WEB SERVICES

1
WEB SERVICES

• DAVIDE ZERBINO

2
Summary

• Introduction
• Definition
• Web Service Model
• Web Service Architecture
• Web Service in action
• Advantages
• Web Service Development Lifecycle
• Tools
• References

3
Introduction

• A Software Service is a something that accepts
  digital requests and returns digital responses
  e.g. C function, a Java Object

• A computer application can be thought of as a
  well-orchestrated set of services

• Web Services are a new breed of software
  component that is a language, platform, and
  location indipendent

• Is accessible over the web
• Web services are an abbrevation for Web of
  Services

• Distributed applications will be assembled from a
  web of software services

4
Web Service

• Is registred and can be located through a Web
  service registry.
• Communicate using XML message over standard Web
  protocols.
• Support loosely-coupled connections between
  systems.

5
Definition of Web Service

• A Web service is an interface that describes a
  collection of operations that are
  network-accessibile through standardized XML
  messaging.

Heather Kreger IBM Software Group
6
The Web Services Model

• The Web service architecture is based upon the
  interactions between three roles

7
The Web Services Model

• Others element are

Service
8
The Web Services Model

• Others element are

9
The Web Services Model

• The interactions involve the publish, find and
  bind operation

10
The Web Service Stack
11
The Network
Web services must be network-accessible

• HTTP is the standard network protocol for
  internet-available Web Services

• Others network protocols are SMTP, FTP and for
  intranet domain MQSeries, CORBA

12
XML-based Messaging

• Represent the use of XML as the basis for the
  messaging protocol

• The current industry standard for XML messaging
  is SOAP

• IBM, Microsoft, Sun and others submitted SOAP to
  the W3C

• SOAP (Simple Object Access Protocol)
• Is a simple and lightweight XML-based mechanism
  for exchanging structured data beetween network
  applications

13
SOAP

• Lightweight communication protocol
• For communication between applicationsone-way,
  request/response, multicast, etc..
• Designed to communicate via HTTP
• Not tied to any component technology
• Not tied to any programming language
• Based on XML
• Simple and extensible

14
SOAP

• SOAP consists of three parts
• An envelope that defines a framework for
  describing what is in a message
• A set of encoding rules for expressing istances
  of application-defined data types
• A convention for representing remote procedure
  calls and responses

15
SOAP
1
4
2
3
16
Service DescriptionFrom XML to Web services

• Service provider comunicates all the
  specifications through service description

• The service description combined with SOAP
  infrastructure hides details as platform,
  programming language from the service
  requestrors application and the service
  providers Web Service

• Web service uses WSDL for base-level service
  description

17
WSDL

• WSDL Web Service Definition Language

• is an XML-based language used to define Web
  Services and describe how to access them

• Industry standard W3C

18
Discovery and PublicationUDDI

• Stands for Universal Description, Discovery and
  Integration
• Defines a way to publish and discover information
  about web services
• Collaboration between Microsoft, IBM, Ariba that
  resulted in the creation of web service registry
• Not standard

19
UDDI

• Defines a data structure standard for
  representing service description information in
  XML
• The core component of the UDDI project is the
  UDDI business registration, an XML file used to
  describe a business entity and its Web services

20
UDDI

• The UDDI Business Registry can be used at a
  business level
• To check whether a given partner has particular
  Web service interfaces.
• To find companies in a given industry with a
  given type of services.
• To locate information about how a partner or
  intended partner has exposed a Web service in
  order to learn the technical details required to
  interact with that service

21
WSFL Overview

• Web Service Flow Language (WSFL) is an XML
  language for the description of Web Services
  Composition
• It is possible to produce web services by
  composing web services
• Intra-enterprise web services might collaborate
  to present a single Web Service Interface to the
  public
• Web services from different eneterprises might
  collaborate to perform business to business
  transactions
• Service Flow described how service-to-service
  communications, collaborations and flows are
  performed.

22
WSFL Overview

• Composition of Service
• Flow Model execution sequence of activities
• Global Model Interactions of services
• Recursive Composition scalability
• It is layered on the top of Web Services
  Description Language(WSDL) that is used for
  description of service interface and their
  protocol bindings

23
Web Service in Action B2B
Customer
Supplier
Credit Bureau
Warehouse
24
Advantages

• Interoperability
• Any web services can interact with any other web
  service

• Ubiquity
• Web services communicate using HTTP and XML.

• Low Barrier to Entry
• The concepts behind web services are easy to
  understand and toolkits are frely available from
  many vendors

• Industry Support
• All the major vendor are supporting SOAP and the
  surrounding web services standards

25
Web Services Development Lifecycle

• The development lifecycle can have four phase
• BUILD
• development and testing of the web service
  implementation
• definition of the services interface description
• definition of the service implementation
  description
• DEPLOY
• publication of the services interface and service
  implementation
• RUN
• The web service is available for invocation
• The web service is fully deployed, operational
  and network-accessible from the services provider
• Now the service requestor can perform the find
  and bind operations
• MANAGE
• Covers ongoing management and administration of
  the web services application

26
Tools

• Microsoft SOAP Toolkit 2.0
• Microsoft Visual Studio .NET and .NET Framework
• Apache SOAP Toolkit and AXIS
• IBM Web Services Toolkit
• SUN JavaTM 2 Platform, Enterprise Edition (J2EE)

27
ExampleAirport Weather Service

• Interface
• getLocation()
• getWind()
• getTemperature()
• getSky()
• getPressure()
• getHumidity()
• getSummary()

Airport Weather

• More informations
• Web Interface
• http//live.capescience.com/AirportWeather/index.h
  tml

28
References

• About SOAP
• http//www.w3c.org/TR/soap
• About WSDL
• http//www.w3c.org/TR/wsdl
• About UDDI
• http//www.uddi.org
• About WSFL
• http//www.ibm.com/software/webservices

29
Other Papers

• About Web service Architecture
• Web Services Conceptual Architecture (WSCA 1.0)
  -Heather Kreger - IBM SW Group
• About Web service development lifecycle
• Web Services Development Concepts (WSDC 1.0)
  -Peter Brittenham- IBM SW Group
• About Web service model
• Web Services Building Blocks for Distributed
  System -Graham Glass -

30
The End
31
Web Server in Action (2/2)
Interoperability
32
XML

• XML eXtensible Markup Languages

• A version of HTML that allows any kind of data to
  be represented in a simple and portable way

Davide
Zerbino
