Sensitivity: Large Sample Volume Splitless

1
Sensitivity Large Sample Volume Splitless
2
Speed Sensitivity in a NEW way!

• Think about extremes!

3
A breakthrough technique for ULTRA sales

• Large volume techniques OC and PTV
• Overcoming SSL limitations for LV CSR
• When why and what of LVSL
• Practical aspects of LVSL injection
• Understanding how LVSL
• Some fundamentals of operation
• Competition
• Conclusions

4
Large Sample Volume Injection

• Increased sensitivity
• Simplified sample preparation procedures
• cost reduction
• Better use of the sample material
• Lower amount of both solvent and sample used

5
Large Sample Volume Injection

• Large Volume On-Column Injection
• suitable for volatile solute
• few operating parameters to be set
• sensitive to contaminants

• PTV Solvent Split Injection
• robust to contaminants
• difficult for volatile solutes
• several operating parameters to be set

6
And with the SSL

• Sample volume is limited to a few microliters
• The vaporizing chamber must be sufficiently large
  to house the whole sample vapour.
• The vaporizing chamber cannot be enlarged beyond
  a given size.

7
SSL Overcoming of Sample Volume Limitation

• Slow injection
• Introducing liquid at a rate that vapours can be
  immediately transferred to the column.
• Evaporation inside the needle
• DISCRIMINATION OF HIGH BOILING SOLUTES
• Concurrent Solvent Recondensation (CSR)
• Solvent recondenses into a column at the same
  rate as produced by sample evaporation.

8
When and why LVSL injection

• 1uL injection
• Initial Oven T. 60C

9
When and why LVSL injection

• WHEN USE LVSL
• Whenever you use the SSL injector the Worlds
  most used injector
• When you need more sensitivity than standard
  just inject more in the SSL injector!!
• WHY USE LVSL
• Simple to operate
• Performs on standard SSL injector
• NO impact on method validation!!!

10
LVSL what do you need
New Proprietory DPFC with septum purge closure
capability. Forward pressure regulation
with sensor on the purge line and low dead volume
connections/tubes between valves and injector.
Will be the new standard for 250 1000 Kpa DPFC.
Software assist A simple dedicated parameter
selection program (separate from Chromcard)
11
LVSL how do you install it
CSR Large Volume Splitless GC Setup and Injection
Press-fit
Analytical column
Pre-column
12
LVSL What else do you have to change
13
30uL injection for 30 times more sensitivity!

• No difference in method setup!!
• No method revalidation due to h/w differences!!

14
CSR Large Volume Splitless InjectionSteps of
the Process

• Injection with liquid band formation
• Auto pressure surge
• Concurrent solvent recondensation into the
  precolumn
• Sample transfer
• Solvent evaporation in the precolumn

15
Concurrent Solvent Recondensation (LVSL)
Bottom of the liner

• Restricted Evaporation Rate
• Injection with Liquid Band Formation
• Evaporation from a single droplet
• Increased Transfer Rate
• Solvent recondensation into a precolumn generates
  a strong suction effect

Solvent vapour
Liquid sample
Glass wool
High flow
Recondensed solvent
Precolumn
16
Concurrent Solvent Recondensation
Transfer occurs concurrently with solvent
evaporation

• The vapour volume no longer limits the injection
  volume

17
Step 3 visual difference with without CSR

• 35 uL Hexane injection
• BT 69C

• 65C starting temp
• Solvent recondensation
• Strong suction effect -fast pressure
  equilibration

• 100C starting temp
• No solvent recondensation
• No suction effect - long time for pressure
  equilibration

18
Concurrent Solvent Recondensation

• Injection of 30 ul of a hexane solution of
  n-alkanes
• Vapour volume 7.2 ml (300C and 50 kPa)
• Liner volume 1.6 ml

19
Linearity from 5 to 50 ul
Precolumn 5 m x 0.32 mm id deactivated (Mega)
Column RTX1 15 m x 0.32 mm id 0.5 um
20
Injection Conditions
21
Recoveries

• Better than those obtained with conventional SL!

Peak area normalized on C20 ratios calculated on
1 ul OC injection
22
Analysis of PAHs with GC-MS
25 ul PAHs mix 20 ppb in hexane Precolumn 5 m x
0.32 mm id Column RTX5 30 m x 0.25 mm id
23
Analysis of PAHs with GC-MS
25 ul 6 consecutive injections
24
Analysis of OPPs with GC-FPD
40 ul OPPs mix 12 ppb each in hexane Precolumn
5 m x 0.32 mm id Column 15 m x 0.32 mm id RTX1
0.50 um
25
Analysis of OPPs with GC-FPD
40 ul 6 consecutive injections
26
Competition NO COMPETITORS!!!

• Thermo is in dominant position competition is
  trying to defuse the bomb. We are in the position
  to put pressure

27
Competition NO COMPETITORS!!!

• Lets crush them!!!

28
Some Takeaways to keep in mind

• SSL INJECTORS ARE NO LONGER ALL THE SAME!!
• Ours is different in its substance
• TO USE WHENEVER THERE IS SSL INJECTOR
• Basic option and add-on kit (as seen in video!!)
• EASY TO PERFORM AND EXCELLENT RESULTS
• No specific expertise total recovery and No
  discrimination
• NO REQUIREMENT FOR METHOD REVALIDATION
• NO COMPETITION
• Only Trace GC Ultra has Large Volume SL
• Only Trace GC Ultra has suitable pneumatics
• PROPRIETARY!!
• WE ARE THE FIRST LETS CAPITALISE!!!

29
Some Takeaways to keep in mind

• SSL INJECTORS ARE NO LONGER ALL THE SAME!!
• Ours is different in its substance
• TO USE WHENEVER THERE IS SSL INJECTOR
• Basic option and add-on kit (as seen in video!!)
• EASY TO PERFORM AND EXCELLENT RESULTS
• No specific expertise total recovery and No
  discrimination
• NO REQUIREMENT FOR METHOD REVALIDATION
• NO COMPETITION
• Only Trace GC Ultra has Large Volume SL
• Only Trace GC Ultra has suitable pneumatics
• PROPRIETARY!!
• WE ARE THE FIRST LETS CAPITALISE!!!
