A 16Bit Kogge Stone PSCMOS adder with Signal Completion

1
A 16-Bit Kogge Stone PS-CMOS adder with Signal
Completion

• Seng-Oon Toh, Daniel Huang, Jan Rabaey
• May 9, 2005
• EE241 Final Project

2
Motivation

• Asynchronous designs give better throughput and
  has higher efficiency
• Larger circuits and smaller transistors is more
  susceptible to process variations.
• Process variation decreases yield of circuits
• Reach optimum clocking frequency per block
• Need for self timing with the circuits with a
  signal completion, which also increases yield
  from process variations.

3
Past Solution

• GALS
• DCDVSL

IEEE, 1998
4
PS-CMOS 16-bit Kogge-Stone Pipelined Adder

• Adders
• Adder is an integral part of ALU
• Large pipelined adders may be beneficial for
  large adders to increase clock frequencies and
  throughput

5
PS-CMOS 16-bit Kogge Stone Pipelined Adder

• Adder Design
• Kogge-Stone CLA
• Four stages
• Stage 1 Bit P and G
• Stage 2 Dot 1, 2
• Stage 3 Dot 3, 4, Cout
• Stage 4 Sum
• 2-Input gates, no complex logic gates, for
  significant logic depth.

1
2
3
4
6
PS-CMOS 16-bit Kogge Stone Pipelined Adder

• PS-CMOS
• Monotonic output transition
• Noise Immunity
• Pseudo-dynamic, fast evaluate

7
PS-CMOS 16-bit Kogge Stone Pipelined Adder

• Completion Signal
• Simple scheme that is compatible with PS-CMOS
• DCDVSL
• Dummy paths
• Take advantage of monotonic output transition
• Input the worst case input vector upon startup to
  find clock frequency
• Calibrate in situ

8
Completion Signal Scheme
precharge
evaluate
Output signal
Delay Output signal
Clock signal
9
Completion Signal Scheme Slow Clock
precharge
evaluate
Output signal
Delay Output signal
Clock signal
10
Completion Signal SchemeFast Clock
precharge
evaluate
Output signal
Delay Output signal
Clock signal
11
Completion Signal Circuitry
12
Completion Signal Circuitry
Stage 3
Input
Output
Critical path
sum
Input check
8-bit Counter
Check for delay Increase, decrease, stop counting
DAC
Clock Generation
VCO
13
Results
14
Results
15
Results

• Theoretical delay 714ps, measure 850ps
• For in situ calibration how often will the worst
  case input vector appear?
• Assuming perfectly random inputs
• Worst case input vector will appear approximately
  once every 105 switches
• Circuit runs approximately 109 switches per
  second
• Every second there can be a potential of 104
  updates.
• This sets the optimum clock speed to clock for
  the calibration circuitry

16
Results

• Counter able to count up as well as down
• Speed up and slow down based on conditions
• Ability to calibrate for different supply
  voltages
• Ability to test at startup and in situ

17
Discussion

• Ideal sensor has 0 capacitance
• We have small capacitance
• 1 inverter, 1 latch
• Circuit Overhead low
• Probability of Switching
• Maximum clock frequency for test circuit
• Calibration frequency is high
• Multiple paths available for detection
• Closes feedback path for DVS

18
Discussion

• During clock change no evaluation is allowed
• Slack margin 100 ps built in delay from detection
• Nonexistant with registers, because of intrinsic
  need of delay for registers
• PS-CMOS
• Difficult to implement XOR
• Not straight forward logic
• When used with latches timing of precharge and
  evaluate is difficult
• Frequency increments
• Small time step necessary for stability

19
Future Improvements

• Fix delay overhead of detection circuit
• Fix problems from latch based design
• Circuitry for multiple path detection
• Super Pipeline 256-bit adder
• Ability to run adder slower
• Monitor precharge

20
Conclusion

• Shown a simple completion signal scheme for a
  pipelined PS-CMOS adder
• Small amount of overhead
• Ability to adjust clock frequencies during
  operation not only on startup

• Because I could not stop for Death,He kindly
  stopped for meThe carriage held but just
  ourselvesAnd Immortality.
• -Emily Dickinson, 1924
