Methods, Diagnostics, and Practices for Seasonal Adjustment

1
Methods, Diagnostics, andPractices for
SeasonalAdjustment

• Catherine C. H. Hood
• Introductory Overview Lecture Seasonal
  Adjustment

2
Acknowledgements

• Many thanks to
• David Findley, Brian Monsell, Kathy
  McDonald-Johnson, Roxanne Feldpausch
• Agustín Maravall

3
Outline

• Basic concepts
• Software packages for seasonal adjustment
  production
• Mechanics of X-12 and SEATS
• Overview of current practices
• Recent developments in research areas

4
Time Series

• A time series is a set of observations ordered in
  time
• Usually most helpful if collected at regular
  intervals
• In other words, a sequence of repeated
  measurements of the same concept over regular,
  consecutive time intervals

5
Time Series Data

• Occurs in many areas economics, finance,
  environment, medicine
• Methods for time series are older than those for
  general stochastic processes and Markov Chains
• The aims of time series analysis are to describe
  and summarize time series data, fit models, and
  make forecasts

6
Why are time series data different from other
data?

• Data are not independent
• Much of the statistical theory relies on the data
  being independent and identically distributed
• Large samples sizes are good, but long time
  series are not always the best
• Series often change with time, so bigger isnt
  always better

7
What Are Our Users Looking for in an Economic
Time Series?

• Important features of economic indicator series
  include
• Direction
• Turning points
• In addition, we want to see if the series is
  increasing/decreasing more slowly than it was
  before
• Consistency between indicators

8
Why Do Users Want Seasonally Adjusted Data?

• Seasonal movements can make features difficult
  or impossible to see

9
Classical Decomposition

• One method of describing a time series
• Decompose the series into various components
• Trend long term movements in the level of the
  series
• Seasonal effects cyclical fluctuations
  reasonably stable in terms of annual timing
  (including moving holidays and working day
  effects)
• Cycles cyclical fluctuations longer than a year
• Irregular other random or short-term
  unpredictable fluctuations

10
Causes of Seasonal Effects

• Possible causes are
• Natural factors
• Administrative or legal measures
• Social/cultural/religious traditions (e.g., fixed
  holidays, timing of vacations)

11
Causes of Irregular Effects

• Possible causes
• Unseasonable weather/natural disasters
• Strikes
• Sampling error
• Nonsampling error

12
Other Effects

• Trading Day The number of working or trading
  days in a period
• Moving Holidays Events which occur at regular
  intervals but not at exactly the same time each
  year

13
May 2007

• S M T W T F S
• 1 2 3 4 5
• 6 7 8 9 10 11 12
• 13 14 15 16 17 18 19
• 20 21 22 23 24 25 26
• 27 28 29 30 31

14
June 2007

• S M T W T F S
• 1 2
• 3 4 5 6 7 8 9
• 10 11 12 13 14 15 16
• 17 18 19 20 21 22 23
• 24 25 26 27 28 29 30

15
Moving Holiday Effects

• Holidays not at exactly the same time each year
• Easter
• Labor Day
• Thanksgiving

16
Combined Effects

• Trading day and moving holiday effects are both
  persistent, predictable, calendar-related
  effects, so trading day and holiday effects often
  included with the seasonal effects

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
The Simple Case

• The time series would have
• No growth or decline from year to year, only
  rather repetitive within-year movements about an
  unchanging level
• No trading day or moving holidays

23
Change in Variations

• What if the magnitude of seasonal fluctuations is
  proportional to level of series?
• take logarithms

24
(No Transcript)
25
(No Transcript)
26
Log Transformations

• Appropriate when the variability in a series
  increases as its level increases, and when all
  values of the series are positive
• Change multiplicative relationships into additive
  relationships
• Increases/decreases can be thought of in terms of
  percentages

27
Problem Extreme Values

• Solution
• These effects can be estimated also, but they can
  be difficult to estimate when seasonality and
  trend are present

28
(No Transcript)
29
(No Transcript)
30

• Which of these values are outliers (extreme
  values)?

31
Trading Day and Other Effects

• What if trading day and/or other effects
  (holiday, outliers) are present?
• X-11 TD, holiday regression on the irregular
  component, extreme value modifications
• SEATS RegARIMA models for a regression on the
  original series
• X-12 Use X-11 methods or RegARIMA models

32
Models

• Multiplicative model
• Yt St Tt It
• St Nt
• where
• St St TDt Ht

• Additive model
• Yt St Tt It
• St Nt
• where
• St St TDt Ht

33
Objectives

• Estimate Nt (remove effects of St ) for seasonal
  adjustment
• Estimate Tt (remove effects of St and It) for
  trend estimation

34
How Do We Estimate the Components?

• Seasonal adjustment is normally done with
  off-the-shelf programs such as
• X-11 or X-12-ARIMA (Census Bureau),
• X-11-ARIMA (Statistics Canada),
• Decomp, SABL, STAMP,
• TRAMO/SEATS (Bank of Spain)

35
RegARIMA Models (Forecasts, Backcasts, and
Preadjustments)
Modeling and Model Comparison Diagnostics and
Graphs
Seasonal Adjustment
Seasonal Adjustment Diagnostics and Graphs
36
RegARIMA Model

• log ? Xt Zt
• transformations ARIMA process
• Xt Regressor for trading day and holiday or
  calendar effects, additive outliers, temporary
• changes, level shifts, ramps, and
• user-defined effects
• Dt Leap-year adjustment, or subjective prior
  adjustment

(
)
Yt
Dt
Catherine Hood Consulting
37
ARIMA Models and Forecasting

• If we can describe the way the points in the
  series are related to each other (the
  autocorrelations), then we can describe the
  series using the relationships that weve found
• AutoRegressive Integrated Moving Average Models
  (ARIMA) are mathematical models of the
  autocorrelation in a time series
• One way to describe time series

38
Autocorrelation

• The major statistical tool for ARIMA models is
  the sample autocorrelation coefficient

__
__
n
?
( Yt-k Y )
( Yt Y )
rk
tk1
n
?
__
( Yt Y )2
t1
39
Autocorrelations

• r1 indicates how successive values of Y relate to
  each other,
• r2 indicates how Y values two periods apart
  relate to each other,
• and so on.

40
ACF

• Together, the autocorrelations at lags 1, 2, 3,
  etc. make up the autocorrelation function or ACF
  and then we plot the autocorrelations by the lags
• The ACF values reflect how strongly the series is
  related to its past values over time

41
Autoregressive Processes

• The autoregressive process of order p is denoted
  AR(p), and defined by
• Zt ? ?r Zt-r wt
• where ?1 , . . . , ?p are fixed constants and
  wt white noise, a sequence of independent (or
  uncorrelated) random variables with mean 0 and
  variance ? 2

p
r1
42
Moving Average Processes

• The moving average process of order q, denoted
  MA(q), includes lagged error terms t1 to tq,
  written as
• Zt wt ? ?r wt-r
• where ?1 , ?2 , , ?q are the MA parameters and
  wt is white noise

q
r1
43
Random Walk

• Constrained AR Model
• Zt Zt-1 wt with ?1 1
• First differenced model
• Zt Zt-1 wt Zt Zt-1 wt
• (1 B) Zt wt
• Seasonal difference model
• Zt Zt-12 wt

44
ARMA processes

• The autoregressive moving average process,
  ARMA(p,q) is defined by
• Zt ? ?r Ztr ? ?r wtr
• where again wt is white noise

q
p
r1
r0
45
Seasonal Processes

• A seasonal AR process
• Zt ? ?r Zt-Sr wt
• A seasonal MA process
• Zt wt ? Tr wt-r
• where ?1 , . . . , ?P and T1 , , TQ are fixed
  constants, wt is white noise, and S is the
  frequency of the series (12 for monthly or 4 for
  quarterly)

p
46
RegARIMA Model

• log ? Xt Zt
• transformations ARIMA process
• Xt Regressor for trading day and holiday or
  calendar effects, additive outliers, temporary
• changes, level shifts, ramps, and
• user-defined effects
• Dt Leap-year adjustment, or subjective prior
  adjustment

(
)
Yt
Dt
Catherine Hood Consulting
47
RegARIMA Model Uses

• Extend the series with forecasts (or possibly
  backcasts)
• Detect and adjust for outliers to improve the
  forecasts and seasonal adjustments
• Estimate missing data
• Detect and directly estimate trading day effects
  and other effects (e.g. moving holiday effects,
  user-defined effects)

48
Automatic Procedures

• Both X-12-ARIMA and SEATS have procedures for the
  automatic identification of
• ARIMA model
• Outliers
• Trading Day effects
• Easter effects

49
RegARIMA Models (Forecasts, Backcasts, and
Preadjustments)
Modeling and Model Comparison Diagnostics and
Graphs
Seasonal Adjustment
Seasonal Adjustment Diagnostics and Graphs
50
How are component estimates formed?

• X-11, X-12 limited set of fixed filters
• ARIMA Model-based (AMB)
• Fit ARIMA model to series
• This model, plus assumptions, determine component
  models
• Signal extraction to produce component estimates
  and mean squared errors (MSE)

51
Example Trend Filter from X-12-ARIMA

• A centered 12-term moving average

52
Example 3x3 Filters

• 3 x 3 filter for Qtr 1, 1990 (or Jan 1990)
• 1988.1 1989.1 1990.1
• 1989.1 1990.1 1991.1
• 1990.1 1991.1 1992.1
• 9

53
Example Seasonal Filter from X-12-ARIMA 3x3
Filter

• Recall that Y TSI, so SI Y/T, i.e., the
  detrended series

54
AMB Approach

• Fit RegARIMA model yt xt ? Zt
• Given an ARIMA model for series Zt,
• ? (B) ? (B) Zt T (B) ? (B) wt
• and the model Yt St Nt , determine models
  for components St and Nt

55
Where . . .

• St independent of Tt independent of It ( ? St
  independent of Nt )
• St , Tt , It follow ARIMA models consistent with
  the model for Zt (hence so does Nt)
• It is white noise (or low order MA)

56
Canonical Decomposition

• Problem There is more than one admissible
  decomposition
• Solution Use the canonical decomposition, the
  decomposition that corresponds to minimizing the
  white noise in the seasonal component

57
Properties of the Canonical Decomposition

• Unique (and usually exists)
• Minimizes innovation variances of seasonal and
  trend maximizes irregular variance
• Forecasts of St follow a fixed seasonal pattern

58
Advantages of AMB Seasonal Adjustment

• Flexible approach with a wide range of models and
  parameter values
• Model selection can be guided by accepted
  statistical principals
• Filters are tailored to individual series through
  parameter estimation, and are optimal given

59
Advantages of AMB Seasonal Adjustment (2)

• Signal extraction calculations provide error
  variances of component estimates with MSE based
  on the model
• Approach easily extends (in principle) to
  accommodate a sampling error component

60
At the End of the Series

• X-11 asymmetric filters (from ad-hoc
  modifications to symmetric filters)
• X-11-ARIMA, X-12 one year (optionally longer)
  forecast extension
• AMB full forecast extension

61
Issues Relating to Current Practices

• X-12 versus SEATS
• Use of RegARIMA models, for forecasting, trading
  day, holidays, etc.
• Diagnostics

62
Agreement in Current Practices

• Compute the concurrent factors (running the
  seasonal adjustment software every month with the
  most recent data) instead of projected factors
• Use regARIMA models whenever possible (ARIMA
  models required for SEATS)
• Continue to publish the original series along
  with the seasonal adjustment

63
X-12 vs SEATS

• Eurostat recommends use of either program
• US Census Bureau recommends use of X-12-ARIMA
• According to research, X-12 is more accurate than
  SEATS for most series
• X-12 works better for short series (4 to 7 years)
  and for longer series (over 15 years)
• X-12 has better diagnostics

64
Setting Options

• To reduce revisions, best to set certain options
  for production
• Most agencies let the software choose the options
  and then fix the settings for production
• Problems come with SEATS because model used is
  not always the model specified, and model
  coefficients also are not always the ones
  specified

65
Trading Day and Moving Holiday Settings

• In Europe, there has been a lot of work on
  user-defined variables that include trading
  days and moving holidays to incorporate
  country-specific holidays
• Most agencies in the U.S. use built-in trading
  day and built-in moving holidays from X-12-ARIMA
• Unfortunately, not all the built-in variables are
  useful for every situation
• Some agencies avoid trading day altogether

66
Outlier Settings

• At the Australia Bureau of Statistics, they have
  a very rigorous procedure of outlier
  identification, including meta data on certain
  unusual events
• Most other agencies use the automatic outlier
  selection procedure
• At the U.S. Census Bureau
• Choose new outliers with every run
• At annual review time, set outliers for current
  data and set a high critical value for the new
  data coming in

67
Direct/Indirect Definitions

• If a time series is a sum (or other composite) of
  component series
• Direct adjustment a seasonal adjustment of the
  aggregate series obtained by seasonally adjusting
  the sum of the component series
• Indirect adjustment a seasonal adjustment of
  the aggregate series obtained from the sum of the
  seasonally adjusted component series

68
Example Direct and Indirect Adjustment

• US NE MW SO WE
• Indirect seasonal adjustment of US
• SA(NE) SA(MW) SA(SO) SA(WE)
• Direct seasonal adjustment of US SA( NE MW
  SO WE )

69
Comment on Yearly Totals

• When do yearly totals of the original series and
  the seasonally adjusted series coincide?
• When the series has
• An additive decomposition
• A seasonal pattern that is fixed from one year to
  the next
• No trading adjustments

70
Areas for Improvement in Current Practices

• Concurrent adjustment
• Use of regARIMA models
• Moving holidays and other user-defined effects
• Setting options (to reduce revisions) and
  checking the options regularly
• Software to make it easier to check diagnostics
  regularly
• Training in ARIMA modeling and diagnostics

71
Recent Developments and Research Areas

• X-13 (X-13-SEATS)
• Improved and new diagnostics (for both X-12 and
  SEATS)
• New filters for X-12 and new, more flexible
  models for SEATS
• Supplemental and utility software
• Documentation and training

72
Newest X-12

• Version 0.3 includes a new automatic
  ARIMA-modeling procedure based on the program
  TRAMO from the Bank of Spain
• The next release (X-13) will include
  ARIMA-model-based seasonal adjustment options

73
Model-based Adjustment

• SEATS, developed by Agustín Maravall at the Bank
  of Spain
• REGCMPT, developed by Bill Bell at the Census
  Bureau

74
SEATS

• Disadvantages
• No diagnostics for the adjustment
• No methods for series with different variability
  in different months
• No user-defined regressors
• Not very flexible ARIMA models

75
REGCMPT

• Advantages
• Methods for different variability in different
  months
• Can build very flexible regARIMA models
• Still being tested

76
X-13-SEATS

• Advantages
• Would combine the model-based adjustments from
  SEATS with diagnostics from X-12, and keep the
  ability to use X-11-type adjustments also
• Disadvantage
• ????

77
Running in Windows

• TRAMO/SEATS for Windows
• Windows Interface to X-12-ARIMA

78
Supplemental Software

• X-12-Graph in SAS and in R
• X-12-Data and X-12-Rvw
• Programs to help write user-defined variables for
  custom trading day and moving holidays
• Excel interfaces to run SEATS and X-12 from Excel
• Interfaces to other software are available

79
Documentation and Training

• Documentation
• Getting Started papers to use with the Windows
  version, written for novice users
• Documentation on commonly used options for both
  X-12 and SEATS
• Training
• Advanced Diagnostics
• RegARIMA Modeling

80
Resources

• X-12-ARIMA website www.census.gov/srd/www
  /x12a
• Seasonal adjustment papers pages
• TRAMO/SEATS website
• www.bde.es/english/
• Papers and course information www.catherinechhood
  .net

81
Contact Information

• Catherine Hood
• Catherine Hood Consulting
• 1090 Kennedy Creek Road
• Auburntown, TN 37016-9614
• Telephone [phone]
• Email cath_at_catherinechhood.net
• Web www.catherinechhood.net

82
(No Transcript)
