Gnort: High Performance Intrusion Detection Using Graphics Processors

1
Gnort High Performance Intrusion Detection Using
Graphics Processors

• Giorgos Vasiliadis, Spiros Antonatos, Michalis
  Polychronakis, Evangelos Markatos, Sotiris
  Ioannidis
• Institute of Computer Science
• Foundation for Research and Technology Hellas

2
General Idea

• How to speed up the processing throughput of
  intrusion detection systems by offloading the
  pattern matching operations to the GPU.

3
Introduction

• The problem
• Network Intrusion Detection Systems (NIDS) are
  based on String Matching for detecting and
  preventing from well-known attacks
• String Matching process accounts up to 75 of the
  total CPU processing
• String Matching Algorithms
• Aho-Corasick
• Specialized hardware devices (NP, FPGAs, ASICs)
• Complex to modify and program
• Poor flexibility
• Graphics Cards
• Easy to program
• Powerful and ubiquitous
• Researches have begun exploring ways to tap their
  power for non-graphics applications

4
Why use the GPU ?

• The GPU is specialized for compute-intensive,
  highly parallel computation

5
NVIDIA GeForce SIMD Architecture

• Many Multiprocessors
• Each multiprocessor contains many Stream
  Processors
• Memory model
• Shared On-Chip Memory
• 1 cycle
• Constant Memory
• 400-600 cycles 1 cycle if cached
• Texture Memory
• 400-600 cycles 1 cycle if cached
• Global Device Memory
• 400-600 cycles

Size
GPU can be used as a general purpose processor,
capable of executing many threads in parallel
6
The Aho-Corasick Algorithm

• Used in most modern NIDSes
• Scans for multiple patterns simultaneously
• Preprocess all patterns to build a state machine
• The state machine is used to scan for multiple
  patterns simultaneously at linear time
• Complexity is independent of the number of
  patterns

Example Phe, she, his, hers
7
Mapping Aho-Corasick on GPU

• How to represent the State Machine ?
• Snort represent each state as an array of
  pointers
• It is difficult to map them on the GPU memory
• Transform to a 2D array
• Can easily bind to Texture Memory
• Texture fetches are cached
• Aho-Corasick exhibits strong locality of
  references
• Random access memory read
• The usage of Texture Memory boosts GPU execution
  time about 19

8
Parallelizing Packet Searching (1/2)

• Assigning a Single Packet to each Multiprocessor

• Each packet is copied to the shared memory of the
  Multiprocessor
• Stream Processors search different parts of the
  packet concurrently
• Overlapping computation
• Matching patterns may span consecutive chunks of
  the packet
• Same amount of work per Stream Processor
• Stream Processors will be synchronized

9
Parallelizing Packet Searching (2/2)

• Assigning a Single Packet to each Stream Processor

• Each packet is processed by a different Stream
  Processor
• No overlapping computation
• Different amount of work per Stream Processor
• Stream processors of the same Multiprocessor will
  have to wait until all have finished

10
Software Mapping

• Packets are transferred to the GPU in batches
• Performs much better than making each transfer
  separately
• Packets are stored to a buffer that is copied to
  the GPU when gets full
• Use page-locked memory to store the packets
• Higher transfer throughput from host to device
• Copies are performed using DMA, without occupying
  the CPU
• CPU and GPU execution can overlap

11
Evaluation (1/2)

• Scalability as a function of the number of
  patterns

• We ran Snort using random generated patterns
• All patterns are matched against every packet
• Payload trace contained UDP 800-bytes packets of
  random payload
• Throughput remains constant when patterns
  increases
• 2.4x faster than the CPU

12
Evaluation (2/2)

• Throughput as a function of the packets size

• Ran Snort using 1000 random patterns
• All patterns are matched against every packet
• 2.3 Gbit/s for full packets
• 3.2x faster compared to the CPU
• Both GPU implementations do not present
  significant differences in performance

13
Evaluation with real input and rules

• Experimental setup
• Two PCs connected via a 1 Gbit/s Ethernet switch
• To directly compare with prior work Jacob et
  al, we re-implemented the Knuth-Morris-Pratt
  (KMP) and Boyer-Moore (BM) algorithms on the GPU.

14
Evaluation with real input and rules

• Snort loaded about 8000 patterns.
• Preprocessors and PCRE were disabled
• Original Snort (AC) cannot process all packets in
  rates higher than 300 Mbit/s
• GPU-assisted Snort (AC1, AC2) begins to loose
  packets at 600 Mbit/s
• 200 improvement
• KMP and BM algorithms used from Jacob et al
  perform worse in all cases

15
Conclusion

• Graphics cards can be used effectively to speed
  up Network Intrusion Detection Systems.
• Low-cost
• Easy programming
• Future work includes
• Transfer the packets directly from the NIC to the
  GPU
• Utilize multiple GPUs on multi-slot motherboards

16
Thank you

• Any questions?
• gvasil_at_ics.forth.gr
