Title: Entrega Project Update


1
Entrega Project Update
Entrega Gas Pipeline Inc. www.entregapipeline.com
  • Wyoming Natural Gas Pipeline Authority August
    30, 2005

2
Agenda
  • Entrega Project Update
  • Project and Facilities
  • Milestones and Schedule
  • Interconnects and Capacity
  • Access to Markets
  • Wrap-up

3
Wamsutter Compressor Station
Segment 2 Wamsutter to Cheyenne Hub 191 miles of
42-inch pipe
Big Hole Compressor Station
Meeker Compressor Station
Segment 1 Meeker to Wamsutter 136 miles of
36-inch pipe
4
Project Description
  • Entrega is a new open access natural gas pipeline
    developed to move Rocky Mountain gas production
    to Midwest markets
  • FERC regulated interstate pipeline developed
    with cooperation of Bureau of Land Management and
    other Federal and State Agencies
  • Runs from Meeker Hub in Rio Blanco County, CO
    through Wamsutter, WY to the Cheyenne Hub near
    Rockport, CO
  • FERC certificate includes capacity of 1,500
    MMcf/d, developed in 2 phases
  • Phase 1 approximately 750 MMcf/d (free flow)
  • Phase 2 incremental 750 MMcf/d (compression)

5
Description of Facilities
  • Project includes 136 miles of 36-inch pipeline
    and 191 miles of 42-inch pipeline
  • Maximum Allowable Operating Pressure (MAOP) of
    the system is 1,480 psig
  • Route chosen to minimize environmental impact
    94 is adjacent to existing pipeline and utility
    right-of-way
  • Phase 2 will include 3 compressor stations
    Meeker (11,000 HP), Big Hole (22,000 HP), and
    Wamsutter (14,000 HP)
  • Eight delivery/receipt meter stations at
    interconnects with existing pipelines, two at
    Meeker, two at Wamsutter, and four at Cheyenne Hub

6
Recent Significant Milestones
  • FERC Certificate Granted August 9, 2005
  • Construction contract awarded to US Pipeline
    Company
  • Operating contract awarded to Kinder Morgan
    NatGas Operator LLC
  • Agreement to interconnect with TransColorado

7
Timeline of Major Milestones Achieved
9/03 12/03 1/04
12/04 1/05
8
Project Timeline (most recent update)
Phase 1 Segment 2 Construction Jul 06 Nov 06
Phase 1 Segment 1 Construction Sep 05 Dec 05
Wamsutter to Cheyenne
Meeker to Wamsutter
1/05 12/05
1/06 12/06
1/07
Compressor Expansion to 1.5 Bcf/d
Phase 2 Construction of Facilities Apr 07 Jun 07
FERC Notice to Proceed Expected 9/5/05
Note All dates referenced above are
approximate and differ from the FERC filing
9
Proposed Pipeline Interconnects
Bi-directional Interconnects CIG WIC
Delivery Interconnects CIG Cheyenne Plains
XCEL Trailblazer
Receipt Interconnects EnCana Gathering TransColor
ado
10
Entrega Pipeline Capacity
Included in FERC Certificate dated 8/9/05
New FERC Application and open season required
11
Market Pipeline Access
Wamsutter
Opal
Cheyenne Hub
Salt Lake City
Meeker Hub
Denver
Greensburg
12
Wrap-up
  • Review of Project Timeline
  • Segment 1 (Meeker to Wamsutter) In Service
    December 2005
  • Segment 2 (Wamsutter to Cheyenne) In Service
    November 2006
  • Phase 2 (Compressor Expansion) In Service July
    2007
  • We appreciate your continued support
