CWNA Certified Wireless Network Administrator

1
CWNACertified Wireless Network Administrator

• Antenna Accessories

2
RF Amplifiers

• RF Amplifier an active electronic device to
  increase the level of an RF signal.

AC/DC Power Input
RF Amplifier
Phantom Power Input
FCC Certification CFR 15.204
3
Two Types of RF Amplifiers
Antenna
Access Point
T
PowerSource
Unidirectional RF Amplifier
Antenna
T
Access Point
C1
C2
R
PowerSource
Bi-Directional RF Amplifier
4
WLAN RF Amplifiers
A
C
B
5
Amplifier Specification

• Automatic Gain Controlled TX
• Power Output 100mW to 1W in 802.11 b/g
• Receive Gain 20dB (0 to 23dB gain on request)
• High Q 3 Pole Band Pass Filter in both TX RX
• Low 2.5dB RX Noise Figure
• Low Transmit Harmonics
• Indoor Outdoor Models Available
• DC Injector Included for SAX Model
• Machined Aluminum Housing
• Potted Circuit Card Assembly
• Mounting Hardware Included
• Internal Lightning Protection
• Weather Proof Die-Cast Aluminum Housing
• 2 Year Warranty w/ Lightning Protection

SA Series Antennafier Indoor Amplifiers 802.11b/8
02.11g Indoor Amplifier with 12VDC Power Supply
6
Amplifier Installation
D
E
C
F
B
A
G
H
7
RF External Amplifier
Antenna
Antenna Mount
RF Amplifier
Cable Standoffs
Transmission Cable/Line
DC Injector
Antenna Mast
AP
Antenna Ground Rod
WLAN
Building
8
FCC CRF 15.204
B
A
Cisco Aironet 1400 Wireless Bridge
Trango Systems' ATLAS5010
C
Tsunami QuickBridge 11 Kit
A system is inclusively the devices and
components from the Access Point to the Antenna.
9
RF Attenuators

• An RF attenuator is a device that reduces the
  level of an RF signal. RF attenuators can be
  fixed or adjustable.

Stepped Attenuator
Variable Attenuator
Fixed Attenuators
10
RF/Microwave Attenuators
DC through 18 GHz 1 - 60 dB Fixed
DC through 4 GHz 0 - 60 dB Variable
DC through 4 GHz 0 - 70 dB, 10 dB Steps
11
Grounding

• Grounding - connecting an electrical circuit or
  device to the Earth. This serves various
  purposes to drain away unwanted currents to
  provide a reference voltage for circuits needing
  one to lead lightning away from delicate
  equipment to improve the radiation pattern or
  efficiency of an antenna.

12
Grounding
6 AWG
Brass acorn clamp
GND Tester
Earth
Ground Rods
8 min
6 min
13
Antenna/Cable Grounding
14
Lightning Arrestor

• Lightning Arrestor A device used to allow a
  path to ground for unwanted static electricity,
  lightning-induced surges, or any abnormally high
  voltage or current.

¼-? Stub
Gas Discharge
A
B
C
0.4db Max Insertion Loss 350V or 90V Breakdown
Voltage VSWR Better than 1.51 Passes DC
voltage 200W Operation
15
Lightning Arrestors
Antenna
Antenna
To Access Point
To Antenna
Antenna Mount
GND
Arrestor
GND Post
RF Amplifier
To DC Injector
Ground Rod
16
RF Splitter / Power Dividers

• RF Splitter - A passive or active device that
  divides one RF signal into multiple RF signals.

Test Antenna
mW
50
Power Meter
RFAmplifier
RFSplitter
17
RF Splitters
Sector Panel Antennas
RF Splitter
Ant - 1
Ant - 2
Reduced Power Out1
Reduced Power Out2
A
Radiation Patterns
Power In
B
Mechanical Beam Tilt
18
Splitters/Dividers
2-way splitter
4-way splitter
A
B
19
RF Connectors

• An RF device for mechanically terminating and
  providing electrical contact between devices
  and/or cables.

Cable
RF Plug Male
RF Jack Female
20
RF Connector Types
BNC - Type, stands for Bayonet Neill, Concelman,
1940s 50 O and 75 O, up to 11 GHz.
N - Type, named after Paul Neill of Bell Labs,
1040s 50 O, up to 11 GHz.
TNC - Type, stands for Threaded Neill, Concelman,
1950s 50 O, up to 11 GHz, There are two types of
TNC connectors Standard and Reverse Polarity.
SMA - Type is an acronym for SubMiniature version
A, 1960's 50 O, up to 18 GHz.
UHF - Type, is an acronym for Ultra High
Frequency, 1930s 50 O, up to 300 MHz. Not a
good connector for wireless LANs!
21
A Closer Look at Connectors
N-Connectors
Pin
Socket
Male N-type
Female N-type
RP-TNC-Connectors
Pin
Socket
Female TNC-type
Male TNC-type
Note There is also Reverse Thread (left-hand)
connectors
22
Making Connections
RP-TNC to SMA
Coax Adapter kit
Type N m to TNC m adapter
23
N-Type Connectors
Female / Jack
Male / Plug
Female / Jack Chassis
Inline Double Female
Right Angle Male to Female
T Adaptor 2 Female to Male
24
RF Cables

• RF Cables Coaxial Cable - A cylindrical
  transmission line comprised of a conductor
  centered inside a metallic tube or shield,
  separated by a dielectric material, and usually
  covered by an insulating jacket.

Insulating Jacket
Metal Shield
Dielectric
Center Conductor
25
Coaxial Cable
B
A
C
26
Coaxial Cables
Attenuation of cables, dB/100 ft, (dB/100 m)
Table 5-1
27
LMR-400
LMR standard is a UV Resistant Polyethylene
jacketed cable designed for 20-year service
outdoor use. The bending and handling
characteristics are significantly better than
air-dielectric and corrugated hard-line cables.
Table 2
Table 1
Table 3
Interactive calculator available at
http//www.timesmicrowave/telecom
28
RF Cables

• Pigtail cable Usually a short cable that has
  a proprietary connector on one end and a
  industrial standard connector on the other end.

B
C
A
29
Frequency Converter

• Frequency Converter an active device that
  converts a frequency or band of frequency from
  one range to another.
• Up-converter / down-converter Translates a low
  frequency/band to a high frequency/ band and
  vise-versa.

30
Frequency Converter
802.11b
802.11a
Freq.
2 GHz
6 GHz
UP
2.4 GHz Band
5.8 GHz Band
C1
C2
Down
PowerSource
Frequency Converter Bi-directional Translator
31
Frequency converters
B
A
Uni-directional (down converter 2.4 - 2.5 GHz to
1.483 - 1583 GHz
C
Bi-directional (up-down converter 2.4 to 5.8 GHz
Bi-directional (up-down converter 2.4 to 3.4 GHz
32
Test Kits / Instruments

• Digital Multimeter
• Power Meter
• RF Signal Generator
• Spectrum Analyzer
• Time Domain Reflectometer

Power Meter
Site Survey Kit
