Essentials of 80x86 Assembly Language

1
Chapter 2 Software Tools and Assembly Language
Syntax
2
2.1 Assembly Language Statements and Text Editors
3
Assembly Language Syntax

• Example assembly language program -- adds 158
  to number in memory
• Author R. Detmer
• Date 10/2004
• .386
• .MODEL FLAT
• ExitProcess PROTO NEAR32 stdcall,
  dwExitCodeDWORD
• .STACK 4096 reserve 4096-byte stack
• .DATA reserve storage for
  data
• number DWORD -105
• sum DWORD ?
• .CODE start of main
  program code
• _start
• mov eax, number first number to
  EAX
• add eax, 158 add 158
• mov sum, eax sum to memory
• INVOKE ExitProcess, 0 exit with
  return code 0
• PUBLIC _start make entry
  point public
• END end of source
  code

comments
directives
instructions
comments
4
Comments

• Start with a semicolon ()
• Extend to end of line
• May follow other statements on a line

5
Instructions

• Each corresponds to a single instruction actually
  executed by the 80x86 CPU
• Examples
• mov eax, numbercopies a doubleword from memory
  to the accumulator EAX
• add eax, 158adds the doubleword representation
  of 158 to the number already in EAX, replacing
  the number in EAX

6
Directives

• Provide instructions to the assembler program
• Typically dont cause code to be generated
• Examples
• .386 tells the assembler to recognize 32-bit
  instructions
• DWORD tells the assembler to reserve space for a
  32-bit integer value

7
Macros

• Each is shorthand for a sequence of other
  statements instructions, directives or even
  other macros
• The assembler expands a macro to the statements
  it represents, and then assembles these new
  statements

8
Typical Statement Format

• name mnemonic operand(s) comment
• In the data segment, a name field has no
  punctuation
• In the code segment, a name field is followed by
  a colon ()
• Some of these fields may be omitted in some
  statements

9
Identifiers

• Identifiers used in assembly language are formed
  from letters, digits and special characters
• Special characters are best avoided except for an
  underscore (_) with _start.
• An identifier may not begin with a digit
• An identifier may have up to 247 characters
• Restricted identifiers include instruction
  mnemonics, directive mnemonics, register
  designations and other words which have a special
  meaning to the assembler

10
Program Format

• Indent for readability, starting names in column
  1 and aligning mnemonics and trailing comments
  where possible
• The assembler is not case-sensitive but good
  practice is to
• Use lowercase letters for instructions
• Use uppercase letters for directives

11
Creating a Assembly Language Source Code File

• Use a text editor like edit (at the MS-DOS
  prompt) or notepad, not a word processor
• Save program with .asm extension

12
2.2 The Assembler
13
MASM

• Microsoft Assembler
• For source example.asm, invoked at the command
  prompt withml /c /coff /Fl /Zi example.asm
• Switches
• /c compile only
• /coff generate special file format
• /Fl generate assembly listing
• /Zi prepare for debugging
• ml /? give all switches

Blanks are necessary
14
Output of Assembler

• Object file, e.g., example.obj
• Contains machine language statements almost ready
  to execute
• Listing file, e.g., example.lst
• Shows how MASM translated the source program

15
Listing File
locations of data relative to start of data
segment
8 bytes reserved for data, with first doubleword
initialized to -105

• 00000000 .DATA
• 00000000 FFFFFF97 number DWORD -105
• 00000004 00000000 sum DWORD ?
• 00000000 .CODE
• 00000000 _start
• 00000000 A1 00000000 R mov eax,
  number
• 00000005 05 0000009E add eax,
  158
• 0000000A A3 00000004 R mov sum, eax

object code for the three instructions
locations of instructions relative to start of
code segment
16
Parts of an Instruction

• Instructions object code begins with the opcode,
  usually one byte
• Example, A1 for mov eax, number
• Immediate operands are constants embedded in the
  object code
• Example, 0000009E for add eax, 158
• Addresses are assembly-time must be fixed when
  program is linked and loaded
• Example, 00000004 for mov sum, eax

17
2.3 The Linker
18
Functions of the Linker

• Combines separately assembled modules into a
  single module, ready to be loaded into memory
• Arranges the individual object modules
  end-to-end, fixing up addresses for the resulting
  load module
• Load module is copied to memory when the program
  is actually executed, and additional address
  correction may take place at load time

19
Using the Linker

• At the command prompt
• link /debug /subsystemconsole /entrystart
• /outexample.exe example.obj kernel32.lib
• (entered as a single command)
• This command links example.obj and any needed
  procedures from the library file kernel32.lib to
  produce the output file example.exe

20
Link switches

• /outexample.exe specifies example.exe as the
  name of the executable program file
• /entrystart identifies _start as the label of
  the program entry point
• /debug tells the linker to generate files
  necessary for debugging, example.ilk and
  example.pdb
• /subsystemconsole tells the linker to generate
  code for a console application, one that runs in
  a MS-DOS window

21
2.4. The Debugger
22
Functions of a Debugger

• Allows a programmer to control execution of a
  program, pausing after each instruction or at a
  preset breakpoint
• A programmer can examine the contents of
  variables in a high-level language, or registers
  or memory in assembly language
• Useful both to find errors and to see inside a
  computer to find out how it executes programs

23
Using WinDbg (1)

• Type Windbg at the command prompt
• From the WinDbg menu bar choose File, then Open
  Executable. Select example.exe, or the name of
  your executable file
• Press the step into button

24
Using WinDbg (2)

• Click OK in the information window No symbolic
  Info for Debugee source code then appears in a
  Windbg child window behind the Command window
• Minimize the Command window
• Select View and then Registers to open a window
  that shows contents of the 80x86 registers

25
Using WinDbg (3)

• Select View and Memory to open a window that
  shows contents of memory
• Enter the starting memory address using the C/C
  address-of operator ()
• For example, if the first item in the data
  section is number, you could use number as the
  starting address

26
Using WinDbg (4)

• The instruction about to be executed is
  highlighted in yellow.
• Press the step into button to execute each
  instruction one at a time
• When an instruction causes a register value to
  change, the new value is shown in red

27
WinDbg Display
28
2.5. Data Declarations
29
BYTE Directive

• Reserves storage for one or more bytes of data,
  optionally initializing storage
• Numeric data can be thought of as signed or
  unsigned
• Characters are assembled to ASCII codes
• Examples
• byte1 BYTE 255 value is FF
• byte2 BYTE 91 value is 5B
• byte3 BYTE 0 value is 00
• byte4 BYTE -1 value is FF
• byte5 BYTE 6 DUP (?) 6 bytes each with 00
• byte6 BYTE 'm' value is 6D
• byte7 BYTE "Joe" 3 bytes with 4A 6F 65

30
DWORD Directive

• Reserves storage for one or more doublewords of
  data, optionally initializing storage
• Examples
• double1 DWORD -1 value is FFFFFFFF
• double2 DWORD -1000 value is FFFFFC18
• double3 DWORD -2147483648 value is 80000000
• double4 DWORD 0, 1 two doublewords
• Double5 DWORD 100 DUP (?) 100 doublewords

31
WORD Directive

• Reserves storage for one or more words of data,
  optionally initializing storage

32
2.6 Instruction Operands
33
Types of Instruction Operands

• Immediate mode
• Constant assembled into the instruction
• mov al,/ add eax, 135
• Register mode
• A code for a register is assembled into the
  instruction
• mov sum,eax
• Memory references
• Several different modes

34
Memory References

• Direct at a memory location whose address
  (offset) is built into the instruction
• The memory references in the example program are
  direct
• mov al,number1
• Register indirect at a memory location whose
  address is in a register
• add eax,edxthe destination is a doubleword
• mov BYTE PTRebx,0PTR operator declares the
  size of operand
