Pro64: Performance Compilers For IA64

1
Pro64 Performance Compilers For IA-64

• Jim Dehnert
• Principal Engineer
• 5 June 2000

2
Outline

• IA-64 Features
• Organization and infrastructure
• Components and technology
• Where we are going
• Opportunities for cooperation

3
IA-64 Features

• It is all about parallelism
• at the process/thread level for programmer
• at the instruction level for compiler
• Explicit parallel instruction semantics
• Predication and Control/Data Speculation
• Massive Resources (registers, memory)
• Register stack and its engine
• Software pipelining support
• Memory hierarchy management support

4
Structure

• Logical compilation model
• Base compilation model
• IPA compilation model
• DSO structure

5
Logical Compilation Model
6
Base Compilation Model

7
IPA Compilation Model

8
DSO Structure

9
Intermediate Representation

• IR is called WHIRL
• Common interface between components
• Multiple languages and multiple targets
• Same IR, 5 levels of representation
• Continuous lowering as compilation progresses
• Optimization strategy tied to level

10
Components

• Front ends
• Interprocedural analysis and optimization
• Loop nest optimization and parallelization
• Global optimization
• Code generation

11
Front ends

• C front end based on gcc
• c front end based on g
• Fortran90/95 front end

12
IPA

• Two stage implementation
• Local gather local information at end of front
  end process
• Main analysis and optimization

13
IPA Main Stage

• Two phases in main stage
• Analysis
• PIC symbol analysis
• Constant global identification
• Scalar mod/ref
• Array section
• Code layout for locality
• Optimization
• Inlining
• Intrinsic function library inlining
• Cloning for constants, locality
• Dead function, variable elimination
• Constant propagation

14
IPA Engineering

• User transparent
• Additional command line option (-ipa)
• Object files (.o) contain WHIRL
• IPA in ld invokes backend
• Integrated into compiler
• Provides information to loop nest optimizer,
  global optimizer, and code generator
• Not disabled by normal .o or DSO object
• Can analyze DSO objects

15
Loop Nest Optimizer/Parallelizer

• All languages
• Loop level dependence analysis
• Uniprocessor loop level transformations
• OpenMP
• Automatic parallelization

16
Loop Level Transformations

• Based on unified cost model
• Heuristics integrated with software pipelining
• Fission
• Fusion
• Unroll and jam
• Loop interchange
• Peeling
• Tiling
• Vector data prefetching

17
Parallelization

• Automatic
• Array privatization
• Doacross parallelization
• Array section analysis
• Directive based
• OpenMP
• Integrated with automatic methods

18
Global optimization

• Static Single Assignment is unifying technology
• Industrial strength SSA
• All traditional optimizations implemented
• SSA-preserving transformations
• Deals with aliasing and calls
• Uniformly handles indirect loads/stores
• Benefits over bit vector techniques
• More efficient setup and use
• More natural algorithms gt robustness
• Allows selective transformation

19
Code Generation

• Inner loops
• IF conversion
• Software pipelining
• Recurrence breaking
• Predication and rotating registers
• Elsewhere
• Hyperblock formation
• Frequency based block reordering
• Global code motion
• Peephole optimization

20
Technology

• Target description tables (targ_info)
• Feedback
• Parallelization
• Static Single Assignment
• Software pipelining
• Global code motion

21
Target description tables

• Isolate machine attributes from compiler code
• Resources functional units, busses
• Literals sizes, ranges, excluded bits
• Registers classes, supported types
• Instructions opcodes, operands, attributes,
  scheduling, assembly, object code
• Scheduling resources, latencies

22
Feedback

• Used throughout the compiler
• Instrumentation can be added at any stage
• Explicit instrumentation data incorporated where
  inserted
• Instrumentation data maintained and checked for
  consistency through program transformations

23
SSA Advantages

• Built-in use-def edges
• Sparse representation of data flow information
• Sparse data flow propagation based on SSA graph
• Linear or near-linear algorithms
• Every optimization is global
• Transform one construct at a time, customize to
  context
• Handle second order effects

24
SSA as IR for optimizer

• SSA constructed only once at set-up time
• Use-def info inherently part of SSA
• Use only optimization algorithms that preserve
  SSA form
• Transformations do not invalidate SSA info
• Full set of SSA-preserving algorithms
• No SSA construction overhead between phases
• Can arbitrarily repeat a phase for newly
  exposed optimization opportunities
• Extended to uniformly handle indirect memory
  references

25
Software Pipelining

• Technology evolved from Cydra compilers
• Powerful preliminary loop processing
• Effective minimization of loop overhead code
• Highly efficient backtracking for scheduling
• Integrated register allocation, interface with CG

• Integrated with LNO loop nest transformations

26
Global Code Motion

• Moves instructions between basic blocks
• Purpose balance resources, improve critical
  paths
• Uses program structure to guide motion
• Uses feedback or estimated frequency to
  prioritize motion
• No artificial barriers, no exclusively-optimized
  paths

27
Where are we going?

• Open source compiler suite
• Target description for IA-64
• Available via usual Linux distributions and
  www.oss.sgi.com
• Beta version in June
• MR version when Intel ships systems
• OpenMP for c/c (later)
• OpenMP extensions for NUMA (later)

28
Areas for collaboration

• Target descriptions for other ISAs
• real or prototype
• Additional optimizations
• Generate information for performance analysis
  tools
• Extensions to OpenMP
• Surprise me

29
