Mendelian genetics: overview

1
Mendelian genetics overview

• James Garbern MD, PhD
• Neurology and Center for Molecular Medicine and
  Genetics
• 577-2648
• jgarbern_at_med.wayne.edu
• 3206 Elliman Bldg

2
Notes and slides are online

• Web address for my lecture notes and slides
• http//cmmg.biosci.wayne.edu/jgarbern/jgarbern-hom
  e.html

3
Importance of genetics

• The only way to understand hereditary diseases
• What we are begins with our genetic heritage and
  is modified by our environment and experiences
• Our genetic heritage determines susceptibility to
  multifactorial diseases such as
• Hypertension Diabetes
• Vascular disease Cancer
• Osteoarthritis Autoimmune diseases
• Critical to developing new disease treatments
• Statins tPA EPO

4
The scope of genetics

• The human genome has been sequenced!
• Approximately 35,000 genes, most of which encode
  a protein, in a haploid genome of 3 X 109 base
  pairs
• Only about 1.5 of the DNA actually encodes
  functional genes
• All living organisms are remarkably similar at
  the genetic level
• Same genetic code
• About 50 of genes comparable between us and
  plants
• All nucleated somatic cells have a complete set
  of genes
• Only a small fraction of genes are active in a
  single cell
• Enables cloning

5
The burden of Mendelian (single gene) disorders

• Although individually rare, genetic diseases
  collectively constitute a major health problem
• About 5 - 8 of admissions to a pediatric
  hospital and about 1 of admissions to an adult
  hospital are for Mendelian disorders
• 9 of pediatric deaths are due to Mendelian
  disorders
• About 1- 2 of the population has a Mendelian
  disorder
• Most Mendelian disorders are apparent by
  childhood
• Life span is reduced in about 60 of these
  disorders
• Each person is estimated to have 1 - 5 lethal
  recessive alleles

6
From cellular to molecular biology
7
Genetic terminology

• Gene The fundamental unit of heredity. About
  35,000 in the human genome. A typical gene

5
3
enhancer
promoter
repressor
intron
exon
5 UTR
3 UTR
mRNA
AAAAAAAAA
coding domain (ORF)
8
Exons, introns and alternative splicing

• Most genes have introns
• Alternative splicing is common
• Many alternate proteins can be generated from a
  single gene, each of which can have a unique
  function

9
Transcription and translation

• Transcription Generation of an RNA copy of a
  single gene
• Translation Synthesis of a protein using the
  mRNA as a template

10
Gene expression Transcription and translation
tRNA
Protein chain
11
Gene expression transcription
12
Gene expression translation
13
Important definitions

• Alleles Alternative forms of a gene that can be
  distinguished by their alternate phenotypic
  effects or by molecular differences a single
  allele for each locus is inherited separately
  from each parent
• Autosome One of chromosomes 1 - 22
• Dominant allele An allele whose phenotype is
  detectable (even if only weakly) in a single dose
  or copy
• Recessive allele An allele whose phenotype is
  apparent only in the homozygous or hemizygous
  state.
• Heterozygous Having a normal allele on one
  chromosome and a mutant allele on the other
• Homozygous Having identical alleles on both
  chromosomes

14
More terms to know

• Hemizygous Having half the number of alleles
  (e.g. males are hemizygous for all X chromosome
  genes)
• Expressivity The severity or intensity of the
  phenotype of an allele.
• Penetrance The degree to which a gene expresses
  any observable phenotype
• Locus (pl. loci) The position on a chromosome of
  a gene or other chromosome marker also, the DNA
  at that position.
• Proband The first affected individual who comes
  to clinical genetic evaluation. Indicated by an
  arrow on the pedigree diagram.

15
Importance of recognizing Mendelian disorders

• Establishment of definitive diagnosis
• Recognition of other relatives with disease or at
  risk for disease
• More accurate prognosis can be given
• Anticipation/prevention of complications, both
  medical and emotional/psychological
• More informed family planning

16
Major mutation types

• Single base substitutions that cause premature
  termination of protein synthesis, change of amino
  acid, suppress termination of protein
  translation, alter level of gene expression, or
  alter patterns of mRNA splicing
• Translocations, that bring disparate genes or
  chromosome segments together
• Deletions of a few nucleotides up to long
  stretches of DNA
• Insertions and duplications of nucleotides up to
  long stretches of DNA
• Many different mutations can occur within a given
  gene, although it appears that genes have
  different degrees of mutability
• Different mutations affecting a gene can result
  in distinct clinical syndromes

17
Types of mutations

• Point mutations Change of the normal base to
  another
• Possible consequences
• Silent mutation No consequence
• Missense mutation changes the codon to one
  encoding a different amino acid
• Nonsense mutation Changes codon from one
  encoding an amino acid to a stop codon
• Splice site alteration can abolish or create a
  splice site
• Regulatory region mutation Can result in net
  increased or decreased gene expression

18
Location, location, location
19
Small mutations can have subtle or drastic effects
In frame deletion of one codo No frameshift
Deletion of one base Frameshift
Out of frame deletion of three bases Frameshift
20
Types of mutations

• Translocations
• Fusion of one chromosomal segment or gene
  fragment with another
• May result in disruption of gene(s)
• May result in a hybrid gene with novel function
  or combination of the functions of both genes

21
Most genetic diseases manifest during childhood
22
Frequency of Mendelian diseases by organ system
23
Distribution of Mendelian disorders

• 68 Autosomal dominant
• 26 Autosomal recessive
• 6 X-linked recessive

24
Clues that suggest a Mendelian disease

• Positive family history
• Characteristic syndrome
• Unusual syndrome (e.g. progressive neurologic
  deterioration, multiple organ system
  abnormalities, intermittent neurologic symptoms)
  at any age
• Common syndrome at unusually early age
• Lack of environmental or other primary cause of
  symptoms and signs

25
Taking a family history

• Inquire about the health of each family member
  through second degree relatives (grandparents,
  first cousins)
• Pay special attention to any signs or symptoms
  related to your patients condition in relatives
• Inquire about causes of any deaths, including any
  stillbirths or early deaths, institutionalizations

• Obtain medical (and death) records of relatives
  as well as of proband
• Inquire about any possible consanguinity
• Recognize that false paternity does occur

26
Pedigree symbols
27
A famous pedigree
28
A nicer pedigree
29
A modest pedigree
30
A typical X-linked recessive pedigree
31
X Linked Recessive Inheritance

• Trait is much more common in males than females
• An affected man passes the gene to all of his
  daughters
• A son of a carrier mother has a 50 chance of
  inheriting the trait
• Male-to-male transmission never occurs
• Carrier females are usually asymptomatic, but
  some may express the condition with variable
  severity because of Lyonization, or
  X-inactivation.

32
X linked recessive, normal father, carrier mother
1 carrier daughter 1 normal daughter 1 affected
son 1 normal son
33
Clotting cascade
34
Hemophilia A

• Clinical syndrome
• Easily prone to hemorrhage from minor trauma
• Hemarthroses common - result in degenerative
  joint disease
• Ecchymoses, but not petechiae
• Laboratory
• Prolonged PTT, normal PT bleeding times
• Normal platelet function
• A treatable genetic disease Plasma (90 of
  those treated with donor blood products developed
  AIDS in the 1980s), recombinant factor 8 (10 -15
  develop antibodies)
• Over 620 different mutations known to affect the
  factor VIII clotting factor gene (allelic
  heterogeneity)
• Gene lies at Xq28

35
One common Factor VIII mutation
36
Knowing genetic syndromes can help prevent
treatable complications of untreatable diseases
37
Locus heterogeneity

• Same or similar syndrome caused by mutations in
  different genes

38
Hemophilia B

• AKA Christmas disease (After the name of the
  first family and publication in the Christmas
  issue of the British Medical Journal)
• Similar clinical syndrome as seen in Hemophilia A
• Treatment with plasma or recombinant factor IX
• Antibodies develop in 1 to 3
• Caused by mutations affecting the Factor IX gene
  at Xq27

39
Gene therapy pros and cons

• Pros
• No risk of infection from donor blood products
• (Cant rule out infection complications from
  viral vector)
• Potentially life long cure from single treatment
• Cons
• Viral vector may cause disease
• Immunity to viral vector may reduce or prevent
  its taking
• Antibodies may develop to the foreign gene
  product

40
Gene therapy using viral vector (AAV)
41
Ethnic background and geographic origins are
important risk factors for some genetic conditions
42
Glucose-6-phosphate dehydrogenase deficiency

• Common among Africans, Asians and around the
  Mediterranean
• Discovered that about 10 of African American
  servicemen during WWII developed hemolytic anemia
  when given certain drugs, such as sulfonamides,
  antimalarials or when they ate fava beans
• Caused by deficiency of the enzyme, which is
  needed to generate NADPH

43
G6PD deficiency

• Affects the G6PD gene at Xq28
• Many mutations and polymorphisms have been
  discovered
• Heterozygosity (technically hemizygosity) in
  women appears to confer resistance to malaria

44
Prevalence of G6PD
45
Old World Malaria prevalence
46
X linked recessive, affected father
2 carrier daughters 2 normal sons Never any
Male-to- Male transmission!
