ULTRA ENVIRO-SYSTEMS (P) LTD.
Fragmentation Analysis System
2
ULTRA ENVIRO-SYSTEMS (P) LTD. Formerly Globe
Agencies
Visionary and founder Late Shyam Sunder Sharma
started Globe Agencies in 1969 to Sell, Support
and Service high technological instrumentation in
Mining, Atmospheric and Earth Sciences.    We
have maintained over the years High Quality
Personalized Sales After Sales Services to our
customers.    We work in close coordination with
customers and our foreign collaborators and
principals to offer technological instruments and
systems best suited to Indian conditions.   We
also offer total Indian Solutions using Local
Contents, Layouts and Hardware.
3

• WipWare Inc.
• Canada Company Overview
• With the introduction of WipFrag in 1987, WipWare
  became the industry leader in optical
  granulometry of fragmented material. Since that
  time, the company has built a global reputation
  for excellence in software innovation and design,
  earning it the trust and loyalty of hundreds of
  users worldwide. With WipFrag Momentum and
  WipFrag Reflex, WipWare continues to provide
  customers with innovative solutions to their
  optimization and automation needs.
• Because you can't manage what you can't measure

• It is critical to understand that if you don't
  know your existing process performance, it is
  difficult to know how to improve it. The
  information our systems provide is comprehensive
  and allows our end users to make important
  process optimization decisions based on actual
  process data. This capability has saved our end
  users countless millions in electrical,
  mechanical, chemical and environmental costs.
• WipWare is the standard because
• WipWare invented optical granulometry at the
  University of Waterloo nearly two decades ago
  creating WIEP (Waterloo Image Enhancement
  Process) which was later renamed WipFrag
• WipWare has developed and refined this technology
  for over 15 years
• WipWare is the largest supplier of this equipment
  and technology in the world
• To date, WipWare has produced more photo analysis
  systems than all of its known competitors
  combined by an estimated 41 ratio
• WipWare has a network of 27 distributors and
  agents in over 17 countries ensuring our clients
  local access to sales and service
• WipFrag technology has been validated (tested and
  accepted) by more universities, research
  organizations, aggregate producers, mining
  companies and government agencies than any other
  system
• Superior edge detection, optimized code and
  high-speed processors allow WipWare to provide
  real-time results
• WipWare components carry mission critical
  designations They are capable of running 24 / 7
  under high load in volatile environments

4
Explosives
Powerful Optimization ToolAdvanced technology
designed to maximize the use of your explosive
energy.
5
WipFrag
Granulometry Analysis SoftwareImage analysis
software instantly delineates particle size
distribution in unconsolidated material. Blast
models, formulas, expected results, we all know
that this approach to predicting blast results is
useless without the tool to quantify what really
matters fragmentation. Our technologies root
deep in the explosives industry, we understand
the steps required to improve blast
fragmentation, and the infinite number of
variables which effect the results. Our
technology empowers you with the tools you need
to collect historical data, establish a
statistical baseline and track subtle changes
throughout the optimization process so you can
make decisions based on fact, instead of theory.

• WipFrag Features
• Most advanced edge detection algorythm available
• Intuitive user interface optimizes workflow
• Digital image formats TIF, BMP or JPG
• Digital video capture with 1394 FireWire
• Analog video capture with PCI/PCMCIA frame
  grabber
• ISO Metric, US Imperial, or User Defined sieve
  series
• Available in English, French and Spanish versions

• Save results as BMP, JPG or PDF for easy sharing
• One year software upgrade eligibility

6
How It WorksSTEP 1 - Take image sample (s)STEP
2 - Load image sample (s) in WipFragSTEP 3 -
Process image sample (s) and review
results Package IncludesCD-ROMLicense
KeyUsers ManualFrame Grabber DeviceQuick
Reference CardRegistration Card
System RequirementsMicrosoft Windows 98, ME,
2000, or XPPentium 233 MHz or equivalent128 MB
RAMCD-ROM drive100 MB free disk
spaceMicrosoft Internet Explorer 5.0 or
later1024x768 High Color (16 bit) display
adapterAvailable Parallel or USB portAvailable
1394 FireWire port (Optional)Available PCI or
PCMCIA slot (Optional)
7
Frequently Asked Questions (FAQ) WipWare makes
every effort to include up to date information
regarding the use and operation of our products
in the supplied manuals and help files, however
occasionally new issues develop that require
special attention. This area is updated regularly
to provide self serve answers to common
questions. I have upgraded my operating system to
Windows 2000/XP and now my WipWare Software
Product does not work, Do I need an
update?Windows 2000/XP users will need to
install the Rainbow Super Sentinel Pro license
key driver on their computer for WipWare Software
Products to work. This driver can be downloaded
here ftp//anonftp.rainbow.com/support/SSD5411-32b
it.exe
8
WipFrag Momentum Granulometry Analysis
SystemAutomated image analysis system provides
real-time particle size distribution of
unconsolidated material on conveyor belts.

• Blast models, formulas, expected results, we all
  know that this approach to predicting blast
  results is useless without the tool to quantify
  what really matters fragmentation. Our
  technologies root deep in the explosives
  industry, we understand the steps required to
  improve blast fragmentation, and the infinite
  number of variables which effect the results. Our
  technology empowers you with the tools you need
  to collect historical data, establish a
  statistical baseline and track subtle changes
  throughout the optimization process so you can
  make decisions based on fact, instead of theory.
  Other benefits of this technology are
• Reduce overbreak
• Reduce oversize fines
• Maximize use of explosive energy
• Improve process throughput
• Improve material digability

• Options
• Additional Camera
• Additional Lighting
• Additional Frame Grabber
• 4-20mA Card
• TTL-IO Card
• Radar Device
• RS422/485 Card
• Enhanced Workstation
• Fiber Optic Transmitter/Receiver
• Pre-manufactured Camera Frame
• Specialized Lighting Kit

9
WipFrag Reflex Granulometry Analysis
SystemAutomated image analysis system provides
real-time particle size distribution of
unconsolidated material on LHD/HD vehicles.

• Blast models, formulas, expected results, we all
  know that this approach to predicting blast
  results is useless without the tool to quantify
  what really matters fragmentation. Our
  technologies root deep in the explosives
  industry, we understand the steps required to
  improve blast fragmentation, and the infinite
  number of variables which effect the results. Our
  technology empowers you with the tools you need
  to collect historical data, establish a
  statistical baseline and track subtle changes
  throughout the optimization process so you can
  make decisions based on fact, instead of theory.
  Other benefits of this technology are
• Reduce overbreak
• Reduce oversize fines
• Maximize use of explosive energy
• Improve process throughput
• Improve material digability

10
MailFrag Online Analysis ServiceOur online
image analysis system provides quick results of
particle size distribution data from images sent
to us by you.
It does not always make sense to acquire a
WipWare system. A one time test, a student on a
budget or perhaps curiosity do not necessarily
warrant the purchase. This is where MailFrag
comes in. MailFrag is an online service that
allows you to send us your images, and we do the
analysis. Shortly after receiving the images, the
results are e-mailed back to you. The process is
quick, painless and affordable. If you have many
pictures to send, we can accept images on our
secure FTP site. WipFrag is second to none for
speed, accuracy, repeatability, objectivity and
cost. Let the leaders in the field provide
accurate easy to read reports. You have the
images, we have the answers! In only 4 easy
steps.
1 - Send us your images 2 - We do the analysis
3 - Usually Within 48 hours, we send you the
results by email 4 - A booklet of the printed
reports, project summary and invoice are mailed
to you.
How It Works One of our photoanalysis staff will
use the tried, tested and proven WipFrag software
to analyze the images sent to us. With over
10,000 MailFrag images performed, you can feel
confident that you will receive the most
objective accurate results possible.
11
