Digital Image Processing

1
Digital Image Processing

• Chapter 9

2
Chapter 9Morphological Image Processing

• Mathematical morphology
• A useful tool for extracting image components in
  the representation of region shape.
• Boundaries, skeletons, and convex hull.
• Set theory is usually used to describe
  mathematical morphology.
• Sets represent objects in a binary image.
• Black representing object, denoted by 1.
• White representing background , denoted by 0.

3
9.1 Preliminaries

• Our interest in this chapter is sets in Z2, where
  each element denotes the coordinates of an object
  pixel.
• If a(a1, a2), we write if a is an
  element in A.
• if a is not an element in A.
• The null or empty set is denoted by .
• We use braces, , to specify the content of a
  set. For example, Cww-d, for .

4
Operations of Sets
5
Additional Definitions

• Translation
• Reflection

6
9.1.2 Logic Operations Involving Binary Images

• The logic operations discussed in this section
  involve binary images.
• Black pixel 1.
• White pixel 0.

Note logic operations are restricted to binary
variables, which is not the case in general for
set operations.
7
Logic Operations Involving Binary Images
8
9.2 Dilation and Erosion

• These two operations are fundamental to
  morphological processing.
• Dilation to enlarge an object along its
  boundary.
• Erosion to shrink an object into a smaller size.

9
9.2.1 Dilation

• With A and B are sets in Z2, the dilation of A by
  B, denoted A B, is defined as
• A B
• Other interpretation A B
• B is commonly referred to as the structuring
  element.
• The dilation of A by B is the set of all
  displacements, z, such that the reflection of B
  and A overlap by at least one element.

10
The Illustration of Dilation
11
The Implementation of Dilation

• Given a binary image f and the structuring
  element s, construct a duplicate of f, denoted by
  g.
• For each pixel p f(x, y), do the following
• If p is black
• If p is at the boundary (any of the 4-adjacent
  neighbors is white) of the object, center the
  origin of s at (x, y) in g, and fill the pixels
  black on which s covers.
• Return g.

12
Application of Dilation

• One of the simplest applications of dilation is
  for bridging gaps.

13
9.2.2 Erosion

• With A and B are sets in Z2, the dilation of A by
  B, denoted A B, is defined as
• A B
• The erosion of A by B is the set of all points z
  such that B, translated by z, is contained in A.

14
The Implementation of Dilation

• Given a binary image f and the structuring
  element s, construct a duplicate of f, denoted by
  g.
• For each pixel p f(x, y), do the following
• If p is white
• If p is adjacent to the boundary of the object,
  center the origin of s at (x, y) in g, and fill
  the pixels white on which s covers.
• Return g.

15
Application of Dilation

• One of the simplest uses of erosion is for
  eliminating irrelevant detail (in terms of size)
  from a binary image.

Note that objects are represented by white
pixels, rather than by black pixels.
16
9.3 Opening and Closing

• Opening to break narrow isthmuses and to
  eliminate thin protrusions.
• Closing to fuse narrow breaks and long thin
  gulfs, to eliminate small holes, and to fill gaps
  in the contour.

17
(No Transcript)
18
Illustration of Opening and Closing
19
Example 9.4 Application of Opening and Closing
20
9.4 The Hit-or-Miss Transformation

• The morphological hit-or-miss transform is a
  basic tool for shape detection or pattern
  matching.
• Let B denote the set composed of X and its
  background.
• B (B1, B2), where B1X, B2W-X.
• The match of B in A, denoted by A B, is

To find objects that may contain X
To find objects that may be contained in X
21
The Hit-or-Miss Transformation

• Other interpretation
• If B is 3x3, the matching can be done directly
  rather than computing the background image.

22
9.5 Some Basic Morphological Algorithms

• Boundary extraction
• Region filling
• Extraction of connected components
• Convex Hull
• Thinning
• Skeletons
• Pruning

23
9.5.1 Boundary Extraction

• The boundary of a set A, denoted by ß(A), can be
  obtained by first eroding A by B and then
  performing the set difference between A and its
  erosion.

24
Example 9.5 Boundary Extraction

• Binary 1s are shown in white and 0s in black.
• Using 5x5 structuring element would result in a
  boundary between 2 and 3 pixels thick.

The structuring element in this example is 3x3
therefore, the boundary is one pixel thick.
25
9.5.2 Region Filling

• Goal given a point p inside the boundary (Fig.
  (a)), fill the entire region with 1s.
• Let X0 p. The filled set Xk can be obtained by

26
The Procedure of Region Filling

• The algorithm terminates at iteration step k if
  XkXk-1.
• The result is obtained from the union of Xk and
  the boundary in A.

27
9.5.3 Extraction of Connected Components

• Goal given a point p, find the component that
  connects to p.
• Let X0 p. The set Xk can be obtained by
• The algorithm terminates at iteration step k if
  XkXk-1.
• The result Y is obtained from Xk.

28
The Procedure of Finding Connected Components
29
Example 9.7
30
9.5.4 Convex Hull

• A set A is said to be convex.
• If the straight line joining any two points in A
  lies entirely within A.
• The convex hull H of a set S is the smallest
  convex set containing S.
• The set H-S is called the convex difference,
  which is useful for object description.
• The procedure is to implement the equation
• With Xi0A. Let DiXiconv, where conv indicates
  that XikXik-1. The convex hull of A is

31
Convex Hull
32
Limiting Growth of Convex Hull
33
9.5.5 Thinning

• The thinning of a set A by a structuring element
  B, denoted A B, is defined by
• Each B is usually a sequence of structuring
  elements
• B1, B2,are different rotated versions of B.
• The result of thinning A by one pass is the union
  of the results obtained by thinning by Bi by one
  pass.

34
Thinning Procedure
35
9.5.6 Thickening

• The thickening of a set A by a structuring
  element B, denoted A B, is defined by
• A more efficient scheme is to obtain the
  complement of A, say Ac, and then to compute Cc,
  where C is the thinned result of Ac and Cc is its
  complement.

36
9.5.7 Skeletons

• The dot line the skeleton of A, S(A).

37
The Procedure of Skeletonization
38
9.5.8 Pruning
spur
39
The Procedure of Pruning

• Thinning an input set A to eliminate the short
  line segment by
• To restore the character to its original form
• Find the set containing all the end points by
• Dilate the end points and find the intersection
  with A
• The union of X3 and X1 yields the desired result


40
9.6 Extensions to Gray-Scale Images

• Dilation
• Let Df and Db be the domains of f and b, where b
  is the structuring element.
• The dilated image tends to be brighter.
• The dark details either reduce or eliminated,
  depending on their values and shapes relate to
  the structuring element.
• Erosion
• The eroded image tends to be darker.
• The bright details either reduce or eliminated.

41
Example 9.9
42
9.6.3 Opening and Closing
43
Example 9.10

• In (a), the decreased sizes of the small, bright
  details, with no appreciable effect on the darker
  gray levels.
• In (b), the decreased sizes of the small, dark
  details, with relatively little effect on the
  bright features.

44
9.6.4 Applications of Gray-Scale Morphology

• Morphological smoothing
• i.e. performing opening followed by a closing.
• Morphological gradient
• Let g denote the operation, and then
• Depending less on edge directionality.

45
9.6.4 Applications of Gray-Scale Morphology

• Top-hat transformation

46
9.6.4 Applications of Gray-Scale Morphology

• Textural segmentation
• Use closing operation to eliminate the left half.
• Apply opening to restore and join the right half.
• Threshold the result to draw the boundary.

47
9.6.4 Applications of Gray-Scale Morphology

• Granulometry (????)
• Apply opening with different sizes of structuring
  elements.
• Calculate image difference.
• Draw the histogram to evaluate the difference
  with respect to various sizes of structuring
  elements.
• For some x, particles with similar size of x have
  higher responses in the histogram.
