Performance Characteristics of Sensors and Actuators

1
Performance Characteristics of Sensors and
Actuators

• (Chapter 2)

2
Input and Output

• Sensors
• Input stimulus or measurand (temperature
• pressure, light intensity, etc.)
• Ouput electrical signal (voltage, current
• frequency, phase, etc.)
• Variations output can sometimes be displacement
  (thermometers, magnetostrictive and piezoelectric
  sensors). Some sensors combine sensing and
  actuation

3
Input and Output

• Actuators
• Input electrical signal (voltage, current
• frequency, phase, etc.)
• Output mechanical(force, pressure,
  displacement) or display function (dial
  indication, light, display, etc.)

4
Transfer function

• Relation between input and output
• Other names
• Input output characteristic function
• transfer characteristic function
• response

5
Transfer function (cont.)

• Linear or nonlinear
• Single valued or not
• One dimensional or multi dimensional
• Single input, single output
• Multiple inputs, single output
• In most cases
• Difficult to describe mathematically (given
  graphically)
• Often must be defined from calibration data
• Often only defined on a portion of the range of
  the device

6
Transfer function (cont.)

• T1 to T2 - approximately linear
• Most useful range
• Typically a small portion of the range
• Often taken as linear

7
Transfer function (cont.)

• Other data from transfer function
• saturation
• sensitivity
• full scale range (input and output)
• hysteresis
• deadband
• etc.

8
Transfer function (cont.)

• Other types of transfer functions
• Response with respect to a given quantity
• Performance characteristics (reliability curves,
  etc.)
• Viewed as the relation between any two
  characteristics

9
Impedance and impedance matching

• Input impedance ratio of the rated voltage and
  the resulting current through the input port of
  the device with the output port open (no load)
• Output impedance ratio of the rated output
  voltage and short circuit current of the port
  (i.e. current when the output is shorted)
• These are definitions for two-port devices

10
Impedance (cont.)

• Sensors only output impedance is relevant
• Actuators only input impedance is relevant
• Can also define mechanical impedance
• Not needed - impedance is important for
  interfacing
• Will only talk about electrical impedance

11
Impedance (cont.)

• Why is it important? It affects performance
• Example 500 W sensor (output impedance)
  connected to a processor
• b. Processor input impedance is infinite
• c. Processor input impedance is 500 W

12
Impedance (cont.)

• Example. Strain gauge impedance is 500 W at zero
  strain, 750 W at measured strain
• b sensor output 2.5V (at zero strain), 3V at
  measured strain
• c. sensor output 1.666V to 1.875V
• Result
• Loading in case c.
• Reduced sensitivity(smaller output change for the
  same strain input)
• b. is better than c (in this case). Infinite
  impedance is best.

13
Impedance (cont.)

• Current sensors impedance is low - need low
  impedance at processor
• Same considerations for actuators
• Impedance matching
• Sometimes can be done directly (C-mos devices
  have very high input impedances)
• Often need a matching circuit
• From high to low or from low to high impedances

14
Impedance (cont.)

• Impedance can (and often is) complex ZRjX
• In addition to the previous
• Conjugate matching (ZinZout) - maximum power
  transfer
• Critical for actuators!
• Usually not important for sensors
• ZinRjX, ZoutR-jX.
• No reflection matching (ZinZout) - no reflection
  from load
• Important at high frequencies (transmission
  lines)
• Equally important for sensors and actuators
  (antennas)

15
Range and Span

• Range lowest and highest values of the stimulus
• Span the arithmetic difference between the
  highest and lowest values of the stimulus that
  can be sensed within acceptable errors
• Input full scale (IFS) span
• Output full scale (OFS) difference between the
  upper and lower ranges of the output of the
  sensor corresponding to the span of the sensor
• Dynamic range ratio between the upper and lower
  limits and is usually expressed in db

16
Range and Span (Cont)

• Example a sensors is designed for -30 ?C to 80
  ?C to output 2.5V to 1.2V
• Range -30?C and 80 ?C
• Span 80- (-30)110 ?C
• Input full scale 110 ?C
• Output full scale 2.5V-1.2V1.3V
• Dynamic range20log(140/30)13.38db

17
Range and Span (cont.)

• Range, span, full scale and dynamic range may be
  applied to actuators in the same way
• Span and full scale may also be given in db when
  the scale is large.
• In actuators, there are other properties that
  come into play
• Maximum force, torque, displacement
• Acceleration
• Time response, delays, etc.

18
Accuracy, errors, repeatability

• Errors deviation from ideal
• Sources
• materials used
• construction tolerances
• ageing
• operational errors
• calibration errors
• matching (impedance) or loading errors
• noise
• many others

19
Accuracy, errors (cont.)

• Errors defined as follows
• a. As a difference e V V0 (V0 is the actual
  value, V is that measured value (the stimulus in
  the case of sensors or output in actuators).
• b. As a percentage of full scale (span for
  example) e ?t/(tmax-tmin)100 where tmax and
  tmin are the maximum and minimum values the
  device is designed to operate at.
• c. In terms of the output signal expected.

20
Example errors

• Example A thermistor is used to measure
  temperature between 30 and 80 ?C and produce an
  output voltage between 2.8V and 1.5V. Because of
  errors, the accuracy in sensing is 0.5?C.

21
Example (cont)

• a. In terms of the input as 0.5?C
• b. Percentage of input e 0.5/(8030)100
  0.454
• c. In terms of output. From the transfer
  function e 0.059V.

22
More on errors

• Static errors not time dependent
• Dynamic errors time dependent
• Random errors Different errors in a parameter or
  at different operating times
• Systemic errors errors are constant at all times
  and conditions

23
Error limits - linear TF

• Linear transfer functions
• Error equal along the transfer function
• Error increases or decreases along TF
• Error limits - two lines that delimit the output

24
Error limits - nonlinear TF

• Nonlinear transfer functions
• Error change along the transfer function
• Maximum error from ideal
• Average error
• Limiting curves follow ideal transfer function

25
Error limits - nonlinear TF

• Calibration curve may be used when available
• Lower errors
• Maximum error from calibration curve
• Average error
• Limiting curves follow the actual transfer
  function (calibration)

26
Repeatability

• Also called reproducibility failure of the
  sensor or actuator to represent the same value
  (i.e. stimulus or input) under identical
  conditions when measured at different times.
• usually associated with calibration
• viewed as an error.
• given as the maximum difference between two
  readings taken at different times under identical
  input conditions.
• error given as percentage of input full scale.

27
Sensitivity

• Sensitivity of a sensor is defined as the change
  in output for a given change in input, usually a
  unit change in input. Sensitivity represents the
  slope of the transfer function.
• Same for actuators

28
Sensitivity

• Sensitivity of a sensor is defined as the change
  in output for a given change in input, usually a
  unit change in input. Sensitivity represents the
  slope of the transfer function.
• Same for actuators

29
Sensitivity (cont.)

• Example for a linear transfer function
• Note the units
• a is the slope
• For the transfer function in (2)

30
Sensitivity (cont.)

• Usually associated with sensors
• Applies equally well to actuators
• Can be highly nonlinear along the transfer
  function
• Measured in units of output quantity per units of
  input quantity (W/?C, N/V, V/?C, etc.)

31
Sensitivity analysis (cont.)

• A difficult task
• there is noise
• a combined function of sensitivities of various
  components, including that of the transduction
  sections.
• device may be rather complex with multiple
  transduction steps, each one with its own
  sensitivity, sources of noise and other
  parameters
• some properties may be known but many may not be
  known or may only be approximate. Applies equally
  well to actuators

32
Sensitivity analysis (cont.)

• An important task
• provides information on the output range of
  signals one can expect,
• provides information on the noise and errors to
  expect.
• may provide clues as to how the effects of noise
  and errors may be minimized
• Provides clues on the proper choice of sensors,
  their connections and other steps that may be
  taken to improve performance (amplifiers,
  feedback, etc.).

33
Example - additive errors

• Fiber optic pressure sensor
• Pressure changes the length of the fiber
• This changes the phase of the output
• Three transduction steps

34
Example-1 - no errors present

• Individual sensitivities
• Overall sensitivity
• But, x2y1 (output of transducer 1 is the input
  to transducer 2) and x3y2

35
Example -1 - errors present

• First output is y1y01 ?y1. y01 Output
  without error
• 2nd output
• 3rd output
• Last 3 terms - additive errors

36
Example -2 - differential sensors

• Output proportional to difference between the
  outputs of the sensors
• Output is zero when T1T2
• Common mode signals cancel (noise)
• Errors cancel (mostly)

37
Example -2 - (cont.)
38
Example -3 - sensors in series

• Output is in series
• Input in parallel (all sensors at same
  temperature)
• Outputs add up
• Noise multiplied by product of sensitivities

39
Hysteresis

• Hysteresis (literally lag)- the deviation of the
  sensors output at any given point when
  approached from two different directions
• Caused by electrical or mechanical systems
• Magnetization
• Thermal properties
• Loose linkages

40
Hysteresis - Example

• If temperature is measured, at a rated
  temperature of 50?C, the output might be 4.95V
  when temperature increases but 5.05V when
  temperature decreases.
• This is an error of 0.5 (for an output full
  scale of 10V in this idealized example).
• Hysteresis is also present in actuators and, in
  the case of motion, more common than in sensors.

41
Nonlinearity

• A property of the sensor (nonlinear transfer
  function) or
• Introduced by errors
• Nonlinearity errors influence accuracy.
• Nonlinearity is defined as the maximum deviation
  from the ideal linear transfer function.
• The latter is not usually known or useful
• Nonlinearity must be deduced from the actual
  transfer function or from the calibration curve
• A few methods to do so

42
Nonlinearity (cont.)

• a. by use of the range of the sensor/actuator
• Pass a straight line between the range points
  (line 1)
• Calculate the maximum deviation of the actual
  curve from this straight line
• Good when linearities are small and the span is
  small (thermocouples, thermistors, etc.)
• Gives an overall figure for nonlinearity

43
Nonlinearity (cont.)

• b. by use of two points defining a portion of the
  span of the sensor/actuator.
• Pass a straight line between the two points
• Extend the straight line to cover the whole span
• Calculate the maximum deviation of the actual
  curve from this straight line
• Good when a device is used in a small part of its
  span (i.e. a thermometer used to measure human
  body temperatures
• Improves linearity figure in the range of
  interest

44
Nonlinearity (cont.)

• c. use a linear best fit(least squares) through
  the points of the curve
• Take n points on the actual curve, xi,yi,
  i1,2,n.
• Assume the best fit is a line yaxb (line 2)
• Calculate a and b from the following

45
Nonlinearity (cont.)

• d. use the tangent to the curve at some point on
  the curve
• Take a point in the middle of the range of
  interest
• Draw the tangent and extend to the range of the
  curve (line 3)
• Calculate the nonlinearity as previously
• Only useful if nonlinearity is small and the span
  used very small

46
Saturation

• Saturation a property of sensors or actuators
  when they no longer respond to the input.
• Usually at or near the ends of their span and
  indicates that the output is no longer a function
  of the input or, more likely is a very nonlinear
  function of the input.
• Should be avoided - sensitivity is small or
  nonexistent
• In actuators, it can lead to failure of the
  actuator (increase in power loss, etc.)

47
(No Transcript)
48
Frequency response

• Frequency response The ability of the device to
  respond to a harmonic (sinusoidal) input
• A plot of magnitude (power, displacement, etc.)
  as a function of frequency
• Indicates the range of the stimulus in which the
  device is usable (sensors and actuators)
• Provides important design parameters
• Sometimes the phase is also given (the pair of
  plots is the Bode diagram of the device)

49
Frequency response (cont)

• Important design parameters
• Bandwidth (B-A, in Hz)
• Flat frequency range (D-C in Hz)
• Cutoff frequencies (points A and B in Hz)
• Resonant frequencies

50
Frequency response (cont.)

• Bandwidth the distance in Hz between the half
  power points
• Half-power points eh0.707e, ph0.5p
• Flat response range maximum distance in Hz over
  which the response is flat (based on some
  allowable error)
• Resonant frequency the frequency (or
  frequencies) at which the curve peaks or dips

51
Half power points

• Also called 3db points
• Power is 3db down at these points
• 10log0.5?3db or
• 20log (sqrt(2)/2)?3db
• These points are arbitrary but are now standard.
• It is usually assumed that the device is
  useless beyond the half power points

52
Frequency response (example.)

• Bandwidth 16.5kHz-70Hz16.43 kHz
• Flat frequency range 10kHz-120Hz9880 Hz
• Cutoff frequencies 70 Hz and 16.5 kHz
• Resonance 12 kHz

53
Response time

• response time (or delay time), indicates the time
  needed for the output to reach steady state (or a
  given percentage of steady state) for a step
  change in input.
• Typically the response time will be given as the
  time needed to reach 90 of steady state output
  upon exposure to a unit step change in input.
• The response time of the device is due to the
  inertia of the device (both mechanical and
  electrical).

54
Response time (cont.)

• Example in a temperature sensor
• the time needed for the sensors body to reach
  the temperature it is trying to measure (thermal
  time constant) or
• The electrical time constants inherent in the
  device due to capacitances and inductances
• In most cases due to both
• Example in an actuator
• Due to mass of the actuator and whatever it is
  actuating
• Due to electrical time constants
• Due to momentum

55
Response time (cont.)

• Fast response time is usually desirable (not
  always)
• Slow response times tend to average readings
• Large mechanical systems have slow response times
• Smaller sensors and actuators will almost always
  respond faster
• We shall meet sensors in which response time is
  slowed down on purpose

56
Calibration

• Calibration the experimental determination of
  the transfer function of a sensor or actuator.
• Typically, needed when the transfer function is
  not known or,
• When the device must be operated at tolerances
  below those specified by the manufacturer.
• Example, use a thermistor with a 5 tolerance on
  a full scale from 0 to 100?C to measure
  temperature with accuracy of, say, 0.5?C.
• The only way this can be done is by first
  establishing the transfer function of the sensor.


57
Calibration (cont.)

• Two methods
• a. known transfer function
• Determine the slope and crossing point (line
  function) from two known stimuli (say two
  temperatures) if the transfer function is linear
• Measure the output
• Calculate the slope and crossing point in VaTb
• If the function is more complex, need more
  points V aT bT2 cT3 d
• 4 measurements to calculate a,b,c,d
• Must choose points judiciously - if linear, use
  points close to the range. If not, use equally
  spaced points or points around the locations of
  highest curvature

58
Calibration (cont.)

• Two methods
• b. Unknown transfer function
• Measure the output Ri at as many input values Ti
  as is practical
• Use the entire span
• Calculate a best linear fit (least squares for
  example)
• If the curve is not linear use a polynomial fit
• May use piecewise linear segments if the number
  of points is large.

59
Calibration (cont.)

• Calibration is sometimes an operational
  requirement (thermocouples, pressure sensors)
• Calibration data is usually supplied by the
  manufacturer
• Calibration procedures must be included with the
  design documents
• Errors due to calibration must be evaluated and
  specified

60
Resolution

• Resolution the minimum increment in stimulus to
  which it can respond. It is the magnitude of the
  input change which results in the smallest
  discernible output.
• Example a digital voltmeter with resolution of
  0.1V is used to measure the output of a sensor.
  The change in input (temperature, pressure, etc.)
  that will provide a change of 0.1V on the
  voltmeter is the resolution of the
  sensor/voltmeter system.

61
Resolution (cont.)

• Resolution is determined by the whole system, not
  only by the sensor
• The resolution of the sensor may be better than
  that of the system.
• The sensor itself must interact with a processor,
  the limiting factor on resolution may be the
  sensor or the processor.
• Resolution may be specified in the units of the
  stimulus (0.5?C for a temperature sensor, 1 mT
  for a magnetic field sensor, 0.1mm for a
  proximity sensor, etc) or may be specified as a
  percentage of span (0.1 for example).

62
Resolution (cont.)

• In digital systems, resolution may be specified
  in bits (1 bit or 6 bit resolution)
• In analog systems (those that do not digitize the
  output) the output is continuous and resolution
  may be said to be infinitesimal (for the sensor
  or actuator alone).
• Resolution of an actuator is the minimum
  increment in its output which it can provide.
• Example a stepper motor may have 180 steps per
  revolution. Its resolution is 2?.
• A graduated analog voltmeter may be said to have
  a resolution equal to one graduation (say 0.01V).
  ( higher resolution may be implied by the user
  who can easily interpolated between two
  graduations.

63
Other parameters

• Reliability a statistical measure of quality of
  a device which indicates the ability of the
  device to perform its stated function, under
  normal operating conditions without failure for a
  stated period of time or number of cycles.
• Given in hours, years or in MTBF
• Usually provided by the manufacturer
• Based on accelerated lifetime testing

64
Other parameters

• Deadband the lack of response or insensitivity
  of a device over a specific range of the input.
• In this range which may be small, the output
  remains constant.
• A device should not operate in this range unless
  this insensitivity is acceptable.
• Example, an actuator which is not responding to
  inputs around zero may be acceptable but one
  which freezes over a normal range may not be.

65
Other parameters

• Excitation The electrical supply required for
  operation of a sensor or actuator.
• It may specify the range of voltages under which
  the device should operate (say 2 to 12V), range
  of current, power dissipation, maximum excitation
  as a function of temperature and sometimes
  frequency.
• Part of the data sheet for the device
• Together with other specifications it defines the
  normal operating conditions of the sensor.
• Failure to follow rated values may result in
  erroneous outputs or premature failure of the
  device.
