A Grid Computing Use case Datagrid

1
A Grid ComputingUse caseDatagrid

• Jean-Marc Pierson

2
DataGrid a european effort

• 9.8 million euros
• 200 researchers involved
• CERN, ESA, CNRS, INFN
• objective share huge amounts of distributed
  data over the network infrastructure
• developed over Globus Toolkit
• (most figures and material from
  www.eu-datagrid.org)

3
(No Transcript)
4
Applications Domain

• High Energy Physics (HEP), led by CERN, for LHC
  data
• Biology and Medical Image processing, led by CNRS
  (France),
• Earth Observations (EO) led by the European Space
  Agency.

5
Data Grid middleware

• Five work packages
• Workload Scheduling and Management
• Data Management
• Grid Monitoring Services
• Mass Storage Management
• Local Fabric Management

6
Workload Scheduling and Management (1)

• the problems
• dynamic relocation of data
• very large numbers of schedulable components in
  the system (computers and files)
• large number of simultaneous users submitting
  work to the system
• different access policies applied at different
  sites and in different countries.

7
Workload Scheduling and Management (2)

• A need for
• planning job decomposition
• and planning task distribution
• Planning based on knowledge of the availability
  and proximity of computational capacity and the
  required data.
• a need for cost estimation tools (delays, data
  migration, caching...)
• Extension of job description languages (JSL) to
  express data dependencies.

8
Data management

• goals
• to permit secure access of massive amounts of
  data in a universal global name space
• to move and replicate data at high speed from one
  geographical site to another
• to manage the synchronisation of remote data
  copies.
• tools
• dynamic automated wide-area data caching and
  distribution
• generic interface to different mass storage
• performance and reliability issues associated
  with the use of tertiary storage will be
  addressed.

9
Monitoring the datagrid

• goal
• to enable transparent monitoring of the use of
  distributed resources at a large scale.
• to assess finely the interplay between computer
  fabrics, networking and mass storage
• tools
• local monitoring of other middlewares
• local monitoring of applications themselves
• developping short time and long term information
  of monitoring (real timearchiving)
• developping effective means of visual
  presentation of the multivariate data.

10
Local fabric management

• goals
• information publication concerning resource
  availability and performance
• mapping of authentication and resource allocation
  mechanisms to local environment
• self healing dynamic configuration changes and
  error recovery strategies
• difficulty to scale well tens of thousands of
  components
• tools
• automatic fault detection and isolation,
  automatic reconfiguation of the fabric and
  re-running the tasks
• automatic incorporation of new or updated
  components

11
Mass Storage Management

• goals
• to introduce standards for handling LHC data so
  that they can be exchanged
• to spread work to other application field
• tools
• uniform interface to the very different systems
  used at different sites
• provide interchange of data and meta-data between
  sites
• develop appropriate resource allocation and
  information publishing functions

12
Conclusion

• Globus, and all its services, had to be extended
  !
• Datagrid a first effort for handling huge
  amounts of data
• Collaborative work !
• Some key issues are not really treated
• data security is basic
• cache management does not use data semantic
• Useful for raw data intensive computation and
  management, not for semantically strong data Le
  projet Medigrid !
