Title: Using WebBased Tools for Microarray Analysis


1
Using Web-Based Tools for Microarray Analysis
Michael Elgart
2
Outline
  • Introduction to microarrays why use them and
    what to expect from their results
  • What are they?
  • Why use them?
  • What types are there?
  • Low level analysis
  • Background correction
  • Normalization
  • Quality control
  • Significance analysis
  • Annotations
  • Functional Analysis
  • Gene Ontology
  • Promoter Analisys

3
Outline
  • Introduction to microarrays why use them and
    what to expect from their results
  • What are they?
  • Why use them?
  • What types are there?
  • Low level analysis
  • Background correction
  • Normalization
  • Quality control
  • Significance analysis
  • Annotations
  • Functional Analysis
  • Gene Ontology
  • Promoter Analisys

4
What is a microarray?
  • A tool for analyzing gene expression that
    consists of a small membrane or glass slide
    containing samples of thousands of genes arranged
    in a regular pattern.

5
The Boom of Microarray Technology Number of
Publications with Affymetrix Chips
6
Whats the Point?
  • Large scale (genome-wide) screening
  • Eliminate bias of pre-selecting candidate genes
  • Test multiple hypotheses simultaneously
  • Generate new hypotheses by identifying novel
    genes associated with experiment
  • Identify novel relationships/patterns among genes

7
GEO Public Database Example
8
Outline
  • Introduction to microarrays why use them and
    what to expect from their results
  • What are they?
  • Why use them?
  • What types are there?
  • Low level analysis
  • Background correction
  • Normalization
  • Quality control
  • Significance analysis
  • Annotations
  • Functional Analysis
  • Gene Ontology
  • Promoter Analisys

9
What are DNA microarrays?
  • Microarrays are a method of scanning the genome
    based on an well known property of nucleic acids
    (hybridization)
  • Complementary strands of DNA/RNA will find each
    other in solution

10
Types of DNA Microarray Experiments
Some types of experiments that can be done
  • Measure changes in gene expression
  • RNA hybridizes to DNA
  • Identify genomic gains and losses
  • Genomic DNA hybridizes to DNA
  • Identify mutations in DNA
  • PCR product hybridizes to DNA

11
Expression Microarray Basics
  • Two parts
  • Probes the single stranded DNA molecules on the
    solid surface
  • Targets the single stranded labeled population
    from your experimental source

12
Microarray Overview
13
Probe deposition on array
  • Contact printing
  • Ink jet spraying
  • On chip synthesis

14
Pin Spotting of DNA Arrays
  • Can be automated or manual
  • Relatively cheap but may result in QC issues with
    spots

10 per 100 probe array
15
Under the microscope
16
Ink jet spraying
17
Ink jet sprayed spots on a chip
18
Affymetrix
  • Will be dealing mainly with this type today, so
    here is a little more data

19
On chip synthesis
Lithography
20
(No Transcript)
21
(No Transcript)
22
Set of probes that identifies a transcript
ProbeSet
23
Affymetrix
  • Gene Expression Arrays Transcripts/Genes
  • Arabidopsis Genome 24,000
  • C. elegans Genome 22,500
  • Drosophila Genome 18, 500
  • E. coli Genome 20, 366
  • Human Genome U133 Plus 47,000
  • Mouse Genome 39, 000
  • Yeast Genome 5, 841 (S. cerevisiae) 5, 031
    (S. pombe)
  • Rat Genome 30, 000
  • Zebrafish 14, 900
  • Plasmodium/Anopheles 4,300 (P. falciparum)
    14,900 (A. gambiae)
  • Barley (25,500), Soybean (37,500 23,300
    pathogen), Grape (15,700)
  • Canine (21,700), Bovine (23,000),B.subtilis
    (5,000), S. aureus (3,300 ORFS), Xenopus (14, 400)

24
Spots on an Affymetrix chip printed using
photolithography
25
DNA Deposition on Array
2um
Taken from Duggan et al, Nature Genetics 2110
26
(No Transcript)
27
RNA Quality and Quantity
28S rRNA
18S rRNA
Degraded sample
28
Hybridization expression level
  • The amount of hybridization of RNA to a fragment
    of DNA representing any gene can be measured if
    the RNA is labeled with some dye
  • The intensity of hybridization is a surrogate
    that measures the level of expression of the gene
    represented by that DNA fragment

29
Hybridization and Washing of DNA Microarrays
  • Remains one of the most poorly controlled steps
    in the process
  • Long oligonucleotide probes were designed to
    standardize the Tms across the slide
  • However, there will be variable efficiency,
    variable specificity

30
Slide Scanning
Selectable lasers Emission filters with range
from 500-700 nm 5 micron resolution
Goal is to generate images of the arrays that are
used as input for quantitation algorithms
31
Outline
  • Introduction to microarrays why use them and
    what to expect from their results
  • What are they?
  • Why use them?
  • What types are there?
  • Low level analysis
  • Background correction
  • Normalization
  • Quality control
  • Significance analysis
  • Annotations
  • Functional Analysis
  • Gene Ontology
  • Promoter Analisys

32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
Usually the 75th percentile
36
Do not use MM data! MAS (3,4,5) is NOT GOOD Use
RMA !!!
37
Fortunately (?) you dont do this
The result
INTENSITY NumberCells4691556 X Y MEAN STDV NPIX
ELS 0 0 30022.0 4025.9 9 1
0 507.0 48.5 9 2 0 30116.0 4500.7 9 3
0 602.0 97.3 9 4 0 339.0 36.3 9 5
0 491.0 59.1 9 6 0 29208.0 3090.8 9 7
0 877.0 126.0 9 8 0 28683.0 4069.2 9 9
0 645.0 63.6 9 10 0 28536.0 3462.7 9 11
0 473.0 100.5 9 12 0 29509.0 4287.0 9
13 0 667.0 83.2 9
CEL Version3 HEADER Cols2166 Rows2166 Tota
lX2166 TotalY2166 OffsetX0 OffsetY0 GridCorner
UL623 408 GridCornerUR16090 586 GridCornerLR159
32 15984 GridCornerLL464 15807 . . . .
38
So can we just use the data now?
  • Not quite

39
Sources of Microarray Data Variability
  • Biological variability in the populationNo good
    solution here
  • At an experimental level, there is
  • variability between preparations and labelling of
    the sample,
  • variability between hybridisations of the same
    sample to different arrays, and
  • variability between the signal on replicate
    features on the same array.

Expression values in 2 replicas will be
different! Can we handle it?
40
Normalization
  • Deals with the fact that the results from
    identical experiments on two identical
    microarrays will never be exactly the same. In
    addition to unavoidable random errors there are
    also systematic differences caused by
  • Different incorporation efficiencies of dyes. For
    example, green colored markers are stronger then
    red ones (measured as stronger illumination)
    creating a bias between experiments done with
    green and red markers.
  • Different amounts of mRNA in the tested sample,
    causing different expression levels.
  • Difference in experimenter or protocol.
  • Different scanning parameters
  • Differences between chips created in different
    production batches.

41
Quantile Normalization
  • Intensity distributions are adjusted to be
    equivalent
  • Scaling to a target intensity sets the mean
    signal intensity to the defined value

500
Probe Intensity
Probe Intensity
Number of Probes
Number of Probes
42
Background Correction
  • Different GC content of probes
  • Location on Chip Effect
  • etc.
  • All this need to be compensated for. The
    algorythm to do it is
  • RMA

43
Correct Experimental Design
  • Tree representation of replicate experiments
  • The first level is at the level of biological
    replicates
  • This is followed by two independent mRNA
    extractions
  • In each microarray experiment, each gene (each
    probe or probe set) is really a separate
    experiment in its own right

Experiment
Biological Replicates
Replicate 1
Replicate 2
Extract 2
Extract 1
Technical Replicates
We need normalization to be able to look at the
biological differences between samples and not
technical ones Elgart M.
44
Reproducibility
  • How big is the difference between sample that was
    twice hybridized on same type of array?
  • If we look at technical replicas, what do we
    expect to see?

45
Summary Statistics
All using only Top 10,000 brightest probes
Correlation (gt2x Diffl Only)
Red In Replicates
Agree on 2x Diffl
46
Set of probes that identifies a transcript
ProbeSet
If all 10 probes give high signal in Treatment
and low in Control then alls well. But what if
only 6 of 10 are positive? How do we decide
whether this gene is expressed?
47
Set of probes that identifies a transcript
ProbeSet
If all 10 probes give high signal in Treatment
and low in Control then alls well. But what if
only 6 of 10 are positive? How do we decide
whether this gene is expressed?
48
  • Is this a hands-on thing ?
  • Yes.
  • Example

49
(No Transcript)
50
Outline
  • Introduction to microarrays why use them and
    what to expect from their results
  • What are they?
  • Why use them?
  • What types are there?
  • Low level analysis
  • Background correction
  • Normalization
  • Quality control
  • Significance analysis
  • Annotations
  • Functional Analysis
  • Gene Ontology
  • Promoter Analisys

51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
(No Transcript)
80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
(No Transcript)
86
(No Transcript)
87
(No Transcript)
88
(No Transcript)
89
(No Transcript)
90
(No Transcript)
91
(No Transcript)
92
(No Transcript)
93
(No Transcript)
94
(No Transcript)
95
(No Transcript)
96
(No Transcript)
97
(No Transcript)
98
(No Transcript)
99
(No Transcript)
100
(No Transcript)
101
(No Transcript)
102
Outline
  • Introduction to microarrays why use them and
    what to expect from their results
  • What are they?
  • Why use them?
  • What types are there?
  • Low level analysis
  • Background correction
  • Normalization
  • Quality control
  • Significance analysis
  • Annotations
  • Functional Analysis
  • Gene Ontology
  • Promoter Analisys

103
(No Transcript)
104
(No Transcript)
105
(No Transcript)
106
(No Transcript)
107
(No Transcript)
108
(No Transcript)
109
(No Transcript)
110
(No Transcript)
111
(No Transcript)
112
(No Transcript)
113
(No Transcript)
114
(No Transcript)
115
(No Transcript)
116
(No Transcript)
117
(No Transcript)
118
(No Transcript)
119
(No Transcript)
120
(No Transcript)
121
(No Transcript)
122
(No Transcript)
123
(No Transcript)
124
(No Transcript)
125
(No Transcript)
126
(No Transcript)
127
(No Transcript)
128
(No Transcript)
129
(No Transcript)
130
(No Transcript)
131
Outline
  • Introduction to microarrays why use them and
    what to expect from their results
  • What are they?
  • Why use them?
  • What types are there?
  • Low level analysis
  • Background correction
  • Normalization
  • Quality control
  • Significance analysis
  • Annotations
  • Functional Analysis
  • Gene Ontology
  • Promoter Analysis

132
(No Transcript)
133
(No Transcript)
134
(No Transcript)
135
(No Transcript)
136
(No Transcript)
137
(No Transcript)
138
(No Transcript)
139
(No Transcript)
140
(No Transcript)
141
(No Transcript)
142
(No Transcript)
143
(No Transcript)
144
(No Transcript)
145
(No Transcript)
146
(No Transcript)
147
(No Transcript)
148
(No Transcript)
149
(No Transcript)
150
(No Transcript)
151
Outline
  • Introduction to microarrays why use them and
    what to expect from their results
  • What are they?
  • Why use them?
  • What types are there?
  • Low level analysis
  • Background correction
  • Normalization
  • Quality control
  • Significance analysis
  • Annotations
  • Functional Analysis
  • Gene Ontology
  • Promoter Analysis

152
(No Transcript)
153
(No Transcript)
154
(No Transcript)
155
(No Transcript)
156
(No Transcript)
157
(No Transcript)
158
(No Transcript)
159
(No Transcript)
160
(No Transcript)
161
(No Transcript)
162
(No Transcript)
163
(No Transcript)
164
(No Transcript)
165
(No Transcript)
166
(No Transcript)
167
(No Transcript)
168
(No Transcript)
169
(No Transcript)
170
(No Transcript)
171
(No Transcript)
172
(No Transcript)
173
(No Transcript)
174
(No Transcript)
175
(No Transcript)
176
(No Transcript)
177
(No Transcript)
178
(No Transcript)
179
(No Transcript)
180
(No Transcript)
181
(No Transcript)
182
(No Transcript)
183
(No Transcript)
184
(No Transcript)
185
Verifications...
186
The END!
187
Sources
  • Gene Expression Omnibus
  • http//www.ncbi.nlm.nih.gov/geo/
  • R
  • www.r-project.org
  • Bioconductor
  • www.bioconductor.org
  • Race
  • http//race.unil.ch
  • Microarray Blob Remover(MBR)
  • http//liulab.dfci.harvard.edu/Software/MBR/MBR.ht
    m
  • Significance Analysis of Microarrays(SAM)
  • http//www-stat.stanford.edu/tibs/SAM/
  • Affymetrix NetAffx
  • http//www.affymetrix.com/analysis/index.affx
  • Onto Tools
  • http//vortex.cs.wayne.edu/projects.htm
  • Ensembl
  • http//www.ensembl.org/index.html
  • CisGenome
Write a Comment
User Comments (0)
About PowerShow.com
