LIGHT EMITTING DIODES

1
LIGHT-EMITTING DIODES
2
LEDs EVERYWHERE

• small electronics
• traffic lights
• vehicle signal lights
• jumbo stadium displays

3
Not Just a Lightbulb

• no filament less heat
• illuminated by movement of electrons in
  semiconductor material

4
Diodes

• simple semiconductor
• silicon with impurities
• N-type and P-type regions
• electrons and holes

5
Charge Carrier Interaction
6
Producing Light

• photons particle-like packets of light
• released from energy drop of electrons
• electrons combining with holes results in a drop
  to a lower orbital
• energy released is in form of photon
• greater-energy drop higher energy photon
  higher frequency light

7
Different LEDs

• photons emmitted in all diodes
• standard Si diodes electrons drop a relatively
  short distance resultant electron is low
  freqency INFRARED
• visible light LEDs wider gap between conduction
  band and lower orbitals
• gap size determines light freqency color

8
Where Does the Light Go?

• in ordinary Si diodes, the Si absorbs most of the
  light energy
• LEDs are specially constructed to release a large
  number of photons outward
• housed in a plastic bulb that concentrates the
  light in a particular direction

9
See?
10
Advantage, LED

• no filament to burn out
• more durable, smaller
• efficiency - little wasted heat

11
Sources

• http//www.theledlight.com/pdf/technical.pdf
• http//www.howstuffworks.com
