eBioFlow Different perspectives on scientific workflows

1
e-BioFlow Different perspectives on scientific
workflows

• Ingo Wassink1, Paul van der Vet, Anton Nijholt
• Human Media Interaction Group, University of
  Twente
• Han Rauwerda, Timo Breit
• Micro Array Department, University of Amsterdam
• 1) i.wassink_at_ewi.utwente.nl

2
Overview

• Scientific workflow systems
• Problems using workflow systems
• e-BioFlow
• Control flow perspective
• Data flow perspective
• Resource perspective
• Relations between perspectives
• Conclusion
• Current state
• Future work

3
Scientific workflow systems

• A lot of data is stored in online databases
• SwissProt, PDB
• Access to many services in a uniform manner
• BioMoby, WSDL, SoapLab
• Using a graphical workflow tool
• Connect these services and databases
• Share experiments and experimental results with
  others
• Discuss, improve and reuse experiments
• myExperiment, (www.myexperiment.org)
• Automatically store provenance data

4
Problems using workflow systems

• Are often difficult to use due to a complex user
  interface
• It is not possible to model advanced control
  structures
• Loops Choices
• A priori knowledge about services is required
• Function
• Input and output
• Data produced by one service is often
  incompatible with data consumed by others
• If a service is not available, the workflow needs
  to be modified

5
e-BioFlow (I)

• Graphical tool user interacts with the workflow
  directly
• Develop templates for experiments
• Abstract from web services until workflow
  execution
• Enable complex workflow structures
• Sequential, parallel, iteration and choices
• Shows limited information at a time to prevent
  information overload
• But does not restrict the user in modeling
  workflows
• Distributes information using a tabbed user
  interface
• Ultimate goal improve usability of workflow
  systems

6
e-BioFlow (II) Screenshots
Control flow perspective
Data flow perspective
Resource perspective
7
Control flow perspective (I)

• Defines the order of task execution
• Uses dependencies a task can depend on prior
  tasks
• Advanced control structures to define the order
  of task execution
• Sequential a task needs to wait for completion
  of prior task(s)
• Parallel tasks can be executed at the same time
• Iterative a task needs to be repeated until some
  criterion is met
• Branching the execution of a task depends on a
  certain criterion

8
Control flow perspective (II)

• AND execute next tasks in parallel

• XOR execute one of the next tasks, depending on
  conditions

9
Data flow perspective

• A task can require information from prior tasks
• Tasks have input and output ports to consume and
  produce data
• Pipes are used to define output of prior tasks
  being input for next tasks
• Type restrictions on data are tested

10
Resource perspective

• Defines what type of action (service) needs to be
  executed instead of which actor (web service,
  tool, user) to invoke
• Actor is chosen at runtime
• Uses roles to describe constraints on actors
• A role defines the required capabilities of an
  actor
• Service type
• Input and output it should consume and produce

11
Relations between perspectives (I)

• A central workflow specification is shared and
  edited by the different perspectives
• Changes in one perspective are propagated to the
  other perspectives, wherever applicable
• Visual effects
• To ease switching between perspectives
• Task positions size
• Zoom level

12
Relations between perspectives (II)

• If data is transferred between tasks, this
  implies the existence of a dependency between
  these tasks

Task requires information from one of the prior
tasks
Task requires information from both prior tasks
13
Relations between perspectives (III)

• If a task requires input and output, this puts
  constraints on the suitability of actors, and
  vice versa

An alignment task requires two input sequences
A Blast task requires only one input
14
Conclusion

• e-BioFlow enables one to create advanced control
  structures
• By abstracting from services, it is possible to
  design experiment templates
• The amount of information presented to the user
  is limited by providing different perspectives to
  the user
• However, an executable environment is required to
  test the usability of this approach

15
Current state

• Integration of a workflow engine
• A control flow workflow engine Yawl
  (www.yawlfoundation.org)
• Late binding of services
• Support for different type of services
• Support for WSDL/SOAP and BioMOBY services
• Support for scripting tasks (R, Perl, BeanShell)
• User interaction tasks
• New types of services can easily be created using
  a plugin structure
• Framework for storing provenance data

16
Future work

• Creating workflows ad-hoc
• Directly execute tasks during workflow
  construction
• Redo steps, take alternative steps
• Store and browse provenance data
• Provide a user interface closely related to the
  workflow model
• Improve mapping between actors and roles
• Mapping between different ontologies structures
  is required

17
Acknowledgement

• Pieter Neerincx
• Laboratory of Bioinformatics, Wageningen
  University
• Wim de Leeuw
• MAD, University of Amsterdam
• Matthijs Ooms
• HMI, University of Twente
• This work was part of the BioRange programme of
  the Netherlands Bioinformatics Centre (NBIC),
  which is supported by a BSIK grant through the
  Netherlands Genomics Initiative (NGI).

18
Thanks
Questions
Advice
Remarks
Ideas
More information
e-BioFlow is open source http//ewi.utwente.nl/bi
orange/ebioflow
