Using LDAP in your enterprise for PHP Programmers

1
Using LDAP in your enterprise for PHP Programmers

• By Justin Dearing and Alex Ames

2
Who is Alex Ames

• Network Administrator
• Background in mixed systems
• Linux/BSD Windows Netware - i/5 OS
• 12 years in professional IT
• LDAP usage
• Tie together authentication across Apache running
  on multiple platforms.
• Annoy me darcrist_at_gmail.com

3
Who is Alex Ames

• Network Administrator
• Background in mixed systems
• Linux/BSD Windows Netware - i/5 OS
• 12 years in professional IT
• LDAP usage
• Tie together authentication across Apache running
  on multiple platforms.
• Annoy me darcrist_at_gmail.com

4
Who is Justin Dearing

• Multi Talented Programmer/Network Admin
• I write C at the moment professionally
• Done some PHP
• Former Unix Admin and iSeries Operator
• Will admin windows boxes if forced to
• Variety of Open Source Contributions
• https//www.ohloh.net/accounts/zippy1981
• Annoy me zippy1981_at_gmail.com

5
What is LDAP

• The Lightweight Directory Access Protocol,
  or LDAP (IPA '?l dæp), is an application
  protocol for querying and modifying directory
  services running over TCP/IP.1A directory is a
  set of objects with similar attributes organized
  in a logical and hierarchical manner. The most
  common example is the telephone directory, which
  consists of a series of names (either of persons
  or organizations) organized alphabetically, with
  each name having an address and phone number
  attached.
• Source http//en.wikipedia.org/wiki/Lightweight_D
  irectory_Access_Protocol

6
But really, What is LDAP?

• Lightweight Directory Access Protocol
• A light version of the X.500 Directory Access
  protocol
• Developed by the Telecommunications industry
  based on 70 years of phone book printing wisdom

7
So its like a database?

• Sort of, but not exactly
• (Relational Database Management Systems) RDBMSs
  store data is a collection of relational tables
• Directories store hierarchies of data in a tree
  format

8
Principles of LDAP

• Hierarchical Directory of information
• think folder/dir tree!
• LDAP Bind Connection
• requires a username/password with privileges to
  read/search the LDAP Directory.
• Can limit query results to a specific OU/CN or
  branch
• Microsoft AD must be able to browse the entire
  AD structure to reach desired container.
• If you cant read a container, you cant perform
  operations against it (i.e. you cant
  authenticate a user you cant see attributes
  for!).

9
Security

• Authentication
• name/password
• Kerberos authentication
• Accounts
• Users are stored in the directory with attribute
  objectClassuser
• Sometimes there is an admin account stored
  outside the directory structure.
• Connections
• Unencrypted
• SSL
• TLS

10
LDAP Client Libraries

• PHP
• Built in
• Windows
• ADSI/ADSI.NET
• Novell .NET Library
• Wldap32

• C
• Novell Directory Library
• OpenLDAP SDK
• JAVA
• JNDI
• OpenLDAP
• Novell

11
Using LDAP with Apache
12
LDAP in Apache 2.2

• Generally not compiled or available by default.
• Requirements
• OpenLDAP 1.x or 2.x SDK installed
• Novell LDAP SDK installed
• Others Microsoft, Mozilla/Sun/iPlanet
• 2 LDAP modules in Apache
• mod_ldap
• mod_authnz_ldap (depends on mod_ldap)
• Best when compiled from source (IMHO, YMMV)
• Some RPMs work out-of-the-box RedHat, SuSE

13
Apache modules

• mod_ldap
• Provides automatic connection pooling minimal
  connections, many requests
• Provides search bind cache for
• username, password and DN
• Provides SSL support varies by SDK used to
  compile. RTFM!
• mod_authnz_ldap
• Base permissions on groups, users filters
• No more .htpasswd files to mess with!

14
Compiling LDAP for Apache

• Prerequisites
• LDAP SDK installed configured.
• You dont need an LDAP server on the box...
• Get SSL support installed configured
• From the apache source
• in srclib/apr-util
• ./configure with-ldap-include
  /usr/local/include/with-ldap-lib/usr/local/lib/
  with-ldapldap with-apr../apr
• in ././configure with-ssl enable-soenable-m
  ods-sharedall with-ldap with-auth-ldap
  enable-ldap enable-auth-ldap

15
Apache .conf for LDAP
methods provided by
mod_auth_basic AuthType basicAuthName LDAP
Authentication Required"AuthBasicProvider
ldap methods provided by mod_authnz_ldapAuthLD
APURL ldap//ldap.myserver.com/dcyourdomain,dcco
m?uid AuthLDAPBindDN oAdminContainer,dcyourdom
ain,dccom AuthLDAPBindPassword
badidea-thanx-bill Require ldap-group
cnAdministrators, oAdminContainer
16
iSeries LDAP support

• Using Apache and LDAP on the iSeries

17
Installing OpenLDAP client tools on Windows

• Go to http//bowmansolutions.com/mingw-openldap/
• Follow those direction
• You need MinGW, MSYS, lots of dependencies
• Its a giant pain to build
• Add dig.exe while your at it.
• http//ftp.isc.org/isc/bind8/contrib/ntbind-9.3.0r
  c3/

18
OpenLDAP Client tools on Windows made easy

• Install this MSI I made just for you.
• No need to thank me.

19
LDAP Queries

• Three components
• BaseDN
• What portion of the tree are you searching
• Filter
• Attributes and values to limit the result set
• Attributes returned
• What attributes from the result set to what we
  want?

20
LDAP Query filters

• Prefix notation Boolean logic
• Still has parenthesis
• Simple syntax

21
Ok, wheres the PHP?

• ...with just apache LDAP, authenticated user data
  can be found in _SERVER...
• _SERVERPHP_AUTH_USER
• _SERVERPHP_AUTH_PW
• _SERVERPHP_AUTH_TYPE
• ...but to get PHP to cook in LDAP without
  apache....

22
PHP and LDAP

• Prerequisites
• LDAP SDK installed configured.
• You dont need an LDAP server on the box...
• Get SSL support installed configured
• From the PHP source
• in ./
• ./configure --with-ldapPATH
• Uncomment the module in php.ini

23
Using LDAP in PHP
sr someuser ldappwd somepass dn
OUUsers,DCyourdomain,DCcom filterusers
(CN) conn ldap_connect(server) If
(!ldap_bind(conn, ldapusr, ldappwd) ) die(
No LDAP Bind. Nuts!) srch
ldap_search(conn, dn, filterusers) results
ldap_get_entries(conn, srch) usercount
resultscount for (c0 c c) echo resultscdisplayname .
"\n" ldap_unbind(conn) ?
24
PHP LDAP API

• ldap_add  Add entries to LDAP directory
• ldap_bind  Bind to LDAP directory
• ldap_close  Alias of ldap_unbind
• ldap_compare  Compare value of attribute found
  in entry specified with DN
• ldap_connect  Connect to an LDAP server
• ldap_count_entries  Count the number of entries
  in a search
• ldap_delete  Delete an entry from a directory
• ldap_dn2ufn  Convert DN to User Friendly Naming
  format
• ldap_err2str  Convert LDAP error number into
  string error message
• ldap_errno  Return the LDAP error number of the
  last LDAP command
• ldap_error  Return the LDAP error message of the
  last LDAP command
• ldap_explode_dn  Splits DN into its component
  parts
• ldap_first_attribute  Return first attribute
• ldap_first_entry  Return first result id
• ldap_first_reference  Return first reference
• ldap_free_result  Free result memory
• ldap_get_attributes  Get attributes from a
  search result entry
• ldap_get_dn  Get the DN of a result entry
• ldap_get_entries  Get all result entries

• ldap_get_values_len  Get all binary values from
  a result entry
• ldap_get_values  Get all values from a result
  entry
• ldap_list  Single-level search
• ldap_mod_add  Add attribute values to current
  attributes
• ldap_mod_del  Delete attribute values from
  current attributes
• ldap_mod_replace  Replace attribute values with
  new ones
• ldap_modify  Modify an LDAP entry
• ldap_next_attribute  Get the next attribute in
  result
• ldap_next_entry  Get next result entry
• ldap_next_reference  Get next reference
• ldap_parse_reference  Extract information from
  reference entry
• ldap_parse_result  Extract information from
  result
• ldap_read  Read an entry
• ldap_rename  Modify the name of an entry
• ldap_sasl_bind  Bind to LDAP directory using
  SASL
• ldap_search  Search LDAP tree
• ldap_set_option  Set the value of the given
  option
• ldap_set_rebind_proc  Set a callback function to
  do re-binds on referral chasing
• ldap_sort  Sort LDAP result entries

25
LDAP Browser Software

• All LDAP browsers suck

26
LDAP Browsers from worst to not as bad

• LDAP Browser/Editor
• JXplorer
• Apache Studio One
• For web based administration
• phpLDAPAdmin

27
LDAP Browser/Editor

• That crappy LDAP browser app that everyone uses
  http//www.mcs.anl.gov/gawor/ldap/
• Not really free for commercial use
• Ugly AWT
• The author is worse at naming software than I am.

28
JXplorer

• Open Source Software
• Decent AD Support (When I finish writing and
  submitting the patch)
• Not a very active project
• Was originally developed by Computer Associates
• The code seems well documented

29
Apache Studio One

• Eclipse with LDAP browsing plugins
• Probably possible to add ldap plugins to other
  Ellipse setups
• Most mature browser
• A bit resource heavy
• Its eclipse (you might like or hate it.)

30
Show me the screenshots
31
JXPlorer
32
LDAP Browser/Editor
33
phpLDAPAdmin
34
What is my Active Directory LDAP servers
hostname?

• How the simple php programmer can connect to the
  companies LDAP server without bothering the
  Windows Admin

35
Scenario

• Youre the company programmer/unix admin
• The windows admin cant give you the name of the
  LDAP server
• No time to research
• Doesnt know what LDAP is
• You are also the windows admin

36
Scenario (cont.)

• You want to use LDAP (presumably in PHP)
• You have authorization to do this
• You have a user account on the windows domain.

37
What are my domain credentials?

• Environmental variables
• USERDNSDOMAINTurn foo.com into dcfoo,dccom
  to get basedn
• USERNAME_at_USERDOMAINThis is the user name you
  bind as
• Password
• Refer to the post it note on your monitor

38
What's the ldap servers hostname?

• You have to do a DNS query
• Record _ldap._tcp.foo.com
• Record Type SRV

39
Whats a SRV?

• An SRV record or Service record is a category of
  data in the Internet Domain Name
  System specifying information on available
  services. It is defined in RFC 2782. Newer
  internet protocols such as SIP and XMPP often
  require SRV support from clients.
• http//en.wikipedia.org/wiki/SRV_record

40
Whats a SRV? (cont)

• An SRV record has the form
• _Service._Proto.Name TTL Class SRV Priority
  Weight Port Target
• Service the symbolic name of the desired
  service.
• Proto the protocol of the desired service this
  is usually either TCP or UDP.
• Name the domain name for which this record is
  valid.
• TTL standard DNS time to live field.
• Class standard DNS class field (this is
  always IN).
• Priority the priority of the target host, lower
  value means more preferred.
• Weight A relative weight for records with the
  same priority.
• Port the TCP or UDP port on which the service is
  to be found.
• Target the canonical hostname of the machine
  providing the service.

41
Whats a SRV? (cont)

• So basically _ldap._tcp.foo.com means
• Give me the ldap servers for the foo.com domains.

42
How do we lookup SRV records

• Nslookup
• http//technet.microsoft.com/en-us/library/cc73899
  1.aspx
• Dig
• Dig _ldap._tcp.foo.com SRV

43
Putting our knowledge to use

• Unfortunately, I dont have a domain to show you
  tonight. But I can run through the settings.

44
Some Java research
