Core Topic 1

1
Core Topic 1
The aims of immunisation national policy and
schedules
2
Learning Outcomes

• To be able to explain the aims of immunisation,
  describe national policy and schedules and deal
  with variations to the schedule

3
Learning Objectives

• Explain the different factors that inform vaccine
  policy decisions
• Access current vaccine policy
• Describe the current UK vaccine schedule
• Describe how immunisation programmes are
  monitored through the use of surveillance and the
  COVER programme

4
Public health

• The two public health interventions with the
  greatest impact are clean water and vaccination
• Vaccination is the most effective medical
  intervention in the world

5
History of Vaccination

• Historical recordings of attempts of vaccination
  from 7th century but not really recognised or
  successful until
• 1796 Edward Jenner demonstrated that inoculation
  with cowpox virus produced protection from
  infection with smallpox.
• (Hence Vaccination taken from vacca the
  latin word for cow)
• 1860s-1890s Louis Pasteur produced vaccines
  against chickenpox, cholera, diphtheria, anthrax
  and rabies
• Early 20th Century toxoid vaccines against
  diphtheria and tetanus produced following
  discovery of effective inactivation with
  chemicals
• Post World War 2 successful live viral vaccines
  developed using cell culture techniques
• Present and future new technologies constantly
  developing recombinant protein vaccines, DNA and
  conjugate vaccines

6
Components of vaccination programmes
Vaccine delivery - supply, clinics
Vaccine development
Communication
Surveillance of coverage
Monitoring attitudes to vaccination
Policy development
Surveillance of population susceptibility
Adverse events surveillance
Predicting the future - modelling
Surveillance of diseases
7
Development of a vaccination programme

• The aim of a vaccination programme is to control
  a disease successfully
• Before designing a vaccine programme, important
  to establish
• Is there a need for the programme?
• i.e. does the disease cause a significant
  public health problem?
• Is a suitable vaccine available that is safe and
  effective?

8
New vaccines for UK children? Definite or
probable

• Newer vaccines for diseases already targeted in
  the childhood programme
• inactivated polio vaccine (IPV)
• acellular pertussis vaccine (aP) 5 components
• New combinations of existing vaccines
• DTaP/Hib/IPV (Paediacell)
• Men C / Hib

9
New vaccines for UK children?Probable or possible

• More widespread use of vaccines already used
  selectively
• hepatitis B
• varicella vaccine
• Vaccines where the need is not yet established
• influenza vaccines for children

10
New vaccines for UK children?Not yet clear

• Vaccines where there is no current UK need
• Meningococcal ACWY conjugate vaccines
• Vaccines where development of effective vaccines
  has been problematic
• Eg. Vaccines against group B meningooccus
• Vaccines where safety concerns have been raised
• Eg. rotavirus

11
Establishing the need for a vaccination programme

• Disease incidence
• Age distribution
• Trends
• Disease complications
• Mortality
• These are ascertained by surveillance and also
  through published literature and special studies

12
Hepatitis B vaccine policy

• Current policy
• Selective vaccination of high risk groups
• Antenatal screening and vaccination of infants
  born to positive mothers
• Additional policy options
• Universal vaccination of adolescents
• Universal vaccination of children
• Geographically selective policy
• Combination of the above

13
Acute HBV laboratory reports to CDSCBy age
group, 1990-2002
14
Objectives of surveillance

• Surveillance needs to be carried out both before
  and after a vaccine programme is introduced
• Pre-implementation of vaccine
• To estimate burden of disease
• To decide vaccination strategy
• Post implementation of vaccine
• To monitor effectiveness of vaccine strategy

15
Reported acute HBV infections by exposure
category (n675/yr)
16
Surveillance for Vaccine Programmes

• Disease incidence
• Reports of disease from a variety of sources are
  collated by the Centre for Infections (CfI)
• Susceptibility
• Residual blood samples used for serological
  surveillance
• Vaccine Coverage
• Vaccine uptake monitored across the country,
  collated by CfI from local Child Health Computers
• Monitoring adverse events and vaccine safety
• Collated by Medicines and Healthcare products
  Regulatory Agency (MHRA) Yellow Card scheme
• Investigated by CfI and immunisation experts
  worldwide

17
Pertussis notifications
18
Disease incidence

• Main sources of data
• - Statutory notification
• - Laboratory reporting
• Death notification
• Other sources
• - Hospital episodes
• - Sentinel physician reporting
• - Paediatric surveillance

19
Serological surveillance

• Residual blood samples from routine tests are
  used to provide information on disease immunity
  in population
• Collected on an annual basis for all age groups
  and sent to HPA seroepidemiology unit
• Anonymous age and sex known only
• Serological surveys provide information on how
  well-protected population is against preventable
  disease this needs to be known when deciding on
  new vaccine programmes or the need for campaigns

20
Rubella susceptibility, 1991
25
Males
20
Females
15
susceptible
10
5
0
0
5
10
15
20
25
30
35
40
Age
21
Vaccination CoverageCOVER (Cover of Vaccination
Evaluated Rapidly)

• It is important to know what proportion of any
  targeted population has received each vaccine
• Since 1988 computerised child health registers
  across the country have held vaccination details
  for all children resident in the area
• Every 3 months, information collected by CfI from
  each child health computer as to number of
  children who have completed scheduled vaccine
  courses at 1,2 5y of age
• This information used to evaluate and improve
  immunisation coverage by regular feedback to
  local areas

22
COVER (cont)

• Additionally, COVER data can be used to
• detect change rapidly and monitor trends in
  uptake
• provide information on impact of media stories
• look for pockets of poor coverage
• estimate vaccine efficacy
• measure impact and success of a vaccination
  campaign
• It is thus vital than anyone who gives an
  immunisation, records and reports that
  immunisation to the childs local Child Health
  Computer

23
Issues in vaccine policy decisions

• As well as information about disease incidence,
  vaccine safety and efficacy from surveillance,
  vaccine policy makers need to consider
• Aim of programme
• Cost of programme
• Population accessibility
• Cultural attitudes and practices
• Facilities available for delivery

24
Aim of immunisation programme

• Need to decide overall aim
• To protect those at highest risk
• (selective immunisation strategy)
• or
• To eradicate, eliminate or contain disease
• (mass immunisation strategy)

25
Selective vaccination

• Vaccine does not need to be given to all, only to
  those at increased risk of disease
• Travel
• e.g. Japanese B encephalitis
• Occupational risk
• e.g. Anthrax
• High risk groups
• e.g. Hepatitis B vaccine for neonates,
• Outbreak control
• e.g. Hepatitis A vaccine

26
Mass vaccination

• Either
• EradicationDisease and its causal agent have
  been removed worldwide e.g. smallpox
• Elimination
• Disease has disappeared from one WHO Region but
  remains elsewhere e.g. polio
• Containment
• The point at which the disease no longer
  constitutes a "significant public health problem
  e.g. Hib

27
Mathematical modelling and cost effectiveness

• Used to predict impact of a vaccination programme
  and thus inform policy by
• Modelling whether a programme can achieve its
  goals
• Comparing the costs and impact of various
  programme options

28
UK mechanisms for making and implementing of
vaccination policy

• Recommendations for vaccine policy
• Joint Committee on Vaccination and Immunisation
• Vaccine policy decisions
• Department of Health
• Licensing of vaccine
• Medicines and Healthcare products Regulatory
  Agency (MHRA)
• Purchase of vaccine
• Dept Health from pharmaceutical companies
• Control of vaccine (including batch release)
• National Institute for Biological Standards and
  Control

29
Joint Committee of Vaccination and Immunisation
(JCVI)

• The JCVI is an independent expert advisory
  committee.
• Its role is
• To advise the Secretaries of State for Health,
  Scotland, Wales and Northern Ireland on matters
  relating to communicable diseases, preventable
  and potentially preventable through immunisation

• Taken from JCVI websitehttp//www.advisorybodi
  es.doh.gov.uk/jcvi/)
• They review all available evidence and make
  recommendations to the Dept Health
• who then decide on and make UK vaccine policy

30
UK Vaccine Policy published in

• Immunisation against Infectious Disease
• (the Green Book)
• Currently available on Dept Health website
• Chapters can be individually downloaded from the
  website and printed off - updated chapters will
  replace previous versions as they become
  available
• Chief Medical Officer Updates, Letters,
  Publications and Urgent Communications
• These detail any changes to vaccine policy and
  recommendations

31
Vaccination schedule in UK May 2006

• Primary immunisation
• 2, 3 and 4 months
• Diphtheria-tetanus-acellular pertussis,
• inactivated polio vaccine
• Haemophilus influenzae type b DTaP-Hib-IPV
• Meningococcal group C conjugate MenC
• 12-15 months
• Measles-mumps-rubella MMR

Booster immunisation 3½-5 years Diphtheria-tetanus
-acellular pertussis Inactivated polio
vaccine DTaP-IPV or dTaP/IPV Measles-mumps-rubel
la MMR 15 years Tetanus-low dose
diphtheria Inactivated polio vaccine Td-IPV
32
Changes to Childhood Schedule Sept. 2006

• PCV pneumococcal conjugate vaccine (7 valent)
  at 2 and 4 months boost at 13 m with MMR
• Men C at 3 4 months boost at 12 m with Hib
• BCG school programme stopped for targeted
  neonatal immunisation family history and
  country of origin
• MMR 2 doses under age 25y

33
Conjugate pneumococcal vaccines

• Streptoccoccus pneumoniae
• 90 plus different serotypes
• carried in upper respiratory tract
• Wide range of disease
• Conjugate vaccines contain between 7 and 11
  serotypes responsible for disease in children
• 80 of childhood pneumococcal disease caused by 7
  serotypes
• Induce long-term memory
• Reduce carriage
• Induce herd immunity

34
Place of conjugate pneumococcal vaccine in UK?

• Cost effectiveness data needed to justify routine
  use in UK infants
• Lower rate of invasive disease in UK vs US
• Role of herd immunity and serotype replacement
  may be crucial
• Appropriateness for UK schedule
• 3 doses plus booster?
• Acceptability of 3rd injections
• What combinations (MenC/PCV) or alone?

35
Varicella Vaccine

• Live attenuated vaccine licensed July 2002 in UK
• Widely used in Japan and US (with MMR)
• Routine vaccination will have an impact on burden
  from both
• Varicella
• Zoster
• Cost effectiveness analysis and modelling needed

36
Chickenpox - epidemiology
Photograph by kind permission of Dr Philip Welsby
and Dr Mike Jones, Edinburgh
Photograph by kind permission of Dr S Ruffle
Twyford
37
Annual burden of diseasevaricella zoster
Sources Edmunds et al. Vaccine (2001) Brisson
Edmunds Arch Dis Child (2003)
38
Arguments for mass varicella vaccination

• In favour
• Preventable deaths and hospitalisations
• Large economic cost, particularly through
  parental work-loss
• Against
• Increase in average age at infection could lead
  to more severe disease (particularly if low
  coverage)
• Decrease in incidence of varicella could lead to
  an increase in the incidence of zoster due to the
  loss of exogenous boosting

39
Effect of varicella vaccination on zoster
40
Summary

• Infant varicella vaccination highly unlikely to
  be cost-effective
• Adolescent vaccination may be cost-effective in
  UK
• Adult vaccination against zoster may also be
  cost-effective
• No other economic analysis has looked at effect
  on zoster
• Most have not taken account of herd effects

41
New vaccines for UK children?Vaccines where
development is problematic

• Group B meningococcal vaccines
• Concerns about tolerance and safety have limited
  development of conjugates
• Problems of non capsular (group B) meningococcal
  vaccines
• Efficacy in the age group at greatest risk
• Coverage of protection against extremely diverse
  organism
• Feasibility of large enough conducting efficacy
  studies

42
Confirmed meningococcal infections1998-2003
43
Main approach to meningococcal group B vaccine

• Outer membrane vesicles of epidemic strains
• Moderate efficacy in Norway, Cuba, South America
• Limited duration of protection
• Only useful in older age groups
• How much group B disease will be covered?
• Will there be any heterotypic protection
• Will it cover variants of same Por A
• May be useful in response to an epidemic of a
  single clone
• Currently being conducted in New Zealand

44
New vaccines for UK children?Possible

• Influenza is major cause of morbidity and
  mortality in developed world
• Elderly account for the vast majority of deaths
• Hospital admissions common in other age groups
• US have now recognised the need to vaccinate
  children under two
• Current influenza vaccine
• Need for annual vaccination
• Possible role of live attenuated vaccines in the
  future?
• Children are major source of infection for others

45
Hospitalisation rates for influenzaUSA studies
/100,000

• Children
• Under one 496-1038
• Aged 1-2 yrs 186
• Aged 3-4 yrs 86
• Aged 5-14 yrs 41
• Adults
• Aged 15-44 yrs 23-25
• Aged 45-64 yrs 13-23
• Aged gt 65 yrs 125-228
• What is the burden of influenza in children in
  the UK?

May already have been reduced by between 30-70
by vaccination
46
Live attenuated influenza vaccine

• Live attenuated, cold-adapted viruses
• Replicate in upper but not in lower airways
• Protective mucosal immunity without disease
• Trivalent preparation given by nasal spray
• same strains as killed vaccine (A H3N2, A H1N1,
  B)
• LAIV is an now recommended in the US
• an alternate to inactivated vaccine for healthy
  people aged 5-49 years
• Not for those at high risk, or with asthma

47
Recommendations in the US

• Inactivated vaccine is strongly recommended for
• All age groups at risk
• Healthy adults aged over 65 yrs
• Adults aged 50-64 yrs (high prevalence of RFs)
• Inactivated vaccine is encouraged (where
  feasible)
• Healthy children aged 6-23 months
• Moving towards a policy of annual vaccination
  for all aged 6-23 months within three years
• Also recommending use of LAIV for older healthy
  children
• Role of influenza vaccines for the UK unclear

48
Summary

• Several likely developments in the UK schedule
• Introduction will depend upon good surveillance
  data and economic and epidemiological analysis
• Practical issues must not be under-estimated
• number of injections
• complexity of schedules
• Safety issues have the ability to side-track
  programme
• Important that justification for the introduction
  of vaccines are clear
