Title: MAGNETOHYDRODYNAMICS


1
MAGNETOHYDRODYNAMICS
(Bozeman, July, 2005) Eric Priest
2
(No Transcript)
3
Check Google for eric priest
4
CONTENTS
1. Introduction 2. Flux Tubes Example 3.
Fundamental Equations 4. Induction
Equation Example 5. Equation of Motion
Example 6. Equilibria 7. Waves
5
Traditionally
close link Mathematics - Astronomy
e.g., Gregory Chair of Maths James Gregory
(1638-1675)
Invented Reflecting Telescope
Co-founder of Calculus
6
James Gregory
  • Elected FRS (Academician) 1668 (age 30)
  • Appointed 1st regius prof maths at St Andrews
    (1668)
  • Given hall as lab -- see line for telescope
    along meridian

7
James Gregory
- wrote 1st text book on Calculus -
discovered
-- General binomial theorem
-- Taylor expansions
-- Ratio test for convergence of a series
-- Series for sin x and tan x
-- Integral of log x and sec x
-- Differentiation is inverse of integration
-- How to use change of variable in integration
8
1. INTRODUCTION
Role of Theory ?
  • Not -- reproduce images
  • Nor explain every observation

Understand Basic Processes
-- step-by-step -- simple -gt
sophisticated model
  • Listen to Observers -- clues
  • Diff. Types Theory -- complement
  • -- analytical -- computational -- data interp.


9
The Sun
Amazingly rich variety of MHD phenomena
10
Magnetic Field Effects
E.g., A Sunspot
B exerts a force
  • - creates intricate structure

What is equilibrium ? / nature of instabilities
11
E.g., A Prominence
Magnetic tube w. cool plasma
B --gt Thermal Blanket Stability
What is global equilibrium? / fine structure
?
Why erupt ?
12
E.g., A Coronal Mass Ejection

Magnetic instability ??
13
E.g., A Solar Flare
(from TRACE)
B stores energy - converted to other forms

Why erupt ? How is energy converted?
14
Magnetohydrodynamics
  • MHD - the study of the interaction between a
    magnetic field and a plasma, treated as a
    continuous medium
  • The assumption of a continuous medium is valid
    for
  • length-scales
  • Chromosphere
  • Corona

15
2. FLUX TUBES
Magnetic Field Line -- Curve w. tangent in
direction of B.
Equation
or in 3D
In 2D
16
Magnetic Flux Tube
-- Surface generated by set of field lines
intersecting simple closed curve.
  • Strength (F) -- magnetic flux crossing a
  • section
  • i.e.,

17
(ii) But
--gt No flux is created/destroyed inside flux
tube So is constant along tube
(iii) If cross-section is small,

B lines closer --gt A smaller B increases
18
EXAMPLE
Sketch the field lines for
  • Eqn. of field lines


y2 - x2 constant
  • Sketch a
  • few field lines

? arrows, spacing
19
(iii) Directions of arrows
20
(iv) Spacing
At origin B 0.
A "neutral" or "null" point
Magnetic reconnection energy conversion
21
? Studying Sun Entails
22
? THOUGHT of MATHS FILL with CONFIDENCE
23
Eqns of Magnetohydrodynamics
Model interaction of B and plasma (conts medium)
PDE's for v and B as functions of x,y,z,t
As beautiful as the Sun !! -- Nonlinear
Impossible to solve completely
So approximate in imaginative ways --
Construct models for many dynamic phenomena on Sun
24
3. FUNDAMENTAL EQUATIONS of MHD
  • Interaction of B and Plasma
  • Unification of Eqns of
  • (i) Maxwell

25
(ii) Fluid Mechanics
or (D / Dt)
26
In MHD
?D/?t
  • 1. Assume v ltlt c --gt Neglect
  • 2. Extra E on plasma moving

  • 3. Add magnetic force

  • Eliminate E and j take curl (2), use (1) for j

27
4. INDUCTION EQUATION

28
Induction Equation
N.B. (i) --gt B once v is known
(ii) In MHD, v and B are induction
eqn eqn of motion --gt basic physics
primary variables
(iii) are secondary variables
29
Induction Equation
A B
(iv) B changes due to transport diffusion
  • (v) --

magnetic
Reynold number
eg, L0 105 m, v0 103 m/s --gt Rm
108
(vi) A gtgt B in most of Universe --gt
B frozen to plasma -- keeps its energy
Except SINGULARITIES -- j B large
Form at NULL POINTS, B 0
30
(a) If Rm ltlt 1
  • The induction equation reduces to
  • B is governed by a diffusion equation
  • --gt field variations on a scale L0
  • diffuse away on time

with speed
  • E.g. sunspot ( 1 m2/s, L0 106 m), td
    1012 sec
  • for whole Sun (L0 7x108 m), td 5x1017
    sec

31
(b) If Rm gtgt 1
The induction equation reduces to
and Ohm's law --gt
Magnetic field is
frozen to the plasma
32

Magnetic Flux Conservation Magnetic Field
Line Conservation
33
5. EQUATION of MOTION
(1) (2) (3) (4)
  • In most of corona, (3) dominates
  • Along B, (3) 0, so (2) (4) important


Scale Height
34
Example
MHS Eqm. along B
35

On Earth H 9 km,
so on munro (1 km) p 0.9 p0
or on Everest (9 km) p 0.37 p0
T 5000 K, H T 2 x 106
K, H
150 km
50 Mm
36
Magnetic force
Tension B2/ ----gt force when lines
curved
Magnetic field lines have a
Pressure B2/(2 )----gt force from high to low
B2
37
EXAMPLE
Find Magnetic Pressure force, Magnetic Tension
force and j x B force for
38
Ex.
39
Ex.
40
Equation of Motion
(1) (2) (3) (4)

Plasma beta

Alfvén speed
41
6. EQUILIBRIA
(1) (2) (3) (4)
  • If v ltlt vA, then (1) ltlt (3) and so

( Equilibrium)
Magnetohydrostatic
42

(2) (3) (4)
  • If Lo ltlt H, then (4) ltlt (2) and
  • If Lo ltlt 2H/ , then (4) ltlt (3) and

(Magnetostatic Equilibrium)
(Force-Free)

43
Example
Shapes -
caused by magnetic field (force-free)
Fineness -
small scale of heat sources small kperp
Structure along loops -
hydrostatics/hydrodynamics (?H)
44
7. WAVES
(i) Sound Waves (B0 0)

Dispersion Relation
Waves propagate with speed
45
(ii) Magnetic Waves (p0 0)
Repeat, but uniform (B0) - include j x B
force - assume wave propagates at angle to B0
Either
Alfvén Waves
Incompressible - due to magnetic tension
Or Compressional Alfvén Waves
Compressible - due to magnetic pressure
- propagate at speed
46
(iii) MHD Waves (p0 and B0 nonzero)
  • Alfvén Wave is unaffected
  • Compressional Alfvén Wave and Sound Wave are
    coupled

Slow Magnetoacoustic Wave (Slow-Mode) Fast
Magnetoacoustic Wave (Fast-Mode)
Propagate slower/faster than Alfvén Wave
47
8. CONCLUSIONS
  • Understanding how B interacts with plasma
  • Key to many solar system phenomena
  • Two main equations
  • Induction equation -- advection diffusion
  • Eqn. motion -- magnetic tension pressure
    forces
  • --gt Theory for equilibria, waves,
    instabilities,
  • and reconnection


48
PS. SOLUTIONS
Ex. 1
--gt
49
Ex. 2
50
sunearth.gsfc.nasa.gov/sunearthday/2004/vt_edu2004
_venus_back_his.htm
In 1663, Rev. James Gregory (1638 - 1675) who
was considered one of the most important
mathematicians of the 17th century suggested that
a more accurate measurement of the Earth-Sun
distance could be made using the transit of
Venus. Sir Edmund Halley (1656-1742), the
namesake for Halley's Comet, made the same
suggestion 14 years later in 1677 and published
an important paper on the details of this
technique in 1716. In science, it is not always
'being first' or 'being correct' that gets you
into the history books.
But - James Gregory was not a minister.
Jeremiah Horrocks used transit in 1639 to obtain
1AU 60 million miles
51
EXAMPLES 1 2
Sketch field lines for
52

Lo lt H --- p const
Lo gt H --- p falls
- acts from high to low p - is normal to isobars
isobars
53
EXAMPLE .
Diffusion of a 1D Field satisfies
Find B(x,t) if B0 for xgt0 B(x,0)
- B0 for xlt0
54

55
(No Transcript)
56

57
Typical Values on Sun
N (m-3) 106 N (cm-3), B (G) 104 B (tesla)
3.5 x 10 -21 N T/B2, vA 2 x 109 B/N1/2
58
Force-Free Fields

is constant along each field line
So
59

Constant- or fields
linear force-free
60
(iv) Shock Waves
  • Nonlinear sound wave can steepen to a shock
    wave -- propagates at speed gt cs
  • In MHD 3 modes
  • (1) Slow-mode shock
  • - propagates faster than slow-mode speed
  • - turns B towards normal

(2) Fast-mode shock - propagates faster than
fast-mode speed - turns B away from normal
(3) Finite-amplitude Alfvén Wave - no change in p
- reverses tangential magnetic field
61

Slow-mode Alfvén Fast-mode
