DOS Attacks

1
DOS Attacks

• Laxmikant Patil
• Ashish Khurange

2
Overview

• What are DoS (Denial of Service) attacks?
• Other types of Attack
• DoS Attack Classification
• Popular DoS attacks
• Attack Description
• Intrusion Detection System (IDS) signature
• Prevention

3
What are DoS attacks?

• DoS Denial of Service attacks
• Attacks intended to consume the resources of a
  remote system, thereby denying or degrading
  service to legitimate users.
• Easier to accomplish than remotely gaining
  administrative access, hence very common on the
  Internet.
• e.g. Ping of death, Teardrop, smurf

4
Other types of Attack

• viruses, Trojan Horses, worms
• Viruses
• propagates itself by infecting other programs on
  the same computer
• Can not spread to a new computer without human
  assistance (floppy, sent e-mails)
• Worm
• A worm is also a program that propagates itself
• Unlike a virus, however, a worm can spread itself
  'automatically e.g. blaster_worm

5
Blaster worm

• W32.Blaster.Worm is a worm that exploits the DCOM
  RPC vulnerability.
• Port 135 is used for RPC.
• An infected node starts scanning network for open
  port 135.
• Sends data on TCP port 135 that may exploit the
  DCOM RPC vulnerability.
• creates a hidden remote shell process that will
  listen on TCP port 4444, used to issue remote
  commands on an infected system.

6
Blaster worm (cont.)

• Worm listens on UDP port 69. Port 69 is TFTP
  (Trivial FTP) port.
• When the worm receives a request from a computer
  on port 69, it will send msblast.exe to that
  computer and tell it to execute the worm.
• And thus the other end gets infected.

7
Other types of Attack (cont.)

• Trojan Horses
• programs that appear desirable, but actually
  contain something harmful
• looks like a free game, but when you run it, it
  erases every file in that directory
• trojan's contents could also be a virus or worm

8
Cost of DoS attacks
DoS most expensive computer crime
9
DoS Attack -Classification
Attacker
DNS Server
DBs
Firewall Router Load
Balancer
WEB Servers
Source students.cs.tamu.edu/kam2959
10
DoS Attack -Classification

• System Attacked
• Firewall, Router, Load Balancer, WEB Server,
  DBs
• Part of the System (Resource) Attacked
• Network Card, CPU, Storage, kernel buffer
• Bandwidth consumption
• Attack will consume all available n/w bandwidth
• Programming flaws
• Failures of applications or OS components to
• handle exceptional condition (protocol loop
  holes)

11
Popular DoS attacks

• Win Nuke Attack
• Land Attack
• Ping-of-Death Attack
• Smurf Attack
• Fraggle Attack
• PinPong Attack
• TCP-SYN Flood
• Teardrop

12
Win Nuke attack

• WinNuke was the first DoS attack.
• Port 139 All "File and Printer Sharing" on a
  Windows machine runs over this port.
• Can affect only Windows 95 and NT.
• Works by sending "Out of Band" data to port 139
  of the target host.
• Out of band is sent by setting URG pointer in TCP
  header.

13
Win Nuke attack (cont.)

• The reason is program accepting the packets
  doesn't know how to appropriately handle Out Of
  Band data. So, it crashes.
• Port 445 The SMB (Server Message Block)
  protocol is used for file sharing in Windows
  NT/2000/XP. TCP port 445 which is used for SMB
  over TCP.
• New version of WinNuke has surfaced recently, and
  it can affect Windows NT, 2000, XP, and even
  .NET. A malformed Server Message Block (SMB)
  packet is sent to port 139 or 445, brings the
  system down.

14
Win Nuke attack

• IDS signature
• Destination port 139 or 445
• URG pointer set in TCP header.
• Prevention
• Block traffic intended to port 139, 445 at
  firewall.
• If you are not using file sharing services block
  ports 135, 445.

15
Land Attack

• Sends a packet where
• source IP addr port dest IP addr port
• If the attack is launched against a TCP port that
  is actually listening, then it can
• prevent further legitimate connections for
  approximately 30 seconds.
• Or very high CPU utilization.
• Or will hang indefinitely and must be physically
  reset.

16
Land (cont.)

• List of OS found vulnerable to Land attack.
• AIX 3
• AmigaOS AmiTCP 4.2 (Kickstart 3.0)
• BeOS Preview Release 2 PowerMac
• BSDI 2.0
• BSDI 2.1 (vanilla)
• FreeBSD 2.2.5-RELEASE
• HP External JetDirect Print Servers
• IBM AS/400 OS7400 3.7
• IRIX 5.2
• IRIX 5.3
• MacOS MacTCP
• MacOS 7.6.1 OpenTransport 1.1.2
• MacOS 8.0
• NetApp NFS server 4.1d
• NetApp NFS server 4.3

17

• Novell 4.11
• OpenBSD 2.1
• OpenVMS 7.1 with UCX 4.1-7
• QNX 4.24
• Rhapsody Developer Release
• SCO OpenServer 5.0.2 SMP
• SCO OpenServer 5.0.4
• SCO Unixware 2.1.1
• SCO Unixware 2.1.2
• SunOS 4.1.3
• SunOS 4.1.4
• Windows 95 (vanilla)
• Windows 95 Winsock 2 VIPUPD.EXE
• Windows NT (vanilla)
• Windows NT SP3
• Windows NT SP3 simptcp-fix
• Now it is noticed that both Windows XP SP2 and
  Windows Server 2003
• remain susceptible to an eight-year-old LAND
  attack.

18
Land attack (cont.)

• IDS signature
• dest IP source IP
• dest port source port
• Prevention
• Eliminate packets at firewall whose source IP is
  set to some of internal IP address.

19
Ping-of-Death Attack

• Sending a packet of size gt 64 KB can cause lot of
  systems to reboot, crash or hang.
• Size of IP packets can be up to 64 KB.
• Packets that are bigger than the MTU are
  fragmented into smaller packets, which are then
  reassembled by the receiver.

20
Ping-of-Death (cont.)

• At the receiver side the node can not process the
  packet untill it gets all the fragments. So, it
  has to buffer all the fragments.
• Now if the kernel uses 16 bit variable to store
  packet size and 64 KB buffer to store packet, by
  sending packet greater than 64 KB, it results
  into buffer 16 bit variable overflow.

21
Ping-of-Death (cont.)

• IDS signature
• For any fragment offset length gt 64 KB

22
Smurf Attack

• The attacker sends ping requests directed to a
  broadcast address, with the source address of the
  IP datagram set to the address of the target
  system under attack.
• All systems within the broadcast domain will
  answer back to the target adress, thus flooding
  the target system with ICMP traffic and causeing
  network congestion.

23
Smurf Attack (cont.)

• Traffic amplification strength to the attack is
  given by the amplification factor provided by all
  affected syetms in the broadcast domain.
• Systems with limited network resource may
  generate a large amount of network traffic
  towards sophisticated sites.
• If there are N nodes in broadcast domain, then an
  attacker with bandwidth equal to 1/N of targets
  bandwidth can bring down the target.

24
Smurf Attack (cont.)
Broadcast address 10.129.127.255
Attacker
Send Ping request to broadcast with source
address 10.129.22.35
Target 10.129.22.35
25
Smurf attack (cont.)

• IDS signature
• Any node sending ping broadcast request more than
  some threshold within a time window.
• Prevention
• At firewall eliminate all ping request to
  broadcast address.

26
Fraggle Attack

• Fraggle is UDF amplification attack.
• In this attack victim ports are the ports that
  generate some charcter strings such as chargen,
  time, daytime, echo etc.
• In fraggle attack a spoofed UDP packet is send to
  the chargen port on a target system with the
  source address set to broadcast address.
• On receving this packet, the target starts
  sending 512 bytes of randomized character data to
  all the nodes in the broadcast domain, causing
  bandwidth cosumption.

27
Fraggle Attack
Broadcast address 10.129.127.255
Send UDP packet with source IP
10.129.127.255 Destination IP
10.129.22.35 Destination port 19
Target 10.129.22.35
Attacker
28
Fraggle attack (cont.)

• IDS signature
• Any packet with source addr broadcast addr
• And UDP port chargen, echo, daytime, time etc.
• Prevention
• At firewall block packets with source address as
  broadcast address.
• If you are not using some UDP services then block
  those ports.

29
PingPong Attack

• This attack uses basic functionality of two ports
  echo port chargen port.
• In this attack the attacker sends a malformed UDP
  packet to chargen port of target A, with source
  address of target B and source port as echo.
• Now the target A sends random character string to
  echo port of target B. Target B replies it back
  to chargen port of target A. This sequence run
  infinitely between target A and B. Consuming
  bandwidth and processing power of targets.

30
PingPong Attack
Attacker Send UDP packet with Source IP
10.129.30.10 Source port 7 Destination IP
10.129.22.35 Destination port 17
Target A 10.129.22.35 Port 19 (chargen)
Target B 10.129.30.10 Port 7 (echo)
31
PingPong Attack (cont.)

• Imagine a scenario where attacker sends malformed
  UDP packet to chargen port of target node with
  source address set to broadcast address and
  source port set to echo.
• Very large traffic will be generated in the
  network, entire bandwidth of network will be
  consumed.
• This effect will be like chain reaction.

32
PinPong Attack
Broadcast address 10.129.127.255
Attacker Send UDP packet with Source IP
10.129.127.255 Source port 7 Destination IP
10.129.22.35 Destination port 19
Target 10.129.22.35
33
PingPong attack (cont.)

• IDS signature
• Any communication between two hosts using chargen
  and echo port.
• Prevention
• If you are not using chargen, daytime, time, echo
  ports block these ports.

34
TCP SYN Flood

• Based on 3 way handshake of TCP connection.
• Attacker sends TCP SYN packet with spoofed source
  IP address to target system.
• Now the target replies back with SYN / ACK
  packet. But as the source IP of request is
  spoofed, it wont get ACK back.
• It results in to half open connections.
• Now the kernel has limited data structure to
  store information about half open connections.
• Because of this attack that data structure
  overflows.

35
TCP SYN flood (cont.)
0
31
Victim 10.129.22.35
Attacker send packet with IP addr 10.129.13.13
Imaginary node with IP 10.129.13.13
36
TCP SYN attack (cont.)

• IDS signature
• Number TCP SYN packets directed to a node greater
  than threshold within a time window.

37
References

• DoS attack resource page http//www.denialinfo.com
  /
• MIT IDS attack DB http//www.denialinfo.com/

• http//www.insecure.org/sploits_all.html
• http//pintday.org/whitepapers/dos-smurf.shtml
