTEGRITY YES AUTHENTICATION
YES METHODS GSI,SSL
21
Security Policy Configuration
Another Example Policy

• As you can see, you may specify a different
  policy for each authorization level

SEC_DEFAULT_ENCRYPTION OPTIONAL SEC_DEFAULT_INTE
GRITY PREFERRED SEC_DEFAULT_AUTHENTICATION
REQUIRED SEC_DEFAULT_AUTHENTICATION_METHODS FS,
GSI, KERBEROS, PASSWORD, SSL SEC_READ_INTEGRITY
OPTIONAL SEC_READ_AUTHENTICATION
OPTIONAL SEC_CLIENT_INTEGRITY
OPTIONAL SEC_CLIENT_AUTHENTICATION OPTIONAL
22
Security Policy Configuration

• Once you have authenticated users, you may use a
  more fine-grained authorization list
• ALLOW_WRITE zmiller_at_cs.wisc.edu
• ALLOW_WRITE zmiller_at_cs.wisc.edu/goose.cs.wisc.e
  du
• ALLOW_WRITE zmiller_at_cs.wisc.edu/.cs.wisc.edu

23
Security Policy Configuration

• Format of canonical username
• user_at_domain/host
• One wildcard allowed in the user_at_domain portion,
  and one allowed in the host portion
• If there is no / character, Condor will do one
  of two things
• If there is an _at_ character, it is assumed to be
  a username, and maps to user_at_domain/
• If there is no _at_, it is assumed to be a
  hostname and maps to /hostname

24
Security Policy Configuration

• Usernames can now be mapped with regular
  expressions. Old GSI mapfile
• /CUS/STWisconsin/LMadison/OUniversity of
  Wisconsin -- Madison/OComputer Sciences
  Department/OUCondor Project/CNZach
  Miller/Emailzmiller_at_cs.wisc.edu
  zmiller_at_cs.wisc.edu
• /CUS/STWisconsin/LMadison/OUniversity of
  Wisconsin -- Madison/OComputer Sciences
  Department/OUCondor Project/CNTodd
  Tannenbaum/Emailtannenba_at_cs.wisc.edu
  tannenba_at_cs.wisc.edu
• Etc.

25
Security Policy Configuration

• New map file applies to all types of
  authentication, not just GSI.
• In your condor_config
• CERTIFICATE_MAPFILE /path/to/mapfile
• Each line is a mapping rule
• Each rule has three fields
• method regex mapped_name

26
Security Policy Configuration

• Default map file
• (each line is ltmethodgt ltregexgt ltmappednamegt)
• RegEx matches and sub-matches can be referenced
  using \1, \2, etc.
• FS (.) \1
• FS_REMOTE (.) \1
• GSI (.) GSS_ASSIST_GRIDMAP (Special Token
  to call Globus)
• SSL (.) \1
• KERBEROS (.) \1
• NTSSPI (.) \1
• CLAIMTOBE (.) \1
• ANONYMOUS (.) CONDOR_ANONYMOUS
• PASSWORD (.) \1

27
Security Policy Configuration

• Review
• The security policy determines which types of
  security mechanism will be used for a given type
  of command
• SEC_ADMINISTRATOR_AUTHENTICATION REQUIRED
  SEC_ADMINISTRATOR_AUTHENTICATION_METHODS GSI

28
Security Policy Configuration

• Review
• The map file gives you a canonical name from the
  authenticated user
• GSI Email(.) \1

/CUS/STWisconsin/LMadison/OUniversity of
Wisconsin Madison/OComputer Sciences
Department/OUCondor Project /CNZach
Miller/Emailzmiller_at_cs.wisc.edu
zmiller_at_cs.wisc.edu
29
Security Policy Configuration

• Review
• The ALLOW_ and DENY_ lists control the
  authorization of the canonical users
• ALLOW_WRITE _at_cs.wisc.edu, zach_at_otherdomain.com
• DENY_WRITE .evildomain.net

30
Configuring Security Methods

• CLAIMTOBE is not configurable, and is meant for
  testing purposes only.
• ANONYMOUS is also not configurable, and always
  sends the username CONDOR_ANONYMOUS

31
Configuring Security Methods

• FS works by creating a directory and checking to
  see who the owner of that directory is. By
  default, it is created in /tmp, but this path can
  be overridden using FS_LOCAL_DIR in the
  condor_config.

client
Created a directory called /tmp/FS_qN21p4
mkdir(/tmp/FS_qN21p4)
Done, check the owner
Success/Failure
rmdir(/tmp/FS_qN21p4)
32
Configuring Security Methods

• FS_REMOTE is similar to FS, but is intended for
  shared file systems. To this end, it has some
  extra steps to help insure the file system is
  synchronized between the two machines.
  FS_REMOTE_DIR must be specified in the
  condor_config.

Created a directory called /tmp/FS_qN21p4
client
mkdir(/tmp/FS_qN21p4)
Done, check the owner
mkdir(/tmp/FS_bl4hB3eF) rmdir(/tmp/FS_bl4hB3eF
)
Success/Failure
rmdir(/tmp/FS_qN21p4)
33
Configuring Security Methods

• NTSSPI uses Windows SSPI authentication. This
  requires that the username and password be the
  same on two machines that are authenticating to
  each other. There are no configuration options
  for this method.

34
Configuring Security Methods

• GSI is the Globus Toolkits implementation of
  X.509. There are quite a number of configuration
  options for this which essentially specify which
  credentials to use, which to expect, and who is
  allowed to sign the credentials.

35
Configuring Security Methods

• When using GSI, a user typically has a public key
  (certificate) and a private key that is encrypted
  with a password.
• A temporary certificate, called a proxy, is
  created for use with condor
• grid-proxy-init -cert zmiller.crt -key
  zmiller.key
• Your identity /CUS/STWisconsin/LMadison/OUni
  versity of Wisconsin -- Madison/OComputer
  Sciences Department/OUCondor Project/CNZach
  Miller/Emailzmiller_at_cs.wisc.edu
• Enter GRID pass phrase for this identity 1 2 3
  4 5
• Creating proxy ..................................
  ............. Done

36
Configuring Security Methods

• For the Condor daemons to use GSI authentication,
  however, they will need either a proxy or a
  private key with no password.
• Proxies would need to be valid for a considerable
  length of time to be useful in this context, so
  usually a cert/keypair is used.

37
Configuring Security Methods

• GSI_DAEMON_CERT condor_cred.crt
• GSI_DAEMON_KEY condor_cred.key
• Also, Condor needs to know the public key of any
  CA that signs certificates
• GSI_DAEMON_TRUSTED_CA_DIR/path/to/keys

38
Configuring Security Methods

• Typically, there is a host credential which is
  owned by root in
• /etc/grid-security/host.crt
• /etc/grid-security/host.key
• And also a directory of signing keys in
• /etc/grid-security/certificates

39
Configuring Security Methods

• Condor will use those defaults without any
  additional configuration, if it has root
  privilege to read the host key.
• Alternatively, you can specify your own directory
  to hold the key files and the signing
  certificates by using
• GSI_DAEMON_DIRECTORY/home/condor/credentials

40
Configuring Security Methods

• Since GSI is currently available only on UNIX
  systems, we have also added support for OpenSSL.
• It needs essentially the same information as GSI,
  which is specified in this case with a different
  set of configuration parameters
• AUTH_SSL_SERVER_CAFILE
• AUTH_SSL_SERVER_CADIR
• AUTH_SSL_SERVER_CERTFILE
• AUTH_SSL_SERVER_KEYFILE
• AUTH_SSL_CLIENT_CAFILE
• AUTH_SSL_CLIENT_CADIR
• AUTH_SSL_CLIENT_CERTFILE
• AUTH_SSL_CLIENT_KEYFILE

41
Configuring Security Methods

• Example SSL config
• Creds to use as server
• AUTH_SSL_SERVER_CAFILE /scratch/zmiller/ssl_keys
  /root-ca.crt
• AUTH_SSL_SERVER_CERTFILE /scratch/zmiller/ssl_k
  eys/host.crt
• AUTH_SSL_SERVER_KEYFILE /scratch/zmiller/ssl_ke
  ys/host.key
• Creds to use as client
• AUTH_SSL_CLIENT_CAFILE /scratch/zmiller/ssl_keys
  /root-ca.crt
• AUTH_SSL_CLIENT_CERTFILE /scratch/zmiller/ssl_k
  eys/host.crt
• AUTH_SSL_CLIENT_KEYFILE /scratch/zmiller/ssl_ke
  ys/host.key
• For instructions on creating these certificates
  and keys using the openssl tool, please see
• http//pages.cs.wisc.edu/zmiller/ca-howto/

42
Configuring Security Methods

• For both GSI and OpenSSL, you can use the openssl
  command line tool to create all the necessary
  keys and files.
• Also, you will almost certainly want to use the
  condor map file functionality to map your SSL and
  GSI subject names to users.

43
Configuring Security Methods

• KERBEROS is available on both UNIX and Windows
  platforms, and is currently version 1.4.3.
• On UNIX, it authenticates against a KDC (Kerberos
  Domain Controller). On Windows, the Active
  Directory server fills this role.
• Windows-gtUnix and Unix-gtWindows Kerberos
  authentication is now possible.

44
Configuring Security Methods

• For Kerberos, a user may need to run kinit if
  that is not part of the normal login process
• kinit zmiller_at_CS.WISC.EDU
• Password for zmiller_at_CS.WISC.EDU 1 2 3 4 5
• klist
• Ticket cache FILE/var/adm/krb5/tmp/tkt/tkt_24842
  _pid19635
• Default principal zmiller_at_CS.WISC.EDU
• Valid starting Expires Service
  principal
• 10/22/08 155413 10/23/08 035413
  krbtgt/CS.WISC.EDU_at_CS.WISC.EDU

45
Configuring Security Methods

• The Condor daemons can use the host credential
  if they are running as root. The default keytab
  file is typically in /etc/v5srvtab and contains a
  credential similar to
• host/goose.cs.wisc.edu_at_CS.WISC.EDU
• Alternatively, you can specify your own keytab
  file and server principal to use
• KERBEROS_SERVER_KEYTAB /scratch/zmiller/keytab.
  zmiller
• KERBEROS_SERVER_PRINCIPAL zmiller/condor_at_CS.WIS
  C.EDU

46
Configuring Security Methods

• PASSWORD authentication also works on both UNIX
  and Windows, although the interface is somewhat
  different.
• On Windows, the password is stored in a secure
  part of the registry.
• On UNIX, the password is stored in a root-owned
  file specified by
• SEC_PASSWORD_FILE /path/to/file

47
Configuring Security Methods

• To set the pool password, use the
  condor_store_cred command with -c
• condor_store_cred c add

48
Conclusion

• Now you have seen a general overview of the
  different methods that Condor supports, how to
  configure them, and how to set policy so they get
  used where you want them.

49
Questions?

• Check the manual
• http//www.cs.wisc.edu/condor/manual/v6.9.2/3_6Se
  curity.html
• Email condor-admin_at_cs.wisc.edu, or
• Email me directly, zmiller_at_cs.wisc.edu.
