Grid Testbeds A U.S. ViewHEP-CCC 29 June 2002

• Larry Price
• Argonne National Laboratory

2
Existing or PlannedUS-Testbed Activities

• US-ATLAS Test Grid
• US-CMS Test Grid
• Combine to make an iVDGL-1 Test Grid by November
• Combine further with EDG Testbed to make an iVDGL
  / DataTAG Testbed
• GLUE Collaboration (iVDGL / DataTAG)
• TeraGrid Facility

3
US-ATLAS Test Grid

• Testbed has been functional for 1 year
• Decentralized account management

• Grid credentials (based on globus CA)
• updating to ESnet CA
• Grid software Globus 1.1.4/2.0, Condor 6.3
  (moving towards full VDT 1.x)
• ATLAS core software distribution at 2 sites (RH
  6.2)

4
ATLAS related grid software

• GridView - simple tool to monitor status of
  testbed Kaushik De, Patrick McGuigan
• Gripe - unified user accounts Rob Gardner
• Magda - MAnager for Grid DAta Torre Wenaus,
  Wensheng Deng (see Gardner Wenaus talks)
• Pacman - package management and distribution tool
  Saul Youssef
• Being widely used or adopted by iVDGL VDT, Ganga,
  and others
• Grappa - web portal using active notebook
  technology Shava Smallen (see Gardner talk)
• GRAT - GRid Application Toolkit
• Gridsearcher - MDS browser Jennifer Schopf
• GridExpert - Knowledge Database Mark Sosebee
• VO Toolkit - Site AA Rich Baker

5
Some Near Term US-ATLAS Plans

• Develop a data movement/management prototype
  using
• Condor, GDMP, MAGDA
• Continue development of "easy to use" data
  analysis tools
• Enhance GRAPPA web portal
• Further develop leading work on packaging and
  Pacman
• Automate the packaging of a grid production
  mechanism
• Develop an MDS information provider for
  Pacman-deployed software
• Participate in Data Challenge 1 (begins this
  month in June!)
• Interoperate with US-CMS Test Grid and EDG
• Run ATLAS apps on US-CMS Test Grid (done!)
• Run ATLAS apps from US-ATLAS Site on EDG Testbed
  (done!)
• Expand to Interregional ATLAS Testbedlate 2002

6
ATLAS Summer Schedule

• July 1-15 Phase 0, 107 events
• Globus 2.0 beta, Athena 3.0.1, Grappa, common
  disk model, Magda, 5 physics processes, BNL VO
  manager, minimal job scheduler, GridView
  monitoring
• August 5-19 Phase 1, 108 events
• VDT 1.1.1, Hierarchical GIIS server,
  Athena-atlfast 3.2.0, Grappa, Magda - data
  replica management with metadata catalogue, 10
  physics processes, static MDS based job
  scheduler, new visualization
• September 2-16 Phase 2, 109 events, 1 TB
  storage, 40k files
• Athena-atlfast 3.2.0 instrumented, 20 physics
  processes, upgraded BNL VO manager, dynamic job
  scheduler, fancy monitoring
• Need some planning of analysis tools

7
Atlfast Production Architecture
Boxed Athena-Atlfast
Storage Elements
MDS
Globus
Resource Broker
Magda
VDC
JobOptions Higgs SUSY QCD Top W/Z
Grappa Portal or GRAT script
User
8
US-CMS Test Grid

• Testbed has been functional for 1/2 year
• Decentralized account management

• Grid credentials (based on Globus CA)
• updating to ESnet CA
• Grid software VDT 1.0
• Globus 2.0 beta
• Condor-G 6.3.1
• Condor 6.3.1
• ClassAds 0.9
• GDMP 3.0
• Objectivity 6.1
• CMS Grid Related Software
• MOP distributed CMS Monte carlO Production
• VDGS - Virtual Data Grid System Prototype
• CLARENS - Distributed CMS Physics Analysis
• DAR Distribution After Release for CMS
  applications (RH 6.2)

9
Some Near Term US-CMS Plans

• Prototype Virtual Data Grid System (VDGS)
• Based upon the GriPhyN Data Grid Architecture
• First prototype by August
• Production prototype for November
• Grid-enabled Monte Carlo Production
• Build upon the CMS experience (already quite
  mature)
• Run live CMS production this Summer
• Integrate with VDGS for November
• Grid-enabled Analysis Environment
• Based upon web services (XML, RPC, SOAP, etc)
• Integrate with VDT and VDGS for November
• Interoperate with US-ATLAS Test Grid and EDG
• Run CMS apps on US-ATLAS Test Grid
• Run CMS apps from US-CMS Site on EDG Testbed

10
Example of CMS MC Production on a Grid
Remote Site 1
Batch Queue
Master Site
GDMP
DAGMan Condor-G
IMPALA/ BOSS
mop_submitter
GDMP
Remote Site N
Batch Queue
GDMP
11
Recent CMS Results

• Assigned 200 000 Monte Carlo Events from CMS
• Requested a real assignment to ensure production
  quality of the grid software
• Produced 100 000 Fully Validated Events (many
  times over)
• Discovered/corrected many fundemental core-grid
  software bugs (Condor and Globus)
• huge success from this point of view alone
• Anticipate finishing full assignment soon
• Will request another assignment for the
  summer

12
ATLAS-CMS Demo. Architecture
SC2002 Demo
Visualization (status, physics)
ATLAS-CMS User Job
Globus, Condor-G?
MDS, Ganglia, Paw/Root
Scheduling Policy
??
Condor, Python?
ATLAS-CMS Testbed
Production Jobs
MOP, GRAT, Grappa
13
General Observations

• Easy to say We have a Grid!
  ...more difficult to make it do
  real work
• a grid is like an "on-line system" for a physics
  detector.
• a grid is complex with many modes of failure
• often difficult to track down simple problems
• host certificates expired
• gatekeepers not synchronised
• sometimes difficult to fix the problem
• bugs still exist in the core-grid software itself
• need for multiple monitoring systems
  (performance, match-making, debugging,
  heart-beat, etc)
• need for more transparent data access
  (Virtual Data)
• Nevertheless, these are typical of "growing
  pains!"

14
Lessons Learned (so far)

• Test Grid commissioning revealed a need for
• grid-wide debugging
• ability to log into a remote site and talk to the
  System Manager over the phone proved vital...
• remote logins telephone calls not a scalable
  solution!
• site configuration monitoring
• how are Globus, Condor, etc configured?
• on what port is a particular grid service
  listening?
• should be monitored by standard monitoring tools?
• programmers to write very robust code!

15
Current Grid-Monitoring Efforts

• MDS (Globus)
• Uses an LDAP schema as well as "sensors"
  (Information Providers)
• Scalable GRIS update information to a central
  GIIS
• FLAMES (Caltech Package)
• Provides a complete-seamless picture from LAN to
  WAN
• Based on modular services
• e.g. SNMP with interfaces to JINI, MDS, Web, etc
• Hawkeye (Condor)
• Leverages the ClassAd system of collecting
  dynamic information on large pools

16
Virtual Organisation Management on US-Test Grids

• US-projects are just beginning work on VO
  management
• looking to adopt much of the excellent work from
  the EDG.
• Currently no VO management on the Test Grids
• Account management is fully decentralized
• Local account policy/management varies widely
  from site to site
• Some sites do not allow group accounts !
• Decentralized situation is starting to become
  un-wieldy
• EDG VO Scripts are being deployed and tested
  across two US-CMS Test Grid sites
• Florida
• Caltech

17
VO Management (cont.)

• Group (or pooled) accounts vs. individual
  accounts
• Current VO management scripts only work well if
  group accounts are allowed at every site
• Not every site allows group accounts (for very
  good reasons) !
• The interaction between local and grid-wide
  account management needs to be understood
• Will sites be willing (or even able) to delegate
  account management to a trusted CA or RA?
• Need a centralized LDAP server where information
  for all iVDGL VOs is kept
• Hope to begin evaluating the Globus Community
  Authorization Service (CAS) and Policy
  enforcement soon

18
GLUE Grid Laboratory Uniform Environment

• Originated by HICB/HIJTB process
• Goal interoperability between EU (EDG) and US
  (iVDGL) HEP Grid Projects at the core-grid
  middleware level
• Define a common schema to describe Grid Resources
• Advantage independent of the particular Data
  Grid Architecture implementation

19
CDF
GLUE
20
GLUE history its ancient history

• HICB and JTB established. Looked for
  Intercontinental Testbed Showcases
• Experiment organizations responded with their
  already planned data challenge schedules and/or
  cross experiment tests. Experiment top down
  organizational process already in place
• HICB and JTB organization naturally focus on
  collaboration between Grid Middleware/Service
  projects no top down organization that spans
  the projects
• Proposed common TestBed GRIT

21
GRIT Grid Reference Intercontinental Testbed

• GRIT - A TestBed solely for the purposes of
  testing interoperability across the Grid Projects
  without impacting progress of each End User,
  Project or Experiment.
• Concern about overlap with other projects
  deliverables and duplication of effort.
• At that time there was a strategy of one and
  only one EDG TestBed in EU (Trident had not
  been agreed to). US Experiment TestGrids only
  just being considered.
• Disposible Logical Grids raising of TestBeds,
  TestGrids, Prototype grids, development,
  integration and stable grids easy and ubiquitous
  a goal for the future.

22
So we have GLUE

• Acquire and define software, configuration
  guidelines and policies to allow Middleware
  Services developed by the participating Grid
  Projects to Interoperate.
• Results must be independent of the particular
  Data Grid Architecture implementation.
• But to succeed will need agreement on
  Principles
• What does Interoperate mean?
• Someone in US/EU can run on the EDG/US Grid
  using their US/EU obtained credentials.
• Someone in EU/US can submit a Job in the EU/US
  that will be scheduled on Resources that span EU
  and US sites.
• Someone in US/EU can move Data from/to US and EU
  sites without specific knowledge of which
  continent the Site is on the knowledge of the
  Site Resources, Performance, and Policies is
  sufficient.

23
Glue is NOT

• What does interoperate not mean?
• Interoperability between the Experiments and end
  user applications User Interfaces and Portals
  VO specific Planners, Brokers, Optimizers
• That all Grid Sites being used necessarily use
  the same software
• That all Grid Sites necessarily have consistent
  policies
• GLUE is not an independent software development
  project. Software development is proposed and
  work done by others.
• GLUE is not a project staffed to the scope of its
  deliverables and schedule.

24
Organization Responsibility

• First 2 projects that in practice need to
  interoperate with Middleware and Grid Services
• EU EDG/DataTAG and US Physics Grid Projects
  Trillium
• DataTAG and iVDGL have mandates to work on
  Interoperability Issues.
• Thus GLUE is a collaboration coordinated by
  DataTAG and iVDGL.
• These projects are responsible for the
  Deliverables and Delivering to the Schedules.
• Deliverables will be made to
• EDG Release and Virtual Data Toolkit (VDT)

25
Documents, Plans and Meetings

• GLUE V1.1.2 now in existence recent edits by
  Ewa (iVDGL) and Antonia (DataTAG)
• Is a living document - IF projects are to rely
  on its deliverables this is not sufficient
• Joint DataTAG WP4 and iVDGL Interoperability
  meetings have proven useful.
• Core Team to date Antonia, Cristina, Sergio,
  Flavia, Roberto, Rick, Ewa, Jenny, Brian, Doug,
  Ruth
• Core Team relies on many others to get the work
  done
• Core team not sufficient to successful meet
  milestones for Deliverables
• Need to Tie the Deliverables to Software Release
  Schedules
• Need good coordination with EDG Release
  Management, Bob, Cal, and VDT Release management,
  Scott, Alain

26
Basic Components as Defined in the Document

• Authentication Infrastructure
• Service Discovery (information) Infrastructure)
• Data Movement Infrastructure
• Authorization Services
• Computational services
• Added through work of DataTAG maps well to
  other activities of iVDGL
• Packaging
• Interoperable Experiment Grids

27
Authentication

• Cross organizational authentication using Grid
  Security Infrastructure
• DONE?
• DOE SG and EDG Cas have mutual trust for
  Certificates.
• Policies are agreed to
• BUT Still issues with respect to Revocation
  Lists.
• BUT Distribution of Certificate files not
  consistent or automated.
• Work Remains..

28
Service Discovery (Information) Infrastructure

• The GLUE SCHEMA Project.
• Define common and base set of information to be
  supplied by both EDG and VDT software.
• Idea adopted by Globus MDS group as useful for
  inclusion as part of base release of MDS.
• Goal of consistent naming and structure of
  information
• Requires also upgrade of Information Providers
  and Consumers to match the new information.

29
Defined new structure for Compute Element
information
30
Glue Schema the full flavor of collaboration

• Spreadsheet version 12. Listing EDG, Globus and
  new schemas for CE
• First draft March 19 12 calls, more than 500
  emails, and MANY hours of work later Draft 12
  sent out May 22 pm
• Document defining schema structure v. 6 Layered
  structure CE, cluster, (homogeneous) subcluster,
  node Attributes collected into object classes
  UML class diagram for generic representation
• Mapping into ldap is going on now.
• Modification of information providers
• MDS information providers with new schemas part
  of the MDS 2.2 release, mid July
• EDG information providers need updating what
  is the schedule for this?
• After CE, SE and NE Discussion of SEs has
  started other experts joining in Arie
  Shoshani, John Gordon. Glue Storage Model
  beginning to be discussed to understand general
  constraints.

31
UML Class diagram GLUE Schema
32
GLUE Schema Test Grid
iVDGL
Gatekeeper Padova-site
GIIS giis.ivdgl.org mds-vo-nameivdgl-glue
DataTAG
LSF
Gatekeeper US-CMS
GIIS edt004.cnaf.infn.it Mds-vo-nameDatatag
Resource Broker (tbc)
Condor
Gatekeeper US-ATLAS
Gatekeeper edt004.cnaf.infn.it
Gatekeeper grid006f.cnaf.infn.it
LSF
Computing Element -2 Fork/pbs
WN1 edt001.cnaf.infn.it WN2 edt002.cnaf.infn.it
Computing Element-1 PBS
dc-user.isi.edu
hamachi.cs.uchicago.edu
rod.mcs.anl.gov
Job manager Fork
33
Initial Timeline (very optimistic)

• 1)  Refine and agree on above terminology
  (April 1-15) (done?)
• 2)      Define common schema attributes for a CE.
  This includes definitions of all attributes,
  constants, and relationships between objects.
  Ensure that the schema maps to LDAP, R-GMA
  (relational tables), and XML. (April 7-30)
  (glue-schema group)
• 3)      Convert CE schema to GOS. (May 1-7)
  (Cristina ?)
• 4)      Identify GLUE testbed hosts, install
  Globus, get host certifications, and configure
  trusted CAs. Install EDG CE/SE software in the
  European (and possibly US?) part of the glue
  testbed. There should be at least 2 CEs and 1 SE
  in both the EU and US. (April 15-May 15) (TBD
  ??)
• 5)      Add new CE schemas to MDS information
  provider package, add the new CE schema to
  EDG/MDS information providers, and write new
  information providers as necessary. Write unit
  tests to test modifications (May 1-30) (ISI?)
• 6)      Grid Searcher is a tool for browsing
  MDS. (http//people.cs.uchicago.edu/
  hai/GridSearcher/) This should be a good tool
  for testing new schemas. Need to modify Grid
  Searcher Tool to work with new schemas (May
  1-30) (Jenny student)
• 7)      Modify EDG WP1 Resource Broker and other
  middleware to use the new schemas, and test. (May
  1 - June 30) (EDG?)
• 8)      Define a schema versioning mechanism to
  allow easy changes/additions to the schemas in
  the future. (May 1-30) (Brian, Cristina, Jenny)
• 9)      Install R-GMA on GLUE testbed, and test.
  Configure EDG CE/SE with R-GMA information
  providers, and write new information providers if
  necessary (July 1-30) (EDG?)
• 10)  Modify R-GMA equivalent to Grid Searcher
  to work with new schemas (does this tool
  currently exist?) (July 1-30) (EDG?)
• 11)  Define common schema for Storage Element in
  GOS, and repeat step 4 and 5 (June 1-30)
  (glue-schema group)
• 12)  Define common schema for Network Elements in
  GOS, and repeat step 4 and 5 (July 1-30)
  (glue-schema group)
• 13)  More testing (August) (all)

34
Data Movement Infrastructure

• Move data from storage services operated by one
  organization to another.
• Work Already started
• GDMP - in EDG and VDT
• SRM (HRM,DRM) Buy In conceptually from VDT and
  EDG
• GridFTP protocol server work
• This could use a dedicated meeting of the right
  technical people to discuss.
• In iVDGL core team - Brian. In DataTAG it is ?

35
Authorization services

• Perform some level of cross organization,
  community based authorization
• Still a bit chaotic on the US /VDT Side.
• EDG has a set of LDAP/VO management scripts and
  policies. Continuous discussion in this area.
• For iVDGL Core Team Doug is organizing meetings
  of Site AA on the issue and Rick and Kaushik are
  aware of Experiment needs and short term
  deployments. Ewa is working with Cristina on
  specific needs for the Glue Testbed.

36
Authorization Site, Service and Virtual
Organization

• In US have already engaged the Site Security
  people. US Physics Grid Project experimental
  groups are looking to use their Grids in
  Production.
• Possible 3 Layers of Authorization (work in
  progress)
• Cert publishing directory that ESnet is providing
• LDAP VO server from each VO
• Mapping cert DN to local user account.
• Proposal for new BOF at GGF for presentation of
  the Site Security view.

37
Deployments of Authorization Infrastructure
starting in the US

• Currently no VO management on the Test Grids
• Account management is fully decentralized
• Local account policy/management varies widely
  from site to site
• Some sites do not allow group accounts !
• Decentralized situation is starting to become
  un-wieldy
• EDG VO Scripts are being deployed and tested
  across two US-CMS Test Grid sites
• Group (or pooled) accounts vs. individual
  accounts
• Current VO management scripts only work well if
  group accounts are allowed at every site
• Not every site allows group accounts (for very
  good reasons) !
• The interaction between local and grid-wide
  account management needs to be understood
• Will sites be willing (or even able) to delegate
  account management to a trusted CA or RA?

38
Computational services

• Coordinate computation across organizations to
  allow submission of jobs in EU to run on US sites
  and vice versa.
• All Grids use GRAM as the Job Submission
  Interface. Thus we can interoperate at this time
  if we try. This is in the short term plans for
• CMS using MOP/Impala/Boss
• ATLAS using EDG
• D0/CDF using Job Information Management layer
  with SAM
• Making it Robust to do actual Work is necessary
  before can claim any success.
• Would like to have interoperability at High Level
  Services
• Job Submission Language and
  Resource Broker
• These may well be VO specific and so there will
  be several Interoperating Infrastructures and may
  NOT be packaged with VDT (or at the HENP
  Application Layer) with the EDG..

39
Experiment Grid Interoperability

• DataTAG has significant focus on Experiment Grid
  Interoperability
• iVDGL has significant focus on deployment and
  operation multi-application multi-site Grids
• Part of wider DataTAG and US Physics Grid Project
  collaboration, and is part of the Joint
  Trillium and DataTAG meeting agendae.
• Explicitly includes non-LHC experiments D0,
  CDF, LIGO/Virgo

40
GLUE, the LCG and Schedules

• Deliverables from GLUE are needed to meet the LCG
  Production Grid Milestone at the end of the year.
• That means deliverables from GLUE are needed for
  EDG TestBed 2.
• To date the effort available and schedules of the
  actual Sub-Projects are slower than the
  milestones require.
• Does sufficient infrastructure already exist in
  practice?
• Experiment Jobs Scheduled through Condor-G and
  GRAM
• Data Movement through GridFTP and GDMP
  interfaced to HRM.
• Authorization grid mapfiles done by hand.

41
The TeraGrid A National Infrastructure
www.teragrid.org
42
NSF TeraGrid 14 TFLOPS, 750 TB
ANL Visualization
Caltech Data collection analysis

• WAN Bandwidth Options
• Abilene (2.5 Gb/s, ?10Gb/s late 2002)
• State and regional fiber initiatives plus CANARIE
  CANet
• Leased OC48
• Dark Fiber, Dim Fiber, Wavelengths

• WAN Architecture Options
• Myrinet-to-GbE Myrinet as a WAN
• Layer2 design
• Wavelength Mesh
• Traditional IP Backbone

Myrinet
Myrinet
NCSA Compute-Intensive
SDSC Data-Intensive
43
NSF TeraGrid 14 TFLOPS, 750 TB
574p IA-32 Chiba City
256p HP X-Class
HR Display VR Facilities
128p HP V2500
Caltech Data collection analysis
92p IA-32
HPSS
HPSS
ANL Visualization
SDSC Data-Intensive
Myrinet
UniTree
HPSS
Myrinet
1024p IA-32 320p IA-64
1176p IBM SP Blue Horizon
1500p Origin
Sun E10K
NCSA Compute-Intensive
44
To Build a Distributed Terascale Cluster
Interconnect
Big Fast Interconnect
OC-192
n x GbE (large n)
5 GB/s 200 x 25 MB/s 25 MB/s 200 Mb/s or 20
of GbE
10 TB
10 TB
45
Terascale Status

• Finalizing node architecture (e.g. 2p vs 4p
  nodes) and site configurations (due by end of
  June)
• Expecting initial delivery of cluster hardware
  late 2002
• IA-32 TeraGrid Lite clusters up today, will be
  expanded in June/July
• Testbed for service definitions, configuration,
  coordination, etc.
• NSF has proposed Extensible TeraScale Facility
• Joint between ANL, Caltech, NCSA, PSC, and SDSC
• PSC Alpha-based TCS1 as test case for
  heterogeneity, extensibility
• Transformation of 4-site internal mesh network
  to extensible hub-based hierarchical network
• First Chicago-to-LA lambda on order
• Expect to order 2nd lambda in July, 3rd and 4th
  in September
• Initial definitions being developed
• Batch_runtime
• Data_intensive_on-demand_runtime
• Interactive_runtime
• Makefile Compatibility service
• Merging Grid, Cluster, and Supercomputer
  Center cultures is challenging!
