Pulmonary

1

• Pulmonary
• Manifestations of
• Aspergillosis
• Mutaz Labib, MD
• MHRI
• January 18, 2006

2
ASPERGILLOSIS

• Aspergilloma. (Fungus ball)
• ABPA. (Hypersensitivity)
• Aspergillus necrotizing bronchitis.
• endo-bronchial mass, obstructive pneumonitis,
  collapse, hilar mass.
• Invasive Pulmonary Aspergillosis.
• Angioinvasive/ hemorrhagic infarcts.
• Airway invasive-obstructing.

3
Saprophytic Aspergillosis
(Aspergilloma )

• Most common cause A. fumigatus 80-90 , then
  A.flavus, A.terreus, A.niger.
• Microscopic features of A fumigatus.
• High-power photomicrograph can show the
  conidiophores with the characteristic head
  appearance and minute spores.
• Medium-power photomicrograph shows septate hyphae
  branching and angulations.

4
(No Transcript)
5
(No Transcript)
6
  Saprophytic Aspergillosis
(Aspergilloma )

• Review of 60.000 CXR indentified 0.01
  prevelance.
• Infection without tissue invasion.
• Solid rounded mass, some times mobile.
• Fungal hyphae mixed with mucus and cellular
  debris within a preexistent pulmonary cavity or
  ectatic bronchus .
• If peripheral, Pleural thickening is
  characteristic.
• Mass is usually seperated from the cavity wall.

7
(No Transcript)
8
(No Transcript)
9
Saprophytic Aspergillosis
(Aspergilloma )

• Clinical findings could be non-specific.
• Some patients may remain asymptomatic.
• Most frequent symptom is HEMOPTYSIS 75.
• Less commonly chest pain, dyspnea , malaise.
• Wheezing and fever (could also be secondary to
  underlying disease, or bacterial super infection
  of the cavity or aspergilloma itself).

10
Aspergilloma

• The most common predisposing factors are
  tuberculosis and sarcoidosis.
• Other conditions that occasionally may be
  associated with aspergilloma include bronchogenic
  cyst, pulmonary sequestration, and pneumatoceles
  secondary to Pneumocystis carinii pneumonia in
  patients with (AIDS) .
• Bronchiectasis, ankylosing spondylitis, neoplasm.

11
Aspergilloma

• Tuberculosis is the most frequently associated
  condition.
• Aspergilloma with history of tuberculosis. May
  show multiple irregular fungus balls virtually
  filling the pulmonary cavity

12
(No Transcript)
13
Aspergilloma

• Radiography
• Presence of a solid, round or oval mass with
  soft-tissue opacity within a lung cavity.
• Mass is separated from the wall of the cavity by
  an airspace of variable size and shape "air
  crescent" sign seen in thin section CT
  (mediastinal window).
• Other causes of the air crescent sign include
  angioinvasive aspergillosis, echinococcal cyst,
  and, rarely, tuberculosis, lung abscess,
  bronchogenic carcinoma, hematoma, and P carinii
  pneumonia.

14
Aspergilloma

• Aspergillomas are often associated with
  thickening of the cavity wall and adjacent
  pleura.
• Pleural thickening may be the earliest
  radiographic sign before any visible changes are
  seen within the cavity.
• Associated scarring in lung lobes.
• Aspergillomas are usually single, they may also
  be present bilaterally.
• Change in position.

15
(No Transcript)
16
(No Transcript)
17
Aspergilloma

• Mobile aspergilloma
• The aspergilloma usually moves when the patient
  changes position .
• Chest CT scans obtained with the patient supine
  and prone show a change in the position of the
  aspergilloma within a pulmonary cystic cavity.

18
(No Transcript)
19

• Mobile aspergilloma within a pulmonary cystic
  cavity in a 43-year-old man. Chest CT scans
  obtained with the patient supine (a) and prone
  (b) show a change in the position of the
  aspergilloma. A fumigatus was discovered at
  bronchoscopy. (Courtesy of Josep M. Mata, MD,
  Unidad Diagnóstica de Alta Tecnología, Sabadell,
  Spain.)

20
Aspergilloma

• Approximately 10 of mycetomas resolve
  spontaneously.
• Reversibility of the pleural thickening upon
  resolution of intracavitary fungal material
  suggests that the thickening of the cavity wall
  and pleura is due to a hypersensitivity reaction.

21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Aspergilloma

• Treatment
• In asymptomatic patients, No therapy needed.
• Medical therapy with bed rest, humidified oxygen,
  cough suppressant, and postural drainage is
  helpful in cases of mild hemoptisis.
• Surgical resection is indicated for patients with
  severe life-threatening hemoptysis.
• Selective bronchial artery embolization can be
  performed in those with poor lung function.

26
Aspergilloma

• Antifungal therapy
• Patient is not a candidate for surgery
• Concomitant tissue invasion
• Itraconazole with some help
• Ampho B for invasive component.
• Newer Azoles, Voriconazole , Posaconazole , and
  Ravuconazole.Their role is not clear.
• Antibiotics for bacterial superinfection.

27
Hypersensitivity Reaction (Allergic
Bronchopulmonary Aspergillosis)

• ABPA is seen most commonly in patients with
  long-standing bronchial asthma (7-14) or CF (6)
  .
• Characterized by the presence of plugs of mucus
  containing Aspergillus organisms and eosinophils.

• This results in bronchial dilatation typically
  involving the segmental and sub segmental
  bronchi.

28
Allergic Bronchopulmonary Aspergillosis

• ABPA is caused by a complex hypersensitivity
  reaction to Aspergillus organisms.
• The fungi proliferate in the airway lumen ,
  producing a constant supply of antigen.
• A type I hypersensitivity reaction with IgE and
  IgG release occurs.
• Immune complexes and inflammatory cells are then
  deposited in the bronchial mucosa.
• Production of necrosis and eosinophilic
  infiltrates (type III reaction) with bronchial
  wall damage and bronchiectasis.



29
Allergic Bronchopulmonary Aspergillosis

• Excessive mucus production and abnormal ciliary
  function lead to mucoid impaction.
• Many patients cough up thick mucous plugs in
  which hyphal fragments can be demonstrated at
  culture or histologic analysis.
• Acute clinical symptoms include recurrent
  wheezing, malaise with low-grade fever, cough,
  sputum production, and pleuritic chest pain.
• Patients with chronic ABPA may also have a
  history of recurrent pneumonia.

30
Allergic Bronchopulmonary Aspergillosis

• Radiologic manifestations
• Homogeneous, tubular, finger-in-glove areas of
  increased opacity in a bronchial distribution,
  usually predominantly involving the upper lobes.
• Band like opacities related to plugging of
  airways by hyphal masses with distal mucoid
  impaction and can migrate from one region to
  another.
• Occasionally, isolated lobar or segmental
  atelectasis may occur.

31
Allergic Bronchopulmonary Aspergillosis

• In later stages central bronchiectasis and
  pulmonary fibrosis develop.
• CT findings in ABPA consist primarily of mucoid
  impaction and bronchiectasis involving
  predominantly the segmental and sub segmental
  bronchi of the upper lobes .
• In approximately 30 of patients, the impacted
  mucus has high attenuation or demonstrates frank
  calcification at CT.

32
(No Transcript)
33

• .

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
Allergic Bronchopulmonary Aspergillosis

• Diagnostic criteria
• Asthma.
• Immediate skin reactivity to Aspergillus.
• Serum precipitins to A fumigatus.
• Total serum IgE gt1.000 ng/ml
• Current or previous pulmonary infiltrates.
• Central Bronchiectasis.
• Peripheral Eosinophilia.

38
Allergic Bronchopulmonary Aspergillosis

• Stages /Patterson et all
• Stage 1 ( Acute stage)
• Stage 2 ( Remission stage)
• Stage 3 ( Exacerbation stage)
• Stage 4 ( Steroid dependent stage)
• Stage 5 ( Fibrotic stage)

39
Allergic Bronchopulmonary Aspergillosis

• Treatment
• Oral corticostroids, relief of bronchospasm,
  clearing of pulmonary infiltrates and decrease
  IgE levels( 0.5 mg/kg/d for 2 wks then taper).
• Most patients require prolonged low dose therapy.
• Itraconazole low dose(200 mg bid for 16 weeks)
  can Help in 50 reduction of corticosteroid dose.
  With no significant toxicity.

40
Allergic Bronchopulmonary Aspergillosis

• Syndromes Related to ABPA
• Mucoid Impaction
• Without asthma, mucus plug lead to
  atelectasis. Usually presents with cough.
• Bronchocentric Granulomatosis.
• Necrotizing granulomas, obstruct and destroy
  bronchiols . Eosinophilic inflamatory infiltrate
  and fibrosis with no tissue or vascular invasion
  by aspergillus, almost always asthmatics with
  persistent cough and high IgE levels. good
  response to corticosteroids.

41
Allergic Bronchopulmonary Aspergillosis

• Eosinphilic pneumonitis
• Rarely caused by aspergillus, cough dyspnea
  and fever with peripheral pulmonary infiltrate,
  diagnosis made by biopsy, good response to
  corticosteroids.
• Hypersesitivity pneumonitis
• Extrinsic allergic alveolitis, intense
  repeated inhalation of thermophilic bacteria,
  fungi, bird excreta, and chemical agents causes
  hypersensitivity granulomatous inflamation of
  distal airway disease.

42
Semi-invasive (Chronic Necrotizing) Aspergillosis

• Fungus is intermediate.
• No vascular invasion.
• Tissue necrosis and destruction.
• Granulomatous inflammation similar to that seen
  in reactivation tuberculosis.
• Usually no previous cavity, vs presence of cavity
  in non-invasive form.
• May occur with mild immunosuppression.

43
Semi-invasive (Chronic Necrotizing) Aspergillosis

• Predisposing factors
• Chronic debilitating illness, Advanced age.
• Alcoholism, Malnutrition.
• DM, CF, COPD.
• Prolonged steroid therapy, Radiation therapy.
• Inactive TB.
• Pneumoconiosis.
• Sarcoidosis.

44
Semi-invasive (Chronic Necrotizing) Aspergillosis

• Symptoms
• Often insidious and include chronic cough, sputum
  production, fever, and constitutional symptoms.
• Hemoptysis has been reported in 15 of affected
  patients .
• May manifest with chronic bronchitis and
  recurrent episodes of mild hemoptysis.

45
Semi-invasive (Chronic Necrotizing) Aspergillosis

• In patients with COPD, may manifest with
  non-specific clinical symptoms such as cough,
  sputum production, and fever lasting more than 6
  months.

46
Semi-invasive (Chronic Necrotizing) Aspergillosis

• Radiologic manifestations
• Thin-section CT scan (lung window) shows
  unilateral or bilateral rounded segmental areas
  of consolidation with or without cavitation or
  adjacent pleural thickening,
• Multiple nodular areas of increased opacity .
• The findings progress slowly over months or
  years.

47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
Semi-invasive (Chronic Necrotizing) Aspergillosis

• Diagnosis Criteria
• Clinical and Radiologic features
• Isolation of Aspergillus species by culture from
  sputum, bronchoscopic or percutaneous samples.
• Exclusion of other conditions

55
Semi-invasive (Chronic Necrotizing) Aspergillosis

• Treatment
• Antifungals should be initiated once the
  diagnosis is made. IV Ampho B, Itraconazole is
  also effective.
• Surgical resection for healthy individuals with
  good lung reserves, not tolerating antifungals or
  where antifungals are ineffective in setting of
  active disease.

56
Invasive Pulmonary Aspergillosis (IPA)

• Major risk factors.
• Prolonged neutropenia gt3 wks or neutrophil
  dysfunction.
• Corticosteroid therapy (prolonged, high dose).
• Transplantation (Lung and BM )
• Hematologic malignancy( leukemia)
• Cytotoxic therapy.
• AIDS.

57
(No Transcript)
58
Airway-invasive Aspergillosis

• The presence of Aspergillus organisms deep to the
  airway basement membrane.
• It occurs most commonly in immunocompromised
  neutropenic patients and in patients with AIDS.
• Clinical manifestations include acute
  tracheobronchitis, bronchiolitis, and
  bronchopneumonia.

59
Airway-invasive Aspergillosis

• Patients with acute tracheobronchitis usually
  have normal radiologic findings.
• Occasionally, tracheal or bronchial wall
  thickening may be seen.
• Bronchiolitis is characterized at HRCT by the
  presence of centrilobular nodules and branching
  linear or nodular areas of increased attenuation
  having a "tree-in-bud appearance.

60
Airway-invasive Aspergillosis

• The centrilobular nodules have a patchy
  distribution in the lung.
• Aspergillus bronchopneumonia results in
  predominantly peribronchial areas of
  consolidation.
• Rarely, the consolidation may have a lobar
  distribution.

61
(No Transcript)
62
(No Transcript)
63
Airway-invasive Aspergillosis

• Centrilobular nodular areas of increased opacity
  similar to those seen in Aspergillus
  bronchiolitis have been described in a number of
  conditions, including endobronchial spread of
  pulmonary tuberculosis, Mycobacterium
  avium-intracellulare, and viral and mycoplasma
  pneumonia.
• The radiologic manifestations of Aspergillus
  bronchopneumonia are indistinguishable from those
  of bronchopneumonias caused by other
  micro-organisms.

64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
Airway-invasive Aspergillosis

• Obstructing bronchopulmonary aspergillosis
• noninvasive form of aspergillosis.
• Characterized by the massive intraluminal
  overgrowth of Aspergillus species.
• Usually A fumigatus, in patients with AIDS .
• Affected patients exhibit cough, fever, and new
  onset of asthma.
• Patients may cough up fungal casts of the bronchi
  and present with severe hypoxemia.

68
Airway-invasive Aspergillosis

• CT findings in obstructing bronchopulmonary
  aspergillosis
• Mimic those in allergic bronchopulmonary
  aspergillosis.
• Bilateral bronchial and bronchiolar dilatation.
• large mucoid impactions (mainly lower lobes).
• Diffuse lower lobe consolidation caused by
  postobstructive atelectasis.

69
(No Transcript)
70
Angioinvasive Aspergillosis

• Angioinvasive aspergillosis occurs almost
  exclusively in immunocompromised patients with
  severe neutropenia.
• For many reasons, however, there has been a
  substantial increase in the number of patients at
  risk for developing invasive aspergillosis.

71
Angioinvasive Aspergillosis

• These reasons includes
• Development of new intensive chemotherapy
  regimens for solid tumors.
• Difficult-to-treat lymphoma, myeloma, and
  resistant leukemia.
• Increase in the number of solid organ
  transplantations.
• Increased use of immunosuppressive regimens for
  other autoimmune diseases.

72
Angioinvasive Aspergillosis

• Despite having a normal neutrophil count,
  affected patients have functional neutropenia
  because the function of the neutrophils is
  inhibited by the use of high-dose steroids.
• Invasion and occlusion of small to medium-sized
  pulmonary arteries by fungal hyphae.
• This leads to the formation of necrotic
  hemorrhagic nodules or pleura-based, wedge-shaped
  hemorrhagic infarcts.

73
Angioinvasive Aspergillosis

• Characteristic CT findings
• Nodules surrounded by a halo of ground-glass
  attenuation "halo sign or pleura-based,
  wedge-shaped areas of consolidation.
• These findings correspond to hemorrhagic
  infarcts.
• In severely neutropenic patients, the halo sign
  is highly suggestive of angioinvasive
  aspergillosis.

74
Angioinvasive Aspergillosis

• However, a similar appearance has been described
  in a number of other conditions.
• Infection by Mucorales and Candida.
• Herpes simplex and cytomegalovirus.
• Wegener granulomatosis, Kaposi sarcoma , and
  hemorrhagic metastases .

75
Angioinvasive Aspergillosis

• Separation of fragments of necrotic lung from
  adjacent paren-chyma results in air crescents
  similar to those seen in mycetomas.
• The air crescent sign in angioinvasive
  aspergillosis is usually seen during
  convalescence (ie, 23 weeks after initiation of
  treatment and concomitant with resolution of the
  neutropenia).

76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
(No Transcript)
80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
Angioinvasive Aspergillosis

• Diagnosis
• The clinical diagnosis is difficult, and the
  mortality rate is high.
• Positive culture Methanamine silver, PAS
• BAL 97 specific. But less sensitive.
• Chest CT findings, Halo sign, Cresent sign.
• Open or thoracoscopic lung biopsy is the gold
  standard.

86
Invasive Pulmonary Aspergillosis (IPA)

• Galactomannan Antigen
• Polysaccharide cell wall component.
• ELISA test.
• Approved for detection of IPA in pts who receive
  chemotherapy or Transplant.
• In these group of pts it has 67-100 sensitivity
  and 86-98.8 specificity.
• Can precede the clinical diagnosis by 6-14 day.

87
Invasive Pulmonary Aspergillosis (IPA)

• Treatment
• Start empiric therapy ASAP, when diagnosis
  suspected.
• Most commonly used medicine Ampho B 0.6 1.2
  mg/kg/d , in severly immunocomromized 1 -1.5
  mg/kg/d.
• Duration depends on the period of
  immunosuppression. response 20-83.

88
Invasive Pulmonary Aspergillosis (IPA)

• Other treatment options
• Itraconazol 200-400 mg/d , 39 response.
• Could be used in less immunocompromised.
• Late stage therapy after initial control of Ampho
  B.
• Combination therapy , no great efficacy.
• Caspofungin ,recently approved medicine.
• Voriconazole, Posaconazole.

89
Invasive Pulmonary Aspergillosis (IPA)

• Voriconazole vs Ampho B, (391 pt randomized ).
• Succesfull response rate

• 49.7 for Vorico arm, 27.8 for Ampho B.
•
  Herbrecht et al, NEM 347 408 (2002).
• Caspofungin, 70 favorable response in pulm.
  disease for salvage therapy, daily dose.
• Ampho B Caspo ,
• Vori Caspo, combination better out come.
•
  marr et al, clin inf . Dis 2003.

90
Invasive Pulmonary Aspergillosis (IPA)

• Surgical resection
• Massive hemoptysis.
• Localized lesion.
• Continuing immunosuppression.
• Further immunosuppressive therapy.
• Outcome is poor in BMT, Pt on mechanical
  ventilation and those who have multiple foci of
  infection.

91
Invasive Pulmonary Aspergillosis (IPA)

• Outcome of therapy
• Early diagnosis.
• Recovery of underlying host defense defect.
• Resolution of neutropenia,
• Taper of immunosupressive therapy.
• Disease limited to the lung.

92
Summary

• Aspergillosis is a serious complication that is
  frequently seen in immunocompromised patients.
• The radiologist plays a major role in the
  diagnosis of pulmonary Aspergillus infection.
• When radiographic findings are subtle or
  equivocal, CT frequently allows identification of
  the disease process.

93
Summary

• In the appropriate clinical setting, familiarity
  with the thin-section CT findings may suggest and
  even help establish the specific diagnosis in
  various types of pulmonary aspergillosis .
