Now we get into more complex modeling!
2
And now will take up

• COVER
• APPLYING BOOLEAN LOGIC
• SOME EXAMPLES OF NON-BOOLEAN PROBLEM SOLVING

3
Cover

• NOT available in the modeler but is in the
  calculator
• It is essentially an UPDATE tool.
• An img with a window of zero value is placed
  over another img.
• The data under the window comes through and into
  the resulting file WITH the stuff outside the
  window

4
Cover
1
0
Unacceptable areas in Black
over
When slope overlaid on perc rate get combined
unacceptable areas BECAUSE 1s in perc rate came
thru the window of 0s in slope image
get
5
Cover
First covers second
6
What is COVER used for!

• For finding areas acceptable or unacceptable
• For UPDATING an image.
• Something has changed and you need to edit part
  of your image
• make a binary mask (zero where new data goes)
• multiply times old data
• OVERLAY this image on top of new data
• This is basically the hard way to do it

7
The process
MAKE WINDOW
X OLD DATA

COVER
8
Booleans

• We have covered the use of Boolean images to do
  things like site selection using
• AND, OR, XOR, NOT
• That is not the only way to do things!
• Here are some alternatives

9
ADD the Booleans

• In what way is the addition of the 4 binary
  levels better for decision making?
• In what way is it not so good?

10
How is this better?
11
How is this better?
111 area where all 3 criteria are good 101 AOK
SOK criteria are good
111
101
110
12
A Decimal System for Coding

• Our Ski Slope Example
• 1. Number of cells that simultaneously meet my
  criteria.
• 2. Prefer Steep slopes
• 3. Prefer Forested landuse over Forest403

13
Prioritization again

• Locating building sites
• View of water
• Slope preference
• Road preference

14
Possible combinations
15
More possible combinations
16
Always Boolean

• NO
• Here are two non Boolean models

17
Example 1

• Lands best suited for making Growing coffee
  beans
• Work from bottom up
• Notice that the units for each map work ( if they
  dont you have a problem!)

18
COFFEE
Not every thing is Boolean!
19
COFFEE
Not every thing is Boolean!
20
COFFEE
Not every thing is Boolean!
21
COFFEE
Not every thing is Boolean!
22
COFFEE
Not everything is Boolean!
23
CORN

• Different technique to select the best areas to
  grow corn

24
Example 2

• Find the best place to grow corn
• Start from middle this time
• Note that this analysis is all based on CLASSED
  data

25
CORN
Another non-Boolean idea.
26
CORN
27
CORN
28
CORN
29
CORN
30
CORN
31
Summary

• Cover is a very useful function when you need it
• But it is not available in the modeler
• Only in Calculator and Overlay
• You dont always have to use logic functions with
  Booleans!
• Booleans are not the solution to all problems!

32
Review of Exercise 6

• Part 1 is similar to Ex53
• Have to use Extract and Assign
• Coding for ranking
