31U10

1
INTRODUCTION TO COMPUTERS OPERATING SYSTEMS
AND OPERATING ENVIRONMENTS
2
Installing Windows 2000 Professional

• Getting Started
• Installing Windows 2000 from a CD-ROM PE (Short
  Way)
• Installing Windows 2000 from using four setup
  disks and a CD-ROM PE (Long Way)

3
Pre Installation Tasks

• Identify hardware requirements.
• Determine whether your hardware is on the
  Hardware Compatibility List (HCL). List of
  supported devices
• Determine disk partitioning.
• Choose a file system.
• Determine whether your computer will join a
  workgroup or a domain.

4
Hardware RequirementsAnd Capabilities

• 133 MHz or higher Pentium-compatible CPU.
• 64 MB RAM minimum. 4 GB RAM maximum
• 2 GB hard disk with a minimum of 650 MB of free
  space. (Additional free hard disk space is
  required if you are installing over a network.)
• Network Adapter Card
• Video display adapter and monitor with VGA or
  higher resolution
• Support for up to 2 processors.

5
Disk Partitions

• Setup checks for an available partition.
• If the hard disk is unpartitioned, create and
  size the Microsoft Windows 2000 partition.
• If the hard disk has an existing partition that
  is large enough, you can use that existing
  partition.
• If the hard disk has an existing partition, you
  can delete it and create a suitable partition.

6
File Systems
FAT

• Allows Complete Access
• Widely Used

• Local Security
• Extended Volumes
• File Compression

NTFS
7
Domain or Workgroup Membership
8
Running the Setup Program

• Boot from the installation CD-ROM

9
Running Setup Wizard

• The Setup wizard is the GUI-based portion of
  Setup.
• The Setup wizard helps you customize information.

10
Installing Windows Networking Components

• Setup detects and configures any network adapter
  cards.
• Setup copies files to allow your computer to
  connect.
• You supply the name of the workgroup or domain.
• Setup installs and configures the Windows
  networking components.

11
Completing the Installation
12
BOOTING UP PREBOOT SEQUENCE

• The computer runs power-on self test (POST)
  routines.
• The computer BIOS locates the boot device and
  loads and runs the master boot record (MBR).
• The MBR locates, loads into memory, and executes
  the boot sector.
• The computer loads and initializes the Ntldr file.

13
Boot Sequence

• Gathers information about hardware and drivers
• Consists of four phases
• Initial boot loader
• Operating system selection
• Hardware detection
• Configuration selection

14
CHECK FOR LEARNING
What must you do prior to loading Windows 2000
Professional on your computer ?
Check the HCL
What is the minimum CPU requirements for a
Windows 2000 Professional computer ?
PENTIUM 133
What is the minimum amount of free space required
for installation of Windows 2000 Professional ?
650 MB (685 if installed over a network)
15
INSTALLING WINDOWS 2000 (THE SHORT WAY)INSTALL
WINDOWS 2000 FROM CD PRACTICAL EXERCISE 1
16
Use the Windows 2000 Operating Environment
17
Logon

• Winlogon.exe starts Local Security Authority and
  displays the Logon dialog box.
• Windows 2000 startup is good when a user
  successfully logs on to the system.
• The system copies the Clone control set to the
  Last Known Good control set.

18
THE DESKTOP
WINDOWS 2000 uses the same Graphical User
Interface as the WINDOWS 9X series as well as
WINDOWS NT.
19
MY COMPUTER
By double clicking on the MY COMPUTER ICON you
are given access to the workstations drives as
well as the Control Panel. Double Click on the
Control Panel ICON.
20
THE CONTROL PANEL
The Control Panel is a central point for making
changes and accessing useful tools for setting up
and maintaining your WINDOWS 2000
workstation. Double Click on the Users and
Passwords ICON.
21
USERS AND PASSWORDS
To ensure that users must each enter a password
at LOGON checkmark this box After checking the
box click on the Advanced Tab.
22
USERS AND PASSWORDS
To require that users select CTRL, ALT and DELETE
at LOGON put a checkmark in this box.
23
THE TASKBAR AND STARTMENU
Users can personalize their settings to make
navigation more efficient with WINDOWS 2000.
24
THE TASKBAR AND STARTMENU
The Taskbar Properties allows a user to change
the way the Start Menu is displayed. Checkmark
these boxes Display Administrative Tools Expand
Control Panel
25
THE STARTMENU
With options like Expand the Control Panel, you
do not have to open the Control Panel to access
the folders located within.
26
THE STARTMENU
The Start menu also gives access to all programs
and utilities loaded on to your workstation.
27
SYSTEM PROPERTIES
To access the System Properties, Right click on
My Computer and select Properties.
28
SYSTEM PROPERTIES
In System Properties click on the Device Manager
button under the Hardware Tab.
29
SYSTEM PROPERTIES
The Device Manager shows the Hardware
configuration of all devices within your
workstation.
30
SYSTEM PROPERTIES
To access a devices properties, highlight the
device the under Action in the Menu Bar click
Properties.
31
SYSTEM PROPERTIES
The Properties will display the Status, Advanced,
Driver, Resources and Power Management.
32
SECURITY DIALOG BOX
The Security Dialog Box will give the user the
options to Lock Workstation, Logoff, Shutdown,
Change Password, Task Manager and Cancel.
33
THE TASK MANAGER
The Task Manager is contains three tabs The
Applications Tab is used to stop an application
that is running or has stopped responding. There
are three ways to access the Task Manager CTR,
ALT, DEL CTRL, SHIFT, ESC Right click any empty
portion of the Taskbar
34
THE TASK MANAGER
The Processes Tab shows all processes running in
the background and allows you to End the Process.
35
THE TASK MANAGER
The Performance Tab shows CPU and Memory usage
and is a helpful troubleshooting tool.
36
CHECK FOR LEARNING
What is the Operating System Selection Menu used
for ?
Gives the choice of what operating system to boot.
What are the three tabs in Task Manager ?
Application, Processes, Performance
What option allows users to leave their
workstation unattended allowing no access ?
Lock
37
DISK MANAGEMENT
38
WINDOWS 2000 FILE SYSTEMS

• File Allocation Table (FAT)
• File Allocation Table 32 (FAT 32)
• Windows New Technology File System (NTFS)

39
SELECTING A FILE SYSTEM

• Allows complete access
• Widely used

FAT
FAT32

• New version of FAT
• Supports larger disks (up to 2 terabytes)
• Better storage efficiency than FAT

• Local security
• Disk compression
• Supports large hard disks (up to 2 terabytes)

NTFS
40
DISK MANAGEMENT
Disk Management is a graphical tool for managing
hard disks and volumes. It is used to

• Create, format and delete partitions, logical
  drives, and new dynamic volumes.
• Mark partitions active.
• Assign drive letters.

41
STORAGE TYPES
Windows 2000 supports 2 types of disk storage
BASIC
DYNAMIC
A physical disk that is managed by Disk
Management. Dynamic disks can not be accessed
by MS-DOS.
A physical disk that contains primary partitions,
extended partitions, or logical drives. Basic
disks can be accessed by MS-DOS.
42
DISK MANAGEMENT
PARTITION A portion of a physical disk that
functions as though it were a physically separate
disk. Can only be created on a basic disk.
43
PRIMARY PARTITIONS

• A primary partition is a portion of a disk that
  can be marked as active and used by the system to
  boot the computer.
• Can have up to four primary partitions per disk.
• Cannot be sub-partitioned.
• Multiple primary partitions allow isolation of
  different operating systems or types of data.

44
EXTENDED PARTITION
Can only be created on a basic disk. Created from
free space. Can only be one extended partition on
a hard disk, so you should include all remaining
free space. Are not formatted or assigned drive
letters. Divided into segments called logical
drives. Logical drives are assigned a drive
letter and formatted with a file system.
45
OPENING DISK MANAGEMENT
To open Disk Management, click on Start button,
Programs, Administrative Tools, Computer
Management.
46
DISK MANAGEMENT
Top Menu and Tool Bar
Disk Bars
Legend
47
CREATING A PRIMARY PARTITION P.E.
To create a Primary Partition, highlight the free
space by left clicking on it once.
Once highlighted the free space will have a gray
border around it.
48
CREATING A PRIMARY PARTITION
Right click on the free space. A pop up menu
appears. Click on Create Partition
49
CREATING A PRIMARY PARTITION
The Create Partition Wizard Dialogue box appears.
Click on Next.
50
CREATING A PRIMARY PARTITION
Here, we have the option of selecting the type of
partition, choose Primary partition Click next
51
CREATING A PRIMARY PARTITION
The Specify Partition Size dialog box appears,
type a partition size of 2045 MB Click next
52
CREATING A PRIMARY PARTITION
At this window we have the option of changing the
drive letter, accept drive letter E as the
assignment Click next
53
CREATING A PRIMARY PARTITION
The Format Partition dialog box appears, select
the DO NOT FORMAT THIS PARTITION button Click next
54
CREATING A PRIMARY PARTITION
The Wizard now tells us that we have successfully
completed creating the partition. Click Finish
55
CREATING A PRIMARY PARTITION
Back in the Disk Management console we see that
we have created a new partition with the drive
letter E assigned, but it has no file system.
56
FORMAT A PRIMARY PARTITION
To make use of the partition we have just created
we must format. Left click on the E drive, then
right click. The pop up window will appear,
select Format.
57
FORMAT A PRIMARY PARTITION
At the Format dialog box you have the option of
choosing what file system you want to format
in. Choose FAT32 , check QUICK FORMAT, then OK.
58
FORMAT A PRIMARY PARTITION
When formatting all data on the partition will be
lost. Click OK.
59
FORMAT A PRIMARY PARTITION
We now have a FAT32 partition with a drive letter
of E assigned. Create another Primary Partition
with a size of 2045 MB and FAT32 file system.
Assign drive letter F.
60
CREATE AN EXTENDED PARTITION
To Create an Extended Partition, Select the empty
space by Left clicking on it, Right click and
select Create Partition from the pop up menu.
61
CREATE AN EXTENDED PARTITION
Once again the Create Partition Wizard appears.
Click Next.
62
CREATE AN EXTENDED PARTITION
At the Select Partition Type window,
Choose Extended Partition. Click Next.
63
CREATE AN EXTENDED PARTITION
At the Specify Partition Size accept the Default
to utilize all remaining Unallocated space. Click
Next.
64
CREATE AN EXTENDED PARTITION
We are now informed that we have successfully
created an Extended Partition. Click Finish.
65
CREATE LOGICAL DRIVES
Once an Extended Partition has been created we
must create Logical Drives within the Extended
Partition to enable use of the free space. Your
legend now shows that you have an Extended
Partition.
66
CREATE LOGICAL DRIVES
Left click on the free space then right click and
select Create Logical Drive from the pop up
window.
67
CREATE LOGICAL DRIVES
The Welcome Wizard appears, Click Next.
68
CREATE LOGICAL DRIVES
At the Select Partition Type screen, the Logical
Drive is already chosen for you. Click Next.
69
CREATE LOGICAL DRIVES
Here, we can decide what size we want to make our
Logical Drive. Type 2045 MB Click Next.
70
CREATE LOGICAL DRIVES
We now assign a drive letter of G to the Logical
Drive. Click Next.
71
CREATE LOGICAL DRIVES
At the Format Partition window Select Do Not
Format. Click Next.
72
CREATE LOGICAL DRIVES
The Wizard now informs us that we have
successfully created the Logical Drive. Click
Finish.
73
CREATE LOGICAL DRIVES
At the Disk Management Console, we see that we
now have three Primary Partitions, an Extended
Partition, one Logical Drive and more Free space.
74
FORMAT LOGICAL DRIVES
Select the Logical Drive by Left clicking it,
then Right Click the drive and select Format from
the pop up window.
75
FORMAT LOGICAL DRIVES
Choose FAT32 and check the box for Quick
Format. Click OK to format. Once completed,
create another Logical Drive utilizing the
remaining free space.
76
ASSIGN A DRIVE LETTER
You can assign drive letters to the drives by
Left clicking on the drive then Right clicking
and selectingChange Drive Letter from the pop up
window. Choose the CD-ROM drive.
77
ASSIGN A DRIVE LETTER
At the Change Drive Letter screen click EDIT.
78
ASSIGN A DRIVE LETTER
Click the Down arrow and choose letter Z. Click
OK.
79
ASSIGN A DRIVE LETTER
You will get a message from WINDOWS,
Click Yes.
80
ASSIGN A DRIVE LETTER
Back at the Disk Management Console you now see
that the CD-ROM letter has changed. Close out
Disk Management.
81
MY COMPUTER
At the MY COMPUTER window we now see that we have
more drives available for use.
82
CHECK FOR LEARNING
What file systems does WINDOWS 2000 support ?
FAT, FAT32, NTFS
What is the maximum Primary Partitions per hard
disk ?
4
If you needed to utilize both FAT and NTFS, at a
minimum how many partitions would you need ?
2, one partition per file system
83
PRACTICAL EXERCISE 2 PARTS 1, 2, 3, 4 CREATE
PRIMARY PARTITIONS, EXTENDED PARTITION, LOGICAL
DRIVES AND ASSIGN A NEW DRIVE LETTER TO THE CD-ROM
84
CONVERTING A FAT PARTITION TO A NTFS PARTITION

• You can convert any of your partitions from a FAT
  file system to a
• NTFS file system by
• 1. Using Disk Management
• 2. Using the Convert.exe command
• Planning will play a big role in determining the
  way you decide to convert partitions.

85
CONVERTING A FAT PARTITION TO A NTFS PARTITION
USING DISK MANAGEMENT

• All information/data on the partition will be
  erased.
• Use this option when first installing Windows
  2000.

86
CONVERTING THE FILE SYSTEM DISK MANAGEMENT
To begin conversion of the file system, click on
the partition that you want to convert. Right
click and a pop up menu will appear. Click on
Format
87
CONVERTING THE FILE SYSTEM USING DISK MANAGEMENT
The Format E\ dialogue box appears. Here, you
must choose the file system you want to format
the partition with by clicking on the drop down
arrow under the topic of File Systems.
88
CONVERTING THE FILE SYSTEM USING DISK MANAGEMENT
The Format E\ dialogue box appears. Click OK to
proceed with the format.
89
CONVERTING THE FILE SYSTEM USING DISK MANAGEMENT
You can see that the partition is now being
formated.
90
CONVERTING THE FILE SYSTEM USING DISK MANAGEMENT
Here we can see that the file system has changed
from a FAT file system to a NTFS file system.
The E Partition is now a NTFS file system.
91
CONVERTING A FAT PARTITION TO A NTFS PARTITION
USING THE CONVERT.EXE COMMAND

• Conversion is a one-way process.

• No data loss during conversion.

CONVERT.EXE
DATA
DATA
92
CONVERTING A FAT PARTITION TO A NTFS PARTITION
USING THE CONVERT.EXE COMMAND
To begin conversion of a FAT partition to a NTFS
partition open the Command Prompt by clicking
on Start Button, and click on Run.
93
CONVERTING A FAT PARTITION TO A NTFS PARTITION
USING THE CONVERT.EXE COMMAND
At the C/gt prompt, we type the command convert
f /fsntfs and press enter.
Weve chosen to convert the f drive to an NTFS
file system.
94
CONVERTING A FAT PARTITION TO A NTFS PARTITION
USING THE CONVERT.EXE COMMAND
You are now asked to enter the Volume Label.
TYPE new volume (ENTER)
95
CONVERTING A FAT PARTITION TO A NTFS PARTITION
USING THE CONVERT.EXE COMMAND
Here, the computer tells you that it is
converting the file system and that the
conversion is completed.
96
VIEWING THE CONVERSION OF THE FILE SYSTEM
NOTE Because we formatted the F partitions in
the command prompt using the convert command,
no data on either disk was erased.
We open Disk Management and we can see that our
E F partitions has changed its file systems
from FAT to NTFS.
97
CHECK FOR LEARNING
TRUE OR FALSE
If I format my drive in Disk Management I will
not lose any information.
False
Will you lose information by converting to NTFS
from FAT using the Convert.exe command ?
No
98
PRACTICAL EXERCISE 3 - 4 CONVERT TO NTFS
USING DISK MANAGEMENT, CONVERT TO NTFS USING THE
CONVERT. EXE COMMAND
99
Manage the Microsoft Management ConsoleMMC
100
Manage the Microsoft Management Console

• Introducing the Microsoft Management Console
• Using MMC Consoles
• Creating a Customized Microsoft Management
  Console PE

101
Microsoft Management Console

• Tool to create customized administration tools
• Customized tools known as MMC consoles

102
MMC Consoles

• Centralize administration
• Perform most administrative tasks remotely

103
Console Tree and Details Pane
This is an example of what the Console Tree in a
Details Pane will look like in WINDOWS 2000.
104
Administrative Tools Folder

• Consoles are saved with the extension .MSC.
• Consoles are saved in the Administrative Tools
  folder.

105
Types of Snap-Ins

• Snap-Ins are administrative tools.

106
Using the MMC Console
To open the MMC Console Click Start, and then
RUN.
107
Using the MMC Console
At the RUN dialog box Type MMC then click the OK
button
108
Using the MMC Console
The Console Root will then open. Maximize all
windows.
109
Using the MMC Console
In the Menu Bar click on the Console option.
Select ADD/REMOVE SNAP-IN.
110
Using the MMC Console
The Add/Remove Snap-In window appears. Click the
ADD button.
111
Using the MMC Console
At the Add Standalone Snap-In window
select Device Manager. Click ADD
112
Using the MMC Console
Here you have the option of choosing which
computer you you want the Snap-In to
manage. Choose the Local computer option and
click the Finish button.
113
Using the MMC Console
At the Add Standalone Snap-In window select Disk
Defragmenter and click the ADD button.
114
Using the MMC Console
At the Add Standalone Snap-In window select Disk
Management and the click the ADD button.
115
Using the MMC Console
You once again get the option of choosing which
computer you want the Snap-In to manage. Select
the Local computer and click the Finish button.
116
Using the MMC Console
Next select Event Viewer and click the ADD
button.
117
Using the MMC Console
Select the Local computer option and click Finish.
118
Using the MMC Console
And lastly select the System Information and
click the ADD button.
119
Using the MMC Console
Select the Local computer option and click the
Finish button.
120
Using the MMC Console
At the Add Standalone Snap-In window click the
Close button.
121
Using the MMC Console
You now see the list of Snap-Ins that have been
selected. Click the OK button.
122
Using the MMC Console
The new MMC Console now appears with your own
personalized options.
123
Using the MMC Console
From this new console we can view all properties
of the Snap-Ins that we have selected.
124
Using the MMC Console
With the System Information snap-in we can view
information on our System, Hardware Resources,
Components, Software Environment and I.E. 5.
125
Using the MMC Console
Select the Console option in the Menu
Bar. Select Save As
126
Using the MMC Console
MMC are saved to the Administrative Tools
folder. Name the file the same name as your
position number.
127
Using the MMC Console
Close out the MMC Console.
128
OPENING THE MMC CONSOLE
To open the MMC Console that we just created,
Click Start, Programs, Administrative Tools, and
the file that we just created.
129
OPENING THE MMC CONSOLE
We now see that we have our own personalized MMC
Console. Highlight the System Information folder.
130
CREATING A SYSTEM FILE
From the MMC Console we can create a System File
to assist in troubleshooting and tech
support. Right click the System Information
folder. Select Save as Sys Info file.
131
CREATING A SYSTEM FILE
Save file as your position number. Close out your
MMC Console.
132
CREATING A SYSTEM FILE
Open up youre MY DOCUMENTS folder. Double
click on the system information file that you
just created.
133
CREATING A SYSTEM FILE
We now have a file that can be emailed if
necessary to tech support to aid in
troubleshooting.
134
CHECK FOR LEARNING
What is the Microsoft Management Console ?
Tools to create customized administration tools.
What file extension designates a MMC ?
.MSC
Where are MMC files saved by default ?
The Administrative Tools folder.
135
PRACTICAL EXERCISE 5
Manage the Microsoft Management Console and
Create a System File
136
WINDOWS 2000 NETWORKING
137
WINDOWS 2000 NETWORKING
What is a Computer Network ?

• Two or more computers connected over a common
  media for the purpose of sharing information.

138
WINDOWS 2000 NETWORKING
The two major types of networks are ?

• Peer-to-Peer Network

• Server-Based Networks

139
WINDOWS 2000 NETWORKING

• What is a Peer-To-Peer Network ?

It is a type of network in which all workstations
are equal.
AKA Workgroups
140
WINDOWS 2000 NETWORKING

• Each user acts as his or her own administrator.

• Each resource has its own password.

• User share their resources as they want.

• Each user sets their own security.

141
WINDOWS 2000 NETWORKING
When are Peer-To-Peers appropriate?
142
WINDOWS 2000 NETWORKING
Server-Based Network
A network in which there is a hierarchy in place.
A Domain Controller has been established.
143
WINDOWS 2000 NETWORKING
Workstation
There are two kinds of computers on
networks. Servers and Workstations. A
workstation is a computer on a network where a
user uses the network.
144
WINDOWS 2000 NETWORKING
SERVERS
A computer on a network that provides a service
to that network. Services can be network
printing, network security, network storage, etc.
A Client is a user who is using the resources
of the server.
145
WINDOWS 2000 NETWORKING
Dedicated and NonDedicated Servers

• A Dedicated server is a server only

• A NonDedicated server is a computer that is a
  workstation and server

146
WINDOWS 2000 NETWORKING
Types of Servers

• Print Servers
• File Servers
• Data Base Servers
• E-Mail Servers
• Domain Controller

147
WINDOWS 2000 NETWORKING
Why server-based networking ?

• Centrally administered and controlled.
• Provides access to network resources without
  compromising performance.
• Security Access to resources can be limited to
  specific users
• Backup and redundancy All data backed up to
  one location
• More users, larger network

148
WINDOWS 2000 NETWORKING
PROTOCOLS

• Protocols are rules and procedures established
  that allow different devices and/or software to
  communicate.

149
WINDOWS 2000 NETWORKING

• TCP/IP Transmission Control Protocol
• / Internet Protocol

150
WINDOWS 2000 NETWORKING

• DHCP Dynamic Host Configuration Protocol
• HTTP Hyper Text Transfer Protocol
• (World Wide Web)

151
WINDOWS 2000 NETWORKING
IP ADDRESS
147.51.175.200
A number used to identify a computer or
device on a TCP/IP network. Each computer or
device on a network must have its own unique
address.
152
WINDOWS 2000 NETWORKING
Plain Language Address
WWW.HOTMAIL.COM The plain language
address is essentially the same thing as an IP
Address. Using a Domain Name Server, an IP
Address can be linked to a plain language address
so it can be remembered easily.
153
WINDOWS 2000 NETWORKING
Domain Name Server
A server, usually connected to the
Internet, where you can register a domain name,
or plain language address, that is linked to your
individual IP Address.
154
WINDOWS 2000 NETWORKING
Domain Name
A domain name is registered by its type and/or
purpose. This name is broken down to domains and
sub-domains.
GORDON.ARMY.MIL
155
PREPARATION
Items to have ready prior to installation

• Authorization - User Name and Password
• Network Card Drivers Floppy Disk or CD-ROM
• IP Addresses - Computer, Subnet Mask, Gateway,
  DNS Service Search Order, and WINS Server
• Computer Name - Name that computer will be known
  as across network
• Workgroup Name or Domain Name

156
NETWORK CARD IRQ AND I/O

• WINDOWS 2000 has a Device Manager to resolve
  hardware conflicts or to make changes to the IRQ
  or I/O range.

157
METHOD OF INSTALLING EXPANSION BOARD DRIVERS

• Almost all expansion board drivers can be
  installed on Windows 2000 operating system by
• Floppy Disk CD-ROM Network
  Manufacturer Website

158
CONFIGURING NETWORK SETTINGS
To begin Network configuration you right click
the MY COMPUTER icon and select PROPERTIES.
159
CONFIGURING NETWORK SETTINGS
At the System Properties, Click the Network
Identification Tab. Then click the Properties
button.
160
CONFIGURING NETWORK SETTINGS
At the Identification Changes window verify that
your computer name is correct. ( I.E. WS?175???
) If wrong change the computer name to the
correct name and Reboot. If the name is correct,
click OK.
161
CONFIGURING NETWORK SETTINGS
Back at the Desktop, Right click MY NETWORK
PLACES and select PROPERTIES.
162
CONFIGURING NETWORK SETTINGS
You will have 2 icons in the Network and Dial-Up
Connections window, Right click on LOCAL AREA and
select PROPERTIES.
163
CONFIGURING NETWORK SETTINGS
In the Network Properties dialog box you should
have Client for Microsoft Networks, File and
Printer Sharing for Microsoft Networks, and
Internet Protocols (TCP/IP). (All should be
Checked)
164
CONFIGURING NETWORK SETTINGS
Highlight INTERNET PROTOCOL (TCP/IP) and click on
the PROPERTIES button.
165
CONFIGURING NETWORK SETTINGS
In the TCP/IP dialog box choose the radio button
next to USE THE FOLLOWING IO ADDRESS.
166
CONFIGURING NETWORK SETTINGS
You must add the following IP Address Subnet
Mask Default Gateway Preferred DNS Alternate
DNS (This information is located in your Student
Position Binder) Click ADVANCED
167
CONFIGURING NETWORK SETTINGS
In the Advanced TCP/IP Settings you see the
settings for your IP Address, Subnet Mask, and
Default Gateway, that you just added. Click the
DNS tab.
168
CONFIGURING NETWORK SETTINGS
In the DNS window you see your settings for the
DNS. Click the WINS tab.
169
CONFIGURING NETWORK SETTINGS
You must add the WINS IP Address. Click ADD.
170
CONFIGURING NETWORK SETTINGS
Type your WINS address and Click on the ADD
button.
171
CONFIGURING NETWORK SETTINGS
At the Advanced TCP/IP Settings window click
OK. Close out any windows still open.
172
CONFIGURING NETWORK SETTINGS
Back at the Desktop, Right click the MY COMPUTER
icon and select PROPERTIES.
173
CONFIGURING NETWORK SETTINGS
At the SYSTEM Properties window click the NETWORK
IDENTIFICATION tab. Click the PROPERTIES button.
174
CONFIGURING NETWORK SETTINGS
We must now join the DOMAIN. Click on the radio
button next to Member of DOMAIN and
TYPE 52div Click OK.
175
CONFIGURING NETWORK SETTINGS
After a connection has been established you will
get a Domain Username and Password dialog
box. Enter the User Name and Password for your
position. Click OK.
176
CONFIGURING NETWORK SETTINGS
After the Authentication process is accomplished
successfully you will get the WELCOME TO THE
52DIV dialog box. Click OK.
177
CONFIGURING NETWORK SETTINGS
You are now informed that the computer must be
restarted. Click OK.
178
CONFIGURING NETWORK SETTINGS
You are told that changes will not take effect
until you restart the computer. Click OK.
179
CONFIGURING NETWORK SETTINGS
Click YES to restart your computer. Once the
computer has been restarted Log On as
administrator.
180
VIEWING THE NETWORK
At the Desktop, double click on the My Network
Places icon. Then double click the Entire Network
icon.
181
VIEWING THE NETWORK
At the ENTIRE NETWORK window click on VIEW ENTIRE
NETWORK (IN BLUE on the left side of the
window). You are then taken to the Microsoft
Windows Network. Double-click the Icon.
182
VIEWING THE NETWORK
You are now at the Microsoft Windows Network
window that allows you to see all networks that
are connected to your workstation. Double click
on the 52DIV icon.
183
VIEWING THE NETWORK
You now have the ability to see all computers
logged onto your domain.
184
CHECK FOR LEARNING
What is a network ?
A group of 2 or more computers connected together
through common media to share information and
resources.
True or False In a Server based environment all
workstations manage their own resources ?
False
What does (DHCP) Dynamic Host Configuration
Protocol do ?
Assigns a different IP address every time that a
user logs on.
185
PRACTICAL EXERCISE 6 SETUP NETWORK SETTINGS
AND JOIN THE 52DIV DOMAIN
186
INSTALLING A VIDEO CARD DRIVER
187
VIDEO DRIVER EXPLANATION

• The initial display driver (commonly referred to
  as a Generic Driver) is installed when
  Windows 2000 is installed.
• Loading the proper driver for devices will
  enhance the devices capabilities.

188
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
To install the video driver from the network,
first double click the MY NETWORK PLACES
icon. Then double click the ENTIRE NETWORK icon.
189
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
In the ENTIRE NETWORK window click on View the
ENTIRE Contents.
190
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
Double click the Microsoft Windows Network icon.
191
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
Double click the 52div icon.
192
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
Double click the icon labeled 52div_pdc
193
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
When opening the 52div_pdc you are prompted for a
User Name and Password. Enter your position user
name and password. Click OK.
194
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
Locate the share point labeled STUDENT and
double click.
195
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
Within the STUDENT folder locate the WINDOWS 2000
folder and double click.
196
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
Locate folder labeled VIDEO and double click.
197
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
Double click the folder labeled GRAPHICS.
198
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
Locate the SETUP icon and double click.
199
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
The SETUP program starts.
200
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
The Welcome wizard begins. Here you are
encouraged to close all open programs before
continuing. Click NEXT.
201
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
The Software License Agreement is displayed,
Click NEXT to proceed.
202
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
Next you are informed what folder the software
will be installed in. Click NEXT.
203
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
The Installation begins.
204
INSTALLING THE VIDEO DRIVER FROM THE NETWORK
You are now informed that you must Restart for
the changes to take effect. Click Finish.
205
PRACTICAL EXERCISE 7 PART 1INSTALL VIDEO CARD
DRIVER FROM THE NETWORK
206
INSTALLING A SOUND CARD DRIVER
207
SOUND CARDS

• Sound cards enable the computer to output
  sound through speakers, record sound input from
  a microphone, and manipulate sound stored on a
  disk.
• In order to install the drivers for a sound
  card, you must know the make and model of your
  sound card.

208
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
Ensure that you are logged on as the
Administrator. To begin installation of Sound
Card Driver, Click on My Network Places.
Click Here
209
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The My Network Places dialogue box appears.
Click on Entire Network.
Click Here
210
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Entire Network dialogue box appears. Click
on view the entire contents to view the entire
network.
Click Here
211
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Entire Network Dialogue Box appears. Click
on Microsoft Windows Network.
Click Here
212
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Microsoft Windows Network dialogue box
appears. Click on 52div.
Click Here
213
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The 52div dialogue box appears. Click on
52div_pdc.
Click Here
214
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Enter Network Password dialogue box appears.
Here you will enter your user name and password.
Click ok.
Enter User Name and Password
215
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The 52div_pdc dialogue box appears. Click on the
folder labeled Student.
Click Here
216
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Student on 52div_pdc dialogue box appears.
Click on the folder labeled Windows 2000.
Click Here
217
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Windows 2000 dialogue box appears. Click on
the folder labeled Sound.
Click Here
218
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Sound dialogue box appears. Click on the
folder labeled Micron Soundmax.
Click Here
219
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Micron Soundmax dialogue box appears. Click
on Setup.
Click Here
220
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Micron Soundmax Driver Setup program begins
to install the InstallShield Wizard.
221
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Welcome dialogue box appears. Here you are
reminded to close all other windows before
proceeding with the setup program. Click next.
222
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The Setup Program begins to install program files.
223
INSTALLING A SOUND CARD DRIVER FROM THE NETWORK
The restarting Windows dialogue box appears.
Accept Yes, I want to restart my computer now by
clicking on OK.
224
INSTALLING A SOUND CARD DRIVER
You have now successfully loaded the Sound Driver
for Win 2000. Notice the Speaker in the System
Tray.
225
PRACTICAL EXERCISE 7 PART 2 INSTALL SOUND CARD
DRIVER FROM THE NETWORK
226
TROUBLESHOOTING IN WINDOWS 2000
227
TROUBLESHOOTING IN WINDOWS 2000

• Troubleshooting is the process of eliminating
  faults from a system.
• As a 31U, it is important to know how to
  diagnose the problem and where start
  troubleshooting.

228
TROUBLESHOOTING IN WINDOWS 2000

• You must know how the specific system you are
  troubleshooting works if you want to be able to
  diagnose faults.
• Most importantly, begin troubleshooting by
  isolating the fault.

229
WINDOWS 2000 HELP FILES

• The Windows 2000 Help files are an excellent
  troubleshooting resource.
• Help files are based upon Microsofts
  experience with customer support, so they include
  specific troubleshooting help for the problems
  reported to Microsoft most often.

230
WINDOWS 2000 HELP FILES
Using Windows 2000 Help may assist you with using
and/or troubleshooting windows 2000.
231
F1 KEY HELP OPTION
In WINDOWS 2000 pressing the F1 key will provide
HELP with the application that is currently
active. This is called Context sensitive help.
Note It will not provide as complete a help
database as in the WINDOWS 2000 database will.
232
THE EVENT VIEWER
The Event Viewer displays event logs that have
been generated by your System, Security,
Applications or User actions. You should begin
all troubleshooting sessions by reviewing the
Event Log with the Event Viewer. Quite often the
log will tell you exactly what is wrong.
233
THE EVENT VIEWER

• Event logs are records of system events.
• Log file contents can be displayed with Event
  Viewer.
• The three types of Event Logs are
• The System Log
• The Security Log
• The Application Log

234
THE EVENT VIEWER
2000 assigns one of three priorities to events in
the Event Log. Represents informative message.
They are only for your information. They do not
affect the operation of your computer. Represents
alerts or warnings. They indicate that your
computer is operating in a degraded condition or
some non-critical source is not operating
correctly. Indicates a critical warning.
Something serious is wrong with your computer or
configuration that will cause denial of service.
i
!
X
235
THE EVENT DETAIL

• The Event Detail dialog box displays further
  information
• on an event by providing
• Date and Time of the event.
• Event Identification.
• Text Description of the selected event.
• To access the Event Detail double click on the
  event that
• you want the details for.

236
USING THE EVENT VIEWER
To open the Event Viewer click on Start Button,
select Programs, select Administrative Tools ,
and click on the Event Viewer.
237
THE SYSTEM LOG
The system log contains events generated by all
Windows 2000 internal services and drivers. For
example, the failure of a driver or service to
load is recorded here.
238
THE EVENT DETAIL

• The Event Detail dialog box displays further
  information
• on an event

239
THE SECURITY LOG
The security log contains security events when
auditing is enabled. Only administrators can view
the security log.
240
THE APPLICATION LOG
The application log contains events generated by
applications. For example, a database program
might report a file error in the application log.
241
THE EMERGENCY REPAIR DISK (ERD)

• If a file that contains Windows 2000 Registry
  information becomes corrupt, Windows 2000 can
  become unstable to the point of making it
  impossible to fix the problem from within.
• You can create an emergency repair disk to
  restore the Registry from the last time you
  performed an emergency repair disk update.

242
THE EMERGENCY REPAIR DISK (ERD)

• You should create a new repair disk each time
  you make a major change to the security policy,
  add new users, or change the configuration of
  your Windows 2000 Professional Workstation.
• The emergency repair disk is not a replacement
  for regular backups. The emergency repair disk
  stores only Registry configuration information,
  not your data.

243
THE EMERGENCY REPAIR DISK (ERD)

• When you create a Emergency Repair Disk, the
  computer also copies the accounts password.
• Ensure that once a Emergency Repair Disk is
  created that it is safeguarded.

244
REPAIR DISK UTILITY

• The Repair Disk Utility saves all of your current
  system settings to an Emergency Repair Disk. You
  can then use this disk to restore your computer
  if files become damaged.

245
REPAIR DISK UTILITY
To open the Repair Disk Utility Click on Start,
Programs, Accessories, System Tools and Backup.
246
REPAIR DISK UTILITY
Click on the Emergency Repair Disk button.
247
REPAIR DISK UTILITY
Insert a blank floppy disk into the floppy
drive. Click OK
248
REPAIR DISK UTILITY
The Repair Disk Utility begins copying the data.
249
REPAIR DISK UTILITY
The ERD was created successfully. Click OK.
250
TROUBLESHOOTING RESOURCES
Access to resources can make support tasks
easier. Microsoft support resources, including
TECH NET WORLD WIDE WEB ONLINE SERVICES
251
TECH NET

• The TechNet CD-ROM contains a complete set of
  online Microsoft Resource Kits packed with
  technical references, utilities, and accessories
  to help install and support Microsoft products.
• TechNet provides in depth how to technical
  information on Microsoft products.

252
WORLD WIDE WEB
You can use many of the Web search engines and
indexes to locate information about Windows 2000
and troubleshooting.
EXAMPLES
253
WORLD WIDE WEB
You can also go to the manufacturers Web site.
www.microsoft.com
254
ONLINE SERVICES
The major online services sponsor forums that
provide support for most popular software,
including Windows 2000. America Online Has an
active Windows 2000 forum.
255
MICROSOFT ONLINE
Microsoft has created a web page that covers many
useful tools and information on WINDOWS 2000
Professional
256
CHECK FOR LEARNING
What is an excellent troubleshooting resource?
Windows 2000 Help files
In a Windows 2000 environment, what happens when
you press the F1 key ?
You receive help only for the program that you
are currently in.
What displays events that have been generated by
the Windows 2000 system, applications, or user
actions ?
The Event Viewer
257
CHECK FOR LEARNING
What are the three types of Event Logs in the
Event Viewer ?
The System, Security, and application Logs.
When should you create a new Emergency Repair
Disk ?
Each time you make a major change to the
security policy, add new users, or change the
configuration of your Windows 2000 Workstation.
What three troubleshooting resources can you use
to assist you in troubleshooting Windows 2000 ?
TechNet, World Wide Web, and Online Services.
258
PRACTICAL EXERCISE 8 FORMAT, RELOAD, RESTORE
NETWORK SETTINGS AND REJOIN THE 52DIV DOMAIN, SET
UP VIDEO AND SOUND DRIVERS
