Searching Algorithms

1
SearchingAlgorithms

• Briana B. Morrison
• With thanks to Dr. Hung

2
Topics

• The searching problem
• Using Brute Force
• Lower Bounds
• Interpolation Search
• Searching in Trees
• Hashing
• Finding the k-th largest key

3
The searching problem

• Problem is to retrieve an entire record based on
  the value of some key
• Find an index i such that x Si if x equals
  one of the keys
• If x does not equal one of the keys, report
  failure

4
Brute Force

• Brute force is a straightforward approach usually
  based on problem statement and definitions.
• Examples
• Computing an (a gt 0, n a nonnegative integer)
• Computing n!
• Multiply two n by n matrices
• Selection sort
• Sequential search

5
String matching

• pattern a string of m characters to search for
• text a (long) string of n characters to search
  in
• Brute force algorithm
• Align pattern at beginning of text
• moving from left to right, compare each character
  of pattern to the corresponding character in text
  until
• all characters are found to match (successful
  search) or
• a mismatch is detected
• while pattern is not found and the text is not
  yet exhausted, realign pattern one position to
  the right and repeat step 2.

6
Brute force string matching Examples

• Pattern 001011

  Text 10010101101001100101111010

• Pattern happy

  Text It is never too late to have a happy
  childhood.
• Number of comparisons
• Efficiency

7
Brute force strengths and weaknesses

• Strengths
• wide applicability
• simplicity
• yields reasonable algorithms for some important
  problems
• searching
• string matching
• matrix multiplication
• yields standard algorithms for simple
  computational tasks
• sum/product of n numbers
• finding max/min in a list

8
Brute force strengths and weaknesses

• Weaknesses
• rarely yields efficient algorithms
• some brute force algorithms unacceptably slow
• not as constructive/creative as some other design
  techniques

9
Exhaustive search

• A brute force solution to a problem involving
  search for an element with a special property,
  usually among combinatorial objects such as
  permutations, combinations, or subsets of a set.

10
Exhaustive search

• Method
• construct a way of listing all potential
  solutions to the problem in a systematic manner
• all solutions are eventually listed
• no solution is repeated
• Evaluate solutions one by one, perhaps
  disqualifying infeasible ones and keeping track
  of the best one found so far
• When search ends, announce the winner

11
Final comments

• Exhaustive search algorithms run in a realistic
  amount of time only on very small instances
• In many cases there are much better alternatives!

• In some cases exhaustive search (or variation) is
  the only known solution

12
Sequential (Linear) Searching

• Sequential search starts at the beginning and
  examines each element in turn.
• If we know the array is sorted and we know the
  search value, we can start the search at the most
  efficient end.
• If the array is sorted, we can stop the search
  when the condition is no longer valid (that is,
  the elements are either smaller or larger than
  the search value).

13
Sequential Search

• Algorithm SequentialSearch (A0 n - 1, k)
• //The algorithm implements sequential search with
  a search key as a sentinel
• //Input An array A0 n - 1 of elements and a
  search key k
• //Output the position of the first element in
  A0 n - 1 whose value is equal to k or -1 if
  no such element is found
• i ? 0
• while Ai ? k do
• i ? i 1
• if i lt n return i
• else return -1

14
Sequential Search

• Sequential Search examine each piece of data
  until the correct one is found.
• 1. Worst case Order O(n).
• 2. Best case O(1)
• 3. Average case O(n/2).
• Thus, we say sequential search is O(n).

15
Binary Search

• Search requires the following steps
• 1. Inspect the middle item of an array of size N.
• 2. Inspect the middle of an array of size N/2
• 3. Inspect the middle item of an array of size
  N/power(2,2) and so on until N/power(2,k) 1.
• This implies k log2N
• k is the number of partitions.

16
Binary Search

• Requires that the array be sorted
• Rather than start at either end, binary searches
  split the array in half and works only with the
  half that may contain the value
• This action of dividing continues until the
  desired value is found or the remaining values
  are either smaller or larger than the search
  value.

17
Binary Search

• BinarySearch (List, target, N)
• //list the elements to be searched
• //target the value being searched for
• //N the number of elements in the list
• Start 1
• End N
• While start lt end do
• Middle (start end) /2
• Select (compare (list middle, target)) from
• Case -1 strat middle 1
• Case 0 return middle
• Case 1 end middle 1
• End select
• End while
• Return 0

18
Binary Search

• Suppose that the data set is n 2k - 1sorted
  items.
• Each time examine middle item. If larger, look
  left, if smaller look right.
• Second chunk to consider is n/2 in size, third
  is n/4, fourth is n/8, etc.
• Worst case, examine k chunks. n 2k 1 so, k
  log2(n 1). (Decision binary tree one
  comparison on each level)
• Best case, O(1). (Found at n/2).
• Thus the algorithm is O(log(n)).
• Extension to non-power of 2 data sets is easy.

19
Binary Search

• Best case O(1)
• Worst case O(log2N) (why?)
• Average Case O(log2N)/2 O(log2N) (why?)

20
Lower Bounds on Searching

• Consider only Comparisons of keys
• Associate a decision tree with every
  deterministic algorithm that searches for a key x
  in an array of n keys. Each leaf represents a
  point at which the algorithm stops

21
(No Transcript)
22
(No Transcript)
23
Lower Bounds

• Worst case number of comparisons is the number of
  nodes in the longest path from the root to a leaf
  in the binary tree.
• This number is ?
• Establish a lower bound on the depth of the
  binary tree

24
Lower Bounds

• d lg (n)
• n 1 2 22 23 2d,
• one root, at most 2 nodes with depth 1, etc.
• 2d nodes with depth d
• n 2d1 1,
• n lt 2d1
• lg n lt d 1
• lg n d

25
Average Case

• Binary Searchs average-case performance is not
  much better than its worst case.

26
Interpolation Search

• Reasonable to assume that he keys are close to
  being evenly distributed between the first one
  and the last one (and sorted).
• Instead of checking the middle, check where we
  would expect to find x

27
Searching in Trees

• Binary Search Tree
• Best Case ?
• Worst Case ?
• Average Case?
• B-Trees
• Best Case ?
• Worst Case ?
• Average Case?
• Advantage? Disadvantage?

A(n) 1.38 lg n
28
Balanced trees AVL trees

• For every node, difference in height between left
  and right subtree is at most 1.
• AVL property is maintained through rotations,
  each time the tree becomes unbalanced.
• lg n h 1.4404 lg (n 2) - 1.3277
  average 1.01 lg n
  0.1 for large n

29
Balanced trees AVL trees

• Disadvantage needs extra storage for maintaining
  node balance.
• A similar idea red-black trees (height of
  subtrees is allowed to differ by up to a factor
  of 2).

30
AVL tree rotations

• Small examples
• 1, 2, 3
• 3, 2, 1
• 1, 3, 2
• 3, 1, 2
• Larger example 4, 5, 7, 2, 1, 3, 6
• See figures 6.4, 6.5 for general cases of
  rotations

31
General case single R-rotation
32
Double LR-rotation
33
Balance factor

• Algorithm maintains balance factor for each node.
  For example

34
Hashing

• Hashing
• Hash Table
• Hash Function
• Hash Address
• Collisions
• Open Hashing (Separate Chaining)
• Closed Hashing (Open Addressing)
• (example Linear Probing checks the cell
  following the one where the collision occurs)
  implies that the table size m must be at least as
  large as the number of keys n.

35
Hashing
A 1 B 2 C3 D 4 .. Z26 Hash function
key mod 13



36
Open Hashing

37
Closed Hashing

38
Hashing

• Hash function distributes n keys among m cells of
  the hash table evenly, each list will be about
  n/m keys long.
• load factor a n/m
• Efficiency of hashing (Open Hashing)

• Efficiency of hashing (Closed Hashing)

39
Hashing

• Exercise For the input 30, 20, 56, 75, 31, 19
  and hash function h(K) K mod 11
• (a) Construct the open hash table.
• (b) Find the largest number of key comparisons in
  a successful search in this table.
• (c) Find the average number of key comparisons in
  a successful search in this table.

40
Hashing

• Exercise For the input 30, 20, 56, 75, 31, 19
  and hash function h(K) K mod 11
• (a) Construct the closed hash table.
• (b) Find the largest number of key comparisons in
  a successful search in this table.
• (c) Find the average number of key comparisons in
  a successful search in this table.

41
Finding Largest Key

• public static keytype find_largest (int n,
  keytype S)
• index i
• keytype large S1
• for (i 2 i lt n i)
• if (Si gt large)
• large Si
• return large

T(n) n 1
42
Finding Both Smallest Largest Keys

• public static void find_both (int n, keytype
  S, bothrec both)
• index i
• both.small S1
• both.larget S1
• for (i 2 i lt n i)
• if (Si lt both.small)
• both.small Si
• else if (Si gt both.large)
• both.large Si

Better performance than finding each separately.
Why? Worst case? W(n) 2(n-1)
43
Intro to Adversary Arguments

• Adversarys goal is to make an algorithm work as
  hard as possible. Makes a decision that will
  keep the algorithm going as long as possible.
  Selects worst possible input set.
• Adversary forces the algorithm to do the basic
  instruction f(n) time, then f(n) is lower bound
  on the worst-case complexity

44
Finding 2nd-Largest Key

• Find largest key, eliminate, then find 2nd
  largest
• Sort and return 2nd from end
• Performance?

45
Finding kth-Smallest Key

• Assume keys are distinct
• Sort the keys and return kth key
• Use QuickSort and partition until you find the
  value for the kth slot
• W(n) (n(n-1))/2
• A(n) 3n
