Title: Obstruction Lighting


1
Obstruction Lighting Visual Signals
2
Agenda
  • Key Takeaways
  • Aviation Obstruction Lighting
  • Applications
  • FAA, ICAO Standards
  • Lighting categories
  • Product Line review
  • Obstruction Lighting
  • Visual Signals
  • Medium Intensity Beacons
  • High Intensity Beacons
  • Lighting Technology
  • LED Advantages and Savings
  • Controllers and Accessories

3
Key Takeaways
  • Crouse-Hinds Syracuse has assumed ownership and
    management of CHAPL, Windsor Obstruction Lighting
    business
  • Customer service
  • Project and Order management
  • Special project quotes
  • Pricing approvals
  • Technical support
  • Manufacturing
  • Response time and service levels will improve
    with the move to Syracuse!

Positioning You to Serve Existing Obstruction
Light MRO Business !
4
Key Takeaways
  • System Integration
  • Lighting Products
  • Controls
  • Technical Support
  • New Products
  • LED Obstruction
  • LED Visual Signal

Cooper Crouse Hinds offers complete system
packages, allowing you to pursue project business
with Turn-Key solutions.
5
Key Takeaways
  • Systems Support
  • We will do the work, You sell the project !
  • Lighting Controls configurations
  • Towers, Flares, Buildings, etc
  • Bring us the project with the details
  • Online Registration coming soon

Cooper Crouse-Hinds can design and develop
customized lighting and control solutions to meet
your obstruction lighting requirements
6
Key Takeaways
  • The Advantages of LED Technology
  • LEDs are now the standard for obstruction
    specifications.
  • Long life (50,000 hours) / Low Maintenance
  • Energy efficient and reliable 1/10 the energy
    consumption of an incandescent system
  • Low heat Good T-ratings.
  • Environmentally Friendly - No Mercury.
  • Well design and provide the controls package for
    your customer!

7
Aviation Obstruction Lighting
8
Applications
  • Hazardous Industrial
  • Aircraft Obstruction
  • Broadcast Cellular/PCS
  • Wind energy
  • Buildings
  • Smokestacks
  • Airport heliport
  • Refineries
  • Petro-Chemical
  • Mines
  • Off Shore Platforms

9
Aviation Obstruction Lights
  • Aviation Obstruction Lights
  • Low, Medium, or High Intensity
  • Approved by the FAA
  • ETL certified to FAA standards
  • Meet ICAO requirements

10
Aviation Regulations - FAA
  • FAA Certification Process
  • Lights must be tested by an independent lab (ETL)
  • The lab reserves the right to arrive unannounced
    at our factory and take random samples for
    testing
  • Lights are tested for optical, photometric and
    environmental tests
  • The lights must be compliant with FAA Advisory
    Circular No150/5345-43F
  • US Military Standards and Specifications are also
    used in the Certification Process

11
FAA Lighting System Configuration
TYPE A Red Lighting System TYPE B High
Intensity White TYPE C High Intensity
White (Medium Intensity White Beacon on
Appurtenance) TYPE D Medium Intensity White TYPE
E Dual Lighting System Red/Medium Intensity
White TYPE F Dual Lighting System Red/High
Intensity White (Dual Beacon on Appurtenance
over 40 tall)
  • EQUIPMENT CLASSIFICATION

L-810 Steady Burning Red Obstruction Light L-856
High Intensity Flashing White Obstruction Light
(40 FPM) L-857 High Intensity Flashing White
Obstruction Light (60 FPM) L-864 Flashing Red
Obstruction Light (20-40 FPM) L-865 Medium
Intensity Flashing White Obstruction Light (40
FPM)
L-866 Medium Intensity Flashing White
Obstruction Light (60 FPM) L-864/L-865 Dual
Flashing Red Obstruction Light (20-40 FPM) and
Medium Intensity Flashing White Obstruction
Light (40 FPM) L-885 Red Catenary (60 FPM)
12
Aviation Regulations - ICAO
  • ICAO International Civil Aviation Organization
  • Provides guidance for Civil Aviation around the
    world
  • Provides common Standards and Practices
  • No certification
  • Manufacturers self test and certify
  • 188 Member Countries

7
13
FAA vs ICAO
  • There is no ICAO certification
  • Manufacturers self-certify to meet the
    standards required by ICAO
  • No product testing required
  • FAA products must be certified by an independent
    lab
  • FAA requires additional product testing

FAA product insures a rigorous and well-tested
product
14
Aviation Obstruction Lighting
  • FAA / ICAO recognizes three categories of
    obstruction lights

High Intensity L856/L857
Medium Intensity L864/L865/L866
Low Intensity L810
15
FAA/ICAO Lighting Categories
  • The Category of Light Depends On the Structure
    Height

FAA (ft)
  • Each Category has Sub-Categories

16
Day/Night Options
  • FAA/ICAO recognizes two options for day/night
    operations

Requirements depend on structure height and
application. Always defer to the FAA
specification or local agency for details.
11
17
Regulation Takeaways
  • White Lights in the day eliminate the need for
    paint
  • Red Lights are only for use at night
  • Category of light depends on the structure height
  • Low Intensity Lights are always red, Medium
    Intensity Lights are White or Red, and High
    Intensity Lights are always White
  • Red and White Lights may be installed on the same
    structure, but are never on at the same time.

12
18
Regulation Takeaways
  • Red Lights may be incandescent, halogen, or LED.
    White lights are always strobes.
  • The ICAO does not have a certification process
  • Always defer to the FAA specifications or local
    agency to ensure your applications meets the
    requirements.

13
19
Product Line Review
20
Obstruction Lights
  • Always red
  • Steady burning
  • LED or Incandescent
  • Single or double lamp
  • 32 cd per lamp (FAA)
  • 10 cd (ICAO)

L810
15
21
LED Obstruction Lights
  • Low Intensity
  • Obstruction FAA type L810
  • FAA compliant
  • Available Class I, Div. 2
  • Steady Burning or Optional Flashing
  • Red Single or Double configuration
  • Energy Efficient LED technology
  • Greater then 10 years life expectancy
  • Visual Signal
  • Available Class I, Div. 2
  • Available with ATEX Certification
  • Steady Burning or Optional Flashing
  • Red, Green Blue, White Yellow
  • Single or Double Configuration

22
Obstruction Lights
  • L810 General Use LED Obstruction Light

23
Obstruction Lights
  • L810 Class I, Division 2 LED Obstruction Light

24
LED Visual Signals
  • General Use LED Visual Signal Light
  • Class I, Div. 2 LED Visual Signal Light

25
Medium Intensity Beacons
  • For use on structures greater than 45 meters
    (150ft)
  • Red lights
  • LED, Incandescent and Xenon
  • White Strobe
  • Xenon
  • Dual Strobes
  • LED

FAA type L864/L865/L866
18
26
Medium Intensity Beacons
  • Red lights are only used at night.
  • If only red lights are installed on a structure,
    paint must be used for day marking.
  • For each level of medium intensity red lights on
    a structure, an intermediate level of low
    intensity lights must be installed.
  • The intensity of medium intensity red lights is
    2,000 candela 25.
  • The intensity of low intensity lights is at least
    32 candela.

19
27
LED Medium Intensity
  • L864 General Use LED Medium Intensity Red Beacon

28
LED Medium Intensity
  • L864 Class I, Div. 2 LED Medium Intensity Red
    Beacon

29
LED Medium Intensity
  • L864/L865 General Use LED Medium Intensity Beacon
    Dual Red/White

LEDs 10 years life expectancy

Consult factory for System configuration
30
LED Medium Intensity
  • L864/L865 General Use LED Medium Intensity Beacon
    Dual Red/White
  • Unique System Features
  • Medium Intensity RED output for Nighttime (L864)
  • Medium Intensity WHITE output for Daytime (L865)
  • Complete System Certified to FAA AC 150/5345-43F
  • Long-Life LED Technology
  • System Components
  • Dual LED Flashheads
  • Flashhead Power Supply
  • Photo-Control
  • System Controller
  • Power and Communications Cable

31
Xenon Medium Intensity
  • L864/L865 General Use Dual Beacon System
  • Twin helical flashtube design
  • Easy maintenance with 90 components at ground
    level
  • Structures up to 500ft
  • White strobe - day
  • Red strobe - night

32
Xenon Medium Intensity
  • L864/L865 General Use White Beacon System
  • Low power consumption average of 100W
  • 95 of components located at ground level means
    less climbing and easy maintenance
  • Stainless steel enclosure can be mounted indoors
    or out
  • 20k candelas day / 2K candelas night

33
High Intensity Beacons
  • L856/L857 General Use Beacon High Intensity
  • Beacon Model FTB204
  • High Intensity white strobe
  • For Day, twilight night operation
  • For structures 500ft
  • Requires external controller
  • Controller Model FTC121W
  • Diagnostic capability
  • NEMA 4x wall mount enclosure
  • 95 of electronics at lower level for servicing
  • Control of intensity and flash rate

34
Lighting Technology
35
Lighting Technology
  • Low Intensity
  • LED, and Incandescent and Halogen
  • Medium Intensity
  • LED, Incandescent and Xenon
  • High Intensity
  • Xenon

36
Incandescent/Halogen Technology
  • Advantages
  • Lowest up front cost
  • Numerous distribution sources
  • Fairly resilient to lightning
  • Plug and play to most broadcast towers
  • Disadvantages
  • Short lamp life, high reoccurring costs
  • Frequent maintenance
  • Susceptible to vibration damage
  • Extremely inefficient, Consumes lots of power
  • Light Pollution, ground effects!

37
Xenon/Strobe
  • Advantages
  • Longer life technology than incandescent.
  • Efficient power consumption
  • Numerous distribution sources
  • Disadvantages
  • Large upfront costs
  • Proprietary replacement technology
  • New electrical infrastructure
  • Limited lamp life, depending on design
  • EMI / RF issues and ozone release
  • Expensive high voltage replacement components
  • Expensive maintenance costs
  • Light pollution, ground effects

38
LED Technology
  • LED Light Emitting Diode
  • Semiconductor material converts electricity into
    light
  • Basic structure consists of semiconductor,
    reflector wire bond and epoxy dome
  • Color of the light is dependent on the
    semiconductor material
  • In the past LED technology was limited to
    indicator lamps.
  • Due to advances in technology the LED is becoming
    the preferred light source for many applications
    such as
  • automobile tail lamps, dashboard lights, flash
    lights, signage and aircraft warning lights.

39
The LED Value Proposition
  • Long Life
  • Reduced lifecycle costs
  • Energy Efficient
  • Directional light source avoids wasted light
  • LED technology can save up to 80 in electricity
  • Instant On No Warm-Up Time
  • Enables On-Demand lighting and eliminates quartz
    re strike lamps
  • Full range dimming
  • Environmentally Green
  • No mercury content
  • No UV issue
  • Dark Skies friendly light where you need it
  • Solid State Construction
  • Vibration resistant
  • Potential for intrinsically safe potted designs
  • Very Low Radiated Heat
  • Increased Hazardous Locations T Ratings

Initial VOC surveys suggest that long life and
energy efficiency are the most important features
when deciding on a new light fixture
40
LED Basics
  • LED Structure
  • Light Emitting Semiconductor Material (DIE)
  • The type of material determines the color of
    light
  • Reflector Cup
  • Lead Wires
  • Epoxy Lens
  • Lead Frame

LED Cross Section
LED Chip (die)
LED Package
41
LED Basics
  • LED Indication Grade Packaging
  • Limited Life
  • Low Brightness
  • LED Commercial Grade Packaging
  • Very Long Life Up to 100,000 Hours
  • High Brightness
  • Better Manufacturability
  • Extremely Durable

Cree X-lamp
Osram Ostar
Lumileds Luxeon
Osram Golden Dragon
42
LED Technology
  • Making the transition from a light bulb to a LED
    Source
  • Generally, a single LED cannot replace a single
    light bulb
  • A Light Engine is required
  • Multiple LEDs performing as single light source
  • Optics designed for L.E.D. light engine
  • Removal of the need for filters as L.E.Ds are
    monochromatic
  • 70 to 90 instant energy savings

43
LED vs. Incandescent
Up-Sell to LED!
44
LED vs. Xenon
Up-Sell to LED!
45
Lifetime Cost Analysis
46
LED Life
  • LEDs do not typically fail but gradually loose
    light over time
  • No standard for defining LED life (useable
    lumens)
  • However reputable manufacturers are adopting the
    term L70
  • L70 the time to reach 70 lumen maintenance
  • White LEDs typically have a useable life of 60K
    hours
  • Amber, Red, Yellow, and Orange can last up to
    100K hours.
  • Life is dependent of proper design of the LED
    system

47
Controllers Accessories
48
Controller Monitoring Systems
  • Cooper Crouse-Hinds Offering
  • Standard and Custom Controls
  • Technical Support

49
Why Cooper Crouse-Hinds?
  • Obstruction Light Monitoring Required by FAA
  • Personnel on site
  • Electronic Monitoring System
  • Obstruction Lighting Controller
  • LED Obstruction Lights operate on much lower
    current than incandescent lights
  • Controller modifications required

Cooper Crouse-Hinds Application Engineers Can
Provide the Solution For Both Retrofit and New
Installations!
50
Integrated Products
  • Standard Obstruction Lighting Controllers
  • RED Lighting Systems
  • DUAL Medium Intensity Systems
  • DUAL High Intensity System
  • Custom Obstruction Lighting Controllers
  • Standard Off the Shelf Accessories
  • ATLR Alternating Dual Light Control
  • BFA Flasher Assembly
  • OLR Alarm Relay Assembly
  • PCF Photo-Control Flasher Assembly

51
Basic Controller Components
  • Standard Controller Components
  • Flasher
  • Alarms
  • Additional Controller Components
  • Boost Transformer
  • PEC Override Switch
  • Power Relay
  • Pilot Lights
  • Photo Control
  • Fuse Boxes
  • Circuit Breaker

52
Custom Obstruction Lighting Controllers
  • Cooper Crouse-Hinds offers a full line of
    standard lighting controllers designed to support
    the most common obstruction lighting
    configurations required by the FAA FCC
  • Custom lighting controllers of the highest
    quality are designed by our experienced design
    engineering staff to best meet specific
    application needs

53
LED Standard Controllers
Consult Crouse Hinds for Custom Configurations
54
The LED Controller
55
GPS Synchronized Flasher
Assembly Photocell mounted directly into LED
Beacon
SFM Module
SFM packaged into a NEMA 4X Enclosure
Antenna Options
56
Cooper Crouse-Hinds
  • Knowledge
  • Quality
  • Service
Write a Comment
User Comments (0)
About PowerShow.com
