C Plus Data Structures

1
C Plus Data Structures

• Nell Dale
• David Teague
• Chapter 5
• Stack Structures
• Slides by Sylvia Sorkin, Community College of
  Baltimore County - Essex Campus

2
Definition of Stack

• Logical (or ADT) level A stack is an ordered
  group of homogeneous items (elements), in which
  the removal and addition of stack items can take
  place only at the top of the stack.
• A stack is a LIFO last in, first out structure.

3
Stack ADT Operations

• MakeEmpty -- Sets stack to an empty state.

• IsEmpty -- Determines whether the stack is
  currently empty.
• IsFull -- Determines whether the stack is
  currently full.
• Push (ItemType newItem) -- Adds newItem to the
  top of the stack.
• Pop (ItemType item) -- Removes the item at the
  top of the stack and returns it in item.

3
4
ADT Stack Operations

• Transformers
• MakeEmpty
• Push
• Pop
• Observers
• IsEmpty
• IsFull

change state observe state
4
5
Another Stack Implementation

• One advantage of an ADT is that the kind of
  implementation used can be changed.
• The dynamic array implementation of the stack has
  a weakness -- the maximum size of the stack is
  passed to the constructor as parameter.
• Instead we can dynamically allocate the space for
  each stack element as it is pushed onto the
  stack.

6

class StackTypeltchargt
7

class StackTypeltfloatgt
23.4 -7.9
8

class StackTypeltStrTypegt
9
Tracing Client Code
V
letter
10
Tracing Client Code
letter
V
Private data topPtr NULL
char letter V StackTypelt char gt
myStack myStack.Push(letter) myStack.Push(C)
myStack.Push(S) if ( !myStack.IsEmpty( )
) myStack.Pop( letter ) myStack.Push(K)

11
Tracing Client Code
letter
V
Private data topPtr
V
char letter V StackTypelt char gt
myStack myStack.Push(letter) myStack.Push(C)
myStack.Push(S) if ( !myStack.IsEmpty( )
) myStack.Pop( letter ) myStack.Push(K)

12
Tracing Client Code
letter
V
Private data topPtr
C V
char letter V StackTypelt char gt
myStack myStack.Push(letter) myStack.Push(C)
myStack.Push(S) if ( !myStack.IsEmpty( )
) myStack.Pop( letter ) myStack.Push(K)

13
Tracing Client Code
letter
V
Private data topPtr
S C V
char letter V StackTypelt char gt
myStack myStack.Push(letter) myStack.Push(C)
myStack.Push(S) if ( !myStack.IsEmpty( )
) myStack.Pop( letter ) myStack.Push(K)

14
Tracing Client Code
letter
V
Private data topPtr
S C V
char letter V StackTypelt char gt
myStack myStack.Push(letter) myStack.Push(C)
myStack.Push(S) if ( !myStack.IsEmpty( )
) myStack.Pop( letter ) myStack.Push(K)

15
Tracing Client Code
letter
S
Private data topPtr
C V
char letter V StackTypelt char gt
myStack myStack.Push(letter) myStack.Push(C)
myStack.Push(S) if ( !myStack.IsEmpty( )
) myStack.Pop( letter ) myStack.Push(K)

16
Tracing Client Code
letter
S
Private data topPtr
K C V
char letter V StackTypelt char gt
myStack myStack.Push(letter) myStack.Push(C)
myStack.Push(S) if ( !myStack.IsEmpty( )
) myStack.Pop( letter ) myStack.Push(K)

17
Dynamically Linked Implementation of Stack

• // DYNAMICALLY LINKED IMPLEMENTATION OF STACK
• include "ItemType.h" // for ItemType
• templateltclass ItemTypegt
• struct NodeType
• ItemType info
• NodeTypeltItemTypegt next

17
18

• // DYNAMICALLY LINKED IMPLEMENTATION OF STACK
  continued
• templateltclass ItemTypegt
• class StackType
• public
• StackType( ) // constructor
• // Default constructor.
• // POST Stack is created and empty.
• void MakeEmpty( )
• // PRE None.
• // POST Stack is empty.
• bool IsEmpty( ) const
• // PRE Stack has been initialized.
• // POST Function value (stack is empty)
• bool IsFull( ) const
• // PRE Stack has been initialized.
• // POST Function value (stack is full)

18
19

• // DYNAMICALLY LINKED IMPLEMENTATION OF STACK
  continued
• void Push( ItemType item )
• // PRE Stack has been initialized.
• // Stack is not full.
• // POST newItem is at the top of the stack.
• void Pop( ItemType item )
• // PRE Stack has been initialized.
• // Stack is not empty.
• // POST Top element has been removed from
  stack.
• // item is a copy of removed element.
• StackType( ) // destructor
• // PRE Stack has been initialized.
• // POST Memory allocated for nodes has been
• // deallocated.
• private
• NodeTypeltItemTypegt topPtr

19
20

• // DYNAMICALLY LINKED IMPLEMENTATION OF STACK
  continued
• // member function definitions for class
  StackType
• templateltclass ItemTypegt
• StackTypeltItemTypegtStackType( ) //
  constructor
• topPtr NULL
• templateltclass ItemTypegt
• void StackTypeltItemTypegtIsEmpty( ) const
• // Returns true if there are no elements
• // on the stack false otherwise
• return ( topPtr NULL )

20
21
Using operator new

• If memory is available in an area called the free
  store (or heap), operator new allocates the
  requested object, and returns a pointer to the
  memory allocated.
• The dynamically allocated object exists until the
  delete operator destroys it.

21
22
Adding newItem to the stack
newItem
B

• newItem B
• NodeTypeltchargt location
• location new NodeTypeltchargt
• location-gtinfo newItem
• location-gtnext topPtr
• topPtr location

23
Adding newItem to the stack
newItem
B

• newItem B
• NodeTypeltchargt location
• location new NodeTypeltchargt
• location-gtinfo newItem
• location-gtnext topPtr
• topPtr location

location
24
Adding newItem to the stack
newItem
B

• newItem B
• NodeTypeltchargt location
• location new NodeTypeltchargt
• location-gtinfo newItem
• location-gtnext topPtr
• topPtr location

location
25
Adding newItem to the stack
newItem
B

• newItem B
• NodeTypeltchargt location
• location new NodeTypeltchargt
• location-gtinfo newItem
• location-gtnext topPtr
• topPtr location

B
location
26
Adding newItem to the stack
newItem
B

• newItem B
• NodeTypeltchargt location
• location new NodeTypeltchargt
• location-gtinfo newItem
• location-gtnext topPtr
• topPtr location

B
location
27
Adding newItem to the stack
newItem
B

• newItem B
• NodeTypeltchargt location
• location new NodeTypeltchargt
• location-gtinfo newItem
• location-gtnext topPtr
• topPtr location

X C L
B
location
28
Implementing Push

• templateltclass ItemTypegt
• void StackTypeltItemTypegtPush ( ItemType newItem
  )
• // Adds newItem to the top of the stack.
• if (IsFull())
• throw PushOnFullStack()
• NodeTypeltItemTypegt location
• location new NodeTypeltItemTypegt
• location-gtinfo newItem
• location-gtnext topPtr
• topPtr location

28
29
Using operator delete

• The object currently pointed to by the pointer is
  deallocated, and the pointer is considered
  unassigned. The memory is returned to the free
  store.

29
30
Deleting item from the stack

• NodeTypeltItemTypegt tempPtr
• item topPtr-gtinfo
• tempPtr topPtr
• topPtr topPtr-gtnext
• delete tempPtr

B X C L
tempPtr
31
Deleting item from the stack
item
B

• NodeTypeltItemTypegt tempPtr
• item topPtr-gtinfo
• tempPtr topPtr
• topPtr topPtr-gtnext
• delete tempPtr

B X C L
tempPtr
32
Deleting item from the stack
item
B

• NodeTypeltItemTypegt tempPtr
• item topPtr-gtinfo
• tempPtr topPtr
• topPtr topPtr-gtnext
• delete tempPtr

B X C L
tempPtr
33
Deleting item from the stack
item
B

• NodeTypeltItemTypegt tempPtr
• item topPtr-gtinfo
• tempPtr topPtr
• topPtr topPtr-gtnext
• delete tempPtr

B X C L
tempPtr
34
Deleting item from the stack
B
item

• NodeTypeltItemTypegt tempPtr
• item topPtr-gtinfo
• tempPtr topPtr
• topPtr topPtr-gtnext
• delete tempPtr

X C L
tempPtr
35
Implementing Pop

• templateltclass ItemTypegt
• void StackTypeltItemTypegtPop ( ItemType item )
• // Removes element at the top of the stack and
• // returns it in item.
• if (IsEmpty())
• throw PopOnEmptyStack()
• NodeTypeltItemTypegt tempPtr
• item topPtr-gtinfo
• tempPtr topPtr
• topPtr topPtr-gtnext
• delete tempPtr

35
36

• templateltclass ItemTypegt
• bool StackTypeltItemTypegtIsFull( ) const
• // Returns true if there is no room for another
  NodeType // node on the free store false
  otherwise.
• NodeTypeltItemTypegt location
• try
• location new NodeTypeltItemTypegt
• delete location
• return false
• catch(bad_alloc exception)
• return true

36
37

• // Alternate form that works with older compilers
• templateltclass ItemTypegt
• bool StackTypeltItemTypegtIsFull( ) const
• // Returns true if there is no room for another
  NodeType // node on the free store false
  otherwise.
• NodeTypeltItemTypegt location
• location new NodeTypeltItemTypegt
• if ( location NULL )
• return true
• else
• delete location
• return false

37
38
Why is a destructor needed?

• When a local stack variable goes out of scope,
  the memory space for data member topPtr is
  deallocated. But the nodes that topPtr points to
  are not automatically deallocated.
• A class destructor is used to deallocate the
  dynamic memory pointed to by the data member.

39

• templateltclass ItemTypegt
• void StackTypeltItemTypegtMakeEmpty( )
• // Post Stack is empty all elements
  deallocated.
• NodeTypeltItemTypegt tempPtr
• while ( topPtr ! NULL )
• tempPtr topPtr
• topPtr topPtr-gtnext
• delete tempPtr
• templateltclass ItemTypegt
• StackTypeltItemTypegtStackType( ) // destructor
• MakeEmpty( )

39
40

• templateltclass ItemTypegt
• void QueTypeltItemTypegtDequeue( ItemType item )
• // Removes element from from front of queue
• // and returns it in item.
• // Pre Queue has been initialized.
• // Queue is not empty.
• // Post Front element has been removed from
  queue.
• // item is a copy of removed element.
• NodeTypeltItemTypegt tempPtr
• tempPtr qFront
• item qFront-gtinfo
• qFront qFornt-gtnext
• if ( qFront NULL )
• qRear NULL
• delete tempPtr

40
