INTERTANKO UK Corrosion 2002 Cardiff, Wales October 24, 2002

1
INTERTANKOUK Corrosion 2002 Cardiff, Wales
October 24, 2002

• CRUDE OIL CARGO TANK CORROSION

2
Purpose of this paper

• Provide a brief background about
• Tanker structures and the cargo tank environment
• Tanker corrosion
• INTERTANKOs Corrosion conference 1998 - Update
  since 1998
• Conclusions way ahead coating access
  class rule harmonization

3
INTERTANKO

• INTERTANKO
• The International Association of Independent
  Tanker Owners.
• INTERTANKO membership represents about 2000
  tankers.
• Chemical, Product and Crude Oil tankers.
• Offices in Oslo, London, Washington D.C and
  Singapore.
• Regional Panels in Americas, the Far East and
  Greece.

4
INTERTANKO

• Examples of INTERTANKO activities
• Cooperates with other organisations like OCIMF
  ICS WWF IACS and numerous others.
• Active in IMO.
• Providing factual information.
• Commenting and working group participation.
• Active with US Coast Guard.
• Commenting on proposed rulemaking.

5
INTERTANKO

• Keep members advised of political developments
  and proposed regulatory changes and other issues
  of general interest like corrosion.
• Tanker events every 6th month
• Membership criteria quality
• Visit Intertanko home page on
• www.intertanko.com

6
VLCC - Typical midship section

• Midship section

• Approximate Dimensions (in meter)
• Length over all 332
• Length B. P. 320
• Breadth moulded 58
• Depth moulded 31
• Design draft 20.8
• Scantling draft 22.0

7
VLCC Double hull

• Double hull tanker in the building dock
• Side ballast tank width abt. 2 4 meter.
• Bottom ballast tank height abt. 2 - 3 meter.
• Height of centre cargo tank abt. 29 meter
• Length of centre cargo tank abt. 50 meter

8
THENAMARIS -Suez max tanker
Notice the red coat on cargo tank inner bottom
9
Corrosion mechanisms at work
10
Volatile/stable crude oil
11
Day/Night
12
Pitting in the tank bottom plate(MIC)
13
Pitting as discovered on new double hull tankers
(MIC)
14
ONE COAT ON TANK BOTTOM
COATING APPLIED ON PITTING CORROSION IN PERFECT
CONDITION 5 YEARS LATER NO FURTHER PROBLEM
EXPECTED
15
RUST FLAKE FROM ABOVE UNDER DECK CORROSION!
RUST FLAKE COMMONLY FOUND ON CARGO TANK
BOTTOM SOURCE UNDER DECK CORROSION
16
Sulphur crystals
FULLY FORMED SULPHUR CRYSTALS FOUND ON THE RUST
FLAKES FROM THE UNDER DECK AREA OF THE CARGO
TANKS
17
ERIKA - December 1999

• MAIN INGREDIENTS OLD TANKER CORROSION BAD
  WEATHER DISTRESS -SINKING POLLUTION ALL
  HANDS SAVED
• SIGNIFICANT CONSEQUENCES OF ONE TANKER ACCIDENT
  ACROSS THE INDUSTRY
• TWO TRENCHES OF MARITIME LEGISLATION KNOWN AS
• ERIKA I AND ERIKA II

18
Castor main deck crack

• December 2000 Part of crack
• Mediterranean bad weather
• Fully loaded tanker Castor developed a 22 meter
  long crack in the main deck
• Coastal states refuse port of refuge
• Castor survives no cargo spilled minor
  regulatory effect
• Main ingredients corrosion bad weather
  inadequate surveys and maintenance

19
So, what can be done?

• The answer is a clear NO! There is more than
  adequate survey regulations in force. If the
  present survey regimes are followed, that is!

• More inspections and more surveys.!?

CARRY OUT SURVEYS AND REPAIRS AS INTENDED!
NOTHING MORE NOTHING LESS!
20
What else can be done?

• Identify risk areas at the design stage
• Arrange access at newbuilding stage
• Apply suitable coating to areas of concern like
  all cargo tank tops and inner bottoms
• Produce inspection manual
• THESE COUNTERMEASURES MUST BE COMPULSORY MEASURES
  EXEMPT FROM COMMERCIAL PRESSURE!

21
Stress analysis
22
AREAS VULNERABLE TO CORROSION
These are the areas in a tanker that are likely
to suffer corrosion during its service life. Well
known! But no permanent access.
23
No access

• Arrows indicate where access is necessary for
  meaningful close up inspection.
• Notice no access arrangement
• Tank inner bottom not coated

24
Practical logistical problems!
100 survey of a VLCC would require Height to
climb 11 km Area to survey 300 000 m2 Length of
weld 1 200 km Length longitudinals 58 km Bottom
area 10 700 m2 1,0 pitting 85 000 pits
25
Wing cargo tank on a small single hull VLCC
(Source DNV)

• Note the surveyor in the tank bottom
• Volume of tank abt. 25.000 cubic meter
• Notice no access no railings on stringers

26
Probability of crack detection (source DNV)
27
Cargo tank top/bottom coating
28
MEASURING METHOD
Hull plate thickness can be measured with the
ship afloat. A vehicle with special
instrumentation will crawl along the bottom
29
THICKNESS MEASUREMENT SHIPS BOTTOM PLATING
THE COLOR DIAGRAM SHOWS THE IN-WATER BOTTOM
PLATING THICKNESS MEASUREMENT RESULT. THE RED
AREA NEEDS ATTENTION. THE YELLOW NEEDS WATCHING.
30
Building blocksBLOCK SIZE IS IMPORTANT TO REDUCE
THE AMOUNT OF PAINT REPAIRS WHEN THE BALLAST
CARGO TANKS ARE COATED AT THE BLOCK STAGE.
BLOCK WELDS - EXTERNAL
31
THENAMARIS - New Suez max tanker during
construction 2000
LAST SECTION OF MAINDECK WILL CLOSE THE
DECK NOTICE THE BULKHEAD PLATFORM
32
THENAMARIS ATHENSMEANS OF ACCESS
WALKWAY FOR INSPECTION IN BALLAST TANK
33
THENAMARIS ATHENSWalkway in ballast tank
using oversized longitudinal fitted with railing
34
THENAMARIS ATHENSCoated cargo tank inner
bottom to prevent MIC corrosion
35
THENAMARIS/ ATHENSCoating of tank head ullage
space
Dark area coated to prevent ullage space
corrosion
Note access platform with railing for inspection
coated
36
THENAMARIS - ATHENSCARGO TANK HEAD INSPECTION
ACCESS PLATFORM
COATED CARGO TANK TOP (DARK AREA)
37
VLCC cargo tank walkway
Walk way
Oversized longitudinals
Notice oversized longitudinals as access walkway
for inspection and the walk way platforms around
the web frames
38
CONCLUSIONS (1/5)

• CORROSION CAN BE DUBBED MANY NAMES BUT NAME
  CHANGE IS NO SUBSTITUTE FOR INSPECTION, DISCOVERY
  AND REPAIRS.
• CORROSION RISK CAN BE PREDICTED, LOCATION
  IDENTIFIED AT DESIGN STAGE, PERMANENT ACCESS
  ARRANGED FOR MONITORING IN SERVICE.
• CORROSION, CRACKS AND BUCKLING CAN BE DISCOVERED
  ACCESS FOR CLOSE-UP INSPECTION IS NEEDED.

39
CONCLUSION (2/5)

• MODIFY LONGITUDINALS ON NEW SHIPS TO BE USED AS
  ACCESS PLATFORMS.
• OWNERS MUST DEMAND THAT CLASS MAKE PERMANENT
  ACCESS REQUIREMENT COMPULSORY AND HARMONIZED FOR
  ALL CLASS SOCIETIES.
• COATING MUST BE APPLIED TO CARGO TANK TOP INNER
  BOTTOM AS COMPULSORY IACS COUNTERMEASURE AGAINST
  CORROSION.

40
CONCLUSION (3/5)

• NEGATIVE TOLERANCE ON STEEL PLATE THICKNESS MUST
  STOP POSITIVE TOLERANCE ONLY ACCEPTABLE.
• SHIPBUILDERS MUST EXTEND HULL STRUCTURE AND
  COATING GUARANTEE FROM ONE TO FIVE CALENDAR YEARS
  TO MATCH THE FIRST SPECIAL SURVEY.
• GUARANTEE LENGTH IS A SAFETY MATTER NOT A
  COMMERCIAL ISSUE.

41
CONCLUSIONS (4/5)

• SHIP REPAIRERS MUST REPAIR SHIPS IN A RESPONSIBLE
  AND PROFESSIONAL MANNER SHIP REPAIRERS SHOULD
  BE HELD LIABLE FOR INADEQUATE REPAIRS.
• OWNERS, CLASS AND THE INDUSTRY HAVE COMMON
  INTEREST IN NEVER AGAIN SEEING A TANKER OR ANY
  SHIP GOING DOWN AND SPILL HER CARGO BECAUSE OF
  CORROSION AND LESS THAN SATISFACTORY REPAIRS.

42
CONCLUSIONS (5/5)

• ALL CLASS SOCIETIES GOVERNING BODIES HAVE
  SIGNIFICANT NUMBERS OF SENIOR EXECUTIVES FROM
  SHIP OWNING, SHIP OPERATING INTERESTS.
• THESE SENIOR EXECUTIVES HAVE A PARTICULAR DUTY TO
  TAKE THE LEAD, BE PROACTIVE AND ENSURE CLASS/IACS
  SPEED UP THE PROCESS OF
• UNIFORM SCANTLING REQUIREMENTS
• UNIFORM FATIGUE CALCULATIONS
• GENERAL HARMONISATION OF CLASS RULES
• INSPECTION ACCESS AND COATING FOR CARGO TANKS
