A Global Channel Exchange

1
A Global Channel Exchange

• May 17, 1999

2
Novell and Citrix Integration Readiness

• Roy Lopez, Senior SE, rlopez_at_novell.com
• Bruce Huber, Senior SE, bruceh_at_citrix.com
• Arlo Paranhos, SE, arlop_at_citrix.com

.
3
Agenda

• I. It Works!
• II. Citrix Synergy with NDS and ZENworks
• III. How to...
• a. The Basics
• b. Domainless Load Balancing (no PN)
• c. PN w/ NDS for NT
• d. ZENworks for Enterprise Application
  Distribution
• IV. Q A

4
I. Novell/Citrix Integration Progress

• Citrix moved code out of GINA into WinLogon.exe
• All Novell NT Clients Since Oct 98 are
  Multi-user Aware
• TSE SP4 includes additional apis
• Upcoming Update (B9CSP1.exe) to the Novell Client
  will allow selective access to Terminal Logon
  Path and Terminal Profile Path variables
• Next version of NWAdmin/Console1 will include TSE
  profile path and home dir gui as well as config
  button info

5
I. What Is democity.novell.com?
Publicly Accessible Citrix Server
Farm Demonstrate Directory- enabled Solutions
Built by Novell and partners Web-based training
6
I. Whats behind Democity?
7
II. Citrix Synergy with NDS and ZENworks
8
II. ZENworks Capabilities

• Application Management
• Software Metering
• Desktop policies and profiles
• Printer driver mgmt.
• Location Profiles
• Remote control
• Helpdesk interface
• Y2k Testing

9
II. Benefits of Integration

• Admins gain access to NWAdmin and now have a
  single solution to administer desktops and
  thin-clients
• Users get same look and feel on fat and
  thin-clients
• When used with NetWare 5, no IPX is needed
• Novells ZENworks and NDS for NT further decrease
  the costs of administering the networks with
  thin-client servers

10
II. ZENworks Features in WinFrame Integration

• Application management
• Novell Application Launcher (NAL) 2.7 or higher
  is recommended
• Software Metering
• Desktop maintenance
• Remote control of terminal server
• Help request system
• Desktop managementWorkstation Manager 1.0
• Dynamic local user
• Path to Microsoft policy and profile
• Automatic client update

11
II. ZENworks features WTS/MetaFrame Integration

• Application management
• All of the WinFrame features
• Desktop maintenance
• All of the WinFrame features
• Desktop management - Workstation Manager 1.1
• All the 1.0 features plus...
• Microsoft policy and profile management in NDS
• Printer and printer driver management
• Client configuration
• Desktop preferences
• Login restrictions
• Hardware inventory

12
III. How to...

• a. The Basics
• b. Domainless Load Balancing
• (no PN)
• c. PN w/ NDS for NT
• d. ZENworks for Enterprise
• Application Distribution

13
IIIa. Novell Client Integration

• MetaFrame
• Requires Novell Client v4.5 for Windows NT or
  later
• Best Case
• TSE SP4
• Novell NT Client 4.6 SP1
• At Least one NetWare 5 server
• NDS for NT 2.01 (on separate NT DC)
• ZENworks 2.0 (1.1 w/update)
• WinFrame
• For WinFrame v1.7, apply Hot Fix SE17B058
• Hot Fix integrated into WinFrame v1.8
• Requires Novell NT Client v4.11b
• Apply SE17B093 (NW5)

14
IIIb. Server Farms without Domains

• How do I Load Balance Citrix without deploying NT
  domains?
• Install Novell Client v4.5 for Windows NT or
  higher
• Create a ZENworks user policy package and enabled
  dynamic local user
• Publish application through thin-client server
  utilities
• Modify registry
• Place the server name in the LocalGroupList
  instead of the domain name
• Null the GroupList
• Export registry hive from initial server for
  published application then import hive to each
  server in the load-balanced farm
• Thats all there is to it

15
IIIb. Deploying Citrix Server Farms without NT
Domains

• By default the GroupList registry key contains
  the name of the NT domain

16
IIIb. Deploying Citrix Server Farms without NT
Domains

• Simply null the GroupList key and input the
  server name\Users in the LocalGroupList registry
  key on each server in the server farm

17
IIIb. Deploying Citrix Server Farms without NT
Domains
Under the application that has been published
enter the name of each server in the server farm
under the ServerList registry key.
18
IIIb. Deploying Citrix Server Farms without NT
Domains
Create a registry key for each server in the
server farm with the InitialProgram and Work
Directory values.
19
IIIb. How Does Dynamic Local User Function?

• Within NDS administrators create a ZENworks
  policy that grants users access to specific NT
  workstations and servers
• As users authenticate to NDS the DLU policy is
  read to identify the workstations and access
  level that has been granted to the user through
  NDS
• ZENworks dynamically creates the user an account
  on the NT workstation or Server

20
IIIb. How To Setup Dynamic Local User Policy?
NT user account is created using NDS credentials
Through NDS you can define NT group member-ships
and create custom groups
User account can be volatile or non-volatile
21
IIIc. Integrating PN using NDS for NT

• With NDS for NT v2
• Not supported on multi-user NT
• Recommended configuration is to configure the
  thin-client servers as member servers, not
  PDC/BDC
• Only IPX Support
• With NDS for NT v2.01
• Installing MetaFrame and Windows Terminal Server
  on the same server as NDS for NT will be
  supported
• Pure IP Supported

22
IIIc. NDS for NT Components

• Single DLL goes on each NT PDC, BDC
• directs domain info to NDS database instead of
  Domain database
• reduced hardware costs because of NDS fault
  tolerance
• NT Domain Object Snap-ins reflect domains as
  objects in NWAdmin
• NT Client for NDS communications

23
IIIc.NT Server Domain architecture
24
IIIc. NDS for NT redirection
25
IIIc. Publish Apps to NDS User Accounts

• NDS for NT redirects the PAM samsrv.dll call to
  the NDS name space

26
Case Study Brunswick Outdoor Recreation Group

• Previous Client Environment
• No Novell services/technologies deployed
• Majority Windows 95 desktops
• No centralized configuration
• Drive mappings and printer connections all done
  locally on workstation (persistent mappings
  performed at logon)
• Microsoft Windows networking-based
• Windows NT Server
• Windows NT SNA Server
• Windows NT Print Servers

27
Todays Customer Environment

• MetaFrame servers deploying server farm doing
  load balancing without NT domains
• Microsoft Windows Terminal Server (application
  servers)
• Citrix MetaFrame and load-balancing software
  (clustering of application servers)
• NetWare, Novell Directory Services, and ZENworks
• User profile and policy management, dynamic local
  user creation, desktop preferences, printer
  definitions, and creation
• Published Novell Application Launcher
• End user presented with NAL windows onlynot
  entire desktop
• End user TCP/IP accessno IPX/SPX

28
Frequently Asked Questions

• How do I manage the different users contexts
  with the thin-client products?
• Contextless login is the best solution
• Can only be used with MetaFrame and WTS since it
  requires the Novell Client v4.5 for Windows NT
  and NetWare 5
• Location profiles
• Can only be used with MetaFrame and WTS since it
  requires the Novell Client v4.5 for Windows NT
• In the intraNetWare Client v4.11b for Windows NT
  (WinFrame solution) the context/username pair is
  stored per server once the user has successfully
  authenticated to the network

29
Frequently Asked Questions (cont.)

• Why are the WinFrame/MetaFrame profile path and
  home directory settings not read when the Novell
  Client for Windows NT is installed?
• Novell in working with both Microsoft and Citrix
  have jointly resolve this issue
• Does the thin-client solution integrate with NDS
  for NT? Yes
• It is recommended from Novell, Microsoft, and
  Citrix that the thin-client servers not be
  configured as PDCs or BDCs
• Required for Program Neighborhood

30
Current Novell Technical Information Docs (TIDs)

• 2945422 Current Novell Client Versions
• 2943151 Novell Client w/MS Terminal Server
  Summary
• 2943813 NDS4NT and a BDC with MetaFrame
• 2943961 Citrix MetaFrame and Context Issues
• 2950353 First Login cant Launch NAL on MetaFrame
• 2950750 Citrix Patch required to login to NW5
  Servers
• 2947624 4.11b Client-WinFrame cant login
  remotely (SE17B074)
• 2946246 Novell Server Locking up with Citrix
• 2950815 Previously logged in User
• For more information visit www.novell.com/product
  s/nds/zenworks/thinclient.html
• www.democity.com
• support.novell.com
• www.citrix.com/support
• www.novell.com/passport

31
(No Transcript)
32
Continuing WorldWide Through August 99
