Title: Management


1
Management
2
Shadow Copies
3
What problems does VSS solve?
  • For Data
  • An application can modify a file while it is
    being backed-up causing data corruption, or cause
    an file open error
  • For Backup Applications
  • No easy way for applications to describe their
    data to backup apps.
  • Excessive number of APIs to deal with.
  • For Data Mining or Transport
  • Very expensive for SQL to calculate a
    point-in-time for analysis.

4
What are the possible solutions?
  • Stop the applications for the duration of the
    backup. BAD!
  • Skip opened files during the backup
  • Sorry, did you want that file? BAD!
  • Use Shadow Copies!
  • Freeze the app
  • Make a Shadow Copy of the data
  • Thaw the app
  • Transport it where you like
  • Back it up, or
  • Use it for analysis and reporting

5
Volume Shadow Copy Service
  • What Is It?
  • Known in the industry as Snapshots
  • Infrastructure for creating a point-in-time copy
    of a single volume or multiple volumes
  • Appears static, even though the original data is
    changing

Data is written to the disk
Write some data
t0
t1
t2
Backup the static shadow copy while
Create a shadow copy
6
Shadow copy architecture
  • Dont copy everything
  • Only copy what changes since the snapshot
  • Can be done as a (volume or file) filter or in
    hardware
  • Proven technology
  • 30 years old on IBM mainframes
  • 3rd party open file backup solutions

7
Persistent Shadow Copies
  • New Feature for Windows Server 2003
  • Allows users to see network folder contents at
    points-in-time in the past
  • Customer Scenarios
  • Accidentally Deleted - User can NOW recover
    files THEMSELVES
  • Forgot to Save as - User can NOW recover files
    that were accidentally overwritten
  • Allow sanity checking while working on documents
  • No more restore from tape for just one file
  • Not a replacement for Archive or Business Recovery

8
DEMO Shadow Copies
9
Disaster Recovery (ASR)
  • Disaster
  • Physical destruction of the computer system
    (fire, earthquakes, etc.)
  • Catastrophic hardware failure (especially
    storage devices)
  • Recovery
  • Restore hardware configuration, base OS
  • Restore user data as a separate process

10
(old) Manual System Recovery
  • User (administrator) gets new hardware
  • User installs Windows
  • User configures all physical storage to their
    original settings
  • User installs backup-and-restore application,
    backup media drivers
  • User recovers operating system
  • User reboots and adjusts services
  • User restores data

11
What Is Automated System Recovery?
XP, Windows Server 2003 Bring a non-bootable
system quickly to a state from which a restore
can be performed re-configure physical storage to
its original state restore the OS, applications
and all settings
Backup App Install Media (Optional)
Data backup Media
Windows CD
On-Line
Retail Media
ASR B/U Media
Provides a mechanism for third-party vendors to
incorporate ASR-related features
ASR Floppy
ASR Floppy
12
Target System Requirements
  • Hardware must be identical as original system,
    except hard disks, video cards and NICs
  • Enough disks to restore all the Critical System
    Disks
  • Storage capacity of each critical disk must be gt
    corresponding original disk. Disk geometries
    must be compatible
  • ASR state file (asr.sif) must be accessible
    through a local floppy drive
  • Copy kept in repair directory

13
Starting ASR
  • Normally need a floppy drive
  • ASR restore not networkable/remotable
  • The ASR process can be completely automated with
    the use of a RIS server
  • No floppy required
  • No F2 to start ASR
  • Uses PxE boot
  • Whitepaper in preparation

14
ASR and Clusters
  • Backup
  • On each node, stores configuration info about
    local and all shared disks
  • ASR each node separately
  • Restore
  • While restoring the first node, all shared disks
    are restored (Lone-wolf up and running)
  • For other nodes, only local critical disks will
    be restored

15
Windows System Resource Manager
16
What Does WSRM Do?
  • Allows an administrator to set application
    resource consumption policies (CPU and memory)
  • Select processes to be managed
  • Set resource consumption targets or limits
  • Manage machine resources according to policies
  • CPU utilization (percent CPU)
  • Process working set size (physical resident
    pages)
  • Committed memory (page table and page file usage)
  • Apply policies based on a date/time schedule
  • Generate, store, view and export accounting
    records
  • Generate email notification for events

17
Consolidate with WSRM
  • Single or multiple important LOB apps with other
    apps or services
  • ltYour Appgt SQL 7 SQL 2000 Exchange 2000
    BizTalk Server Commerce 2000 Server
  • Large Terminal Server system managing users
  • Managing user or group resource usage
  • Managing user or group application resource usage
  • Multiple SQL Server instances
  • Multiple departmental database server machines
    consolidated as separate SQL Server instances
    running on a single machine
  • Manage resource usage of individual IIS6 App
    pools on a server
  • SQL Server, IIS and Exchange running on the same
    machine
  • Set separate resource policies for each

18
WSRM Feature
19
Process Matching Criteria(PMC)
  • Used to identify processes for management and
    accounting
  • Select processes by matching any part of the
    command used to start the process
  • Path to executable (e.g. C\Program
    Files\Microsoft SQL Server\MSSQLInstance1\Binn)
  • Filename of executable (sqlservr.exe)
  • Command line options/parameters (e.g. -d
    mydatafile)
  • Regular-expressions may be used to implement
    complex matching
  • Select processes by matching the user account
    that started the process
  • User name of the account
  • Group name that the user is a member of
  • Exclusion rules reduce the set of matches

20
Percent CPU Targets
  • Allocation rules are applied to matching
    processes
  • Processes are identified and grouped using
    Process Match Criteria
  • CPU specifies how much CPU bandwidth is given to
    the processes
  • All processes not matched by an active selection
    rule go into the default group and share the
    unallocated resources
  • CPU Allocations may be divided into
    sub-allocations
  • Sub-allocations (also a ) divide an allocations
    CPU
  • For example allocation A might have
    sub-allocation A1 with 40 who has sub-allocation
    A11 with 40. Effectively, then A11 actually has
    16 of As allocation
  • Processes in the global exclusion list are not
    managed
  • Built-in system exclusion list contains processes
    that should not be managed
  • User exclusion list is available (empty to start)
  • WSRMs 100 means 100 of CPU not used by
    excluded processes

21
Percent CPU Targets (advanced)
  • Top level allocations divide the resources of the
    whole machine
  • Advanced users may assign a CPU affinity to their
    allocations
  • Indiscriminate use of CPU affinity can lead to
    complex over-allocations of processors
  • Default group is also managed
  • Resources not consumed by a process will be
    reallocated
  • Goes first to the enclosing allocation
  • If the enclosing allocation is unable to consume
    it, then it goes to sibling allocations
  • If sibling allocations are unable to consume it,
    the kernel scheduler will allocate to any thread
    that is able to consume it

22
Default Management
  • WSRM manages processes as groups, so CPU
    bandwidth target applies to the group of
    processes
  • When a group contains more than one process WSRM
    applies default management
  • Default management also applies to the default
    group
  • Always equal by process
  • Built-in policy WSRM Default Policy places
    every process into the default group
  • Provides runaway process protection out of the
    box
  • Provides reasonable management even when there is
    no user policy active

23
Real Memory Management
  • An advanced property of a resource allocation
  • For cases where CPU bandwidth targets are not
    effective due to application memory consumption
    patterns
  • Allows administrator to specify upper limit on
    the applications working set size
  • Prevents working set growing beyond upper limit
  • Uses kernel functions for setting limits on a
    process working set size
  • Limits are automatically applied by WSRM via
    calls to Get/SetProcessWorkingSetSizeEx() function

24
Committed Memory Mgmt
  • An advanced property of a resource allocation
  • For cases where apps behave poorly (e.g. leak
    memory)
  • Policy specifies an upper limit on the committed
    memory consumed by a process
  • Committed memory cannot be taken back by the OS
  • Policy also identifies an intervention action for
    processes that reach the limit
  • Generate a notification (event log)
  • Terminate the offending process

25
Resource Allocation Policies
  • Resource Allocation Policy allocates resources to
    sets of processes
  • Sub-divides all of the managed resources of the
    machine
  • Order of allocation rules within the policy
    determines order of process matching
  • Many policies may be defined, however only one
    can be in effect at a given time
  • Resource Allocation Policies can be scheduled or
    manually activated
  • Manual activation turns off calendar management

26
Scheduling Policies
  • Two scheduling models supported
  • Day-based schedules
  • Calendar events
  • All scheduled items have a priority that removes
    conflicts
  • Default calendar policy applies if calendar is
    active but nothing is scheduled
  • Any policy may be selected for calendar default

27
Job Accounting Records
  • Process resource counters are periodically
    sampled
  • Accounting records are generated and stored on a
    slower interval (10 minutes, modifiable)
  • No separate database required, WSRM implements a
    database in the service
  • Accounting records include
  • User, domain, file name/path, Process Matching
    Criteria and Resource Allocation name
  • PID, Process start time, end time
  • Resource Statistics kernel time, total CPU time,
    handles, thread count, I/O bytes, etc.
  • Full-featured retrieval UI
  • Aggregate, sort and filter columns
  • Move/hide display columns
  • Save and load views
  • Export formats tab-delimited, .CSV, and SMF

28
WSRM Service
  • Written in C, runtime check prevents running on
    anything but WS3 Datacenter and Enterprise
    Editions
  • WSRM service polls system, examines CPU usage of
    processes by Process Match Criteria
  • Base priority of managed processes is dynamically
    modified
  • On a busy system with CPU-bound processes,
    consumption matches allocations closely
  • Allocation above what a group is able to consume
    (for any reason) will be reallocated to other
    groups in same proportion as defined in the
    policy
  • CPU resource above what all groups are able to
    consume is allocated via the normal kernel
    scheduler algorithm

29
WSRM User Interfaces
  • Supported on Win2K and later OSs (32-bit only,
    until Whidbey release of VS.NET)
  • Both GUI and CLI written in C, managed code
  • Installs .NET Framework redist on Win2K and XP
    Pro
  • GUI is an MMC snap-in
  • CLI supports all of the GUI functionality
  • This is the current automation model
  • User interfaces communicate with the WSRM service
    on managed machines via DCOM protocol
  • Service implements the DCOM interface

30
Limitations
  • No 64-bit client support until Whidbey (64-bit
    VS.NET, released first on Longhorn)
  • Does not manage key system services (including
    itself). This is by design.
  • Unable to manage processes being managed by other
    RM tools
  • Proccon, ESS or other Job Object oriented tools
  • Aurema, or other process-oriented tools
  • Does not manage other types of memory resources
  • AWE memory/Large page memory/Locked memory
  • OS Pool memory (paged or non-paged)
  • Does not manage I/O

31
WSRM How To
32
How To Manage Applications
  • Create Process Match Criteria (PMC) to identify
    and group processes
  • Create WSRM Resource Allocation Policies
  • Create a policy and add allocation rules
  • Assign CPU or memory to groups created by Process
    Match Criteria
  • Activate a policy
  • Manually select a policy to activate
  • Create schedules that activate desired policies
    at the desired dates/times
  • Monitor results
  • Use resource monitor (or PerfMon) to view WSRM
    performance counters
  • Examine event log or turn on notification for
    significant events
  • Review accounting records
  • WSRM stores records of process resource
    consumption
  • Full-featured retrieval interface for researching
    application behavior and management

33
Process Match Criteria (PMC)
  • Give it a name (e.g. SQL-Instance1)
  • Match any part of the command used to start the
    process
  • Match the user account that started the process
  • User name of the account
  • Group name that the user is a member of
  • Add exclusion rules that reduce the set of
    matches
  • Logical combinations of multiple criteria

34
Resource Allocation Policy
  • Give it a name (e.g. SQL-Instance1-Weekday)
  • Add resource allocations to the policy
  • Select a PMC to manage (e.g. SQL-Instance1)
  • Give it an allocation (e.g. 40 CPU, 20Mb working
    set)
  • Repeat for other desired allocations within the
    policy
  • Resource allocation list provides matching order
  • Resource allocation policy controls the entire
    machine
  • Only a single policy is in control at a time
  • Processes that dont match receive remaining
    resources
  • Exclusion list names processes that WSRM will not
    manage

35
Activating Policies
  • Option 1 manually set the active policy through
    the UI
  • Policy will stay in effect until manually changed
    via the UI
  • Option 2 schedule the policy
  • Outlook model schedule the periods in which to
    use each policy
  • Schedule model create a 24-hour template and
    assign it to days on the calendar

36
Monitor/Manage WSRM
  • Use accounting UI to examine job accounting
    history
  • Aggregate, sort and filter columns in the
    accounting database
  • Proper matching of processes to policies
  • Allocation targets not being met
  • Export accounting data into other reduction tools
  • CSV, tab-delimited, SMF formats supported
  • Use Resource Monitor GUI to watch WSRM counters
  • View in context with other performance counters
    in the system (OS or app counters)
  • Monitor managed machines event log for
    unexpected behavior
  • Generate email or SMTP notifications of
    unexpected error or warning conditions

37
Release Information
  • Timing
  • Shipped at WS3 RC2
  • Two previous alpha releases (OEM only)
  • WSRM final release ships with WS3 final release
  • WSRM is not built-in to Windows Server 2003
  • Separate CD, separate install
  • Only Enterprise and Datacenter Editions (32 and
    64 bit)
  • WSRM CD will ship with OS CD in all distribution
    channels
  • Correct platform is verified at install and
    startup
  • Administrative UIs are supported on back level
    platforms
  • W2K (all SKUs)
  • XP Professional
  • WS3 (all 32-bit SKUs)
  • WSRM will be fully integrated into next major
    Windows release

38
For More Information
  • Download WSRM collateral
  • http//www.microsoft.com/windows.netserver/downloa
    ds/wsrm.mspx

39
DEMO WSRM
40
Management Tools andTroubleshooting
41
Agenda
  • Management Tool Strategy
  • New tools for Windows Server 2003
  • What is the Support Tools folder?
  • WMIC new management command line interface
  • Automating management tasks
  • Headless Server Management
  • Troubleshooting

42
Management Tools Strategy
Manageability Methods
Out of band
Remote Console
Remote GUI
Automated/preset
  • Cmd Line /
  • Simple scripting
  • WMIC
  • Para-programming/ Complex scripting
  • EMS (Remote Serial)
  • Terminal Server
  • MMC
  • Web Admin
  • Policy
  • RIS
  • Automated setup

Command Line Tools Program
  • Programmer or sophisticated admin
  • Build your own tools or complex scripts
  • Win32 APIs
  • COM Objects
  • WMI ADSI interfaces for scripting
  • Admin focused
  • Pre-built .exe
  • Pre-built .vbs
  • Batch files
  • Redirection / Piping
  • WMIC adds extensibility

43
Web Interface for Remote Admin
44
Windows Command Line Program
  • Command Shell Usage Scenarios
  • Manage a local computer
  • Remotely manage a computer
  • Telnet to a remote computer run tools
  • Use scripting/batch to automate management

45
Windows Command Line Program
Goal provide tools to improve admin experience
for data center scenarios non-gui, automated,
remoteable
  • Provide tools in the box for all admin tasks
  • Document common admin tasks, scenarios current
    tools
  • Add key Resource Kit PSS Support tools to
    product
  • Build missing tools for tasks w/o command line
    capabilities
  • Better online documentation and education
  • Improved online help for cmd line A-Z list
    (ntcmds.chm)
  • New Resource Kit scripting book show how to
    script w/ tools
  • Make tools more consistent discoverable
  • Provide both power and simplicity from the
    command line as an alternative to GUI management

46
Command Line Standards
  • Consistent, standard syntax with /? Help
  • Run under Telnet and Terminal Services
  • Support Stdin, Stdout, Stderr, Error codes
  • Leverage WMI providers whenever possible
  • Remote machine (\\UNC) management capability
  • Allow alternate credentials on remote connections
  • 1many capable via batch or WSH programming
  • Support redirection of output, automation linking

47
Telnet Services
  • Built into all Windows Server products
  • Command line access to remote systems
  • Can manage almost any part of the OS
  • Low overhead on target devices
  • Good for managing individual machines
  • Can execute batch files or character mode scripts
    (cscript.exe) for automation
  • Uses NTLM authentication by default
  • Microsoft is testing all new command line tools
    to ensure they run under Telnet

48
Top New Command Line Tools
  • New Task Scheduling tool - SchTasks.exe, full
    automation of task scheduling, replaces AT.exe
  • Shutdown.exe reboot reason collector version
    logs shutdown/restart data (reliability)
  • SC.exe service controller tool, manage
    start/stop/diagnose all Win32 services
  • 6 New print tools - Prn.vbs (WMI based)
  • New get/set machine name feature added to
    NetDom.exe, renames machines in domains only
  • NetSH.exe has new network diagnostics tools,
    from Windows ME product

49
Top New Command Line Tools
  • GPResult - Group Policy tool, uses new WMI based
    RSOP provider to show policy status
  • 4 Performance Log Tools - LogMan, ReLog,
    TypePerf, TraceRpt, manage perfmon data
  • 3 Event Log Tools EventQuery, EventCreate,
    EventTriggers (execute script when triggered)
  • 6 AD mgmt tools DSQuery, DSGet, DSAdd, DSMod,
    Dsmove, DSRm (delete) for Users, Computers,
    Domains objects in DCs
  • 2 disk management tools Diskpart.exe (for
    partioning) and FSutil.exe for file system
    management

50
WMIC
  • WMI Command Line Interface
  • New tool only available on XP Pro Windows
    Server 2003 SKUs
  • Access various sources of mgmt data via WMI
    without programming
  • Get information from a local computer, remote
    computer and from multiple computers in a single
    command

51
Using WMIC
  • Two ways of using a. C\gt wmic process
    (scripting/batch) b. wmicroot\cligt process
    (interactive)
  • Examples of interactive mode gt OS get name,
    locale, bootdevice gt OS where namesun call
    shutdown gt /node_at_MyOrg os get /all
    /formathtable

52
WMIC Examples
  • PRODUCTS
  • path win32_ltnamespacegt
  • path win32_processor get MaxClockSpeed
  • process where (processIDgt300) list brief
  • /node"computer1","computer2
  • Process Where Description"WinLogon.exe" Get
    VirtualSize /EVERY5
  • SERVICE WHERE CAPTION'TELNET' CALL STARTSERVICE
  • NICCONFIG WHERE index1 CALL EnableStatic
    ("10.0.0.2"),("255.0.0.0")
  • NICCONFIG WHERE index1 CALL SetGateways
    ("10.0.0.8","10.0.0.9"),(1,2)

53
WMIC Complex Example
  • NTEVENT WHERE "eventtypelt3 AND logfile'Applicatio
    n'" GET Logfile, SourceName, Eventtype, Message,
    TimeGenerated /FORMAT"htable-sortby.xsl""datatyp
    enumber""sortbyEventType" gt c\applicationlogs.
    htm

54
Automating WMIC Example
  • WMIC /NODE_at_"c\MyServerList.txt" SERVICE WHERE
    caption "SSDP Discovery Service"
    CALL ChangeStartMode "Disabled"
  • MyServerList.txt


Server1 Server6 Server2 Server7 Server3
Server8 Server4 Server9 Server5 .
55
Automating Management Scripting, Batch and other
tools
56
Scripting Capabilities
  • No major technology changes in Windows Server
    2003 ? other than WSH 5.6
  • Greatly enhanced online docs with accurate
    features, definitions, etc.
  • New Windows Server 2003 ResKit book will
    contain extensive chapter on batch file
    capabilities
  • If you need UNIX shell type features use the
    Services For UNIX product
  • Many shells (korn, etc.)
  • Many utilities (awk, grep, etc)
  • Allows UNIX shell scripts to run on Windows
  • http//www.microsoft.com/WINDOWS2000/sfu/default.a
    sp

57
Windows Script Host (WSH)
  • CSCRIPT.exe for character mode
  • WSCRIPT.exe for GUI output
  • Either host runs all script languages Visual
    Basic Scripting Edition, JScript, 3rd party
    tools,
  • Windows 2000 Resource Kit contains many sample
    scripts see Supplement 1 version on
    www.reskit.com
  • Scripts can leverage the OS management
    infrastructure (WMI, ADSI, COM objects, etc.)
  • Many new tools written in VBscript

58
WSH 5.6
  • Remote support (DCOM)
  • FunctionName CommandLine,MachineName
  • ex. Execute "c\foo.ws \\machine2
  • Command line process integration
  • object.Exec (strCommand, bWaitOnReturn)
  • Piping to scripts - ex. dir filter.vbs
  • SAFER Windows support
  • Windows File Protection for OS scripts
  • Digital Signature Signing
  • See msdn.microsoft.com/scripting for more info

59
For More Information
  • Online Help files
  • A-Z cmd reference - ntcmds.chm
  • Support tool help file - suptools.chm
  • Use c\gtHH helpfilename.chm to launch from cmd
  • WSH, VBScript JScript -
  • http//msdn.microsoft.com/scripting
  • Windows Resource Kit
  • http//www.reskit.com
  • Command Line Newsgroup
  • microsoft.public.Win2000.cmdprompt.admin
  • Management Infrastructure
  • http//www.microsoft.com/management

60
DEMO Tool a linea di comando e WMI
61
Features Components
62
End to End Scenario
Corporate Servers, Desktops and Laptops with the
Automatic Updates Client
63
Questions ?
Write a Comment
User Comments (0)
About PowerShow.com
