Coordinated Scheduling of Jobs in Distributed Systems

1
Coordinated Scheduling of Jobs in Distributed
Systems

• Dr. Dimitrios S. Nikolopoulos
• CSL/UIUC

2
Outline

• Motivation for coordinated scheduling
• Gang scheduling
• Coscheduling with implicit communicated
  information
• Dynamic coscheduling
• Dynamic coscheduling with tight memory resources

3
Motivation

• Processes in distributed systems need to
  communicate
• Parallel jobs
• Client/server
• Peer-to-peer
• What happens if we send a message to a process
  which is not scheduled to receive the message ?

4
Uncoordinated scheduling
running
P1 sends to P2
blocked
P2 not running
unutilized time
5
Cascaded effect
running
P1 sends to P2
blocked
P2 not running
P1 not running
P2 not running
6
Purpose of coscheduling

• Try to schedule simultaneously communicating
  processes
• If for any reason the peer is not scheduled
  release the processors/resources for other jobs

7
Ideal coscheduling
running
P1 sends to P2
blocked
P1 not running, run another job
P2 not running run another job
P1 not running
8
Forms of coscheduling

• Explicit coscheduling a.k.a. gang scheduling
• Implicit coscheduling
• Dynamic coscheduling

9
Gang scheduling
job1
T01
job2
T02
T03
job3
T04
job1
T05
job2
T06
job3
T07
job1
T08
job2
T09
job3
T010
job1
T011
job2
T012
job3
job1
T013
job2
T014
T015
job3
10
Gang scheduling

• Good for tightly synchronized programs
• Inappropriate for client server or peer-to-peer
• Hard to implement event on tightly coupled
  multiprocessors
• Requires centralized controller
• Even distributed or hierarchical control schemes
  for gang scheduling dont scale well enough for
  large systems
• Requires time quanta in the order of 10s of
  seconds

11
Coscheduling with implicit information

• Try to coschedule processes controlled by
  different controllers (i.e. operating systems)
  using implicit information available locally
• Types of implicit information
• The turnaround time of a message
• The frequency of arrivals of messages

12
Basic Idea

• Try to infer if your peer is scheduled or not by
  checking
• The time it takes your peer to respond to a
  message
• The number of messages sent by/to your peer
  recently

13
Implicit vs. dynamic coscheduling

• Implicit coscheduling is based on the
  responsiveness of the peer
• The difficulty of implicit coscheduling
  algorithms is to determine how much time a job
  should wait for its peer to respond
• Dynamic coscheduling is based on message
  send/receive frequencies
• The difficulty of dynamic coscheduling

14
Basic impl. coscheduling algorithm

• Wait for a predefined amount of time
• This time might vary at runtime according to
  measurements obtained at runtime, but the way we
  compute this time is predefined
• If a message does not arrive within the
  predefined time interval release the processor

15
Waiting Interval

• Simple scenario ping-pong, or protocols with
  handshaking
• Wait at least for 2l 2c o (turnaround time
  for message including overhead)
• Competitive solution wait for another 2l2co
• This limits the cost we pay for waiting
  needlessly to 4l4c2o

16
Competitive waiting
running
l
P1 sends to P2
blocked
co
l
co
17
Problems with competitive waiting

• Difficult to compute analytically even for simple
  communication patterns
• Example Hard to find analytical solution for
  barriers (Arpaci-Dusseau, ACM TOCS)
• Impossible to compute analytically for
  unstructured or complex communication patterns
• Personalized, broadcast, shuffles, etc.
• Requires modifications in the communication
  libraries and the operating system.

18
Dynamic coscheduling

• Proposed to cope with the difficulties of
  implicit coscheduling
• Implementation
• Computing the waiting interval
• Main idea
• If a process is not scheduled when a message
  arrives for that process schedule the process
  asap!

19
Intrusive dynamic coscheduling

• Upon message arrival schedule the receiving
  process
• Intrusive because it might mess up the scheduling
  queue
• Frequently communicating jobs are treated
  favorably compared to other non-communicating
  jobs

20
Less intrusive dynamic coscheduling

• Periodic priority boost
• In each time slice
• Boost the priority of communicating processes
  according to the recent message send/receive
  history

co
21
Benefits of dynamic coscheduling

• Effective coscheduling if the communication
  pattern is unstructured, unknown, or hard to
  analyze for determining the right waiting
  interval
• Simple implementation
• You still have to modify the operating system
• But the information/variables you have to access
  are already there (message buffers, priority)

22
Coscheduling and thrashing prevention

• Adaptive scheduling under memory pressure on
  multiprogrammed clusters (NikolopoulosPolychronop
  oulos, IEEE/ACM ccGrid02)
• partly based on
• Adaptive scheduling under memory pressure on
  multiprogrammed SMPs
• (NikolopoulosPolychronopoulos, IEEE IPDPS02)

23
Thrashing prevention

• Thrashing the situation in which a computer
  pages data to/from the disk without doing useful
  work
• Reason the running programs consume the memory
  of the system
• Impact severe (slowdowns of a factor of 100x),
  because I/O from the disk is hundreds of times
  slower than accessing memory

24
Adaptive algorithm for thrashing prevention

• Programs prevent thrashing by
• Dynamically detecting paging at memory allocation
  points
• Backing-off until paging stops
• Memory-hungry jobs make room for memory resident
  jobs
• Algorithm works for dynamic workloads (random
  arrivals and departures of jobs)

25
Thrashing prevention on an SMP
26
Coscheduling under memory constraints

• If one system of a distributed system thrashes
  the effect may be sensed throughout the system
  (busy-waiting jobs)
• Coscheduling solves the problem of needless
  waiting, but not the problem of thrashing. We
  either need a large number of jobs to sustain
  utilization or prevent thrashing (proposed
  solution)

27
Combining coscheduling with thrashing prevention

• Scenarios
• Non-communicating jobs that fit in memory -gt
  nothing to do
• Communicating jobs that fit in memory -gt
  coscheduling takes priority
• Non-communicating jobs that fit in memory -gt
  thrashing prevention takes priority
• Communicating jobs that do not fit in memory -gt
  coscheduling or thrashing prevention first ?

28
Combining coscheduling with thrashing prevention

• If coscheduling takes priority
• Communicating job will consume the message but..
• The system will page
• If thrashing prevention takes priority
• Communicating job will be delayed
• Paging will be avoided
• The priority of the delayed job will be boosted
  so as soon as the job fits in memory it will
  consume the message
• We choose the second option due to the
  unpredictable latency of paging

29
Details

• Implementation of paging prevention in Linux uses
  a shared-memory interface to communicate memory
  utilization info
• Memory requirements of jobs are estimated
  dynamically by intercepting system calls
• Dynamic coscheduling requires no more than 10
  lines of code added to the Linux scheduler

30
Details

• Starvation is avoided by running jobs that are
  suspended more than 10 time needed to load their
  resident (just a heuristic)
• Large jobs are stalled at memory allocation
  points, before the beginning of computation (I.e.
  once a job establishes its working set it runs
  and only jobs submitted later may stall due to
  memory pressure)

31
Results
32
Results
