A Tour of the Cell

1
A Tour of the Cell

• Chapter 6

2
Microscopes windows to the world of the cell

• Cells are the basic unit of life.
• The invention and improvement of microscopes in
  the 17th century led to the discovery and early
  study of cells
• Robert Hooke observed cells in a slice of cork

3
History of Cells
1800s Schwann Animal tissues are composed of
cells Schleiden Plant materials are composed
of cells Virchow - All tissues from living
organisms are composed of cells
4
The Cell Theory

• All living things are composed of cells
• Cells are basic units of structure and function
• All cells come from pre-existing cells

5
HOW CELLS ARE STUDIED

• Microscopy
• Cell Fractionation

6
Overview of Cells

• Plasma Membrane
• Nucleus / Nuclear region
• Cytoplasm.
• Cell Wall

7
The Eukaryotic Animal Cell
8
The Eukaryotic Plant Cell
9
Major type of Cells

• There are two basic types of cells
• Prokaryotic Eukaryotic
• A major difference between prokaryotic and
  eukaryotic cells is the location of chromosomes.

10
Prokaryotic Cells

• Lacks a nucleus and most other organelles
• DNA concentrated in nucleoid region
• Bacteria and Archae
• 1-10 micrometers
• Appear earliest in earths fossil record

11
Eukaryotic Cells

• Nucleus surrounded by its membrane
• Internal organelles bounded by membranes
• 10 100 micrometers
• Protists, Fungi, Plants, Animals

12
Membranes organize a cells activities

• Section 6.2

13
Plasma Membrane

• Boundary that separates the interior of a living
  cell from its surroundings and regulates the
  traffic of chemicals into and out of the cell
• Phospholipid Bilayer
• Protein icebergs float in a sea of
  phospholipids

14
Phospholipid Molecule

• Composed of proteins and a type of lipid called
  phosopholipid (glycerol2 fatty acids)

15
Protein icebergs in a sea of phospholipids
16
Plasma Membrane
17
Functions of Membrane Proteins

• Enzymes
• Cell-Cell Recognition
• Cell Signaling
• Transport

18
Enzyme Activity
19
Cell-Cell Recognition
20
Cell Signaling
21
Transport of Materials
22
Membranes Regulate Traffic of Molecules

• Section 6.3

23
Function of Cell Membranes

• Materials need to move in and out of the cell
• Function like gatekeepers, letting some molecules
  through, but not others ? Selectively Permeable

24
Types of Transport

• Diffusion
• Passive Transport
• Facilitated Transport
• Active Transport

25
Diffusion

• The spread of molecules from areas of high
  concentration, to areas of low concentration.
• EQUILIBRIUM ?when the molecules are even
  throughout a space Concentration Gradient ?
  difference between concentrations in a space.

26
Passive Transport

• Diffusion Some substances are allowed to move
  freely

• Facilitated diffusion? transport proteins

27
Osmosis

• The diffusion of water (across a membrane)
• Water will move in the direction where there is a
  high concentration of solute and low water
  concentration

28
Osmosis

• Dissolved molecules ( ions, organic molecules,
  etc) are called solutes
• Most solutes cannot cross membranes
• As solute conc increases free H2O decreases
• Hypertonic? high solute
• Hypotonic ? low solute

29
Isotonic- means the same
30
Hypotonic- less solute
31
Hypertonic- high solute
32
(No Transcript)
33
Water Balance in Animal Cells

• Net water flow into the cell which can burst
  (Hemolysis)

• Water flow equal in both directions

Net water flow out of cell which
shrinks (Crenation)
34
Water Balance in Plant Cells

• Turgid Flaccid

35
Plasmolysis

• Shrinking of cytoplasm in both plant and animal
  cells

36
(No Transcript)
37
Active Transport

• Cell expends energy to move molecules or ions
  across the membrane
• A specific transport protein pumps solute across
  a membrane
• The chemical energy is supplied by the
  mitochondria
• Example Na(Sodium) K(Potassium) pump.

38
Active Transport
39
Transport of Large Molecules

• Large molecules have to be packaged to be
  transported in and out of the cell
• Vesicles (membranes sacs) are formed to move the
  substances
• Exocytosis
• Endocytosis

40
Exocytosis Ednocytosis
41
More Exo Endo
42
Cell Organelles

• Section 6.4

43
Nucleus contents
44
Endoplasmic Reticulum (rough smooth)
45
Ribosome
46
Protein Synthesis
47
Golgi Body
48
Lysosomes
49
Chloroplasts and Mitochondria energize cells

• The cellular machinery constantly needs energy to
  function.
• Supplied by two organelles the Chloroplasts
  Mitochondria

50
Chloroplasts
51
Mitochondria
52
The Internal Skeleton

• Cytoskeleton
• Flagella
• Cilia

53
Microfilaments
54
Centriole
Cilia
Microtubule
