Title: Lecture 7: Simulations


1
Lecture 7 Simulations
2
http//www.angelfire.com/linux/lecturenotes/
3
What will we cover in this lecture
  • A introduction to the idea and concept of
    stochastic simulation
  • A look at the 2 main methods of stochastic
    simulation Bootstrapping Monte Carlo
    Simulation
  • A look at the use of these methods in the
    calculation of risk

4
The Idea Behind Simulations
  • Simulations are basically the idea of simulating
    a set of possible future outcomes or
    realisations
  • Each future realisation is just one possibility
    of what may occur in the future
  • By generating many possible future realisations
    we can assess the range of future outcomes
  • In an earlier lecture we simulated a possible
    path for stock prices by generating a set of
    possible future returns from a normal
    distribution
  • This was an example of a univariate simulation (a
    simulation of one variable)

5
The Idea of a Simulation
Possible Future Price Paths
Current Price
Possible Range Of Future Prices
Price
Time
6
Useful Simulations
  • For a simulation to be useful the paths generated
    must reflect the behaviour of the
    asset/liabilities we are simulating
  • Each randomly generated future path will then
    represent a possible future outcome
  • The basis for both our Bootstrapping and Monte
    Carlo Simulations will be the Brownian Motion
    Process we have been using so far

7
Brownian Motion Process
At each step the proportional change in the value
is a random variable from a distribution
Value
?
Time
8
Bootstrapping A simple powerful approach
  • Bootstrapping is based on a very simple idea
    that we can use past observations as a bag from
    which we randomly sample to create possible
    future outcomes!
  • The premise is a simple one all of our past
    observations were sampled from a given
    distribution and all future observations will
    also be sampled from this same distribution
  • Instead of having to estimate the underlying
    distribution and then sampling random variables
    from it we directly sample from our past
    observations which are representative

9
Bootstrapping Idea
The Past Outcomes Represent A Random Sample From
The Distribution, We Dont Care About This
Distribution!
?
The Simulated Future Outcome Is A Random Sample
Of The PastOutcomes
Simulated Future Outcome
Directly Observed Past Outcome
10
Univariate Bootstrap
  • Univariate Bootstrap is the generation of a
    possible path for a single simultaneous random
    process
  • We generate a pool of observations from the
    processs historic behaviour
  • We then generate a future path by randomly
    sampling from this pool of observations

11
An Example Bootstrapping a stock price
  • If we assume that the continuously compounded
    return of the stock price each day is sampled
    from a constant distribution then we can generate
    future price paths
  • Firstly we build up our pool of past daily
    returns by calculating the implied return from
    the price history
  • Secondly we randomly sample from this pool to
    generate a possible future path

12
Bootstrapping Stock Price
Historic Price Path
Pool of Daily Returns From Historic Observation
Price
Time
Simulated Future Price Path
Price
Randomly Select From Pool To Generate Future Path
Time
13
Multivariate Bootstrapping
  • It is equally possible to simultaneously generate
    future paths for multiple correlated processes
  • Like our univariate bootstrap we build up a pool
    of observations from the past
  • We maintain any correlations by grouping
    simtaneous observations together
  • Any correlations will be captured in these linked
    historic observations
  • When we randomly sample from the pool to generate
    the future paths we preserve these groupings

14
Bivariate Bootstrap
Price
Price
Time
Time
The pool is made up of linked pairs which were
observed simultaneously
Price
Price
Time
Time
15
What if we do not preserve the grouping of
simultaneous observations?
  • If we do not keep the groups then we cannot
    expect our generated paths to reflect any
    correlations
  • If we have strong reason to believe that there is
    no correlation between the processes then we
    might break apart the observations and sample
    them completely randomly
  • We might do this to increase the size of our
    pool

16
Bootstrapping Is Very Powerful
  • The power of bootstrapping is that it does not
    rely on any statistical assumptions
  • All it says is that the future will be sampled
    from the same distribution as the past
  • We need a large sample of historic observations
    to build up a large pool
  • The assumption that the future will come from the
    same distribution as the past is crucial and
    requires a stationary series
  • This simple bootstrapping technique does not
    capture serial correlation across time.

17
Bootstrapping in Excel
  • For practical usage bootstrapping is better
    suited to a programming language such as VBA, or
    a specialist tool
  • The exercise book for this lecture contains an
    array function called bootstrap
  • bootstrap will take an input range and reorder it
    randomly
  • bootstrap is an array formula for which an output
    range must be selected and ctrl-shift-enter must
    be used to enter it!

18
Monte Carlo Simulation
  • The Monte Carlo Simulation generates random
    numbers from probability distribution rather than
    pools of historic observations
  • We will focus on Monte Carlo Simulations based
    about the normal distribution
  • We will see how we can use the Covariance matrix
    to generate multivariate Monte Carlo Simulations

19
Univariate Monte Carlo Simulations
  • By generating random variables sampled from a
    normal distribution it is possible to generate a
    brownian motion paths based on this sequence of
    random numbers
  • In the example of the stock price if the return
    is normally distributed with mean m and standard
    deviation s then by generating returns from a
    distribution with these properties we can
    generate a possible path for this stock
  • The most common method for generating normal
    random numbers is Box-Muller, and we will use
    Excels built in facility

20
Stock Price Simulation
  • In the case where the stock price is generated
    from the following process
  • By generating a sequence of random variables r we
    can generate a future path for P
  • This would be an example of a univariate Monte
    Carlo Simulation

21
Univariate Stock Price Simulation
Price
Randomly Sampled Returns From Normal Distribution
Randomly generated feasible path
Time
22
Multivariate Monte Carlo Simulation
  • A multivariate Monte Carlo Simulation is where we
    sample random values from a multivariate
    distribution which captures the various
    correlations
  • So if 2 assets have a strong correlation we want
    to see strong correlations in the random numbers
    we generate
  • There is a set method which allows us to generate
    a set of correlated normally distributed random
    variables using the covariance matrix

23
What we would like
  • We have described the statistical properties of
    returns using the expectation vector and the
    covariance matrix.
  • We would like to generate sets of random numbers
    that match this expected return vector and
    covariance matrix
  • We could then generate simultaneous paths for the
    various assets/liabilities described by these
    statistics

24
The Basis of Multivariate Monte Carlo The
Cholesky Decomposition
  • The Cholesky decomposition of the covariance
    matrix will allow us to generate sets of random
    variables described by the covariance matrix
  • The Cholesky decomposition is sometimes called
    the square root of a matrix
  • It takes the form
  • Where CV is the covariance matrix and C is the
    cholesky decomposition. C is a lower diagonal
    matrix and of the same dimensions as CV
  • The Cholesky decomposition only exists for
    positive definite matrices.

25
Cholesky Decomposition Example
C
CT
CV
0.2 0.03
0 0.197
0.04 0.006
0.006 0.04
0.2 0
0.03 0.197


26
The Cholesky Transformation
  • Image we have 2 random variables A and B each of
    which are sampled from a standard normal
    distribution (mean 0, standard deviation 1). We
    will put these in a vector S (S for stochastic)
  • We would like to transform these variables to
    random variables sampled from a distribution with
    mean, variance and covariance described by the
    following

VarA CovA,B
CovA,B VarB
ERA
ERB
A
B
R
CV
S
27
  • Firstly we perform the Cholesky decomposition on
    the covariance matrix to obtain C
  • Then we simply perform the following Cholesky
    transformation
  • Where S is a vector of transformed random
    variables sampled from a distribution described
    by R and CV

A
B
S
  • Where A will have mean ERA and variance VarA, B
    will have mean ERB and variance VarB, and A and
    B will have Covariance CovA,B

28
Cholesky Transformation Graphic
A B Y Z
Input a vector of uncorrelated random variable
with mean 0 and variance 1
Cholesky Transformation
Output a vector of correlated random variable
with mean,variance and covariance described by
the covariance matrix and the expected vector
A B Y Z
29
Cholesky Factorisations in Excel
  • Cholesky Factorisations are not provided by
    Excels built in matrix support
  • The class workbook comes with a VBA macro that
    will perform this factorisation for you, it is an
    array function called cholesky

30
Multivariate Monte Carlo Simulation
  • Using the Cholesky Transformation we can generate
    sets of correlated random numbers
  • Using these sets of correlated random numbers we
    can generate simultaneous future paths for
    correlated processes
  • These simulated paths make up one possible future
    outcome in our Monte Carlo Simulation
  • Monte Carlo Simulations use 1000s or even
    1000000s of possible future outcomes to build up
    a picture of the range of future possibilities

31
Graphic Bivariate Monte Carlo Simulation
Correlated sets of random numbers
Value
Value
Time
Time
32
General Multivariate Monte Carlo Algorithm
  • 1) Decompose the covariance matrix VC into its
    Cholesky decomposition C
  • 2) Generate a vector of N unit variate normal
    random number, where N is the dimensions of the
    simulation
  • 3) Multiply the decomposition C by the vector N
    to get a result vector X
  • 4) Add the vector X to the expected return vector
    R to get a vector V which contains the fully
    transformed random variables
  • 5) Add transformed vector V to the set of
    transformed vectors S
  • 6) If S contains less than the desired number of
    random variables then goto step 2

33
The montecarlo macro
  • Embedded in the exercise spreadsheets there is a
    VBA macro which runs the Monte Carlo algorithm
  • It take two parameters first the range
    specifying the covariance matrix, second the
    range specifying the expected return vector
  • From these inputs it outputs a set of random
    variables sampled from a distribution described
    by the covariance matrix and expected vector in a
    range specified by the user
  • It is important to remember to specify one column
    for every random variate you want to generate and
    press ctrl-shift-enter to tell the computer it is
    an array formula!

34
Stochastic Boundaries And Monte Carlo Simulations
  • In early lectures we looked at placing boundaries
    on the behaviour of a stochastic process
  • These boundaries are linked to Monte Carlo
    Simulations in that we expect only 5 or 2.5 of
    simulations to be outside the respective
    diffusion boundary

35
Diffusion Boundary vs Monte Carlo
Only 2.5 of paths will break above the 2.5
upper boundary
Value
Possible Paths
Time
36
Uses of Simulation
  • Simulations have many uses and allow us to avoid
    a lot of complex mathematics
  • People think you are a rocket scientist if you
    know about Monte Carlo Simulations
  • One example would be an alternative approach to
    calculating the Value-At-Risk
  • We would generate say 100 future paths for a
    portfolios value by generating a set of 100
    simultaneous future paths for each of the assets
    it contains using either a Monte Carlo or
    Bootstrap simulation
  • Out of this 100 we would take the worst 5 or 5
    to calculate the 5 VaR

37
VaR Using Simulation
Portfolio Value
Take the worst 5 of simulated values as 5 VaR
Time
38
Option VaR Using Monte Carlo Simulations
  • One particular use of Monte Carlo simulation is
    the accurate calculation of VaR on non-linear
    portfolios containing options
  • We generate 100s of possible paths for the assets
    on which the options are written and look at the
    value of the option in each state
  • We then take the worst 5 or 2.5 of outcomes to
    calculate the portfolio 5 or 2.5 VaR

39
Appendix Cholesky Transformation A Proof
  • It is important to note that if we have a vector
    of stochastic variables S with mean zero , then
    the E(S.ST) CV

A
B
A.A A.B
B.A B.B
Var(A) Cov(A,B)
Cov(A,B) Var(B)
A B
E
E

  • If we perform the Cholesky transformation on a
    vector of standard normal variables, and assume
    the expectation remains 0

40
  • Now
  • Taking expectations
  • Since S is a vector of unit normal variables
    E(S.ST) will be the identity matrix (why?)
  • So the transformed random variables will have
    variance and covariance described by the
    covariance matrix C was decomposed from.
Write a Comment
User Comments (0)
About PowerShow.com
