Title: Management of MANET Security Issues


1
Management of MANET Security Issues
  • Presenter Aqeel-ur-Rehman

2
Agenda
  • Introduction
  • Mobile Ad-Hoc Networks (MANET)
  • MANET Protocols
  • Research Trends
  • Security Challenges
  • Security Solutions
  • Summary
  • Conclusion and the Future
  • References

3
Introduction
Wireless Network
  • wireless communication does not have the
    constraint of physical cables
  • Different radio frequency (RF) spectrum ranges
    are used in wireless networks

4
Introduction
Wireless Technologies
5
Introduction
Types of Wireless Networks
  • According to the relative mobility of hosts and
    routers, there are three different types of
    wireless networks
  • Fixed Wireless Network
  • Wireless Network with Fixed Access Points
  • Mobile Ad hoc Network (MANET)

6
Introduction
Fixed Wireless Networks
  • Fixed hosts and routers use wireless channels to
    communicate with each other.

For Example wireless network formed by fixed
network devices using directed antennas, as shown
in Figure.
7
Introduction
Wireless Network with Fixed Access Points
  • Mobile hosts use wireless channels to communicate
    with fixed access points.

For Example Number of mobile laptop users in a
building that access fixed access points, as
illustrated in Figure.
8
Introduction
Mobile Ad hoc Network
  • A mobile ad hoc network is formed by mobile hosts.

For Example vehicle-to-vehicle and ship-to-ship
networks that communicate with each other by
relying on peer-to-peer routings, as shown in
Figure.
9
Introduction
Mobile Ad hoc Network
  • The MANET model is usually illustrated as shown
    in Figure.

Nodes i, j, and k are mobile nodes in the
network. The dashed circles shown in the figure
imply the radio coverage areas of nodes
10
Introduction
Mobile Ad hoc Network
  • Another kind of ad hoc network has fixed nodes
    having relatively static connectivity.

For Example A sensor network is typically a fixed
ad hoc network. Network components in a sensor
network are wireless sensors instead of
general-purpose computers
11
Mobile Ad-Hoc Networks
Characteristics and Complexities
  • Autonomous and infrastructure-less
  • Multi-hop routing
  • Dynamic network topology
  • Device heterogeneity
  • Energy constrained operation
  • Bandwidth constrained variable capacity links

12
Mobile Ad-Hoc Networks
Characteristics and Complexities
  • Limited physical security
  • Network scalability
  • Self-creation, self-organization and
    self-administration

13
Mobile Ad-Hoc Networks
Application
14
Mobile Ad-Hoc Networks
Application
15
MANET Protocols
Classification
  • Researchers traditionally classify Protocols as
  • Proactive Protocols
  • Reactive Protocols
  • Hybrid of the two, based on the way they find new
    routes or update existing ones.

16
MANET Protocols
Classification
  • Proactive routing protocols keep routes
    continuously updated,
  • while Reactive routing protocols react on demand
  • Routing protocols can also be classified as
  • Link State Protocols
  • more reliable, easier to debug and less
    bandwidth-intensive
  • Distance-Vector Protocols
  • more complex and more compute- and
    memory-intensive

17
MANET Protocols
Classification
  • Routers using a link state routing protocol
    maintain a full or partial copy of the network
    topology and costs for all known links.
  • Routers using a distance-vector protocol keep
    only information about next hops to adjacent
    neighbors and costs for paths to all known
    destinations.

18
MANET Protocols
Examples
19
(No Transcript)
20
Survey - 1
Research Trends
  • According to a survey of more than 1300 MANET
    related papers in IEEE/ IEE Electronic Library
    (IEL online) from 1998 to 2003, some of the
    issues like routing and power management
    attracted much attention of the researchers.
    Figure showing the trends for various issues
    (grouped in 15 categories) over the six year
    (1998 to 2003).

C. R. Dow, P. J. Lin, S. C. Chen, J. H. Lin,
and S. F. Hwang, A Study of Research Trends and
Experimental Guidelines in Mobile Ad-hoc
Networks, Proceedings of the 19th International
Conference (AINA 05), IEEE 2005.
21
Research Trends
22
Conclusion Survey 1
Research Trends
  • The Quantity of papers shows that the Routing,
    Power management and Bandwidth management are
    larger than the other issues
  • While the IP addressing and fault tolerance
    issues are very few in quantity.
  • These trends shows the maturity of some issues
    like routing and power management and the
    potential study value for IP addressing and fault
    tolerance.

23
Conclusion Survey 1
Research Trends
  • The growth rate for radio interface and the
    security are greater than the other issues.
  • Similarly the issues of mobility management and
    fault tolerance are also positive. It shows that
    these issues have more potential study values in
    the near future.

24
Survey - 2
Research Trends
  • Another survey that grouped the MANET issues in
    10 different categories showing the same trends
    as above.

Ramiro Liscano, Spontaneous Networking
Bridging the gap between ad hoc networking and ad
hoc communications, Wireless Industry Congress,
Ottawa, Canada, 2003.
25
Research Trends
26
Research Trends
27
Conclusion Survey 2
Research Trends
  • In above Figure, it is very much clear that
    quantity of papers in the basic networking issue
    is very high that shows the maturity and the
    research undergoing on that issue.
  • Analysis also showing that the service and
    security issue require more attention of the
    researchers i.e. this issue has more study
    potential in the future.

28
Issues in Ad Hoc Networks
Major Issues
29
Issues in Ad Hoc Networks
Major Issues
30
Security Challenges
What is Security?
  • Confidentiality
  • Integrity
  • Availability
  • Non-repudiation
  • Authenticity
  • Privacy (location, data, identity, existence)

31
Security Challenges
Challenges in Ad Hoc
  • Shared radio channel
  • Insecure environment
  • Lack of central authority
  • Lack of permanent association
  • Limited resources
  • Physical vulnerability

32
Security Challenges
Attacks on MANET
33
Security Solutions
Approaches
  • Security is not a single layer issue
  • But, it is a Multi-Layer/ Cross-Layer issue
  • HOW ??
  • To have comprehensive security we need
  • Protocol Security
  • Communication Security
  • Physical Security

34
Security Solutions
Approaches
  • To achieve above mentioned securities, many
    solution have been proposed and are under
    research
  • Major solutions are for
  • Protocol Security
  • Authentication and Key Management Schemes
  • Trust Management

35
Security Solutions
Protocol Security
  • Why we need Protocol Security ???
  • Answer Protocols were designed by assuming and
    expecting (not Enforced) that all nodes are
    cooperative
  • They are having inherent shortcomings that leads
    to the malicious activities

36
Protocol Security
Routing Protocol Attack???
  • Redirect traffic
  • Packet forwarding to wrong destination
  • Create routing loops
  • Network congestion and channel contention in
    certain area
  • Multiple colluding attackers may partition the
    network
  • Solution??? Secure Protocols

37
Protocol Security
Secure Protocols
  • Requirements
  • Detection of malicious nodes
  • Guarantee of correct route discovery
  • Confidentiality of network topology
  • Stability against attacks

38
Secure Protocols
Examples
39
Security Solutions
Authentication and Key Management Schemes
  • When we talk about Key Management
  • First we should know that where are the keys
    used???
  • CRYPTOGRAPHY
  • Study of principles, techniques and algorithms
    by which information is transformed into a
    distinguished version.
  • Four main goals of Cryptography
  • Confidentiality Authentication
  • Integrity Non-Repudiation

40
Security Solutions
Authentication and Key Management Schemes
  • Process of Encryption and Decryption is governed
    by the Keys
  • Key
  • Small amount of information used by the
    cryptographic algorithms
  • When a key is to be kept secret to ensure the
    security of the system, it is called a secret key
  • Key Management
  • The secure administration of cryptographic keys

41
Security Solutions
Authentication and Key Management Schemes
  • Keys can be Public and Private
  • Private Key Cryptography
  • Also Known as Symmetric Key Algorithm
  • Fast
  • Requires a secret key to be shared between the
    sender and the receiver

42
Security Solutions
Authentication and Key Management Schemes
  • Public Key Cryptography
  • Also Known as Asymmetric Key Algorithm
  • based on mathematical principles which make it
    infeasible or impossible to obtain one key from
    another
  • one of the keys can be made public while the
    other remains secret (private)

43
Security Solutions
Authentication and Key Management Schemes
  • Key Management Approaches
  • The primary goal of key management is to share a
    secret (some information) among a specified set
    of participants.
  • Examples
  • Password-Based Group System
  • Threshold Cryptography
  • Self Organized Public Key Management for MANETs

44
Security Solutions
Trust Management
  • Why and Where the Trust is needed???
  • In Ad Hoc network every node work as Router ?
    Forward Packets of other nodes
  • We need, first of all, the Trusted Users
    (authentic users) and Secondly we need that the
    users maintain their Trust (do not become the
    Selfish Node)
  • Different Solutions are proposed

45
Trust Management
Solutions
  • KPI (Key Pre-Distribution Infrastructure)
  • Trusting the Device instead trusting the owner
    (User)
  • Mobility Helps Security
  • Its simply mimic human behavior if people want
    to communicate each other, they just get close to
    each other in order to exchange information and
    establish mutual credential (they used secure
    channel like infrared or wire)

46
Trust Management
Solutions
  • SAFE (Secure pAcket Forwarding in ad hoc
    nEtworks)
  • Every node is responsible to monitor its
    neighbors
  • Reputation values are assigned based on the
    successful forwarding transaction (1, 0, -1)
  • Currency Based Solution (Nuglets)
  • Network is market where services are exchanged
  • Virtual economy where nodes pay for service
  • Currency nuglets
  • Only data packets require nuglets
  • Works with many protocols
  • Misbehavior not forbidden, only discouraged

47
Trust Management
Solutions
  • Token Based Cooperation Enforcement
  • Tokens
  • o Required to participate in a network
  • o Granted collaboratively by neighbors
  • o Need to be renewed
  • Mechanism components
  • o Neighbor verification
  • o Neighbor monitoring
  • o Intrusion reaction
  • o Security enhanced routing protocol

48
Summary
  • Classification of Wireless Networks
  • Available Wireless Technologies
  • MANET Characteristics, Complexities and
    Applications
  • MANET Protocols Classification
  • MANET Major Issues
  • Security Challenges and their available Solutions

49
Conclusion and the Future
  • Importance of MANET cannot be denied as the world
    of computing is getting portable and compact.
  • Unlike wired networks, MANET pose a number of
    challenges to security solutions due to their
    unpredictable topology, wireless shared medium,
    heterogeneous resources and stringent resource
    constraints etc.
  • Security is not a single layer issue but a
    multilayered issue
  • It requires a multi fence security solution that
    provides complete security spanning over the
    entire protocol stack

50
Conclusion and the Future
  • The Study of this important issue reveals that
    security is divided into different directions of
    the work like secure routing, key exchange,
    distribution and management, secure architecture,
    intrusion detection and protection etc.
  • The Security research area is still open as many
    of the provided solutions are designed keeping a
    limited size scenario and limited kind of attacks
    and vulnerabilities

51
Conclusion and the Future
  • As in wired network role definition has been very
    crucial in security, keeping the same idea in
    mind we can apply the role based security in
    MANETs.
  • Community based solution can be used in role
    specification. Under this scenario policy
    distribution techniques, grouping policy,
    membership management are the major areas to work
    on.
  • Agent oriented solutions are very useful in many
    areas. Similarly MANETs security can also be
    exploited due to its distributed nature.

52
References
  • Michal Grega, Jakub Jakubiak, Krzysztof Marcisz,
    Szymon Szott, Security in Ad Hoc Networks
  • H Yang, H Y. Luo, F Ye, S W. Lu, and L Zhang,
    Security in Mobile Ad hoc Networks Challenges
    and Solutions, IEEE Wireless Communications.
    February 2004.
  • Adam Burg, Seminar on Ad Hoc Network Specific
    Attacks
  • Tao Lin, Mobile Ad-hoc Network Routing
    Protocols Methodologies and Applications, Ph.D.
    Dissertation, Computer Engineering, Virginia
    Polytechnic Institute and State University,
    Blacksburg, Virginia, 2004.
  • Yacine Rebahi, Vicente .E Mujica-V, Cyprien
    Simons and Dorgham Sisalem, SAFE Securing pAcket
    Forwarding in ad hoc nEtworks, 5th Workshop on
    Applications and Services in Wireless Networks,
    ASWN 2005, June 29th - July 1st, 2005.
  • M. Ramkumar, N. Memon, KPI A Security
    Infrastructure for Trusted Devices,
    Pre-Conference. Workshop, 12th Annual Network and
    Distributed System Security Symposium, San Diego,
    California, 2 February 2005.
  • L. Buttyan, J. Hubaux, Stimulating Cooperation
    in Self-Organizing Mobile Ad Hoc Networks, ACM
    Journal for Mobile Networks, Special Issue on
    Mobile Ad Hoc Networking, 2002.

53
References
  • H. Yang, X. Meng, S. Lu, SCAN Self-Organized
    Network-Layer Security in Mobile Ad-Hoc
    Networks, IEEE Journal on selected areas in
    Communications, February 2006.
  • C. R. Dow, P. J. Lin, S. C. Chen, J. H. Lin, and
    S. F. Hwang, A Study of Research Trends and
    Experimental Guidelines in Mobile Ad-hoc
    Networks, Proceedings of the 19th International
    Conference (AINA 05), IEEE 2005.
  • Srdjan Capkun, Jean-Pierre Hubaux, Levente
    Buttyan, Mobility Helps Security in Ad Hoc
    Networks, Fourth ACM International Symposium on
    Mobile Ad Hoc Networking and Computing,
    Annapolis, Maryland, USA, June 1-3, 2003.
  • Jeroen Hoebeke, Ingrid Moerman, Bart Dhoedt and
    Piet Demeester, An Overview of Mobile Ad Hoc
    Networks Applications and Challenges, 2005.
  • Ramiro Liscano, Spontaneous Networking Bridging
    the gap between ad hoc networking and ad hoc
    communications, Wireless Industry Congress,
    Ottawa, Canada, 2003.

54
  • Thank you for your
  • Patience and Attention

55
Routing Protocol Attack
Examples
  • In DSR
  • Deletion of Node
  • Switching the order of appending new node in the
    list
  • Modification of the source route listed in the
    RREQ or RREP (i.e. Rushing Attack)

56
Routing Protocol Attack

Examples
  • In AODV
  • Make change in distance metric
  • Advertising routing updates with large sequence
    numbers and invalidate all other routing updates

57
Attacks on MANET
Impersonation
58
Attacks on MANET
Wormhole
59
Attacks on MANET
Rushing
60
Attacks on MANET
DoS and Flooding
61
Security Challenges
Attacks Classification
62
Security Solutions

Threshold Cryptography
  • Group-sharing private key system, where the
    groups cooperation is required to perform
    cryptography
  • (n,t1) threshold cryptography Shamirs
    scheme
  • Whole service has a public/private key pair K/k
  • All nodes know K, and trust certificates signed
    with k
  • k is divided into n shares
  • k1 k2 kt kt1 -gt k
  • Any subset of up to k - 1 shares does not leak
    any information on the secret.
  • Shamirs scheme is perfectly secure and does not
    depend on the computational power of any party.
Write a Comment
User Comments (0)
About PowerShow.com
