New generation of Space grade Analogue ICs Nicolas Chantier

1
New generation of Space grade Analogue ICs
Nicolas Chantier

• AMICSA 2006
• October 3rd

2
Nationals Space Capabilities

• Continuously Supplied ICs to the space industry
  since Space electronics exist.
• Long TiD experience, including ELDRS guarantee at
  10mrad/s.
• German designed libraries of SEL immune CMOS
  cells to enable low power, high performance space
  worthy ICs.
• Choice of Space grade packaged IC or Space grade
  die products.
• Self funded RD, roadmap execution and EU job
  creation through creation of value for Space
  customers.

3
Nationals Analog Capabilities

• Nationals analogue capabilities in Space
  applications
• High Speed Signal Path.
• Telecommunication payloads.
• Radar / Lidar for scientific missions.
• Precision Signal Path.
• Attitude and Orbit Control System
• Travelling Wave Tube Amplifiers.
• Power management and distribution units
• Advanced CCD Analog Front Ends.
• Push-broom optical remote sensing.

4
High Speed Signal Path

• Objective
• To enable significantly higher revenue per kg in
  orbit for satellite operators!
• Elimination of RF downconverters in L-Band
  payloads using ADCs with Ultra wide input
  bandwidth.
• Highest possible ENOB to minimize the ADC
  resolution to the minimum necessary nb of bits.
• Increased number of FDMA channels in Nyquist
  zone, thus increased revenue per kg for satellite
  operators.
• Advanced Space grade Package design to minimize
  lead inductance and resistance, matched impedance
  lines in signal path, planes on the supply rails
  to minimize noise induced by digital switching.
  Improved thermal characteristics.

5
ADC08D1000WG-QV5962-0520601VZA

• 8-bit dual, 1 GSPS, low power, CMOS ADC
• 8 bits output 7.4bit ENOB at 500MHz input
• DNL /- 0.15LSB
• Bit Error Rate 10-18
• Interleave mode (2x sample rate)
• 800mW/channel at 1GSPS from single 1.9V supply
  (3.5mW in power down)
• Multiple ADC Synchronization capability
• Fine adjustement of input full-scale range and
  offset.
• Internal sample-and-hold function
• Guaranteed no missing codes

6
ADC08D1000WG-QV5962-0520601VZA

• Radiation tolerance solid see reports.
• Available in Military and Space level versions
• Available January 2007
• Ceramic flat package with matched impedance
  lines, ground plane, supply plane.

7
ADC08D1000WG-QV5962-0520601VZA
For more details see - ADC08D1000 datasheet -
Euro DesignCon 2004 paper  Unique 1.6GSPS CMOS
8-bit 1.8V ADC delivers 7.26ENOB past
Nyquist  Robert Taft Maria Rosaria Tursi, Chris
Menkus Valerie Pons Paul McCormack
8
Package of ADC08D1000WG-QV
9
ADC14155

• 14 bit 155MSPS CMOS ADC
• ENOB 11.5 bits
• Low power consumption 940 mW
• Dual supplies 1.8V and 3.3V
• Solid radiation tolerance
• Available in Military and Space level versions
• Available July 2007
• 48 pin cerquad package (with short straight
  leads)

10
Precision Signal PathLMP2012

• High Precision Rail to Rail Output Operational
  Amplifier
• Complete cancellation of 1/f noise in amplifiers
  for DC and near-DC signals such as AOCS sensors,
  thermistors.
• Guaranteed low offset drift over time
  lt0.006µV/Month lt2.5µV over lifetime.
• Guaranteed low offset drift over temperature.
• Power consumption 930µA

11
Precision strain gauge
Av 60dB CMRR gt 108dB (with resistor tolerance
given below) Supply current 930µA / Amplifier
½ LMP2012

-
½ LMP2012

-
R1
R1
R2
R2
10k, 0.1
10k, 0.1
2k, 1
2k, 1
R3
20?
12
Precision Signal PathADC124S101

• 4 Channel, 1MSPS, 12 bit ADC
• 12 bits up to 1MSPS.
• 4 1 input MUX.
• 2.2 mW when sampling, 0.14µW in stand by.
• High Z outputs and CS function for MUX.
• Light weight 10 pin device.

13
Bringing A to D conversion closer to the sensors
ADC Sampling Clock
Serial Data IN (MUX select)
Serial Data OUT
Logic decoder
4
N analog lines from sensors Pressure IR
bolometers Thermistors etc
x ADC CS lines
ADC Selection
ADC124S101
Large Nb of analog sensor Measurement are
digitised early in the signal path. 41 MUX and
serial output minimises ADC pin count and thus
nb of interconnects ADC addressing through
through CS and decoder minimises consumption No
compromise on precision when Combined with
LMP2012.
ADC124S101
14
CCD Analog Front Ends for Pushbroom Remote Sensing

• Nationals technology enabled a very high number
  of scanned pages per minute at any resolution in
  heavy duty copiers.
• This intellectual property is now offered to
  Space customers who need to achieve superior
  pixel rates.
• Objective To double the current levels of pixel
  rate in Pushbroom systems, allowing for
  significant increase of picture resolution.

15
CCD Analog Front Ends for Pushbroom Remote Sensing
ASIC Board
CCD Board
CMOS Timing
Current Gen.
AFE Discrete build
CCD
ASIC
Analog Data
LVDS clk
1 die AFETG
Future Gen.
CCD
ASIC
LVDS Data

• Integrates AFE and CCD Timing Generator.
• Enables Higher Page Rates, and faster CCDs.
• Reduces EMI Due to CMOS Clocks
• Allows the AFE to move closeer to the CCD sensor.

16
CCD Analog Front Ends for Pushbroom Remote Sensing

• Nationals AFE integrates
• Correlated Double Sampling.
• Sample and Hold
• CCD input biasing
• 3 channels multiple operation modes.
• For each channel
• 14 bit ADC for each channel.
• 9bit PGA
• Black level offset DAC.
• Fully programmable timing generator.
• Preliminary datasheets available to customers
  under
• Non-disclosure agreement.

17
Questions ?
