Advanced Algorithms for Fast and Scalable Deep
Packet Inspection
Sailesh Kumar Jonathan Turner John Williams
2
Why Regular Expressions Acceleration?

• RegEx are now widely used
• Network intrusion detection systems, NIDS
• Layer 7 switches, load balancing
• Firewalls, filtering, authentication and
  monitoring
• Content-based traffic management and routing
• RegEx matching is expensive
• Space Large amount of memory
• Bandwidth Requires 1 state traversal per byte
• RegEx is performance bottleneck
• In enterprise switches from Cisco, etc
• Many security appliances
• Use DFA, 1 GB memory, still sub-gigabit
  throughput
• Need to accelerate RegEx!

3
Can we do better?

• Well studied in compiler literature
• Whats different in Networking?
• Can we do better?
• Construction time versus execution time (grep)
• Traditionally, (construction execution) time is
  the metric
• In networking context, execution time is critical
• Also, there may be thousands of patterns
• DFAs are fast
• But can have exponentially large number of states
• Algorithms exist to minimize number of states
• Still 1) low performance and 2) gigabytes of
  memory

4
Delayed Input DFA (D2FA), SIGCOMM06

• Many transitions
• 256 transitions per state
• 50 distinct transitions per state (real world
  datasets)
• Need 50 words per state
• Reduce number of transitions in a DFA

Three rules a, bc, cd
Look at state pairs there are many common
transitions. How to remove them?
4 transitions per state
5
Delayed Input DFA (D2FA), SIGCOMM06

• Many transitions
• 256 transitions per state
• 50 distinct transitions per state (real world
  datasets)
• Need 50 words per state
• Reduce number of transitions in a DFA

Alternative Representation
Three rules a, bc, cd
4 transitions per state
Fewer transitions, less memory
6
D2FA Operation
Heavy edges are called default transitions Take
default transitions, whenever, a labeled
transition is missing
DFA
D2FA
7
D2FA versus DFA

• D2FAs are compact but requires multiple memory
  accesses
• Up to 20x increased memory accesses
• Not desirable in off-chip architecture
• Can D2FAs match the performance of DFAs
• YES!!!!
• Content Addressed D2FAs (CD2FA)
• CD2FAs require only one memory access per byte
• Matches the performance of a DFA in cacheless
  system
• Systems with data cache, CD2FA are 2-3x faster
• CD2FAs are 10x compact than DFAs

8
Introduction to CD2FA

• How to avoid multiple memory accesses of D2FAs?
• Avoid lookup to decide if default path needs to
  be taken
• Avoid default path traversal
• Solution Assign labels to each state, labels
  contain
• Characters for which it has labeled transitions
• Information about all of its default states
• Characters for which its default states have
  labeled transitions

find node Rat location R
Content Labels
find node U athash(c,d,R)
find node V athash(a,b,hash(c,d,R))
9
Introduction to CD2FA
?(R, a)
?(R, b)

?(Z, a)
?(Z, b)









R
R
all
all


Z
U
c
l
cd,R
lm,Z


Y
d
m
pq,lm,Z
V
a
P
ab,cd,R


X
b
q







?(X, p)
?(X, q)


?(V, a)
?(V, b)

hash(p,q,hash(l,m,Z))
lm,Z
pq,lm,Z
hash(c,d,R)
Input char
d
a
hash(a,b,hash(c,d,R))
Current state V (label ab,cd,R)
? X (label pq,lm,Z)
10
Construction of CD2FA

• We seek to keep the content labels small
• Twin Objectives
• Ensure that states have few labeled transitions
• Ensure that default paths are as small as
  possible
• D2FA construction heuristic based upon maximum
  weight spanning tree creates long default paths
• Limit default paths gt less space efficient D2FAs
• Proposed new heuristic called CRO to construct
  D2FAs
• Runs in 3 phases Construction, Reduction and
  Optimization
• Default path bound 2 edges gt CRO algorithm
  constructs upto 10x space efficient D2FAs
• CD2FAs are constructed from these D2FAs

11
Memory Mapping in CD2FA
?(R, a)
?(R, b)

?(Z, a)
?(Z, b)









R
Z
R
all
all


U
Y
c
l
cd,R
lm,R


d
m
pq,lm,R
V
X
a
P
ab,cd,R


b
q







WE HAVE ASSUMED THAT HASHING IS COLLISION FREE
hash(a,b,hash(c,d,R))
hash(c,d,R))
hash(p,q,hash(l,m,Z))
COLLISION
12
Collision-free Memory Mapping












a
Four states
hash(abc, )
b
a
b
c
,
.

c
4 memory locations
p
hash(pqr, )
q
p
q
r
,
.

r
l
hash(def, )
hash(mln, )
WE NEED SYSTEMATIC APPRAOCH
n
,
.
l
m
m

n
hash(lmn, )
d
hash(edf, )
e
d
e
f
,
.

f
13
Bipartite Graph Matching

• Bipartite Graph
• Left nodes are state content labels
• Right nodes are memory locations
• Map state labels to unique memory locations
• An edge for every choice of content label
• Perfect matching problem
• With n left and right nodes
• Need O(logn) random edges
• n 1M implies, we need 20 edges per node
• If we provide slight memory over-provisioning
• We can uniquely map state labels with much fewer
  edges
• In our experiments, we found perfect matching
  without memory over-provisioning

14
Memory Reduction Results
15
Throughput Results
3x Faster 4KB cache
16
Conclusion

• We have proposed CD2FAs
• Matches/surpasses a DFA in throughput
• 10x less memory than table compressed DFA
• Novel randomized memory mapping algorithm based
  upon maximum matching in bipartite graph
• Zero space overhead
• Zero bandwidth overhead
• Thank you and Questions???
