The Tree Data model

1
The TreeData model
2
Why Trees ?

• Convenient for representing many problem
  domains.
• Efficient representation for large sets,
• the linear organization (list), with running
  time of T(n) O(n), is prohibitive.
• Binary Search Trees can be used to handle data
  with running time of T(n) O(lg n)on
  average, for most operations.
• EX
• Linear search O(n)
• Binary search O(lg n), but insert/delete O(n)
• BST search, insert, delete O(n)

3
Basic Terminology

• Trees are sets of points called nodes and lines
  connecting nodes called edges.
• The nodes and edges satisfy the following
  properties
• One node is distinguished, called root ( r ). The
  root has no parent.
• Every node other than the root has a parent, and
  a single one.
• The tree is connected.
• For every node v of the tree, there is a unique
  pathfrom r to v.

r
v
4
Recursive definition of a Tree

• Base
• An empty tree is a tree
• Induction
• let T1,T2,Tn be a set of trees with distinct
  nodes as roots r1,r2,,rn,
• let a be a new node.
• construct edges (a, r1), (a, r2),,(a, rn)(make
  a the parent of the roots of T1,.,Tn).The
  resulting graph is a tree with root a.

5
More Terminology

• Path in a tree a sequence of nodes
• length of a path of edges on the path
• Ancestor and Descendant
• parent and child
• Subtree
• Leaves and interior-node
• Height of a node x - length of the longest path
  from x to a leaf. (all leaves at height
  0)
• Height of a tree - height of the root
• Depth of a node n - length of the path from the
  root (root at depth 0)
• Degree of a node

depth 0
depth 1
depth 2
6
Think Recursively

• Computing the height of a tree is complex without
  recursion.
• The height of a tree is one more than the maximum
  of the heights of the subtrees.

HR1
HL1
HR
HL
7
Routine to Compute Height

• Handle base case (empty tree)
• Use previous observation for other case.
• public static int Height( TreeNode T )
• if( T null )
• return -1 // Why???
• else
• return 1 Max(Height(T.Left),Height(T.Rig
  ht))

8
Running Time

• This strategy is a postorder traversal
  information for a tree node is computed after the
  information for its children is computed.
• Postorder traversal running time is N times the
  cost of processing each node.
• The running time is linear because we do constant
  work for each node in the tree.

9
Ordered Trees

• Ordered tree - (to the left of..)
• A tree with a linear ordering on the children of
  each node. (left to right).
• Defines a total order between siblings
• Defines a total order between nodes not on the
  same path to the root.Ex Defines an order
  between all leaves

Ex Not the same trees
z
y
y
x
z
x
g
d
h
a
c
e
f
g
a
c
b
h
b
d e f
10
Unordered Trees

• Unordered tree

Ex the same trees
z
y
y
x
z
x
g
d
h
a
c
e
f
g
a
c
b
h
b
f d e
11
Labeled Trees
Associates a label (value) with each node.
Example Expression Trees, representing
arithmetic expressions. Just as expressions can
be defined recursively, so can the corresponding
labeled tree.





3
5
2
5
3
5
2
5
35
25
(35) (25)
12
Example
((57)(34))3


3


4
3
5
7
13
A Common Tree ApplicationDirectory Structure
\usr
\avner
\moshe
\leah
\books
\classes
\junk
lecture1.ppt
lecture1.ppt
Example of a labeled tree
14
Tree traversal
Example Printing the directory tree
public void listDirectory(int depth) printname(
depth) // print name of directory or file if
(isDirectory) for each file f in this directory
(i.e., for each child) f.printDirectory(depth1
)
An example of a preorder traversal.
15
Directory Structure
\usr \Moshe \classes
lecture1.ppt lecture2.ppt \junk
\books \Avner \Leah
16
Tree traversal
Example Printing file sizes (also evaluating
expression trees)
\usr 3
\avner 1
\moshe 8
\leah 1
\books 1
\classes 10
\junk 1
lecture2.ppt 20
lecture1.ppt 3
17
Tree traversal
Printing file sizes
public int size( ) int totalSize
sizeOfThisFile( ) if ( isDirectoty ) for
each file f in this directory totalSize
f.size( ) return totalSize
Postorder traversal
18
Tree traversal
Postorder traversal
lecture1 20 lecture2 13 \classes
33 \junk 1 \books 1 \moshe
35 \avner 1 \leah 1 \usr 37
19
Data Structures for Trees
20
Dynamic Representation Array of pointers
array contains object or pointer to object array
of pointers to children
..
..
..
..
..
..
..
..
Array of references - allow access to child in
O(1)
Class TreeNode Class Tree - a reference to
a TreeNode
21
Dynamic Representation Left Child /Right
Sibling
tree
tree
parent pointer ( root (node with parent
pointer null) )
Use linked list to represent siblings - access in
O(i)
22
Left Child, right sibling
public class TreeNode private Object
data private TreeNode lson private TreeNode
rsibling ..
public class TreeNode private Object
data private TreeNode lson private TreeNode
rsibling private TreeNode parent ..
23
Binary Trees
24
Binary Tree Recursive Definition
Base a single node is a binary tree.
(!!) Induction if T1 and T2 are binary
trees, then so is T
T2
T1
T
25
Binary Tree
A binary tree is an ordered , positional tree
T1
T2
T2
T1
Different binary trees
Five different binary trees with 3-nodes
Same ordered, different positional
Worst case binary trees
26
Data structures for binary trees

• Use a dynamic structure with pointers to left
  and right sons

class TreeNode private Object data private
TreeNode left private TreeNode
right .. class Tree TreeNode
root .
27
Example Labeled Binary Trees

• Expression trees (tree representation of
  arithmetic expressions)
• An expression tree is a labeled binary tree
  defined as follows
• Base
• a single operand is an expression, represented by
  a single node, labeled by the operand.
• Induction
• if E1, E2 are expressions represented by labeled
  binary trees T1 and T2, then E1 E2 is
  represented by the following tree

T1
T2
28
Recursive traversal of binary trees
// preorder traversal void preorder( ) print
data if (left ! null) left.preorder (
) if (right ! null) right.preorder ( )
// postorder traversal void postder( ) if
(left ! null) left.postorder ( ) if (right
! null) right.postorder ( ) print data

// inorder traversal void inorder( ) if (left
! null) left.inorder( ) print data if
(right ! null) right.inorder( )
29
Binary Trees Representation
public class TreeNode private Object data
private TreeNode left private TreeNode
righ public void preorder() ..
public void inorder() . public void
postorder() ..
30
Example Expression trees
What will we get if we perform a postorder
traversal preorder traversal inorder
traversal of the following expression
tree ???


3


4
3
5
7
31
Complete, Full and Perfectbinary trees
A binary tree T is full, if each node in T is
either (a) an internal node with
2-children (b) a leaf
full
not full
A binary tree is complete, if it is filled from
left to right, a level at a time.
Complete but not full
not full and not complete
32
The Full Binary Tree Theorem
The number of leaves in a non-empty, full
binary tree is one more than the number of
internal nodes
Proof induction on the of internal
nodes.
33
Number of Nodes versus Height of a Complete
Binary Tree
n lt 20 21 22 2h (2h1 -
1)/(2-1) 2h1 - 1
20
21
sum 20 21 2h -2sum -
21 - - 2h - 2h1 n(1-2) lt (20 - 2h1)
22
23
n lt 2h1 - 1 and ngt 2h - 1
