Polynomials

1
Polynomials
2
Content

• Evaluation
• Root finding
• Interpolation
• Resultant

3
Introduction

• Best understood and most applied functions
• Taylors expansion
• Basis of parametric curve/surface
• Data fitting
• Basic Theorem
• Weierstrass Approximation Theorem
• Fundamental Theorem of Algebra

4
Evaluation Horners Method

• Compare number of multiplications and additions

5
Details
6
Details (cont)
7
Evaluating xk Efficiently

• Instead of using pow(x,k), or any
  iterative/recursive subroutines, think again!
• The S-and-X method S(square) X(multiply-by-x)
• See how it works in the next pages
• Understand how to implement in program

8

• Say the exponent k in base-2 a2a1a0 (kgt3)

Each symbol, S or X, represents a multiplication
Except for the leading digit, replace 1 by SX,
0 by S
7
4
3
3
of ?
9
Implementation
Left-to-right scan
1
1
1
0
1
z
x2
x4
x16
x8
x
10
Multiplication, division

• FFT
• GCD of polynomials (Euler algorithm)

11
Roots of Polynomials

• Low order polynomials (for degree ?4)

Hi-precision formula for quadratics
Quartics see notes
12
Calculator City (ref)
13
Root Counting

• P(x) has n complex roots, counting multiplicities
• If ais are all real, then the complex roots
  occur in conjugate pairs.
• Descartes rules of sign
• Sturms sequence
• Bounds on roots
• Deflation

14
Computing Roots Numerically

• Newton is the main method for root finding
• Can be implemented efficiently using Horners
  method
• Quadratic convergence except for multiple root
• Use deflation to resolve root multiplicity but
  can accumulate error polynomials are sensitive
  to coefficient variations
• Newton-Maehlys method roots converges
  quadratically even if previous roots are
  inaccurate

15
(No Transcript)
16
Experiment

• P(x)(x-1)(x-2)(x-3)(x21)
• Assume two imprecise roots have been found, 1.1
  1.9
• The deflated (cubic) polynomial is then
• x3-3x20.91x-3

17
Original quintic Converged to 3 in many steps (5
was not a good guess for 3)
Deflated cubic Faster convergence, but solution
was plagued with the propagated error
Maehly procedure Fast convergence accurate
solution
18
Polynomial Interpolation

• Given (n1) pairs of points (xi,f(xi)) find a
  nth-degree polynomial Pn(x) to pass through these
  points
• Compute the function value not listed in the
  table by evaluating the interpolating polynomial

19
Lagrange Polynomial

• High computational cost cannot reuse points
• Divided difference a better alternative

20
Divided Difference
21
Divided Difference (cont)
22
(No Transcript)
23
Resultant

• An expression involving polynomial coefficients
  such that the vanishing of the expression is
  necessary and sufficient for the set of
  polynomials to have a common zero.

24
Resultant (cont)
with
The above system has common zero
The equation Qz 0 has nonzero solution IFF
Rdet(Q) vanishes. R is called the resultant of
the equations.
25
Example
26
Applications of Resultant
II. Algebraic curve intersection
I. Common zero
III. Implicitization
R(x) 0 IFF intersection exists
27
Sylvester Matrix and Resultant
28
Find Common Zero

• The system has simultaneous zero iff the
  resultant is zero

29
Result from Linear Algebra
has non-trivial solution if det(A) 0
A reduced system gives the ratio
30
Sylvester Resultant

• To find the common zero, consider the reduced
  system

31
Resultant in Maxima
x as independent variable
32
Algebraic Curve Intersection
No real roots no intersection (circle
hyperbola)
33
Algebraic Curve Intersection
2 real roots 2 intersection points
34
Implicitization
The above system in t has a common zero whenever
(x,y) is a point on the curve.
a parabola
Application parametric curve intersection Find
the corresponding parameter of (x,y) on the curve
35
Parametric Curve Intersection
implicitize
F(s)f(x(s),y(s))0
f(x,y)0
Find roots in 0,1
Bernstein polynomial
Cubic Bezier curve and its control points
36
Quadratic Bezier Curve Intersection
Sketch using de Casteljau algorithm 1, 2
37
De Casteljau Algorithm ref
A cubic Bezier curve with 4 control points
p(t), t?0,1 is defined. Locate p(0.5)
38
Inversion
Given (x,y) on the curve, find the corresponding
parameter t
Example
