Amr Aldaiel Andrew Kravitz

1

• Amr Aldaiel - Andrew Kravitz
• Katie Noble - Zack Taylor - Alan Yim

2
Objectives

• Wireless real-time video with illumination
  capabilities

• Remote manual operation via computer-based user
  interface

• Temperature sensor
• Control via keypad and LCD display

Preliminary Goals

• Wireless network control
• Automatic patrol mode
• Smoke detector, CO detector

Auxiliary Goals
3
Block Diagram
4
Status

• Basic chassis assembly complete
• Preliminary power system schematics complete
• Basic user interface implemented
• PWM output from PIC
• Preliminary FPGA and peripherals schematics

5
Rover Chassis

• Made of 1/8 5052 Aluminum Alloy
• High strength-to-weight ratio
• Excellent corrosion resistance
• Good forming characteristics

6
Motor Selection

• ReliaPro DC Reversible Gearhead Motor
• Operating Range 4.5V-12V
• Speed at 12V 35 RPM
• 1001 Gear Ratio
• 2370 g-cm torque

7
Power Source

• Werker Non-spillable Battery
• 12V
• 7.5 Amp Hours

8
Power Distribution System

• Tasks
• Design and build a Power Management Unit (PMU)
• Build switching power converters as needed for
  different parts of the eyeBot

• Ensure power is adequately distributed and
  efficiently managed


9
PMU Components

• 1st Stage Step-Down Conversion
• 2nd Stage Voltage Regulation (5V and 3.3V)
• Optocoupling of Incoming PWM Signals
• H-bridge Inverters for Motor Driving

10
PMU (Power Management Unit)
11
Step-Up/Step-Down DC-to-DC Converter
12
(No Transcript)
13
Lighting

• High intensity LEDs for area illumination,
  mounted on camera

• OPTEK Inc. OVLEW1CB9 (White)
• PIC will control a switch to turn LEDs on and off

14
Camera

• Linksys WVC54GC
• Capture Resolution
• 320 x 240
• Interface Type
• IEEE 802.11b/g
• Ethernet 10Base- T/100Base-TX
• Approximately ½ second delay at 20 FPS

15
User Interface - Concept

• Programmed using Visual Basic
• Will run independently on a PC
• Send and receive information and commands through
  RS-232

16
User Interface Demo
17
Interface Protocol
18
Microcontroller

• PIC18F8722 Microcontroller (80 Pin)
• ECCP1/2 Left/Right Motor PWM
• ECCP3 Camera Servo Control
• Programmed Using MPLAB IDE Microchip ICD2
• Allows stepping/breakpoints for code running on
  18F8722

• Communications
• RS-232 through MAX3232CDR RS-232 Driver
• Serial Communication
• FPGA through 10 Bit Parallel Bus
• General I/O Pins for Thermometer, and LED Array
  Control

• Operation at 10 MHz

19
Function pwminit()

• void pwminit(void)
• PR20x18 // Sets the Period Register for Timer
  2 (100 KHz)

• TRISC0 // Sets Port C to Output
• TRISG0 // Sets Port G to Output
• TMR21 // Timer 2 Prescaler set to 1 for
  100KHz operation

• T2CON0b00000100 // Timer 2 Control Reg,Turns
  Timer 2 On

• CCP1CON0b00101101 // Initialize CCP1 (Turn on
  PWM 2)

• CCP2CON0b00101101 // Initialize CCP2
• CCP3CON0b00101101 // Initialize CCP3
• CCPR1L26/4 //Sets CCP 1 to 26 Duty Cycle
• CCPR2L50/4 //Sets CCP 2 to 50 Duty Cycle
• CCPR3L74/4 //Sets CCP 3 to 74 Duty Cycle
• // ALL CCP duty cycles can be controlled to
  duty 4CCPRxL2

• // Allows for 25 Speeds for the motors (12
  Forward, 12 Back)

• // Servo can be controlled to 25 positions

20
PIC 18F8722 Schematic
21
HPC-Explorer Board

• Cheap Effective PCB
• Built in wire-wrap/solder points for all general
  I/O Pins

• Can Easily Build Ribbon Cable Interface for FPGA
  Bus

• Built In Voltage Regulator for VDD and Ground of
  18F8722 through 9-15V input

• ICD 2 Jumper and RS-232 Com port on board.
• Built in Temperature Sensor
• 8 LEDs through Port D, for data checking
• Easily Add on additional components

22
HPC Explorer Board Schematic
23
FPGA Overview

• Xilinx XCS10 with XC18V256 EPROM
• Interfaces between PIC, Keypad, LCD display, and
  any future peripherals

• Handles chip selection based on three address bits

• Communicates with PIC through 10 bit parallel bus

24
LCD

• Will display
• temperature
• direction
• eyeBOT status
• 20x4 character display
• Considering
• HD44780 parallel interface
• HD44780U driver

25
4x4 Keypad

• Used for on-board eyeBOT control
• Row/Column matrix will be encoded into 4 data
  bits by MM74C922

• MM74C922 also offers an interrupt signal and a
  keypad available signal

26
FPGA etc Schematic
27
Feedback System

• Optical encoders mounted on eyeBOT wheels
• Quadrature decoders (HCTL2016) will send data
  through PIC and straight back to User Interface

• Two possible encoder setups
• Panel Mount
• Code Wheel

HEDS 5700 series
HEDB-9000 series
28
Parts List

• ReliaPro DC reversible gear-head motor
• Werker 12V 7.5 amp-hour battery
• Linksys WVC54GC
• PIC18F8722 microcontroller
• HPC-Explorer board
• Xilinx XCS10
• XC18V256 EPROM
• 20x4 character display
• MM74C922 encoder

29
Division of Tasks

• Amr
• Power distribution system
• Andrew
• Microcontroller
• Katie
• FPGA, LCD/Keypad, motor feedback, peripherals
• Zack
• User interface, communication link
• Alan
• Rover assembly mechanics, motors, FPGA,
  LCD/Keypad

30
Milestone 1 Deliverables

• Preliminary Verilog code
• Serial communication between GUI and PIC
• Power distribution system complete for main
  components

• Chassis complete with mounted camera and multiple
  levels Plexiglas

• Streaming video in GUI

31
Milestone 2 Deliverables

• All Primary Goals Accomplished
• Wireless real-time video with illumination
  capabilities via computer-based user interface,
  keypad, and LCD display

• Temperature sensor
• Completely battery powered

32
Expo Deliverables

• As many add-ons as possible
• Automatic patrol mode
• Wireless network control
• Additional peripherals
• Smoke detector
• CO detector

33
(No Transcript)
34
Questions?
