Installing and Upgrading Windows

1
Installing and Upgrading Windows

• Chapter 6

2
Overview

• In this chapter, you will learn to
• Explain the installation and upgrade process of
  Windows
• Install and upgrade Windows 9x/Me
• Install and upgrade Windows 2000 Professional
• Install and upgrade Windows XP Professional
• Troubleshoot common installation problems

3
Windows Installation /Upgrade Overview
4
Identify Hardware Requirements

• Requirements
• CPU model
• Amount of RAM memory
• Amount of free hard disk space
• Video adapter
• Display
• Other storage devices

• Minimums
• Absolute minimums
• Recommended minimums

5
Hardware Software Compatibility

• Hardware Compatibility List (HCL)
• www.microsoft.com/whdc/hcl/search.mspx
• If your hardware or software does not appear on
  the HCL, dont panic
• Check the hardware or software manufacturers
  website for compatible drivers or versions
• You should always try to get the latest version
  of all drivers and software from the
  manufacturers website

6
Windows Hardware and Driver Central
7
Clean Installation or Upgrade?

• Clean installation is an installation onto an
  empty hard drive
• All applications will need to be reinstalled and
  reconfigured
• Multi-boot installations
• System partition must be formatted in a file
  system common to all installed OSs
• Install in order of vintageoldest to newest
• Except that you can install NT after any version
  of 9x/Me
• Upgrade installation is on top of an earlier
  version

8
Taking Care of Data

• Determine how to backup and restore existing data
  if necessary
• Any data stored on the local hard drive needs to
  be backed up before performing the installation
• Data may be backed up to a network drive, a Zip
  disk, burned to a CD, backed up to a tape.

9
Select an Installation Method

• Bootable CD or Boot Floppy
• Bootable diskettes for Windows XP?
• Check Microsofts Knowledge Base at
  support.microsoft.com and search for article
  310994
• Other installation methods
• Off the network
• Manual (attended) or scripted (unattended or
  automatic)
• Using an image
• Nortons Ghost (Symantec)
• PowerQuests Drive Image
• Acronis True Image
• Phoenix ImageCast
• Windows 2000 Server Remote Installation Services
  (RIS)

10
Partitioning and File Systems

• Determine how you want to partition your hard
  drive
• Determine what file system you would like to use
• Consider compatibility with other OSs
• If you are planning a multi-boot, use a file
  system that all of the OSs can understand on
  drive c

11
Determine Your Computers Network Role

• Standalone
• Computer does not participate on a network
• Workgroup
• Computer participates with a select group of
  other computers on the network, such as within a
  users department
• Domain
• Computer participates on a much wider scale
  across the network

12
Language and Locale

• Decide on your computers language and locale
  settings

13
Performing the Installation/Ugrade

• Text mode is the first part of the installation
  or upgrade process
• Inspects the hardware
• Displays the End User License Agreement (EULA)
• Partition hard drive
• Copies needed files for the next mode
• Reboots
• Graphical mode begins the graphical portion of
  setup
• Product key required write it on the
  CD itself with a Sharpie so you dont
  loose it

14
Post Installation Tasks

• Service packs are the result of bundling a number
  of previously released patches
• Patches fix issues or bugs in the operating
  system and frequently add better security
• Updated drivers
• Always check for updated drivers the ones that
  came on the CD are almost never the latest
• Updates
• Reinstallation of any applications
• Restore data

15
Installing and Upgrading Windows 9x/Me
16
Preparing to Upgrade/Install

• Determine the minimum hardware requirements for
  Windows 9x
• Check the Microsoft hardware compatibility list
  (HCL)
• Run an antivirus utility and save any data when
  upgrading Windows

17
Preparing to Upgrade/Install

• Ensure availability of a setup disk or a bootable
  CD-ROM (CMOS permitting) depending upon the
  Windows 9x version you want to install
• The Setup Disk may be used to partition and
  format the drive as required before Windows will
  install
• Use the correct version of the CD-ROM full or
  Upgrade
• Decide the type of partition to be used FAT16
  or FAT32

18
Installing vs. Upgrading

• Upgrading
• A clean install requires partitioning and
  formatting of the drive
• The FDISK utility can be used to partition a
  drive
• Windows provides a Drive Converter utility for
  converting from FAT16 to FAT32 without loss of
  data
• CVT at the command prompt or
  CVT1 in Windows

Start ?Programs ?Accessories ?System Tools
?Drive Converter
19
The Install/Upgrade Process

• The Install and Upgrade processes become
  virtually identical once the blank drive is
  formatted
• The SETUP.EXE program from the CD-ROM is used for
  a clean installation

Its a good idea to copy the contents of the
\WIN9x folder from the CD-ROM to a folder on the
hard drive. Installation goes faster and you
wont need to find the CD-ROM later when Windows
asks for it due to configuration changes.
20
The Install/Upgrade Process

• Text Mode
• ScanDisk runs and a check for video and a mouse
  is done
• A few critical files are loaded
• Graphical Mode starts Install Setup Wizard
• See the following screens

21
Setup Options
22
Product Key
23
Choosing the Directory
If you are upgrading from Win95, you must use the
same directory that Win95 used.
24
Win98 Installation Steps Concluded

• Prompt to make a Startup disk
• Prompt for network options
• Opportunity to save the Win95 files if upgrading
• Then the long copying process
• Hardware detection

25
Installing Windows NT 4.0 Workstation
26
Installing Windows NT 4.0 Workstation

• Large installed base at companies
• Usually installed on older machines at this point
• Note PnP
• Check the Hardware Compatibility List (HCL)
• On the CD in the SUPPORT folder as HCL.HLP
• On Microsofts web site
• Or run the NT Hardware Qualifier (NTHQ) on the
  install CD in \SUPPORT\HQTOOL folder
• Use MAKEDISK.BAT to create a bootable disk

27
Installing Windows NT 4.0 Workstation

• NT supports FAT (FAT16) and NTFS4 file systems
• Use NTFS if possible
• Assumes you are part of a network
• Patch it as soon as you install it use Service
  Pack 6a

28
Hardware Requirements
29
Installing and Upgrading to Windows 2000
Professional
30
Preinstallation Tasks

• Identify hardware requirements
• Determine whether your hardware is on the
  Hardware Compatibility List (HCL)
• Determine disk partitioning
• Choose a file system
• Determine whether your computer will join a
  workgroup or a domain
• Complete a checklist

31
Hardware Requirements
32
Hardware Compatibility List

• List of supported devices
• Tested drivers supplied for devices on HCL
• \Support\HCL.txt or http//www.microsoft.com

33
Hardware and Software Compatibility
34
Disk Partitions

• Setup checks for an available partition
• If the hard disk is not partitioned, create and
  size the Microsoft Windows 2000 partition
• If the hard disk has an existing partition that
  is large enough, you can use that existing
  partition
• If the hard disk has an existing partition, you
  can delete it and create a suitable partition

35
File Systems Notes

• The only reason to use FAT or FAT32 is for dual
  booting
• Only NT or Windows 2000 can access an NTFS
  partition
• Partitions smaller than 2 GB are formatted FAT
• Partitions larger than 2 GB are formatted FAT32
• NTFS 5 includes disk quotas, file and folder
  encryption, and Dynamic disk configurations

36
Networking Options

• By default Windows 2000 installs
• Client for Microsoft Networks
• File and Printer Sharing for Microsoft Networks
• Internet Protocol (TCP/IP)
• Workgroup or Domain

37
Language and Locale Settings

• Windows supports many languages, keyboard
  layouts, currency, time/date display, and
  numbering

38
Installing and Upgrading to Windows XP
Professional
39
Upgrade Paths

• Windows 98 (all versions)
• Windows Millennium Edition
• Windows NT 4.0 Workstation (SP5 and later)
• Windows 2000 Professional
• Windows XP Home Edition

40
Windows XP Hardware Requirements
41
Hardware and Software Compatibility

• Windows Catalog
• Go to www.microsoft.com/windowsxp/compatibility/
  and select the Discover the Windows Catalog link
• Upgrade Advisor
• Insert the Windows XP CD and type setup.exe
• Select Check System Compatibility
• Then Check My System Automatically

42
Booting into Windows XP Setup

• All Windows XP CDs are bootable
• Microsoft does not include a way to create bootup
  diskettes
• If you need them, youll need to access
  Microsofts website to create the six diskettes
  youll need

43
Registration versus Activation

• Registration is still optional
• Giving Microsoft your name, address, company,
  phone number, and so forth
• Microsoft Product Activation
• Mandatory
• You will have 30 days from the date of
  installation
• After that the OS will disable itself
• You will receive numerous reminders to activate
  your OS

44
Microsoft Product Activation
45
Windows XP Installation Text Mode
46
Windows XP Installation Graphical Mode
47
Troubleshooting Installation Problems
48
Text Mode Errors

• No Boot Device Present When Booting Off the
  Startup Disk
• Bad startup disk or CMOS is not set to boot off
  floppy
• Windows Has Detected That Drive C Does Not
  Contain a Valid FAT Partition
• Either you forgot to partition the drive or you
  have a drive formatted in a file system the OS
  does not understand
• Windows Setup Requires XXXX Amount of Available
  Drive Space
• Not enough hard drive space or you forgot to
  format the drive

49
Text Mode Errors

• MSCDEX Error No CD-ROM Detected
• CD-ROM driver settings are messed up
• Not Ready Error on CD-ROM
• Damaged CD or maybe the CD is just not ready yet
  (retry)
• A Stop Error (Blue Screen of Death) after the
  reboot at the end of text mode
• Most likely a hardware compatibility issue or
  BIOS
• Check Microsofts knowledge base article 165863

50
Graphical Mode Errors

• Hardware Detection Errors
• Hardware compatibility issue if its not a
  critical device youll be able to come back to it
  later
• Cant Read CAB Files
• CAB (cabinet) files are compressed files with
  .cab extension
• CD may be scratched try copying the i386
  directory to the hard drive and running setup
  from there
• This System Already Has An OS
• Occurs when trying to us a full version Win98 CD
  to upgrade Win95 just rename the following
  files in the system folder and restart setup
• Setupx.dll to setupx.ol1
• Setupx.w95 to setupx.ol2

51
Graphical Mode Errors

• Lockups During Install
• Usually happens only during hardware detection
• Unplug the PC, then plug it back in and try again
  go into Safe Recovery mode which completes the
  installation with only the most critical hardware
• Bad CD-ROM or hard drive

52
Windows XP Log Files

• Setuplog.txt tracks the complete installation
  process
• Detlog.txt tracks the hardware detection process
• Bootlog.txt tracks the boot process

53
(No Transcript)
