'NET Mobile Application Development Concurrency in Distributed Clients

1
.NET Mobile Application DevelopmentConcurrency
in Distributed Clients
2
Introduction

• Concurrency occurs in all distributed systems
• Controlling concurrency is essentially to
  developing scalable, correct distributed
  applications
• In this session and the next we will consider
• Multi-threading and concurrency
• Concurrency in distributed clients
• Concurrency control mechanisms

3
Concurrency in Distributed Applications

• Distributed applications are inherently
  concurrent
• Services have to deal with multiple simultaneous
  clients in a scalable manner
• Clients may need to perform multiple simultaneous
  activities
• Accept user input and use services
• Concurrency needs to be used and managed
  correctly to avoid
• Performance penalties
• Incorrect operation and sequencing of activities

4
Concurrency in Distributed Clients

• Concurrency is mainly used in distributed clients
  to overcome latencies resulting from distributed
  interactions
• This has several benefits
• Increased client performance
• Client can perform other activities / processing
  whilst remote interactions proceed
• Increased client responsiveness and improved user
  experience
• User interface does not freeze when remote
  interactions or lengthy computations occur
• Application responds to user input in a timely
  manner

5
Multithreading

• Thread
• An independent unit of program execution
• Multithreaded program
• Multiple threads execute simultaneously
• Threads multiplexed onto available CPUs using
  timeslicing
• Context switch incurs (minor) overhead
• Threads exist in the same process and share
  common address space
• Multithreading
• can improve performance only when there is an
  operation with some latency
• the longer the delay, the greater the potential
  performance benefit from using threads
• will not improve performance if threads are
  competing for finite (e.g. CPU) resources
  multithreading will actually result in worse
  performance

6
Threading Issues

• Multithreading can improve performance
• Multithreading will introduce
• additional complexity
• unusual errors that are difficult to detect,
  replicate and debug
• additional overhead OS must manage all the
  threads
• Getting threading right is difficult need to
• use synchronization and locking to ensure correct
  interleaving of thread operations and
  interactions
• balance potential improvements from threading
  against additional overheads (number of threads)
• avoid deadlock, livelock, race conditions, etc
  caused by incorrect / insufficient / too much
  synchronization

7
Threading in .NET

• Can use threads in .NET by
• Using .NET types with built-in threading support
• Types that support asynchronous operation (i.e.
  has Begin? and End? methods)
• Windows forms types through the Invoke() method
• Manually creating and manipulating threads using
  the System.Threading.Thread type

8
Using Asynchronous Delegates

• A delegate is
• a type-safe pointer to a method (function
  pointer)
• an instance of the Delegate type
• Delegate type has two important methods
• BeginInvoke()
• invokes the method referred to by the delegate on
  a separate thread
• immediately returns an IAsyncResult instance and
  allows calling thread to continue
• EndInvoke()
• allows retrieval of results from a method invoked
  earlier using BeginInvoke()
• needs to be given IAsyncResult instance returned
  by BeginInvoke()

9
Asynchronous Delegate Example

• delegate int MyDelegate(int i, int j)
• class Program
• public static void Main()
• Maths m new Maths()
• // Create the delegate - note that BeginInvoke
  always takes 2 extra parameters
• MyDelegate dlgt new MyDelegate(m.Add)
• // Asynchronosly invoke it
• IAsyncResult iar dlgt.BeginInvoke(2, 2, null,
  null)
• // Do something else whilst call progresses
• // Wait for async method to complete and
  retrieve the results
• int result dlgt.EndInvoke(iar)
• class Maths

• Criticisms
• EndInvoke() call blocks if method invoked by
  delegate not yet completed
• Can poll for completion using the IAsyncResult
  instance
• Neither option is good

10
Using Callbacks

• Callback
• method called when an asynchronously invoked
  delegate completes its operation
• Callbacks
• eliminate inefficient polling
• simplify coding
• Callback method
• signature must match System.AsyncCallback
  delegate type
• AsyncCallback instance referencing desired
  callback method must be passed to BeginInvoke()
• callback is passed an IAsyncResult object when it
  is invoked
• use this to call EndInvoke() and retrieve results

11
Asynchronous Callback Example

• delegate int MyDelegate(int i, int j)
• class Program
• static MyDelegate dlgt
• public static void Main()
• Maths m new Maths()
• AsyncCallback cdlgt new AsyncCallback(MyCallbac
  k)
• dlgt new MyDelegate(m.Add)
• // Penultimate BeginInvoke() parameter is
  callback delegate
• IAsyncResult iar dlgt.BeginInvoke(2, 2, cdlgt,
  null)
• Console.ReadLine() // Do something else
• public static void MyCallback(IAsyncResult
  iar)
• int result dlgt.EndInvoke(iar) // Use
  IAsyncResult instance to retrieve the results

• NOTE
• Callback method executes on yet another thread

12
Advantages of Asynchronous Invocation

• Implicitly using threads by using asynchronous
  invocation has several advantages
• environment takes care of creating and managing
  all threads for us
• no need for explicit concurrency control
  operations
• improves performance by enabling long-running
  tasks to be started without stalling application
• Asynchronous invocation not suitable for
• code which needs to communicate between threads
• applications which need to prioritize threads
• this requires manual thread creation

13
Creating .NET Threads

• Threads are created by
• declaring a method which will be the body of the
  thread
• must be of return type void and accept no
  parameters
• can call any other methods
• creating a ThreadStart delegate instance which
  refers to this method
• creating a new Thread object, passing it the
  delegate
• calling Thread.Start()
• System.Threading.Thread
• is the primary type used for managing threads
• allows threads to be created, started, stopped,
  suspended, resumed, joined, delayed, etc

14
Custom Threading Example

• class Program
• public static void Main()
• // Create the threads
• Thread tA new Thread(new ThreadStart(TaskA))
• Thread tB new Thread(new ThreadStart(TaskB))
• tA.Start() // Start the threads
• tB.Start()
• Console.ReadLine() // Pause until user
  presses key
• private static void TaskA()
• for (int i 0 i lt 10 i)
• Console.WriteLine("Task A at "i)
• WasteTime(1000)
• private static void TaskB()
• for (int i 0 i lt 10 i)

15
Thread Priorities

• Threads are selected for execution based on their
  priority
• highest priority execute first, lowest priority
  last
• All threads created equally with default normal
  priority
• priority can be adjusted via Thread.Priority
  property
• five relative priority levels supported
• Lowest, Below Normal, Normal, Above Normal,
  Highest
• Setting thread priorities correctly is important
• giving a thread too high a priority can lead to
  starvation of other threads

16
Thread Priority Example

• class Program
• public static void Main()
• Thread tA new Thread(new ThreadStart(TaskA))
• Thread tB new Thread(new ThreadStart(TaskB))
• tA.Priority ThreadPriority.AboveNormal
  tB.Priority ThreadPriority.Normal
• tA.Start() tB.Start() // Start the threads
• Console.ReadLine() // Pause until user
  presses key
• private static void TaskA()
• for (int i 0 i lt 10 i)
• Console.WriteLine("Task A at "i)
• WasteTime(1)
• private static void TaskB()
• for (int i 0 i lt 10 i)

17
Threaded Clients

• Any operation which will take a long time to
  complete or adversely affect application
  responsiveness is a good candidate for executing
  on a separate thread
• e.g. Windows Media Player 9
• Info Center View takes time to retrieve data from
  the Internet
• executing this on separate thread from user
  interface allows user to control playback in the
  meantime
• when data is returned from Internet, UI can be
  appropriately updated

18
User Interfaces in .NET Threaded Clients

• Windows Forms controls in a .NET application
• are not thread safe
• can only be safely operated upon by the thread
  which owns them
• Consider the Windows Media Player example with a
  thread which fetches data from the Internet. This
  thread
• is separate from the UI thread
• should not update the applications UI as it is
  not the owner of the UI controls

19
Win Forms and Threading

• Windows.Forms.Control base class provides an
  Invoke() method which is passed a delegate to
  another method
• Delegate must be of type MethodInvoker
• Delegated method acts as a callback used to
  update the relevant control
• Calling Invoke() causes the delegated update
  method to be safely invoked on the User Interface
  thread which owns the control

20
WinForms Threading Example

• Simple Form application with two threads
• UI thread created by Application.Run()
• separate thread used to periodically increments
  counter
• button controls operation of counter thread
• UIUpdater() displays latest count value in
  lblCount Label
• Counter thread
• creates delegate to UIUpdater()
• calls lblCount.Invoke() with this delegate each
  time it wishes to update the count value in the UI

21
Concurrency Control

• Two key aspects to concurrency control
• Mutual exclusion
• Preventing object / resource from being accessed
  by more than one thread at once
• Needed to prevent corruption of state in presence
  of multiple client updates
• Implemented through locking
• Synchronization
• Imposes order on interleaving of operations of
  multiple threads (usually for correctness)
• Implemented using semaphores, condition variables
  or monitors

22
Condition Synchronization

• Needed when a thread wishes to perform an
  operation which can only sensibly(safely) be
  performed if another thread has itself taken some
  other action or is in some defined state
• Example A bounded buffer has 2 condition
  synchronization
• producer thread must not attempt to put data in
  buffer if it is full
• consumer thread must not attempt to get data from
  buffer if it is empty
• Is mutual exclusion necessary?

23
Locks and Mutual Exclusion

• Critical Section - a sequence of statements that
  appear to execute indivisibly
• Mutual Exclusion - synchronization required to
  protect a critical section
• Locks - implement mutual exclusion and guard
  critical sections
• Code construct which marks a critical section of
  code that must be executed under mutual exclusion

24
Locking

• In an OO environment, every object has an
  associated lock
• Lock construct specifies the object on which the
  lock should be obtained
• First thread to execute the lock statement will
  be granted the lock and can execute protected
  section of code
• Whilst first thread has the lock, any other
  threads executing the lock statement will block
  until lock is released. Waiting threads will then
  compete for the lock.

25
Example Locking in C

• int Withdraw(int amount)
• lock (this)
• if (balance gt amount)
• Console.WriteLine("Balance before Withdrawal
  " balance)
• Console.WriteLine("Amount to Withdraw
  -" amount)
• balance balance - amount
• Console.WriteLine("Balance after
  Withdrawal " balance)
• return amount
• else
• return 0 // transaction rejected

26
Locking - Disadvantages

• Locking is essential to preventing conflicting
  updates but can adversely affect performance
• If scope of lock is too great
• forces some threads to wait
• decreases potential concurrency and throughput /
  performance
• If scope of lock is too small
• forces reacquisition of locks, leading increased
  lock contention and reduced throughput /
  performance
• can result in difficult-to-debug race conditions

27
Advanced Locking

• Mutual exclusion
• not needed if all threads are reading values
• needed if at least one thread is writing values
• ReaderWriter lock
• allows concurrent read access for multiple
  threads, or
• write access for a single thread
• uses separate locks for readers and writers
  clients must specify which lock they want

28
Advanced Locking Example

• ReaderWriterLock rwl new ReaderWriterLock()
• void ReadFromResource(int timeOut)
• try
• rwl.AcquireReaderLock(timeOut)
• try
• / Safe for this thread to read from
• // the shared resource.
• finally
• // Ensure that the lock is released.
• rwl.ReleaseReaderLock()
• catch (ApplicationException)
• // The reader request timed out.

void WriteToResource(int timeOut) try
rwl.AcquireWriterLock(timeOut) try
// It is safe for this thread to read
// or write from the shared
resource. finally //
Ensure that the lock is released.
rwl.ReleaseWriterLock()
catch (ApplicationException) // The
writer lock request timed out.
29
Monitors

• Monitor
• code construct that provides both mutual
  exclusion and condition synchronization
• acts like a smart lock
• Thread enters the monitor and attempts to acquire
  lock
• if successful, thread executes under mutual
  exclusion thread frees lock when finished
• if unsuccessful, thread blocks until monitor is
  available

30
Monitors Condition Synchronisation

• When inside a monitor, condition variables can be
  used
• Thread can Wait() on condition variable
• thread blocks and releases lock, freeing monitor
  to other threads
• when condition becomes true, thread unblocks,
  reacquires lock and executes under mutual
  exclusion
• Thread can Signal() a condition variable
• notifies waiting threads that condition is true
• teleases lock, freeing monitor to other threads

31
.NET Monitors Example

• public class MyClass
• private object x
• public void DoSomething()
• Monitor.Enter(x)
• try
• // Code that needs protected by the
  monitor.
• // Monitor.Wait and Monitor.Pulse can be
• // used in here
• finally
• // Ensure that you exit Monitor.
• Monitor.Exit(x)

32
Common Concurrency Problems

• Two common problems
• Deadlock
• A situation where two or more threads are unable
  to proceed because each is waiting for the others
  to do something
• Avoid by
• always acquiring / releasing locks in the same
  order
• ensuring that all Wait()s have a matching
  Signal()
• Race Conditions
• Anomalous behaviour due to unexpected critical
  dependence on the relative ordering of operations
• Can occur is scope of locks is too small and some
  code left outside critical sections
• These problems are
• Easy to unwittingly introduce
• Difficult to detect and remove

33
Summary

• In this session we have discussed
• The role of concurrency in distributed clients
• Multi-threading and thread management in .NET
• Asynchronous invocation and callback
• Locks, monitors and performance
• Alternative thread coordination mechanisms

34
Reading and Resources

• Reading
• Coulouris, Dollimore Kindberg, Distributed
  Systems Concepts and Design, 3rd Edition,
  Addison-Wesley, 2001
• Chapter 12, pp 465 514
• MacDonald, Microsoft .NET Distributed
  Applications Integrating XML Web Services and
  .NET Remoting, Microsoft Press, 2003
• Chapter 6, pp 175 220
