Classroom presentations to accompany Understanding Earth, 3rd edition

1
Classroom presentations to accompany
Understanding Earth, 3rd edition

• prepared by
• Peter Copeland and William Dupré
• University of Houston

Chapter 6 Weathering and Erosion
2
Weathering and Erosion
Tim Davis/Photo Researchers
3
Weathering

• Physical and chemical changes that occur in
  sediments and rocks when they are exposed to the
  atmosphere and biosphere.
• Not the same as erosion.

4
Factors Controlling Rates of Weathering
5
Chemical weathering

• This process occurs because minerals formed deep
  in the earths interior are not stable under
  surface conditions.
• Stability is generally the reverse of Bowens
  reaction series.
• The principle agent of chemical weathering is
  water.

6
Chemical weathering of silicates

• Quartz very stable
• Feldspars form clay minerals
• Mafic minerals decompose to oxides

7
Chemical weathering of carbonates

• Easily soluble in water (especially with some
  acid present)
• Ca and Mg taken into solution

8
Weathering rates of gravestones
Marble
Slate
Fig. 6.1
R. Siever
9
Etched and corroded feldspar in the soil zone
Fig. 6.2
Berner Holden, 1977
10
Fig. 6.3a
11
Fig. 6.3b
12
Fig. 6.3c
13
Analogy of weathering making coffee
fresh grounds water coffee residue
(a
solution) K-feldspar water K kaolinite
(a clay
mineral)
14
Weathering and Making coffee
Fig. 6.4
15
Weathering by solution

• The complete breakup of minerals into
• ions in solution
• NaCl (halite) is the best example, but is
• geologically unimportant
• calcite (limestone) CaCO3
• CaCO3 H2CO3 Ca2 2HCO3-
• Mafic silicates dissolve much more
• slowly

16
Mechanical Weathering Changes the Surface to
Volume Ratio
Fig. 6.5
17
Fig. 6.6
18
Fig. 6.6
19
CO2 and the Atmosphere, Weathering, and the
Climate
Fig. 6.7
20
Fig. 6.8
21
Weathering Oxides Provide Color to the Desert
Landscape
Betty Crowell
Fig. 6.9
22
Weathered Limestone
Fig. 6.10
Ric Ergenbright
23
(No Transcript)
24
Joint-controlled Weathering
Fig. 6.11
Jeff Foott/DRK
25
Mechanical weathering

• Frost water expands by 9 when it freezes
• Thermal expansion differential thermal
  expansion of minerals creates stress in rocks
• Organic activity tree roots to
  micro-organisms
• Mechanical abrasion things go bump

26
Role of Organisms in Weathering
Fig. 6.12
Peter Kresam
27
Gneiss Boulder Fractured by Frost Action
Michael Hambrey
Fig. 6.13
28
Exfoliation Dome in Yosemite
Fig. 6.14
Tony Waltham
29
Spheroidal Weathering
Fig. 6.15
Michael Follo
30
Weathering terms

• Bedrock unaltered rock of any kind
• Regolith a layer of broken pieces of rock
  and slightly altered rock that overlies the
  bedrock
• Soil a layer of altered mineral material
  usually mixed with organic material

31
Weathering, Soil Formation, and Erosion
Fig. 6.16
32
Weathering, Soil Formation, and Erosion
Fig. 6.16
33
Change in U.S. soil erosion rates
34
Soil Profile
Fig. 6.17
35
Laterite
Fig. 6.18a
36
Pedalfer
Fig. 6.18b
37
Pedocal
Fig. 6.18c
38
Sand
Fig. 6.19
Rex Elliot
