Sampling the Subsurface in Final Status Decommissioning Surveys

1
Sampling the Subsurface in Final Status
Decommissioning Surveys

• Carl V. Gogolak
• U.S. DHS Environmental Measurements Laboratory

2
Sampling the Subsurface

• How is designing a sampling survey for subsurface
  materials different from designing a sampling
  survey for surface materials within the first 15
  cm of soil?
• At issue is how to design the survey more
  efficiently, because the sampling effort is
  considerably higher for subsurface sampling than
  it is for surface soil sampling.
• It doesnt have to be perfect, it only has to be
  better than what we are doing now, will a
  justifiable technical basis and no hidden
  assumptions

3
Designing more efficient surveys

• The number of samples required in a survey can
  be reduced by increasing the information
  available by other means than simply taking more
  direct measurements. This can be done in two
  ways
• 1) increase the information available from
  professional knowledge of site processes,
  historical data, pollutant transport etc.
• 2) make more efficient use of the hard data that
  is already available by the use of more advanced
  statistical methods.

4
Improved Survey Efficiency in MARSSIM

• Incorporates prior information qualitatively in
  Survey Unit Classification
• Sampling Design based on anticipated data
  variability of independent samples simple random
  sampling on systematic grid
• Data analysis based on nonparametric tests for
  independent identically distributed data
• Elevated areas found by scanning ELIPGRID can
  be used for the risk of missing an area

5
Possibilities for further design efficiency

• Incorporate prior information quantitatively as
  soft data that can be combined with hard
  concentration data from samples- Bayesian
  Statistics
• Sampling Design based on maximizing the
  information that will be added (not all locations
  are equally informative)
• Geostatistical Data analysis that incorporates
  known spatial relationships among data locations
• Geophysical data may be used for scanning -
  Bayesian extensions to ELIPGRID

6
Incorporating soft information

• Data other than the results of specific
  measurements at a location within the survey
  unit, soft information, can be incorporated
  into the process so that fewer hard data points
  will be required.
• Bayesian methods are used in statistics to make
  use of information available from prior
  knowledge.
• Geostatistical methods are used to make more
  efficient use of spatial data.

7
Designing more efficient surveys

• The information added in this way can only aid
  the decision-making process if
• 1) the assumptions are reasonable (i.e. really
  add more of what we actually know about the
  physical processes underlying the data rather
  than just multiplying assumptions)
• 2) the methodology is implementable, i.e., can be
  made simple enough to be used in practice.

8
TOOLS

• ASAP Adaptive Sampling and Analysis
• Developed at ANL
• Simple implementation of Bayesian Analysis
• Binomial distribution for number of samples
  exceeding DCGL
• Conjugate beta distribution for prior probability
  of exceeding the DCGL based on professional
  judgment (same as Sign p in MARSSIM)
• Indicator kriging of hard sample data updates
  prior probabilities
• Update based on number of pseudo-samples
  related to inverse of kriging variance

9
TOOLS

• SADA Spatial Analysis for Decision Assistance
• Developed at UT
• Graphical User Interface for data display
• 2D and 3D capability
• Incorporates GSLIB geostatistical methods
• Freeware
• No third party software needed
• Flexible and customizable platform for
  development of ASAP and extensions to MARSSIM
  data design and analysis

10
Summary of the Procedure

• (1) Roughly estimate, using whatever information
  is at hand, the probability that a sample taken
  at any given location, z, in the survey unit
  would result in a measurement exceeding the
  release criterion.
• (2) Roughly estimate the uncertainty of the
  estimate made in step 1.

11
Prior Probability of Exceeding 3.0
12
Uncertainty in the Prior Probability of Exceeding
3.0
13
Summary of the Procedure

• (3) Convert (in software) these estimates of
  and F for the prior distribution of into the
  parameters " and of a Beta distribution.
• The information value of the prior knowledge
  implied by the specification of a particular Beta
  distribution with parameters a and ß is the same
  as that which would be obtained from a series of
  results (Bernoulli trials) with a -1 samples
  above the release criterion and ß-1 samples below
  the release criterion.

14
Prior Probabilities

• One is estimating
• and where agt0 and ßgt0 are the parameters of a
  Beta distribution.

15
Some combinations of a and b with the
corresponding values of m and s.
a b m s 1 1 0.500 0.289 1 2 0.333 0.236 1 3 0.
250 0.194 1 4 0.200 0.163 1 5 0.167 0.141 1 6 0
.143 0.124 1 7 0.125 0.110 1 8 0.111 0.099 1 9
0.100 0.090
16
Some Beta Distributions
17
Summary of the Procedure

• (4) Take data at n sample locations, and convert
  the results to an indicator variable which is
  equal to 1 if the measurement exceeds the release
  criterion, and 0 otherwise.
• SADA can be used to optimize the locations.

18
Hard Data
19
Summary of the Procedure

• (5) Perform indicator kriging using an
  exponential variogram model with appropriately
  estimated values of the parameters c0, c, and a.

20
Exponential Variogram
21
Summary of the Procedure

• (6) Update the parameters " and of the Beta
  distribution to obtain the posterior distribution
  of the probability of exceedence.

22
Data above 3.0 are indicator transformed to 1,
below 3.0 to 0.
Indicator kriging interpolates those
probabilities between sample locations to a
value p(z) at each location z
23
Updating Prior Probabilities

• Following the suggestion of Johnson (1996) the
  parameters of the beta distribution are updated
  using to x n p(z) with
• where c0 is the nugget, and c is the sill, of
  the assumed exponential semivariogram . The
  posterior update of a is a x. The posterior
  update of b is b n - x.

24
Summary of the Procedure

• (7) Calculate updated estimates of the expected
  value, , and standard deviation, F, of the
  probability that a sample taken at the location
  z in the survey unit would result in a
  measurement exceeding the release criterion.

25
Update of Prior Probabilities
26
Update of Uncertainties
27
Future development of SADA

• 1. Survey Sampling Design Optimizing the Number
  of Samples
• 2. Starting with (combined) professional judgment
  () obtain
• a secondary sampling design
• Develop a metric for optimizing the sample size
• 3. Variography and Variogram Specification
• using a Markov-Bayes type assumption on the soft
  data
• Exponential with no nugget global variance sill
  range guess
• 3rd dimension still tough
• 3. Elevated areas Bayesian Elipgrid
• 4. Develop Criteria for Determining Compliance
