SQL Server 2000 Query Processing and Optimization

1
SQL Server 2000Query Processing and Optimization

• Don Vilen
• Program Manager
• SQL Server Development Team

2
Agenda

• SQL Server Overview
• SQL Server Architecture
• Storage and Access Methods
• Query Processing and Optimization
• Transaction Processing
• Other Topics

3
Query Processing and Optimization
4
Query Processing and Optimization

• SQL Server Architecture
• Query Processor goals
• Optimization techniques
• Query plans
• Futures

5
Server ArchitectureThe Big Picture
6
Query Processor Components

• Query optimization
• Selection of best execution plan
• Cost-based, transformation-driven
• Extensive logical inferences
• Query execution
• Algorithms to perform join, group by,
• Hash-based, merge-based
• Parallelism
• Provides plan building blocks

7
Query Processor Goals

• Responsibilities
• Processing of DML queries (T-SQL and )
• SELECT, INSERT, UPDATE, DELETE,
• Processing of DDL operations
• Index creation, DBCC CHECK,
• Creation and maintenance of statistics
• DBCC UPDATE STATISTICS

8
Query ProcessorGoal Performance

• SQL Server 6.5 provides excellent OLTP
  performance
• SQL Server 7.0 extends to set-oriented, decision
  support queries (star schema)
• SQL Server 2000 extends to handle snowflake
  schemas, indexed views, partitioned views, and
  extensive parallelism

9
Query ProcessorGoal Modularity

• Robustness
• Rapid future innovation
• Uniform internal interfaces
• Learn from the lessons of 6.5
• Keep the code clean ? extensible

10
Query Processor Goal Functionality

• Distributed and heterogeneous queries
• More complex queries, gt 16 tables
• Some extensions, like SELECT TOP
• Indexed views support
• Statistics on non-indexed columns
• Partitioned views
• SELECT, INSERT, UPDATE, DELETE
• Cascading DRI, etc
• Rich heterogeneous query support (OLEDB)

11
Agenda

• SQL Server Architecture
• Query Processor goals
• Optimization techniques
• Query plans
• Futures

12
Query OptimizerOverview

• Rewrite- property- cost-driven
• Like DB2 C/S v5 Tandem, not Oracle v6 (but
  Oracle 8i does)
• Extensive rewrite set
• E.g. index selection, join order,
• Rich inference capabilities
• E.g. contradiction detection
• Sensitive to query complexity
• Optimization time-out based on estimated
  execution cost

13
Query OptimizerOptimization model
Input tree
Subtree
Pool of alternatives
Rewrite
Output cheapest plan
New subtree
14
Query OptimizerOptimization time

• Will you wait for the exhaustive optimization of
  your 20-table query?
• Goal Make optimization time proportional to the
  query complexity
• Query complexity ? cost of the optimal plan

15
Query OptimizerMulti-stage optimization

• Multiple stages
• No-choice queries (trivial plan)
• Transaction processing queries
• Complex query I
• Complex query II
• Parallel queries
• No knobs!

16
Query OptimizerTree-rewrite and search

• Change join order
• (R JOIN S) JOIN T, can also be done as
• (R JOIN T) JOIN S
• Alternative or replacement
• Evaluate filter conditions early
• Extent of search based on query
• Sub-second queries optimized quickly

17
Query OptimizerTransformations

• Lots of transformations in SQL Server (over 300)

Filter (A.x 5)
GrpBy A.x, sum(A.y)
Join
Join
Join
B
A
B
A
B
A
Join
Join
Hash-Join
Filter (A.x 5)
B
B
GrpBy A.x, sum(A.y)
B
A
A
A
Simplification
Implementation
Exploration
18
Query OptimizerOver 300 transformation rules

• Join reordering
• Outerjoins
• Subqueries
• Aggregation
• Star and snowflakes
• Join elimination
• Materialized views
• Index plans
• Update plans

• Halloween protection
• Empty tab simplification
• (Integrity constraints)
• Partitioned tables
• Parallelism
• Remote queries

19
Query OptimizerLogical inferences

• Equivalence classes for columns
• If ab then sort(a) same as sort(b)
• Implied join predicates
• Keys and functional dependencies
• GROUPBY(e,ename) same as GROUPBY(e)
• Contradiction detection
• Infer empty table(s) from check constraints
• Join simplification using FK constraints
• Outer join simplification using nullability

20
Query OptimizerResult size estimation

• Basis for cost estimation
• Uses statistics on stored data
• Densities and histograms
• Keys (from unique indices)
• Constraints (DRI, check constraints)
• Available in showplan

21
Query OptimizerStatistics on demand

• Optimizer relies on up-to-date statistics
• Automatic create, drop and update statistics
• Fall-back mechanism
• Quick statistics estimation (heuristics)
• Statistics on histogram and density
• MAXDIFF to capture frequent values

22
Query OptimizerCost calculation

• Cost to first/last row
• I/O CPU, normalized to seconds
• Row goals during optimization
• E.g. optimize for first-10 rows retrieval
• Available in showplan output
• Forms basis for FAST-N/TOP-N hints

23
Query OptimizerChoosing the right plan

• Give as much information as possible!
• You wont always know how your tables will be
  used
• Declare constraints they can help
• Uniqueness
• DRI
• Nullability
• Keep statistics up to date
• Use auto-stats or your own maintenance plan
• Provide useful indexes ?

24
Query OptimizerHints

• Youre smart but
• One or more indexes
• Join order
• Join, grouping, distinct algorithms
• Row goal (FAST N)
• But be careful!
• Maintenance
• Compatibility
• your data volume can change

25
Query OptimizerUtility Operations

• More than queries
• Update plans
• Bulk Import, export convert
• CREATE INDEX
• DBCC CHECKDB/CHECKTABLE
• ALTER TABLE
• CREATE STATISTICS

26
Query OptimizerOptimized update plans

• Small updates (e.g., OLTP operations)
• Row-by-row update all indexes for each row
• Standard technique may use lots of random I/O
• Large updates (e.g., warehouse refresh)
• Index-by-index update
• Pre-sorting per index merges change into index
• Each index leaf is touched at most once
• Saved index update cost often exceeds sort cost

27
1 of every 8 rows is deleted
(These spool operations share one work file)
8KB/page / 24B/entry 335 entries/page 70
fill factor ? 235 1 in 8 ? 30 deletions/page
A sort operation per updated index very fast
index maintenance
Is each index leaf touchedonce or 30 times?
On average, after lots of random insertions and
deletions, B-tree pages are about 70 full
thats why this fill factor is used in the
example.
28
Query OptimizerUtility example BCP IN

• OLE/DB over local text file or TDS INSERT
  SELECT from tds-stream
• Query semantics conversion, restriction
• Standard optimized update plans
• E.g. sorted insertions in each index

29
Agenda

• SQL Server Architecture
• Query processor goals
• Optimization techniques
• Query plans
• Futures

30
Query PlansIterator execution model

• An iterator consumes/produces a stream of rows
• A query plan is a graph of iterators
• Open, get-next, close methods
• Pull parent-demand-driven
• Modular, easy to add new iterators
• Just like LEGO
• E.g. sample, rank, top, segment, sort,

31
Query PlansExample Filter

• GetNext Method
• Repeat
• Call child.GetNext() to obtain row r
• IF EndOfStream, RETURN END_OF_STREAM
• IF predicate(r) is TRUE, RETURN r

32
Query PlansCovering indices

• Index with all needed columns
• Clustering columns automatically added
  non-clustered indices (as key/bookmark)
• CREATE INDEX ON Orders(employeeid)
• Delivers employeeid and orderid columns
• Clustering column not in 6.5 indices
• 6.5 uses a RID (physical locator) model

33
Query PlansMulti-index operations

• Index intersection, union, difference
• month January AND store 3
• month January AND store ltgt 3
• Join indices of a single table
• Extends covering indices
• Performed using existing join algorithms (no
  special stuff)
• Good for complex DSS/adhoc queries

34
Query PlansIndex-lookup JOIN

• CUSTOMER JOIN ORDERS ON cust
• For every row in CUSTOMER
• Use index on ORDERS.cust to look up matches
• Apply fetch performance techniques
• Sort/pre-fetch lookup values
• Fetch columns from CUSTOMER or ORDERS after join
• Workhorse for OLTP queries

35
Query PlansIndex lookup/scan, Fetch

• Indices are used to
• Restrict rows (T.a between 10 and 20)
• Extract columns (covering indices)
• Obtain rows in sorted order or random order
• QP can scan forwards or backwards
• SQL 2000 supports mixed ASC and DESC indexes
• Fetch locates rows in table from bookmark
• Fetch is a separate operator

36
Query PlansFetch performance

• Locates base table row using bookmark retrieved
  from non-clustered index
• Simple fetch
• Synchronous I/O
• Scattered I/O
• Pre-fetch reduces I/O latency issues
• Delayed, hinted queue of records
• Sort by RID for good caching

37
Query PlansSorting

• Integrated as iterator, not a step
• Pipeline result of last merge to consumer
• Support for sort distinct
• Sorted-input algorithms for join, grouping
• Merge join
• Stream aggregation

38
Query PlansAggregation GROUP BY

• MIN/MAX
• Use sort order provided by index
• First non-null value
• Forwards or backwards direction
• Multiple min/max computed independently then
  joined
• Local-partial-global
• Aggregates split into multiple stages
• Exploit interesting sort orders, joins, etc

39
Query PlansAggregation hash/stream

• Select sum(sales) group by quarter

sort on quarterstream aggregation
hash on quarterhash aggregation
40
Query PlansMerge Join

• T join R on T.a R.a
• Sorted input streams
• Nested loops on groups
• Many-1 / Many-Many
• Finds non-matches
• Mark and re-scan
• Outerjoin, not exist subq
• Preserves order on join columns

41
Query PlansSummary

• Large set of interesting plans
• Combined together to answer user queries
• Plan choice and combination decided at compile
  time by the Optimizer
• We looked at-
• Index-lookup join
• Small outer input, large indexed inner
• Merge join
• Sorted inputs, e.g. (covering) index
• Sorted output, e.g. stream aggregation
• Aggregation min/max/local/global/partial
• Others hash-join, nested-loop join,

42
Query ProcessorConclusion

• State of the art query technology
• Industrial strength
• Framework for rapid future innovation
• More than just a query processor
• How you can help
• Provide as much information as you can DRI,
  CHECK, NULL, etc
• Keep statistics up to date (try auto-stats)
• Provide sensible indexes

43
Questions?
