(Some) Key Issues in Grid Computing
David Walker School of Computer Science Cardiff
University
http//www.cs.cf.ac.uk/user/David.W.Walker
3
Main Thesis of Talk

• At a surface level many aspects of Grid Computing
  appear to be straightforward, and reduce to
  simple programming tasks and the use of existing
  tools.
• This talk aims to show that for domain scientists
  to effectively use the Grid many challenging CS
  issues need to be addressed.

4
A Typical Scientific Process
5
Key Elements of the Grid

• The specification of problems how do you
  program the Grid?
• The dynamic discovery of Grid resources.
• Provenance support for Grid applications.
• The interoperability and federation of different
  Grid middleware stacks.
• Grid access to legacy applications.
• Support for remote collaboration over the Grid.

6
A Simple Example

• A simple use of the Grid involves the use of a
  PSE or portal to do a set of pre-determined
  tasks.
• This corresponds to the utility computing mode
  of use.
• No support for building new applications or
  services.
• No support for dynamic discovery of resources.
• No support for collaboration.

7
Programming the Grid

• Problem specification could involve
• Use of high-level domain-specific
  programming/scripting language.
• Representing coordinated tasks with a workflow
  graph assembled in a visual programming
  environment.
• Use of recommender systems to assist users in
  formulating and solving problems.

8
Workflow

• Commonly used to represent applications composed
  of interacting services.
• Services may be hierarchical composed of other
  services.
• Easy to represent graphically, but not scalable
  with number of services or number of
  inputs/outputs.

9
Workflow Composition
Would like to support the domain scientist in
designing workflows to solve problems.
10
Problems in Workflow Composition

• How do you know that the input port of one
  service is compatible with the output port of
  another service?
• Given that the services may have been created by
  different people/organisations?
• Type signatures must match, but semantics must
  also match.

11
Annotating Services

• To support plug-and-play between services in a
  workflow requires the use of ontologies.
• Need to give semantic content (meaning) to
  service inputs and outputs.
• This allows composition hints in the form of
  semantic suggestions. For example, for a given
  service port we could find all services that
  could be connected to it.

12
Types of Workflow Composition
13
Workflow Composition in Semantic Grids

• Semantic Web technologies enable automation at
  several levels automated resource discovery,
  selection, management, service composition,
  execution.
• Promises automated seamless interoperation of
  autonomous, heterogeneous distributed
  applications.
• Our focus is on the use of Semantic Web
  technologies to automate service composition in
  Grid environments.
• See S Majithia, DW Walker, and WA Gray Automatic
  Composition of Web Services, in Proceedings of
  the UK e-Science Programme All-Hands Meeting
  2004. Available online at http//www.allhands.org.
  uk/proceedings/papers/148.pdf
• Main developer is Shalil Majithia.

14
Framework - Overview
WFMS Workflow Manager Service AWFC Abstract
Workflow Composition Service CWFC Concrete
Workflow Composition Service RS Reasoning
Service MMS Matchmaking Service AWFR
Abstract Workflow Repository CWFR Concrete
Workflow Repository RB - Rulebase
15
Framework - Interactions
16
Abstract Workflow Composer

• An abstract workflow specifies a workflow without
  referring to a specific service implementation .
• The Abstract Composer tries to generate an
  abstract workflow by using
• AWF Repository stores semantically annotated
  descriptions of services and workflows. Use
  ontology to match services.
• Rulebase a rulebase specifies the recipe to
  achieve an objective
• Chaining services try and chain services by
  matching service outputs and inputs.

17
Concrete Workflow Composer

• A concrete workflow specifies an executable
  workflow by referring to specific service
  implementations.
• The Concrete Composer tries to generate an
  executable workflow by using
• Matchmaking match abstract workflow with service
  implementations available at that time.
• Chaining services try and chain services by
  matching service outputs and inputs.

18
Other Components

• Matchmaker service (based on that of Paolucci et
  al.) adapted for dynamic substitution.
• Chaining service backward chaining service based
  on domain ontologies.
• Repositories store semantically annotated
  abstract and concrete workflows.

19
Implementation

• All components implemented as Web services using
  Axis server.
• Services and workflows described using OWL-S.
• DQL/JTP server used for subsumption reasoning
• Rulebase implemented in RuleML
• Plug-in module enables generation of concrete
  workflows in BPEL4WS.

Snippet of OWL-S Profile for FFT
20
Family Tree Example

• Families trees have 3 basic relationships
• Spouse_of
• Child_of
• Parent_of
• Other relationships (aunt, grandparent, cousin,
  etc) can expressed in terms of these
  relationships through an ontology.

21
Cousins Example

• Suppose we want to create a workflow to find the
  cousins of a given person, X.
• Query is submitted to WFMS which checks the AWF
  repository (i.e., checks annotated name of
  workflows)
• If no match then check rule base

22
Rulebase

• Grandparents(X)ParentsParentsX
• Cousins(X)excludeGrandchildrenGrandparents(X),
  ChildrenParentsX
• Note There is no rule for GrandchildrenX. The
  Chaining Service would deduce how to do this from
  the ontology.

23
Abstract Workflow From Rulebase
Atomic service
Composite service
24
WF after Recursive Application of Rulebase
25
WF after Application of Chaining Service
Note opportunity for optimization and
parallelism.
26
Dynamic Resource Discovery and Scheduling

• Assume that semantically annotated services can
  be found through a registry or repository
  service.
• Scheduling of workflow nodes on distributed
  resources.
• Early binding model bind to specific
  service/platform at composition time
  (validation).
• Intermediate binding model bind at compile
  time (when converting from XML to executable
  form).
• Late binding model bind dynamically at runtime.
• Later binding allows the use of more up-to-date
  information to make scheduling decisions.
• In our framework binding is done by the
  Matchmaker Service, and can follow any of the
  above binding models.

27
Provenance Support in Service-Oriented Grids

• A workflow may produce many intermediate and
  final data products that may need to be later
  reviewed and analysed.
• A person, project, or organisation may need to
  archive many such workflows and their results.
• Want to store the provenance of data products
  how they were produced and why.
• Main developer is Shrija Rajbhandari.

28
Provenance

• Provenance can be regarded as historical metadata
  that provides an explanation of how a particular
  data product has been generated.
• Uniquely defines the derived data.
• Identifies what data is passed between services.
• Provides a traceable path to the origin of the
  data.

29
Provenance Importance and Problem

• No known standards to support archiving
  provenance in service-oriented Grid environment.
• Requires recording the provenance
• The transformation of data occurred during the
  invocation of services in a workflow.
• Complex service executed via a workflow Engine.

30
Original Motivation

• Would like to be able to view an electronic
  publication, and click on tables and figures of
  results to
• See how they were generated requires provenance
  browser.
• Re-run the workflows that generated the results
  to verify them, or to perform what-if study by
  changing the workflow inputs.
• See the results of any re-run workflows in the
  same format as the original data (table of graph).

31
Provenance Model
RDF Schema
Workflow Engine BPWS4J
Provenance Server
I N TER FACE
PCS
Provenance mySql Database
JENA
PQS
PCS Provenance Collection Service PQS
Provenance Query Service Jena is a Java framework
for building Semantic Web applications.
http//jena.sourceforge.net/
32
Prototype Provenance System

• Provenance Schema
• Resource Description Framework (RDF).
• Provenance of workflow execution.
• Provenance Collection Service (PCS)
• Provenance is represented in RDF statements.
• Database storage.
• Provenance Query Service (PQS)
• Client interface to browse provenance.
• Allows re-execution of retrieve provenance for
  what- if style of analysis.

33
Prototype Dataflow
34
Services Composition and Invocation

• Compose Web services using BPEL4WS
• Execute with BPEL4WS compliant engine IBMs
  BPWS4J
• Dynamically invoke Web services using Web Service
  Invocation Framework (WSIF).

35
Provenance RecordingExample Adding two numbers
and multiplying the result with a third number
36
Provenance Recording (cont..)
37
Provenance Recording (cont..)
38
Provenance Query
39
Re-execution for what-if analysis
40
Support for Collaboration in Grid Environments

• Collaboration can take various forms.
• Making services available to others.
• Making workflows available to others.
• Making results available to others.
• Collaboratively doing steering an application.
• Collaborative visualisation of results.

41
Resource-Aware Visualisation Environment (RAVE)

• Aims to develop a collaborative visualization
  environment that scales across a wide range of
  network-enabled devices.
• Will respond to changes in network bandwidth and
  capabilities of the target display device.
• Will start by examining VizServer and COVISE
  systems.
• RAVE postdoc is Dr Ian Grimstead.

42
RAVE Overview
43
RAVE Motivation

• Current systems make assumptions about available
  resources.
• RAVE makes use of local and/or remote resources,
  and can react dynamically to changes in these
  resources and the network connecting them

44
RAVE Infrastructure

• The RAVE infrastructure is based on Web services.
• Services are published and discovered through a
  UDDI server.
• Main services are
• Data Service.
• Render Service.

45
Data Service

• Imports data from a file, web resource, or
  external application.
• Acts as a central distribution point for scene
  graph.
• Bridging services link to external applications.

46
Render Service

• Render services connect to the Data Service which
  accepts and broadcasts changes in the scene
  graph.
• Render services contain complete scene graph.
• View may be rendered in mono or stereo mode.
• Multiple render sessions supported.

47
Thin Client

• A thin client is a client with modest rendering
  capabilities, e.g., a PDA.
• It can connect to a remote render service and
  make requests for off-screen rendered copies of
  the data.
• Local user can still manipulate camera and
  underlying data.

48
RAVE on Zaurus PDA
49
Connecting to an Application

• Data Service can receive live updates from an
  external application via a bridging service.
• Future work will extend this to allow
  computational steering.

50
Other Grid Projects

• Quality of Service http//www.cs.cf.ac.uk/user/Ra
  shid/
• Grid-Enabled Computational Electromagnetics
  (GECEM) http//www.wesc.ac.uk/projects/gecem/
• Workflow Optimization Services for e-Science
  (WOSE) http//www.wesc.ac.uk/projects/wose/

51
Summary

• Semantic Web technologies play a key role in
  enabling
• plug-and-play in the composition of service to
  create workflows.
• dynamic discovery of resources.
• Support for provenance.
• The above, together with collaborative
  visualisation, are important in convincing
  scientists (and others) to use the Grid.

52
(No Transcript)
