Commonsense Reasoning 0809 HC 13: Abduction

1
Commonsense Reasoning 08/09HC 13 Abduction

• Henry Prakken
• 07-01-2009
• (with thanks to Annette Ten Teije)

2
Reasoning with causal defaults

• Prediction sprinkler on what will happen?
• Modelling deduction (M.P.)
• Explanation grass wet why?
• Modelling abduction
• Invalid!

Sprinkler on ? Grass wet
3
Abduction what is it?

• Finding the best explanation for a set of
  observations
• What is the best explanation for the wet grass?

Sprinkler on ? Grass wet Rain ? Grass wet
4
Abduction application areas

• Commonsense reasoning
• Diagnosis
• Legal proof
• Planning
• Scientific theory formation

5
Abduction in AI

• Part of Model-based diagnosis
• Model based reasoning
• Build a formal model of a system
• Reason about the systems behaviour by reasoning
  with the model
• Applied to diagnosis
• Build causal model of the systems abnormal
  behaviour
• Observe behaviour
• Find explanation of abnormal behaviour by
  reasoning with the causal model

6
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing
7
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing
8
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing
9
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing
10
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing
11
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing
12
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing
13
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing
14
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing headache
15
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing headache
Abduction is nonmonotonic!
16
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing headache
17
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing headache
18
Causal network (1)
flu
cold
hangover
smoke allergy
fever
coughing
headache
observed coughing headache
19
(No Transcript)
20
piston-rings used
oil-cup holed
old-spark-plugs
?1
oil-below-car
lubric-oil burning
oil loss
spark-plugs used-up
irreg-oil consumpt
oil lack
stack smoke
?3
dirty-spark-plugs
high-engine temp
burnout
irreg- ignition
ignition problems
?2
?4
temp-indic red
power decrease
coolant evaporation
mumbling engine
vapour
?5
lack-of-accel
melting
melted pistons
?6
smoke-from engine
21
piston-rings used
oil-cup holed
old-spark-plugs
?1
oil-below-car
lubric-oil burning
oil loss
spark-plugs used-up
irreg-oil consumpt
oil lack
stack smoke
?3
dirty-spark-plugs
high-engine temp
burnout
irreg- ignition
ignition problems
?2
?4
temp-indic red
power decrease
coolant evaporation
mumbling engine
vapour
?5
lack-of-accel
melting
melted pistons
?6
smoke-from engine
22
piston-rings used
oil-cup holed
old-spark-plugs
?1
oil-below-car
lubric-oil burning
oil loss
spark-plugs used-up
irreg-oil consumpt
oil lack
stack smoke
?3
dirty-spark-plugs
high-engine temp
burnout
irreg- ignition
ignition problems
?2
?4
temp-indic red
power decrease
coolant evaporation
mumbling engine
vapour
?5
lack-of-accel
melting
melted pistons
?6
smoke-from engine
23
Logical model of abduction idea

• Given
• a causal model CM
• a set of observations O
• Find explanations for O, i.e. hypotheses H such
  that
• H ? CM - O
• H ? CM is consistent
• Compare the explanations

24
Logical model of abduction(with strict causality)

• Causal specification (DFS,OBS,CM)
• DFS d1, , dn (di literals)
• possible defects
• OBS o1, , om (oi literals)
• possible observations
• CM set of causal rules
• d1 ? ? dm ? dn
• d1 ? ? dj ? ok
• Abductive Causal Problem (C,O)
• C is a causal specification
• O ? OBS
• Solution an explanation for O in terms of C
• with H ? DFS

25
Example theory

• H1 ? S1
• H2 ? S2
• H3 ? S3
• S1 ? Obs1
• S2 ? Obs1
• S2 ? Obs2
• S3 ? S4
• S4 ? Obs2
• observed behaviour Obs1 ? Obs2

26
Negative observations
- observed coughing, headache, ?fever. - An
explanation only needs to be consistent with
the negative observations!
27
Revised definition solution

• H ? DFS is a solution of (C,O) iff
• H ? CM - O
• H ? CM ? Oc is consistent
• Oc is the set of negative observations
• Oc ? ?oo ? OBS/O
• (Further constraints are possible)

28
Weak causality
- coughing ? O ?headache ? Oc - Problem smoke
allergy is no explanation! - Solution allow
weak causal rules
29
Weak causality logically

• DFS also contains assumption literals ?i
• A ? ?i ? B A may cause B
• Definitions remain unchanged
• Explanations can now also contain assumption
  literals.

30

flu ? fever flu ? ?1 ? coughing flu ?
headache cold ? coughing hangover ?
headache smoke-all. ? ?2 ? coughing smoke-all. ?
?3 ? headache
O coughing Oc ?headache
CM U smoke-all., ?2 -- coughing CM U
smoke-all., ?2 U Oc is consistent
31
Preference criteria for explanations

• subset minimal
• number minimal (cardinality)
• Variations
• Ignore assumption literals
• Only consider initial causes
• Consider only designated defect literals
• Add probabilities

32
Abstract model abduction(Bylander et al.)

• Abduction problem ?Dall,Hall,e,pl ?
• Dall data to-be explained
• Hall individual hypotheses
• e map from subsets of Hall to subsets of Dall
• h explains e(h)
• pl partial ordering of subsets of Hall
• plausibility

33

e(h1)d1 e(h2)d1,d2 .
Hallh1,h2,h3,h4,h5 Dalld1,d2,d3,d4
pl(h1,h2) pl(h2,h3) pl(h1,h2) lt
pl(h4,h5) ..
34
Terminology

• H is a hypothesis iff H ? Hall
• H is complete iff e(H) Dall
• H is parsimonious iffno proper subset of H
  explains the same data
• Hypothesis H is an explanation iffH is complete
  and H is parsimonious
• H is a "best explanation" iff there is no
  explation H' such that pl(H') gt pl(H)

35
Example

• Is h1,h2,h3,h4 an explanation?

36
Logical model in terms of abstract model

• Dall O
• Hall DFS
• e(H)
• o ? O H ? CM - o (if H ? CM ? Oc is
  consistent)
• ? otherwise
• pl (for example)
• pl(H) ? pl(H) iff H ? H

37
Types of abduction problems

• (1) Independent abd-problem
• (2) Monotonic abd-problem
• (3) Incompatibility abd-problem
• (4) Cancellation abd-problem
• Type of abduction problem
• depends on domain properties!!
• Does not depend on representation method

38
1. Independent abduction problem

• Composite hypothesis explains a datum iff one of
  its elements explains that datum
• ? H ? Hall (e(H) ?h?H e(h))

39
Example

• h1 and h2 together explain d1, but not
  independently
• ? no independent abduction problem!!

40
2. Monotonic abduction problem (MAP)

• Composite hypothesis can explain more than its
  parts
• ? H, H ? Hall (H ? H ? e(H) ? e(H))
• - composite hypothesis does not lose explained
  data
• - composite hypothesis possibly explains
  additional data

41
Example
h1
h2
h3
d2
d4
d3
d1
e(h1) ? e(h2) ? e(h3) ? e(h1,h2,h3)
42
3. Incompatibility abduction problem

• Some hypotheses exclude each other
• I hi,hj, hk,hl, set of incompatible
  hypothesis pairs
• H ? Hall ((? I ? I (I ? H)) ? e(H) ?)
• independent incompatibility problem
• ? H?Hall ((?? I?I (I?H)) ? e(H) ?h?He(h))

43
Cancellation problems

• Sometimes extending a hypothesis causes loss of
  previously explained data
• pneumonia causes fever and breathing problems
• increased adrenal glands function causes moonface
• pneumonia with increased adrenal glands function
  causes breathing problems and moonface (so no
  fever any more)

44
4. Cancellation abduction problem

• Abduction problem ?Dall,Hall,e,pl,eproc,econs?
• eproc, econs, maps of Hall to subsets of Dall
• for resp. producing and consuming
• d ? e(H) ?
• ?h h ? H ? d ? eprod(h) ?gt
• ?h h ? H ? d ? econs(h) ?

45
Example
h1
h2
h3
h4
d3
d1
d2
d2 ? e(h2) d2 ? e(h1,h2)
