Use of Water Soluble Polymers to Prevent Membrane fouling in MBR

1
Use of Water Soluble Polymers to Prevent Membrane
fouling in MBRs
Belgische Membraangroep 8 november
2007 Jeroen Koppes Email jkoppes_at_nalco.com Wate
r RD, Nalco Europe
2
Nalco Company
1947Nalco goes public
1964Nalco shares listedon New York
StockExchange
2004Nalco initial public offering on New York
Stock Exchange
3
Who We Are

• World leader in water treatment and industrial
  process services with more than 3.6 billion in
  sales
• Nalcos 11,000 employees work with more than
  60,000 customers in 130 countries in industry,
  government and institutions.

4
Global presents
European Operations Leiden, The Netherlands
Global Headquarters Naperville, Illinois
Pacific RimSingapore

• RESEARCH CENTERS
• U.S.
• Netherlands
• Singapore

• Latin America Operations Sao Paulo, Brazil

5
What We Provide
SERVICES
CHEMICALS

• Corrosion and scale inhibitors
• Biocides, bioengineering
• Coagulants, dispersants, flocculating agents
• Alkalizers, passivators,membrane improvers,
  sludge dewatering
• Defoamers, process lubricants, odor and

• On-site system auditing and start-up
• Product and equipment selection
• Program assurancemonitoring and testing
• Performance measurement
• Analytical/failure testing
• Equipment consulting
• Installation, maintenance repair
• Operator training certification

EQUIPMENT

• RO systems
• Chemical feed equipment
• Standard water treatment equipment

6
Content

• What is an MBR and its fouling problems
• What is Membrane Performance Enhancer (MPE) ?
• Full scale Membrane Bioreactor Results
• MPE Toxicity
• Overview Capital and Investment savings
• Conclusions

7
Conventional versus MBR
Conventional Activated Sludge
Wastewater
Aeration Tank Biomass 4 g/l
settler
Water with 10-30 ppm solids
Sludge recycle
Waste sludge
Membrane Bioreactor (MBR)
Aeration Tank Biomass 12 g/l
Wastewater
UF / MF Membrane
Reuse in Cooling tower or RO, water with 0 ppm
solids
Sludge recycle
Waste sludge
8
Submerged MBR membrane modules
MBRs use Ultra (UF) or Micro filtration (MF)
Operation
Kubota Toray
Mitsubishi
Zenon Memcor
9
Advantages MBR

• Save space, small footprint (2 3 x smaller)
• Better effluent quality (no solids)
• Reuse of wastewater (e.g. RO or cooling tower)
• Improved operation (no sludge settlement
  problems, bulking etc ...)
• No final clarifier needed
• Easy to retrofit existing conventional
  installation

10
Limitations MBR

• Fouling of the UF or MF membranes due to
  biopolymers formed by the bacteria and particles
  resulting in reduced wastewater throughput (flux)

• High membrane cleaning frequency due to membrane
  fouling
• High energy costs, especially due to scouring air
  to keep membranes clean
• Relatively higher capital investment and
  operational expenses compared to conventional
  wastewater treatment
• Low temperature wastewater resulting in higher
  viscosity (lower flux)
• Replacement cost of membrane modules after 5-8
  years

11
What is MPE Technology?

• Specially modified cationic polymer
• Prevents membrane fouling
• Adsorbs completely to bio-material
• No residual polymer in filtrate
• MPE30 MPE50 products
• Compatible with all commercial submerged MBR
  membranes
• Added directly to mixed liquor
• Patented technology

12
What is the Mechanism for MPE Chemistry?
Less Biofilm Higher Porosity
Biofilm Layer SMP and EPS(Colloidal Particles)
SMP/EPS in Floc Structure
Mixed Liquor
Permeate
Permeate
Increase Particle Size Distribution
Membrane
Membrane
MPE chemistry forms polymer-biopolymer complexes
and these complexes become part of bio-floc
structure.
13
Membrane Fouling
Wastewater
Constant Flux Mode
Filtration Time
14
Membrane Bioreactor (MBR)
Bioreactor
Membraan tank
Membrane Performance Enhancer- MPE

Effluent
Influent
Recycle
15
MPE Agglomerates Biopolymers
No MPE50 added
16
Membrane Fouling/Biopolymer Reduction(At High
Fouling Condition)
Control
600 ppm MPE50
After operating at 15 LMH
After operating at 25 LMH
17
MPE Reduces Small Particles
MFR reactor Membrane Fouling Reducing Reactor
Reference Byung-Kook Hwang et al., NAMS2005
18
Effect of MPE Chemistry on Biofilm Characteristics
Reference Chung-Huk Lee et al., 4th MBR Workshop
Sapporo August, 2006
19
MPE50 Technology has been applied to more than 40
sites world-wide
20
Full scale Example

• Food industry, the Netherlands

21
Industrial MBR in the NetherlandsSystem overview
Effluent to sewer
Biology membrane tank 125 m3
Buffer tank 75 m3
30 m3/day Influent
Sludge wastage to 55 m3 storage tank
Air
Food industry wastewater COD influent 2 20
g/l (average 7g/l) Sludge concentration (MLSS)
15 20 g/l
22

Industrial MBR (Side view)
23
Top view of industrial MBR
Membranes are 5 meter below turbulent area
Dosage location of MPE50
24
Effect of MPE50 on the sludge filterability
(laboratory test)
25
Continuous Performance of MPE50 Industrial MBR,
the Netherlands
26
200 increase in permeability
Average data
27
Effect of MPE50 on foam
Before MPE50
After MPE50
28
Foam reduction
29
Toxicity ?

• 8 Cell Respirometer - Toxicity Testing
• Dosage 0 3000 PPM MPE-50 - Same Oxygen Uptake
• Agreed with Previous Respirometer Results
• No Negative Effect on Nitrification
• 3000 ppm MPE-50
• Measure TKN
• Influent 370 PPM / Effluent Averaged 3 PPM TKN -
  99 removal

30
MPE is not toxic for the biomass
MLSS 12 g/L Sample 500 ml Initial COD 200 mg/L
31
MPE Technology Creates Significant Value
Capacity 170m3/h SRT 20 days
32
Conclusions

• MPE prevents membrane fouling
• Long term test show significant flux increase, 30
  70
• MBR investment and operational cost reduction can
  be achieved due to reduced membrane surface
• MPE is non toxic and an effective foam reducer
